XS Power Batteries PB-13.0 User manual

USER GUIDE
800.4XSPOWER
|
XSPOWERBATTERIES.COM

1
Thank
you for purchasing this XS Power Batteries PB-13.0 Performance Bank! Always
follow
basic safety precautions when using electrical equipment. Read the
entire
instructions manual carefully. Please keep this instruction manual for
easy reference.
INTRODUCTION
PRODUCT OVER
VIEW
JUMP ST
ART CABLE
OPERA
TING GUIDELINES
INDICA
TORS LIGHTS
Press the switch to check power storage level of the PB-13.0 PERFORMANCE BANK.
The
indicator will flash one by one during the period of charging. Different
number of solid indicators show different storage level of PB-13.0. All indicators
light off when the charging is paused or complete.
Quick Charge Output Port
USB-C Input/Output Port
5V, 2.4A Output Port
15V, 10A Output Port
Jump Start Port
Power
Indicator
LED Flash Light
USB-C TO USB-C CABLE USB TO MICRO CABLE

2
1- Plug the suitable home adaptor into a power outlet.
2- Connect the USB-C to the USB-C Input/Onput Port.
1- Connect the blue plug into the Jump Start Port and make sure
that the cable indicator is turned off.
2- Connect the red clamp to the positive (+) battery terminal and
the black clamp to the negative (-) battery terminal.
3- Operate following the instruction of the cable indicator.
4- Start the vehicle.
5- When the vehicle is started, remove the jumper cable clamps from the vehicle battery.
6- Leave the vehicle running to recharge the battery.
OPERATING GUIDELINES(cont)
PB-13.0 CHARGING INSTRUCTIONS
VEHICLE JUMP STARTING INSTRUCTIONS
(KKV(KKV
(KKV(KKV
RED light on, with buzzing:
Saying the vehicle battery is low,
press “BOOST” and wait for the
green light to become solid.
Within 30 seconds, start the
engine.
NO lights on, with no buzzing:
This indicates the vehicle’s
battery may be damaged. After
confirming the clamps are
correctly connected, press
“BOOST” and wait for the green
light to come on and start the
engine within 30 seconds.
GREEN light blinking with
buzzing:
This indicates the vehicle battery
has low voltage. Press “BOOST”
and wait for the green light to
stop blinking and start the engine
within 30 seconds.
GREEN light on:
Ensure the connection is correct
and the circut is working, you
can start the engine to jump start
diectly.
(559:
XK\KXYKIUXXKIZ
(559:
XK\KXYKIUXXKIZ
POWER SUPPL
Y TO VEHICLE
1- Plug the optional power cable into th 15V
, 10A Output Port.
2- Connect the optional power cable and vehicle product or electronics
.
3- Press the power button to power on the device
.

3
CHARGING MOBILE DEVICE INSTRUCTION
S
1- Plug the power cable into the “Quick Charge Output Port”
.
2- Select the appropriate adapter and connect it to your mobile device
.
3- Select the power button and the PB-13.0 will automatically recognize the device’
s suitable
charging parameters and start charging.
LED FLASHLIGHT
1- Press and hold the power button for three seconds to turn on the flashlight.
2-
To cycle through the 4 modes(flashlight, strobe, SOS, off) by pressing the power button.


Part List
PB-13.0 Device
Jump Start Cable
USB to Micro Cable
#
1
2
3
Quantity
1
1
1


Part List
USB-C to USB-C Cable
User Guide
#
4
5
Quantity
1
1
PA
RTS LIST
TECHNICAL SPECIFICA
TIONS
Dimensions: 185 x 97 x 31mm
Weight: 1. 11lbs
Battery Capacity: 13,000mAh(48.1Wh)
Output: USB-C(5V2.1A), Quick Charge(5V 3A / 9V 2A / 12V 1.5A),
5V 2.4V, 15V 10A; 12V Jump Start
Input: USB-C(5V 3A)
Full Charging Time: Approximately 4 hours
Start Current: 300A
Peak Current: 800A
Operating Temperature: -4
o
F~140
o
F/-20
o
C~60
o
C
Dustproof and waterproof grade: IP66
OPERATING GUIDELINES(cont)

4
Q. How to turn off the PB-13.0 device
?
A. This appliance will power off automatically when under no load or charging is complete
.
Q. How long does it take to completely charge the PB-13.0 device
?
A. Approximately 4 hours using the USB-C input port.
Q. How many times can a PB-13.0 charge my mobile device?
A. Depending on the battery capacity of your device, roughly 5 times
.
Q. How many times can a PB-13.0 jump start a vehicle if it is fully charged
?
A. Depending on the vehicle, approximately 25 times.
Q. What is the lifetime of a PB-13.0?
A. Usually 3-5 years under normal conditions.
Q. How long will a charge last?
A. Under normal conditions, 6-12 months, however we suggest recharging every 3 months
.
FAQ
No response when
pressing the power button.
Low voltage protection of
the PB-13.0 is enabled.
Plug the adaptor into the
USB-C input port to activate.
Findings Cause Solution
TROUBLESHOOTING
Composition and amount of toxic and harmful substances in PB-13.0 devices.
O: Indicates all hazardous substances that are below the MCV limit specied in
Standard 2002/95/EC(RoHs).
TOXIC & HARMFUL SUBSTANCES

5
WARNING
Read the entire instruction manual carefully before using this device.
Always use caution using this device and keep out of reach of children.
This PB-13.0 device is designed for 12V vehicles only. Do not attempt to use on
vehicles of any other voltage settings(14V, 16V, etc).
DO NOT jump startmore than 3 times in a row to avoid damage.
DO NOT connect the two clamps together.
DO NOT use this device to attempt to jump start aircrafts, watercrafts, ect.
DO NOT use this device if any of the cables, clamps or cords are damaged.
DO NOT use as a vehicle battery.
DO NOT use as a battery charger.
DO NOT leave this device attached to the vehicle battery after jump starting and
remove this device with from vehicle battery within 30 seconds to avoid damage.
DO NOT expose this device to extreme heat or fire.
DO NOT store this device in temperatures exceeding 158
o
F or 70
o
C.
DO NOT allow this device to get wet or submerged in water.
DO NOT operate in the presents of flammable liquids, gases or dust.
DO NOT modify or disassemble this device.
DO NOT use this device if it is is leaking or otherwise damaged.
DO NOT use this device to jump start a vehicle while charging this device.
Only use the Jumper Start Cable provided with this device.
Be sure that the BLUE plug of the jumper cables is securely and completey
plugged into the Jump Start Port. Failure to do so will result in the melting
connections and other possible damage.
Make sure that connections are clean and well connected before jump starting.
Only use the Quick Charge Cable provided with this unit.
Only charge this device in ambient temperatures between 32
o
F-140
o
F or 0
o
C-60
o
C.
Remove jewelery and other metal items such as rings, bracelets, necklaces, etc.
If leakage occurs, do not handle this unit with bare hands. In case of skin
contact, wash with soap and wash immediately. If the liquid comes in contact
with your eyes, rinse for at least 10 minutes and seek medical attention.
To reduce the risk of damage to the electrical plug or chord, pull the plug, rather
than the cord to disconnect the device.
This product contains a lithium based battery, dispose of this device according
to local regulations.
1-
2-
3-
4-
5-
6-
7-
8-
9-
10-
11-
12-
13-
14-
15-
16-
17-
18-
19-
20-
21-
22-
23-
24-
25-
26-

6
WARRANTY INFORMATION
XS
Power Batteries offers a limited warranty of this product against any defects in
material
and craftsmanship for a period of 6 months from the date of purchase by the
e
nd use. The conditions of the warranty are as follows.
The
warranty is only valid upon presentation of the original receipt(from dealer/retailer)
by the original pur
chaser with the product to be repaired or replaced.
The warranty is void if the serial numbe
r, date of purchase or label has been removed.
The
warranty does not cover damage or product failer resulting from normal wear,
physical
abuse, improper installation, misuse, modifications or repair by unautho-
rized third parties
.
We
do not assume responsibility for loss or damage incurred during shipping or as a
result of a for
ce majeure.
We
are not liable for any incidental or consequential damages arising from the use or
miuse of this product.
A
ll warranty claims are limited to repair or replacement of the defective product and
at the sole discretion of XS Power Batteries.
If
the product is repaired or replaced, the product will be covered for the remaining
time
of the original warranty period. Repair or replacement may involve the use of
reconditioned
units which are equivalent in function. Replaced parts or products
become the property of XS Power Batteries.
C
onsumable components such as batteries are not covered by the warranty.
Applied Standard: CAB 1022-2014
Overcharge and
Overdischarge Protection
Fuse Protection Against-reverse Plug
