XtendLan DPC-81-F Series User manual

English
Quick Installation Guide
DPC-x81-F Module

2 EASY
-2-
FP MODULE
Fingerprint
window
LED
indicator
Connect to main
or other module
Panel Introduction
Fingerprint Setting and Management
[Management Fingerprint] will serve as a registered or delete credential of user
ngerprint. The system can only store two management ngerprints.
1. Register [Management Fingerprint]
When the system has never been registered [Man-
agement Fingerprint], you can according to the
following operation to register [Management Finger-
print].

2 EASY
-3-
LED Buzzer
LED BuzzerLED Buzzer
FP MODULE
Standby mode.1. Put the 6th dip switch of VD
module on.
2.Short circuit the exit button of VD
module.
3.On FP module, press any nger for
5 seconds to enter the management
ngerprint mode.
1.Press nger in the ngerprint
window,the "beep,beep" prompt tone
indicates that the input is successful.
2.Repeat the above operation for 2-6
times
Successfully set as ADD management
ngerprint.
LED Buzzer
(blue) (purple)
(purple)(blue)
(1 seconds)
(beep,beep)(beep)
1.1 Setting ADD Management Fingerprint

2 EASY
-4-
LED Buzzer LED Buzzer
1.Press nger in the ngerprint
window,the "beep,beep" prompt tone
indicates that the input is successful.
2.Repeat the above operation for 2-6
times
Successfully set as DEL management
ngerprint.
(purple) (blue)
(1 seconds)
(beep,beep) (beep)
1.2 Setting DEL Management Fingerprint
After the step of setting ADD Management Fingerprint, the LED indicator will turn
to purple, follow the steps below to setting DEL Management Fingerprint.
Note:
1) After input, it will return to standby mode automatically, or exit after 10s timeout;
2) The management ngerprint can not be duplicated or deleted, and can only be covered. It can be deleted
after initialization
User ngerprints will serve as a unlock credential for user. The system can
store 198 user ngerprints.
2. Manage User Fingerprints

2 EASY
-5-
LED Buzzer LED Buzzer
LED Buzzer
Press the [ADD Management
Fingerprint] In the standby mode;
It will enter the state of add user
ngerprints setting.
1.Press nger in the ngerprint
window,the "beep,beep" prompt tone
indicates that the input is successful.
2.Repeat the above operation for 3-7
times
Successfully set as user ngerprint.
Note:Before add the ngerprint, press the
call button or KP keyboard to specify the
room number. If not, it is classied as public
room number;
(blue,ash) (blue,ash)
(blue)
(1 seconds)
(beep,beep)
(beep)
Note:
1) After input, press ADD Management ngerprint will return to standby mode, or exit after 10s timeout;
2) The user ngerprint can not be duplicated , and cannot be managerment ngerprint;.
FP MODULE
2.1 Add User Fingerprints

2 EASY
-6-
FP MODULE
LED Buzzer
LED Buzzer
LED Buzzer
LED Buzzer
LED Buzzer
Press the [DEL Management
Fingerprint] In the standby mode;
It will enter the state of delete user
ngerprints setting.
Press the [DEL Management
Fingerprint] In the standby mode;
It will enter the state of delete user
ngerprints setting.
Press the [ADD Management
Fingerprint].
Press the [DEL Management
Fingerprint].
1.On other modules, press the call
button or KP keyboard to specify the
room number. If not, it is classied as
public room number.
2.Press the [DEL Management
Fingerprint] again to execute the
deletion operation;
(purple,ash)
(purple,ash)
(purple,ash)
(purple,ash)
(purple,ash)
(beep,beep,beep--It means that
there is no ngerprint record
under the room number)
(beep--Deletion succeeded.)
2.2 Delete User Fingerprints
2.3 Delete All User Fingerprints
Note:
Delete completed, it will return to standby mode automatically, or exit after 10s timeout;
Note:
Delete completed, it will return to standby mode
automatically, or exit after 10s timeout;

2 EASY
-7-
FP MODULE
2.4 Clear All Fingerprints
Note:
The backup time is about 0.5s * n, n = 2 + the number of user ngerprints.
Note:
The backup time is about 0.5s * n, n = 2 + the number of user ngerprints.
Clear all ngerprints, including management ngerprints and user ngerprints, ini-
tialization operation is required.
1. Create an empty folder “FPBACKUP” in an empty SD card.
2. Put the 6th dip switch of VD module on.
3. Insert the SD card to start the backup operation.
1. Copy the “fpbackup” folder to the SD card and rename “FPRESUME”.
2. Put the 6th dip switch of VD module on.
3. Insert the SD card to start the restore operation.
3. Backup ngerprint data
4. Restore ngerprint data
