Xtool P2 Riser Base User manual

D1.2.4_KD010590000
User Manual
P2 Riser Base

Statement
Safety first (important)
List of items
Meet the riser base
Assemble the riser base
Use the riser base
After-sales services
For online help, visit support.xtool.com.
线上帮助，请访问 makeblock.com/cn/docs/x-
tool-accessories/p2-riser-base。
1
1
2
2
3
8
8
11
12
12
13
makeblock.com/cn/docs/
xtool-accessories/p2-riser-base
support.xtool.com
Safety first (important)
Do not leave the
device unattended
when it is working.
Keep combustible
materials away
from the device.
■ During laser processing, do not put your hands into the riser base, or your skin may get hurt. If you are
accidentally burned by laser beams, disinfect the skin with a povidone-Iodine solution immediately and apply
burn ointment to the wound. If you are severely burned, go to a hospital and see a doctor as soon as possible.
■ To process a material that is too long for xTool P2, you need to open the door panels of the riser base. Diffuse
reflection of laser beams occurs, and your eyes may be exposed to the laser beams. Do not look at them
directly through the doors of the riser base, or your eyes may get hurt.
■ Do not open the door panels unless you are to process a material that is too long for xTool P2.
■ Do not engrave or cut any material that contains PVC or vinyl (processing plastics is not recommended).
These materials (and other materials containing chlorine/chloride) may generate corrosive vapor that
is extremely harmful to the human body and can cause damage to the device. Any damage caused
by engraving or cutting any material containing PVC or vinyl is not covered by the Company's
warranty.
■ Do not engrave or cut any unknown materials. Vaporization or melting of many materials, which
include but are not limited to PVC and polycarbonate, may release harmful smoke.
Statement
■ Thank you for choosing xTool products!
■ If you use the product for the first time, read carefully all the accompanying materials of the product to
improve your experience with it. If you do not use the product according to the instructions and requirements
of the Manual, or mis-operate the product due to mis understanding, etc., the Company shall bear no
responsibility for any loss resulting therefrom.
■ The Company has collated the content of the Manual rigorously and carefully, but errors or omissions may
remain.
■ The Company is committed to continuously improving product functions and service quality, and therefore
reserves the right to change any product or software described in the Manual and the content of the Manual at
any time.
■ The Manual is intended to help you use the product properly and does not include any description of
hardware and software configuration. For product configuration, refer to the related contract (if any) and
packing list, or consult your distributor. Images in the Manual are for reference only and the actual product may
vary.
■ Protected by copyright laws and regulations, the Manual shall not be reproduced or transcribed in any way, or
be transmitted on any wired or wireless network in any manner, or be translated into any language, or be
modified in any way, such as content, image, or layout modification, without the prior written authorization of
the Company.
1
Preparations
Process thick materials
Process regular or irregular cylindrical materials
Process materials that are too long for xTool P2

2 3
List of items
Front door panel Rear door panel Left side panel Right side panel Rear cover panel
Flat head
screw M4*8
Tape
measure
Cylindrical head
screw M3*6
ScrewdriverFixing
plate A
Fixing
plate B
Left corner Right corner Support corner
Left guide rail panel Right guide rail panel
Meet the riser base
Front door panel
Rear door panel
Right side panel
Rear cover panel
Left rear corner
Right rear
corner
Left front corner
Right front corner
Support corner
Support corner
Left side panel
Left guide
rail panel Right guide
rail panel
Assemble the riser base
Flat head
screw M4*8
Left corner
Left side panel
1. Assemble the left structure
Flat head
screw M4*8
Flat head
screw M4*8
Support corner
Left guide
rail panel

4 5
2. Assemble the right structure
Right side panel
Right corner
Reserve a spacing so that you
can fit the fixing plate in.
Fixing plate B
Cylindrical head
screw M3*6
Push the corner toward the
side panel to fit them
together.
Flat head
screw M4*8
Support corner
Right guide
rail panel

6 7
Flat head
screw M4*8
3. Fit the door panels
Front door panel
The front door panel is slightly wider than the rear one.
Rear door panel
Reserve a spacing so that you
can fit the fixing plates in.
Flat head
screw M4*8
Front door panel
Rear door panel
Left structure
Right structure
Front door panel
Rear door panel
Fixing plate A
Push the right
structure toward the door
panels to fit them together.

8 9
4. Fit the rear cover panel
Rear cover panel
Cylindrical head
screw M3*6
Place xTool P2
The riser base is designed with
positions on the left and right
sides for placing your hands. To
place xTool P2, hold it on the
sides instead of at the corners, so
that your hands don’t get hurt.
Use the riser base
Preparations
Assembly completed!
xTool P2 is not included
in the pack. You need to
purchase it before use.
1
Remove the slats and baseplate
2
Press to open the door panel
Position for
placing hands
Position for
placing hands

The riser base is designed with 9 placement levels to adapt to materials of multiple thicknesses.
You need to determine the level at which the baseplate of xTool P2 is to be placed based on the
processing mode used and the thickness of the material to be processed.
You can keep the removed screw and slats, for subsequent use, in the storage space on the right side of the riser base.
Place the baseplate
3
For example, if a flat material is 130 mm thick, you can place the baseplate at level 2a and then
place the material for processing.
To process a flat material of a thickness greater than 30 mm, you can use Open plane processing,
and determine the level at which the baseplate is to be placed based on the thickness of the
material.
1
1a
2
2a
3
30 ≤ h ≤ 102
43 ≤ h ≤ 115
55 ≤ h ≤ 127
68 ≤ h ≤ 142
80 ≤ h ≤ 154
h (mm)
3a
4
4a
5
93 ≤ h ≤ 167
105 ≤ h ≤ 179
118 ≤ h ≤ 192
130 ≤ h ≤ 200
Process thick materials
To use Open plane processing, you need to close the lid and door panels after
placing the baseplate and material.
10 11
For details about how to use the tape measure, visit
support.xtool.com/hc/en-us/articles/13280821588631.
Use the tape measure
4

Process materials that are too long for xTool P2
To use Conveyor feeder processing, you need
to use the riser base in combination with xTool
Conveyor Feeder.
Conveyor feeder
xTool Conveyor Feeder is not included
in the pack. You need to purchase it
before use. For details about how to use
it, see the user manual delivered with it.
Process regular or irregular cylindrical materials
To process a cylindrical material of a diameter greater than 42 mm, you
need to use the riser base in combination with xTool Rotary
Attachment and use Laser cylindrical processing. You can determine
the level at which the baseplate is to be placed based on the diameter
of the material.
xTool Rotary Attachment
is not included in the pack.
You need to purchase it
before use.
Roller mode
1
12 13
For technical support, contact us at [e-mail].
For more information about after-sales services, visit support.xtool.com.
更多产品信息，可访问 makeblock.com/cn/docs。
如需技术支持，可通过以下方式联系我们：
■ QQ 技术支持：800182013
■ 技术支持热线：400-893-0004
■ 微信公众号：童心制物售后
After-sales services
售后服务
For example, to process a material of diameter 90 mm in roller mode, you can place the baseplate at level 2
and then place the rotary attachment and material for processing.
d (mm) 3a
4
4a
5
1
1a
2
2a
3
42 ≤ d ≤ 83
54 ≤ d ≤ 94
67 ≤ d ≤ 104
79 ≤ d ≤ 115
92 ≤ d ≤ 126
104 ≤ d ≤ 139
117 ≤ d ≤ 150
129 ≤ d ≤ 163
142 ≤ d ≤ 174
Chuck mode
2
For example, to process an irregular cylindrical material of diameter 95 mm in chuck mode, you can place
the baseplate at level 2 and then place the rotary attachment and material for processing.
1a
2
0＜ d ≤ 90
90 ≤ d ≤ 100
d (mm)
