Xtreamer A211 User manual

User Manual

Safety Notes
ENGLISH
Warning Caution
The following are to protect safety of user and to prevent damages to property.
Use product properly after carefully reading the following contents.
Violating instructions
may lead to serious
injury or death.
Violating instructions may
lead to slight injury or
damage to product.
Act prohibited Contact by wet hand prohibited
Instructions
Modification prohibited Power plug to be separated
from power outlet
Do not connect a number of power
plugs at the same time. (This may
generate heat or cause fire.)
Do not forcefully pull out power cord.
(Breakage of power cord may cause
fire and electric shock.)
Do not insert of pull out power plug
with wet hand. (This may cause
electric shock.)
Do not insert power plug if it fits loose
to
p
ower outlet.
(
This ma
y
cause fire Make sure to turn off power switch and
p
ull out
p
ower
p
lu
g
when movin
g
Do not place plant pots, cups or ob
j
ects filled with chemical or water,
p(y
or electric shock.)
pppg g
product.
j
etc. on top of product. (This may
cause breakdown of product.)
Clean the outside of product by
wiping it with lightly wet or dry towel.
(Using detergent for grease removal,
thinner or heavily wet towel, etc. may
cause breakdown of product.)
Product must not be disassembled,
repaired or modified. Take caution not
to have foreign substances inserted
into products. (This may cause
breakdown of product or electric
shock.)
Do not forcefully bend the connected
power cord or have it pressed down
by heavy objects. (This may cause
fire or electric shock.)
2

Safety Notes
ENGLISH
Warning Caution
The following are to protect safety of user and to prevent damages to property.
Use product properly after carefully reading the following contents.
Violating instructions
may lead to serious
injury or death.
Violating instructions may
lead to slight injury or
damage to product.
Act prohibited Contact by wet hand prohibited
Instructions
Modification prohibited Soaking prohibited
Do not drop objects on top of product
or exert impact to product. Keep
product away from severe vibration or
magnetic objects.)
Do not place plant pots, cups or
containers filled with chemical or
water, etc. on top of product. (This
may cause fire/ electric shock. Falling
of the objects may also cause injury.)
Do not place heavy objects on top of
product. (Falling of objects may cause
injury.)
Do not cover up product or install it in
p
laces with
p
oor ventilation, such as a Install product in level and stable
p
lace.
(
Otherwise,
p
roduct ma
y
not Product must not be disassembled, re
p
aired or modified. Take caution not
pp
wall closet, etc
p( p y
operate normally.)
p
to have foreign substances inserted
into products. (This may cause
breakdown of product or electric
shock.)
Do not install product in places where
temperature is too high (35˚or
higher)/ too low (5˚or less) or
humidity is high
Do not install product under direct
sunlight or near objects of heat, such
as lit candle, cigarette or fire, etc.
Do not place product in water. (This
may cause breakdown of product or
electric shock.)
3

Table of Contents
ENGLISH
Safety Notes
About Product
Titles of parts
Specification
2
5
7
8
Hard-Disk Installation
Connection
1. Connect to your PC
2. Connect to the Network
3. Video & Audio output Connect
Remote Control Functions
9
10
10
11
12
14
Remote
Control
Functions
Media Environment Setting
1. System setting
2. Playback setting
3. A/V setting
4. Network setting
4-1 Wired Network
4
2Wi l N t k(O ti l)
14
17
17
18
19
20
20
21
4
-
2
Wi
re
l
ess
N
e
t
wor
k
(O
p
ti
ona
l)
5. Misc setting
Major Functions
1. Media Library Menu
1-1. Movie Playback in Media Library
1-2. Photo Playback in Media Library
1-3. Music Playback in Media Library
2It t
21
22
23
23
25
27
28
29
2
.
I
n
t
erne
t
menu
2.1. What is Xtreamer Live
2-2. How to Use You Tube
2-3. Using Picasa Function
3. File Manager Menu
For Advanced Users
1. UPnP Media Server
1
1UPPt t
29
29
29
30
31
32
32
32
1
-
1
.
UP
n
P
t
o connec
t
1-2. UPnP to setup
1-3. UPnP Media Server
1-4. File upload and download
2. NAS (Network Attached Storage)
3. Windows Vista Share Folder Setting
4.Change/Give Power for Windows Vista Share Folder (Copy Function)
5. Firmware Upgrade
32
33
34
35
36
37
40
41
4
Limited Warranty
Copyright and Legal Attributions
42
43

About Product
ENGLISH
Multimedia library
High Resolution HD-level File Play: Xtreamer supports the max. of 1920X1080
progressive scan to provide clear and high resolution picture quality.
StiDiMiFtT
S
uppor
ti
ng
Di
verse
M
ov
i
e
F
orma
t
T
ypes
Xtreamer supports a variety of HD files, such as TP, TS ,TRP and M2T,M2TS.MTS files,
but also MPEG1/2/4 , Divx (3/4/5/6), Xvid, DAT, ISO, DVD (VOB, IFO) and MKV(X.264),
AVC HD, WMV9, ASF, H.264,MOV,MP4, RMVB, FLV, etc. You can conveniently enjoy
watching movies anywhere as long as you have access to a display device, such as TV,
etc.
Convenient Copy
Xtreamer allows you to copy a media file to a network-connected PC.
Also, you can copy files by high-speed from PC to Xtreamer HDD or to
USB storage device connected to Xtreamer.
Supporting Diverse Music Files
Supporting
Diverse
Music
Files
Xtreamer supports a variety of music sources, such as AAC,MPEG audio MP1/2/3/A,
WMV,WMA,FLAC,OGG, AC3 and DTS, etc. As the player supports fast rewind/
forward functions, you can quickly find the desired part you require for listening.
Digital Photo Album
Xtreamer supports the upgraded JPEG and BMP image files. The entire
family can enjoying watching the files through TV, etc. Also, vertically
photographed filed can be rotated in screen for viewing without requiring
modification.
Network
shared File Play
Network
-
shared
File
Play
Files shared on a network can be played through wired/ wireless means
without having to move them to the Xtreamer hard disk.
5
NAS (Network Attached Storage)
Xtreamer uses the network drive in Window at support SAMBA function

About Product
ENGLISH
StiUPPlit
Supporting USB Host
Xtreamer supports 2 USB2.0 hosts. By connecting USB external storage devices,
you can easily add additional storage to the Xtreamer and play the files on the
external USB devices. A USB type memory card reader, etc. can also be used.
S
uppor
ti
ng
UP
n
P
c
li
en
t
Xtreamer supports UPnP server functions. Xtreamer supports free DDNS so
that you can connect to the internal HDD of the Xtreamer not only from your local
PC, but also from any PC with a Internet connection. This function can be used
from an external device that supports UPnP client.
Supporting High Resolution HDMI
Supporting
High
Resolution
HDMI
Built in with HDMI terminal for digital signal output, Xtreamer enables you to
enjoy video content with better picture quality.
5.1CH Audio Output and Down Mix Function
Xtreamer provides 5.1CH Dolby Digital audio and DTS, etc. Also, down mix function lets
you play 2CH audio through TV etc without requiring an additional decoding device
you
play
2CH
audio
through
TV
,
etc
.
without
requiring
an
additional
decoding
device
,
such as amplifier, etc (optical).
6
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories
DTS is a registered trademark & the DTS logos and Symbol are trademarks of DTS, Inc.

Part names and functions
ENGLISH
①
①
②
③
③
⑤
⑥
③
④
⑧
⑦
②
④
Front PanelBack Panel
⑤
①USB host X 2port
②USB slave port
③Stereo RCA terminal
④Composite terminal
⑤Optical terminal
⑥HDMI terminal
⑦
10/100Mbps LAN port
①Top cover for install HDD
②LED status
③IR reception part
④Cradle
⑤Cooling Fan
7
⑦
10/100Mbps
LAN
port
⑧Power

Specification
ENGLISH
Product Name Xtreamer
Processor RTD1283DD 400Mhz
Operating System Linux
File System FAT16/FAT32/NTFS/UDF/EXT3
Video
Formats
ASF / AVI / DIVX / FLV / IFO / ISO / M2P / M2TS / M2V / M4V / MKV /
MOV / MP4 / MPEG / MPG / MTS / RMVB / TP / TRP / TS / VOB /
WMV
Video
Codecs
XVID SD/HD / MPEG1, VCD 1.0/2.0, SVCD / HD MPEG2 (up to
MP@HL1080i), ISO/IFO/VOB/TS / HD MPEG4
SP/ASP(720p/1080i/1080p), Xvid / H.264 BP@L3, [email protected] /
WMV9/VC-1 AP@L3 / RealVideo 8/9/10, up to 720@30P /
DviX3/4/5/6 (Licensee Only)
Supported File
& Formats Audio Formats AAC / AC3 / DTS / FLAC / FLC / M3U / M3U8 / M4A / MP1 / MP2 / MP3 / MPA / MPC / OGG / PCM / RA / RM / WAV / WMA
Audio
Codecs
Dolby® Digital Plus, TrueHD / DTS HD Master Audio, High
Resolution, LBR / 7.1 down-mix / WMAWMA Pro, Dolby® Digital
AC3 and DTS® (Licensee Only) / MPEG I Layer 1, 2, 3 (2-CH) and
MPEG II Layer 1, 2 (Multi-Channel) / LPCM,ADPCM, FLAC, AAC,
WAV, and OGG Vorbis / RA1/RA-cook/RA-lossless
HD JPEG/BMP/GIF/MGIF(not act)/PNG/TIFF/TIF /
HD
JPEG/BMP/GIF/MGIF(not
act)/PNG/TIFF/TIF
/
HD JPEG with unlimited resolution(40M-pixel tested) / Full-pixel
JPEG decode with high resolution zoom-in
Video Output Composite and HDMI1.3
Audio Output Analog Stereo RCA
Digital Optical
TV System NTSC, PAL or HDMI auto
Hi-Def Decoding HD HDMI(480P, 576P, 720P 50HZ/60HZ , 1080i 50HZ/60HZ, 1080P 50HZ/60HZ)
Networking Wired Ethernet (10/100) LAN via RJ-45 Port
Wireless USB host port
Network Security Wireless : WEP, WPA
Network Protocol Wireless : IEEE802.11N, 3dBi USB antenna(Optional) Wired : 10/100Mbps Fast Ethernet (RJ45)
TCP/IP (DHCP client mode, Manual IP mode)
Hard-Disk Type 2.5” Internal SATA I/II
USB Interface USB2.0 host and USB slave
8
Specifications subject to change without prior notice
Powe
r
DC 12V, 2A
Dimension 110mm(W) X 162mm(H) X 27mm(D)

Hard-Disk Installation
ENGLISH
Remove the HDD cover on the top of
01
Remove
the
HDD
cover
on
the
top
of
product by pulling and separating the HDD
guard from the main body of Xtreamer
01
.
Connect the HDD guard and SATA HDD
as shown in the picture. Fasten screws.
02.
03
As shown above, slowly push the HDD
guard together with the SATA HDD into
the main body of Xtreamer.
03
.
Caution
Do not force HDD into unit under any
circumstances. If installation doesn’t
9
go easily, it could break the SATA
port in Xtreamer. Must reinstall from
beginning.

Connection
ENGLISH
1. Connect to your PC
ㆍConnect the Adapter ㆍConnect the USB cable
PC
ㆍDisconnect the Xtreamer
(1) Click on (2) Disconnect
Click
Click
1
2
10

Connection
ENGLISH
2. Connect to the Network
ㆍWired Network
Wired IP Sharing Router
ㆍWireless Network
Wireless IP Sharing Router
Optional : Wireless USB antenna
11

Connection
ENGLISH
3. Video & Audio output Connect
ㆍHDMI cable connection
Connect HDMI cable to HDMI terminal at the back of product. Connect the remaining cable
terminal to HDMI terminal at the back of digital TV Make sure to carefully distinguish
ㆍComposite cable connection
terminal
to
HDMI
terminal
at
the
back
of
digital
TV
.
Make
sure
to
carefully
distinguish
between input and output terminals.
12
Connect yellow cable for video signal to the terminal located at the back of side of TV. Then,
select external input of TV. Connect the remaining red and white terminal cables to the left/ right
and audio output terminal at the back of the device. Then, connect red and white cables to the
left/ right terminal of DTV input or component audio input located at the back of digital TV.

Connection
ENGLISH
ㆍOptical cable connection
You can enjoy high-quality sound 5.1CH if the audio device is an amplifier or a receiver with
optical output cable input terminal. Connect optical cable to Optical, the optical output terminal
of Xtreamer as shown above. Then, connect amplifier or receiver to enjoy 5.1CH.
13

Remote Control Functions
ENGLISH
12
4
5
3
4
6
7
9
10
13
5
8
11
14
12
13
15 16
17
19
21
18
20
23
26
27
28
22
24
25
29
14

Remote Control Functions
ENGLISH
1POWER
To turn on/ off power mode
2HOME
To go to top menu
3EJECT
To add the selected media file to list / Eject for DVD
4
ADD
ADD
4
ADD
ADD
5 DELETE Delete
6 GOTO To select file in the same title or to execute shortcut to the already designated chapter position/shortcut to the
desired time position
7
ZOOM
To enlarge and reduce screen/ repetitive pressing for
adjusting zooming percentage/moving to position of
7
ZOOM
adjusting
zooming
percentage/moving
to
position
of
enlarged output by using direction keys.
8MENU
To change or set DVD file menus by moving to MENU
screen during DVD(VOB) file play
9 FUNC To implement the function of ~
10
SETUP
Function available when playing media file or using
menu
’
s in VIDEO IN screen to display various setup
10
SETUP
menu s
in
VIDEO
IN
screen
to
display
various
setup
screens
11 TVOUT Toggle Video Output Modes and resolution (HDMI, AV)
12 PREVIEW To turn on/ off preview screen automatically displayed
in media play file search mode
13
O
To display the current status function available while
recording is in play/ repetitive pressing for displaying
13
INF
O
recording
is
in
play/
repetitive
pressing
for
displaying
network status/ to hide or display OSD of TIME SHIFT
function
14 RETURN For returning
15 DIRECTION KEY To move and select cursor
16 ENTER To confirm selection/ play
17 PGUP To move to previous chapter or file (list)
18 PGDN To move to next chapter or file (list)
19 PLAY/PAUSE To play and pause the selected file
20 STOP To stop file in play
21
FR/FF
1.5x/2x/4x/8x/16x/32x speed, function available in mp3
15
21
FR/FF
1.5x/2x/4x/8x/16x/32x
speed,
function
available
in
mp3
as well sound output available in 2x speed
22 VOLUME To adjust volume

Remote Control Functions
ENGLISH
23 AUDIO To change or select audio tracks of file in play
24 A-B To set zone repetition
25 MUTE For mute function
26
SHUFFLE
To change play sequence to shuffle
26
SHUFFLE
To
change
play
sequence
to
shuffle
27 REPEAT To repeat file in play or to repeat all media files in the
corresponding folder
28 SUBTITLE To select multi-language in a subtitle file
29 SYNC SUBTITLE To adjust sync of subtitle files played with film
(100ms/ 0.1sec)
16

Media Environment Setting
ENGLISH
1. System setting
Menu Language
Language for menu can be changed. Available languages are English, Spanish, French, German,
Italian, Greek, Hebrew, Korean and Dutch. The changed language is immediately applied
Text Encodin
g
g
Method of display to fetch subtitle file from computer can be changed.
Unicode(UTF8)/Korean/Western/Turkish/Central European/Greek/Cyrillic/Hebrew/Source Eastern
are available
UPNP Media Server
Using Xtreamer UPnP media server
Samba Server
Using NAS network driver to PC
System Update
Currently, firmware version is displayed and firmware update through USB storage device and
hard disk in Xtreamer is possible.
Time
Set time of Xtreamer that serves as the basis of using Timer function. Using up/down/left/right keys
in remote control, set year/month/day/hour/minute/second. Press OK to save the set values.
HDD Format
Xtreamer includes the automatic format menu and can format to NTFS file system.
17
Restore default
All set values can be restored to default (UPnP)

Media Environment Setting
ENGLISH
2. Playback setting
Resume Play
For replaying the movie file which was previously played, select the starting place either from
the beginning or from the paused point.
Slide Show Time
This is to set the time of which display is produced and maintained when viewing photos
Time can be desi
g
nated as off/2sec/5sec/10sec/30sec/1min/2min.
Transition Effect
When viewing photos, transition effect to move to the next photo is set. Total of 7 effects are
available. All other randomly applied effects are also supported.
g
Background Music
Folder : The audio file automatically replays in the same folder of picture files.
Play list : The audio file automatically replays in the playlist in Xtreamer
Media Play Movie Preview
18
In media play function, you can disable or enable preview function. This is not applied in Playback
menu. On/Off setting can be made by using Preview key in remote control.

Media Environment Setting
ENGLISH
3. A/V setting
Pan Scan 4:3 This ratio is used when aspect ratio of TV is 4:3. This setting is to show the film of 16:9 ratio
by cutting it to 4:3 size.
Aspect Ratio
Screen ratio can be set to suit TV type. Setting is changed to Pan Scan 4:3/Letter Box 4:3/16:9.
by
cutting
it
to
4:3
size.
Letter Box 4:3 This ratio is used when aspect ratio of TV is 4:3. This setting is to show the 16:9 film full of
screen in its original ratio.
16:9 This ratio is used when aspect ratio of TV is 16:9 to show film with the ratio of 16:9. As of
4:3 ratio, this ratio shows the film full of screen.
Brightness
Brightness of the displayed screen is adjusted. While video is in play, press SETUP in remote
TV Out
Brightness
of
the
displayed
screen
is
adjusted.
While
video
is
in
play,
press
SETUP
in
remote
control. Brightness can be adjusted while video is in play.
Contrast
Contrast of the displayed screen can be adjusted. While video is in play, press SETUP button in
remote control. Contrast can be adjusted while video is in play.
Video output resolution can be changed. PAL and NTSC modes are not compatible with each
other, therefore, it must be adjusted to the TV in use. There is a function that automatically adjusts
output to TV system, therefore, it is not necessary to change PAL/ NTSC modes.
Night Mode
Output the sound comfortably during the night. Support the night mode to Off/On
19
Digital Output
Select the HDMI LPCM/SPDIF LPCM, output the Dolby D(AC3) or DTS of down mixing. Support
the 7.1ch down mixing. And select the HDMI RAW/SPDIF RAW, output the 5.1ch Dolby D(AC3) or
DTS through the optical cable.

Media Environment Setting
ENGLISH
4. Network setting
4-1 Wired Network
<Wired Network Not Connected> <Wired Network Connected>
Automatic Allocation Mode (DHCP)
When making connection by using wired LAN, connection is automatically made to network if
selecting automatic IP allocation.
When setting is completed, press
OK to attempt connection. Then,
network is connected.
Static IP (Manual)
This function is for using static IP or for manual connection.
20
If IP address is displayed as of the example on
the right, network connection is completed with
IP successfully received.
