BYPASS DISTRIBUTION MODULE
XBDM
USER & INSTALLATION MANUAL

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 2
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS: ................................................. 4
INTRODUCTION........................................................................................... 6
PRODUCT DESCRIPTION .......................................................................... 6
Bypass Distribution Description................................................................................................................ 6
SYSTEM CONFIGURATION........................................................................ 8
LED Description ......................................................................................................................................... 9
HARDWARE INSTALLATION GUIDE................................................... 10
Installation .............................................................................................................................................. 10
Horizontal Installation (1U)................................................................................................................. 10
Vertical Installation (0U) .....................................................................................................................11
CONNECTING ............................................................................................. 12
Initial Connection and Startup Sequence ............................................................................................... 12
USER’S OPERATIONS .............................................................................. 15
Normal Operation ...................................................................................................................................16
Bypass Operation....................................................................................................................................16
SPECIFICATIONS ...................................................................................... 19
SHIPPING LIST .......................................................................................... 20
OBTAINING SERVICE............................................................................... 21
XTREME POWER CONVERSION® (XPC) CORPORATION LIMITED
WARRANTY ............................................................................................... 22
Thank you for selecting this bypass distribution module. It is designed to work in conjunction with a UPS
to provide you with protection for connected equipment. Please read this manual before installing the
XBDM-Series models XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, and XBDM-1020HV as it provides
important information that should be followed during installation allowing you to correctly set up your

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 3
system for the maximum safety and performance. Included is information on customer support and
service. If you experience a problem with the XBDM, please contact technical support.
WARNING: Incorrect installation, operation, and/or modifications made to the XBDM will void the
manufactures warranty. Xtreme Power Conversion is not liable for personnel or equipment damages as
a result.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 4
IMPORTANT SAFETY INSTRUCTIONS:
(SAVE THESE INSTRUCTIONS)
CAUTION! Two sources of power are present in the XBDM: UPS power
and Utility power
CAUTION! (UPS has Internal Batteries): Risk of electrical shock – Hazardous live parts
inside the UPS are energized from the battery supply even when the input AC power is disconnected.
CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover.
No user serviceable parts inside. Refer servicing to qualified service personnel.
WARNING! Unit intended for installation in a controlled environment per installation instructions.
CAUTION! If flammable substances such as gases or fumes are present, or if the room is airtight, a
hazardous situation may exist in which no electrical equipment should be operated.
WARNING!
It is strongly recommended that the XBDM not be opened as components have very high
voltage and touching those components may be fatal. Only a qualified technician or
authorized agent may service the unit.
The XBDM unit’s output receptacles can carry live voltage even when not connected to an
input voltage source. The UPS has its own internal energy source.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 5
CAUTION
The unit has a dangerous amount of voltage. If either the UPS or BYPASS indicator is on, the unit’s
outlets may have a dangerous amount of voltage even when not plugged into the wall outlet because
the battery from the UPS may continue to supply power.
Care should be taken to undertake installation indoors, free from electrically-conductive particles
which are under temperature and humidity control, in order to reduce the risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the equipment is placed in
a position near the outlet where easily accessible.
All servicing on this equipment must be carried out by qualified service personnel.
The Xtreme Bypass Distribution Module (XBDM) is intended to allow replacement of the UPS
connected without having to shut down the equipment connected to the load circuits on the XBDM.
Caution should be observed as the XBDM is always supplied with power by either the UPS or UTILITY.
Environment
Ensure that all environmental concerns and requirements are met according to specifications listed in
this document, otherwise the safety of installation personnel cannot be guaranteed, and the unit may
malfunction.
Ensure that you remember the following when locating the XBDM:
•Avoid extremes of temperature and humidity.
OOperating temperature: 0°C to +50°C (+32° to +122° F)
OOperating elevation: 0 to 3000m (0-10,0000 ft)
ORelative humidity: 0-90%, non-condensing
OStorage temperature: 0-65° C (+32 to +149° F)
OStorage elevation: 0 to 15,000m (0 to +50,0000 ft)
•Provide protection for the equipment from moisture.
•Space and ventilation requirements must be met.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 6
INTRODUCTION
The information provided in this manual covers single phase 15A, 20A, and 30A bypass distribution
modules, their basic functions, operating procedures, options available and emergency situations. It also
includes information on how to ship, store, handle, and install the equipment. Only detailed
requirements of the XBDM units are described herein, and installation must be carried out in
accordance with this manual. Refer to the associated UPS manual for UPS operating instructions.
Electrical installation must also carefully follow local legislation and regulations. Only qualified personnel
should conduct these installations as failure to acknowledge electrical hazards could prove to be fatal.
PRODUCT DESCRIPTION
Many different kinds of sensitive electrical equipment can be protected by an Uninterruptible Power
Supply (UPS) including computers, workstations, process control systems, telecommunications systems,
sales terminals, other critical instrumentation, etc. The purpose of the XBDM is to provide an extra level
of protection in allowing for the replacement of a UPS without powering down the loads connected. The
XBDM can work with most single phase topologies. It will not work with topologies that have a phase
shift between input and output (like ferro of UPS with an isolation transformer) .
Electrical interference exists in many forms, causing problems in AC power, from lightning, power
company accidents and radio transmission motors, air conditioners, and vending machines. Protection
of sensitive electrical equipment is vital to protect against power outages, low or high voltage
conditions, slow voltage fluctuations, frequency variations, differential and common-mode noise,
transients, etc.
To prevent power line problems from reaching critical systems causing damage to software, hardware,
and equipment malfunctions, the UPS maintains constant voltage, isolating critical load output and
cleaning the utility AC power. When a UPS fails or needs maintenance, many times it is necessary to turn
off the UPS and disconnect it from incoming electrical circuits. With the XBDM installed between the
incoming Utility and the UPS, you can replace the UPS and/or Batteries without dropping the load. You
simply switch the XBDM from UPS power to Utility power and remove the UPS while the load connected
to the XBDM continues to operate temporarily from Utility power.
Bypass Distribution Description
The Xtreme Bypass Distribution Module (XBDM) is designed to operate with a single-phase UPS up to
30Amps in output capacity. The XBDM allows you to:
•Replace or upgrade the UPS without losing power to the protected equipment
•Provide surge protection if the UPS is not present
•Provide extra surge protection when the UPS is present
As shown in fig. 1 block diagram:

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 7
•Under normal operation, the UTILITY INPUT flows through the XBDM to the UPS and then out to
the CONNECTED LOADS.
Figure 1 – Block Diagram with UPS
As shown in fig. 2 block diagram:
•Under maintenance operation, the UTILITY INPUT flows through the XBDM to the CONNECTED
LOADS – the UPS is not in the circuit.
Figure 2 – Block Diagram without UPS

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 8
SYSTEM CONFIGURATION
The diagrams shown give front, top and rear view of the XBDM
Figure 3 – XBDM-1015LV Front View
Figure 4 – XBDM-1015LV Rear View
Figure 5 – XBDM-1020LV Front View
Figure 6 – XBDM-1020LV Rear View
Figure 7 – XBDM-1030LV Front View
Figure 8 – XBDM-1030LV Rear View

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 9
Figure 9 – XBDM-1020HV Front View
Figure 10 – XBDM-1020HV Rear View
Figure 11 – XBDM-1015LV Top View
LED Description
The XBDM has three LED’s on the front control panel. These LED’s allow the user to quickly understand
the status of the unit.
Red LED = UPS power is available
Orange LED = Utility is available for Bypass operation
Green LED = Surge Protection is available.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 10
Figure 12 – XBDM Front Panel LED’s
CAUTION: The Orange LED must be illuminated before transferring to BYPASS power.
The Red LED must be illuminated before transferring to UPS power.
HARDWARE INSTALLATION GUIDE
Inspect the XBDM upon receipt. The packaging is recyclable; keep it for reuse or dispose of properly.
Installation
The XBDM supports horizontal 1U rack mount and vertical rack mount installation.
Horizontal Installation (1U)
1. Attach the two (2) XBDM horizontal mounting brackets (included) on each end of the XBDM
using four (4) retaining screws (included) see Figure 1.
Figure 13 – XBDM Horizontal Mounting

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 11
2. Install the XBDM in a suitable horizontal location in the rack rail using four (4) user-provided
mounting screws.
Vertical Installation (0U)
1. Attach the two (2) XBDM horizontal mounting brackets (included) on each end of the XBDM
using four (4) retaining screws (included) see Figure 2.
Figure 14 – XBDM Vertical Mounting
2. Attach the two vertical mounting brackets (included) to the horizontal rack mounting brackets
on each end of the XBDM using four (4) retaining screws (included) see Figure 2.
3. Install the XBDM in a suitable vertical location on the side of the rack rail with four (4) user
provided mounting screws.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 12
CONNECTING
Initial Connection and Startup Sequence
1. If the UPS is already installed and operating, continue to Step 3.
2. Install the UPS and any optional Extended Battery Packs or Modules according to UPS
manufacturers’ documentation. Do not connect loads to the UPS (Proceed to step 5)
3. Prepare your equipment for shutdown.
4. Turn the UPS OFF in accordance with UPS manufacturers’ documentation.
5. Unplug the UPS. Depending on the model of UPS it may take a few seconds for the UPS
to completely shut down. All indicators on the UPS front panel should shutdown.
6. Disconnect the protected equipment power cord(s) from the UPS.
7. Verify that the BYPASS switch on the XBDM is in the UPS position.
Figure 15 – XBDM Bypass Switch – UPS Position

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 13
8. Plug the XBDM into a properly wired utility outlet.
Figure 16 – XBDM to AC Input Receptacle
The orange bypass available light should illuminate on the Bypass Distribution Module.
9. Plug the UPS OUTPUT cord from the XBDM into an OUTPUT RECEPTACLE on the UPS.
Figure 17 – XBDM Cord to UPS Output Receptacle

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 14
10. Plug the equipment to be protected into the appropriate XBDM output receptacles.
Note: XBDM-1030LV has two LOAD GROUPS. If you have a combination of loads greater
than 20A, split the loads by plugging some cords into LOAD GROUP 1 and the others into
LOAD GROUP 2.
Figure 18 – XBDM-1015/1020LV Output Receptacles
Figure 19 – XBDM-1030LV Output Receptacles

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 15
Figure 20 – XBDM-1020HV Output Receptacles
11. Plug the UPS INPUT power cord into the UPS INPUT RECEPTACLE on the XBDM.
Depending upon the UPS operation, once the XBDM is connected to AC INPUT, the UPS
may begin its startup procedure.
Figure 21 – XBDM UPS Input Receptacle
12. Press the ON BUTTON on the UPS. All indicators on the UPS should operate normally
and output power should be provided to LOADs connected to the XBDM OUTPUT. The
red UPS available light should illuminate on the Bypass Distribution Module.
USER’S OPERATIONS
The purpose of this BYPASS DISTRIBUTION MODULE is to allow servicing of the UPS so as not to affect
the LOADs connected and protected. To transfer between UPS and utility sources, swiftly actuate the

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 16
bypass switch to the opposite position. Both the UPS, and Utility lights available must be illuminated to
prevent transferring to a non-powered source.
Normal Operation
When operating in NORMAL mode the switch on the front of the XBDM will be in the UPS position
Figure 22 – XBDM Bypass Switch – UPS
CAUTION: The red LED on the bypass module must be illuminated before transferring to the UPS
position.
Bypass Operation
To transfer your equipment to Maintenance Bypass (AC Line operation) and remove the UPS:
1. Toggle the Bypass Switch on the XBDM to UTILITY position. The XBDM is now powering your
equipment from Utility power.
Figure 23 – XBDM Bypass Switch - UTILITY
CAUTION: The Orange LED must be illuminated before transferring to BYPASS operation.
CAUTION: When the XBDM is operating in UTILITY MODE, the LOAD connected is not
protected from power outages.
2. Press the OFF BUTTON on the UPS per the UPS manufacturers’ documentation.
3. If any optional Extended Battery Packs or Modules are connected to the UPS, turn off
the circuit breaker on the battery pack or module (if applicable), and disconnect the
cable from the battery pack or module to the UPS.
4. Disconnect the UPS output cord from the XBDM to the UPS output receptacle.
5. Disconnect the UPS INPUT CORD from the UPS INPUT RECEPTACLE on the XBDM.
6. Remove the UPS.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 17
To reinstall the UPS and transfer your equipment from Maintenance Bypass (AC Line operation) to the
UPS:
1. If optional Extended Battery Packs or Modules are installed, reconnect the cable from
the battery pack or module to the UPS, and turn on the circuit breaker on the battery
back or module (if applicable) per the UPS manufacturers’ documentation.
2. Connect the UPS output cord from the XBDM to a UPS output receptacle
3. Plug the UPS INPUT POWER CORD into the XBDM UPS INPUT RECEPTACLE.
4. Start the UPS per the manufactures instructions. The red UPS available light should
illuminate on the Bypass Distribution Module.
5. Toggle the Bypass Switch on the XBDM to UPS position. The XBDM is now powering your
equipment from UPS power.
Note: XBDM-1030LV has two BYPASS SWITCHES each controlling a separate group of
receptacles. Please assure you have operated both BYPASS SWITCHES prior to removing the
UPS from the XBDM.
A label is placed on the top of each XBDM to highlight the proper connectivity of the INPUT and
OUTPUT of the XBDM and UPS.
Figure 24 – XBDM-1015/1020LV Top Unit Label

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 18
Figure 25 – XBDM-1030LV Top Unit Label
Figure 26 – XBDM-1020HV Top Unit Label

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 19
SPECIFICATIONS
XBDM MODEL XBDM-1015LV XBDM-1020LV XBDM-1030LV XBDM-1020HV*
POWER RATING 15A / 120VAC 20A / 120VAC 30 A / 120VAC 20A / 230VAC
UTILITY INPUT 5-15P 12FT 5-20P 12FT L5-30P 6FT IEC C20
AC FREQUENCY 50 / 60 HZ
MAXIMUM OUTPUT 12A 16A 24A 16A
RECEPTACLES
FRONT OUTPUT (6) 5-15R (6) 5-20R (5) 5-20R (2) IEC C19 + (4)
IEC C13
REAR OUTPUT (4) 5-15R (4) 5-20R (5) 5-20R (4) IEC C13
REAR UPS INPUT (1) 5-15R (1) 5-20R (1)L 5-30R (1)IEC C19
UPS OUTPUT 5-15P 3FT 5-20P 3FT L5-30P 3FT IEC C20
TRANSFER SWITCH BREAK
BEFORE MAKE TWO-POLE
(MAX 8ms TRANSFER TIME)
(1) 15A (1) 20A (2) 20A (1) 20A
AC SURGE
MAX SPIKE CURRENT 6500A
ENERGY DISSIPATION 114 Joules 220 Joules
MAX CLAMPING VOLTAGE 330V 775V
INDICATORS
UPS AVAILABLE RED LED
UTILITY AVAILABLE ORANGE LED
SURGE PROTECTION GREEN LED
PHYSICAL
SIZE (1U) (W x D x H) 17” x 3.5” x 1.75”
WEIGHT 3.5 LBS
*Note: XBDM-1020HV has two different part #’s. Please see Shipping List on next page.

XBDM-1015LV, XBDM-1020LV, XBDM-1030LV, XBDM-1020HV USER’S MANUAL BYPASS DISTRIBUTION MODULE
Xtreme Power Conversion® (XPC) Corporation (Rev 2/7/13) Page 20
SHIPPING LIST
1. (1) XBDM
2. Standard 19” rack mounting hardware
3. User’s Manual
4. For XBDM-1020HV:
A. FOR USE WITH NXRTi-1000 (XBDM1020HV1):
I. (1) IEC C19 to SCHUKO
II. (1) IEC C13 to C20
III. (1) IEC C14 to C19
B. FOR USE WITH NXRTi-2000/3000 (XBDM1020HV2):
I. (2) IEC C19 to C20
II. (1) IEC C19 to SCHUKO
