Xult XT-6-DEF User manual
C
3X
D
2X
F
G
B
E
A
5X
G
UPRIGHT W/SERIAL #
LEFT FRONT
SEE BUMPER PLATE
ASSEMBLY GUIDE
SEE 6' CHIN BAR-LONG ASSEMBLY GUIDE
SEE 2' SUPPORT PAIR ASSEMBLY GUIDE
SEE DB/KB SHELF ASSEMBLY GUIDE
70" DUMBBELL SHELF "ANGLED" MOUNTING
SEE DB/KB SHELF ASSEMBLY GUIDE
70" KETTLEBELL SHELF "HORIZONTAL" MOUNTING
SEE MEDICINE BALL SHELF
ASSEMBLY GUIDE
6' DEFENDER
ITEM
NO.
PART
NUMBER
DESCRIPTION
QTY.
A
XR10
XULT;RIG;UPRIGHT 8FT W/MTG HW
5
B
XR10S
XULT;RIG;UPRIGHT 8FT W/SERIAL#/MTG HW
1
C
XR02
XULT;RIG 6' CHIN BAR
3
D
XR04
XULT;RIG 2' SUPPORT PAIR
2
E
XS08
XULT;RIG BP STACKER 70" W/MTG HW
1
F
XS02
XULT;SHELF;MED BALL 70" W/MTG
1
G
XS06
XULT;SHELF;DB/KB 70" W/MTG
2
ASSEMBLY GUIDE
XT-6-DEF
DRAWING NAME:
LAST UPDATED:
2017.OCT.24
DESCRIPTION:
MODEL:
XT-6-DEF
SUPPORT (PAIR)
SCREW;HEX HEAD
0.500-13
8 PLACES
UPRIGHT
WASHER;FLAT
0.500"
16 PLACES
NUT;NYLOCK
0.500"-13
8 PLACES
USE 2nd MOUNTING
HOLE IN UPRIGHT
UPRIGHT
2' SUPPORT (PAIR)
TOOLS NEEDED:
3/4" WRENCHES X 2.
TORQUE SCREWS TO 57 ft-lbs
ASSEMBLE WITH HARDWARE PROVIDED WITH UPRIGHTS
(EXPLODED VIEW SHOWN FOR REFERENCE ONLY)
ASSEMBLY GUIDE
XR04 ASSY GUIDE
DRAWING NAME:
LAST UPDATED:
2017.OCT.19
DESCRIPTION:
MODEL:
XULT;RIG 2' SUPPORT PAIR
XR04
6' CHIN BAR
(SHOWN IN EXPLODED VIEW)
UPRIGHT
UPRIGHT
CHIN BAR MOUNTING
2ND HOLE LOCATION
SCREW;HEX HEAD 0.500-13
4 PLACES
WASHER;FLAT 0.500"
8 PLACES
NUT;NYLOCK 0.500"-13
4 PLACES
CHIN BAR (4' & 6')
4' CHIN BAR
TOOLS NEEDED:
3/4" WRENCHES X 2.
TORQUE SCREWS TO 57 ft-lbs
ASSEMBLE WITH HARDWARE PROVIDED WITH UPRIGHTS
(EXPLODED VIEW SHOWN FOR REFERENCE ONLY)
ITEM NO.
PART
NUMBER
English Part Name
GUIDE_ASSY/QTY.
1
104-266
Weldment;6' Chin Bar;Rig
1
2
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
8
3
817-820
NUT;NLK;.500-13;ZN;
4
4
810-818
SCREW;HH;.500-13 x 4.50;ZN;
4
5
402-854
3" X 3" .120 WALL TUBE; 108"
2
ITEM
NO.
PART
NUMBER
English Part Name
Default/QTY.
1
104-266
Weldment;6' Chin Bar;Rig
1
ITEM
NO.
PART
NUMBER
English Part Name
Default/QTY.
1
104-265
Weldment;4' Chin Bar;Rig;
1
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-265
Weldment;4' Chin Bar;Rig;
1
1.1
250-919
1 1/4"OD X .120 WALL;41.5"
1
1.2
503-732
1/4" PLASMA;PLATE 3" X 12"
2
1.2.1
-
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-266
Weldment;6' Chin Bar;Rig
1
1.1
250-920
1 1/4"OD X .120 WALL;69.5"
1
1.2
503-732
1/4" PLASMA;PLATE 3" X 12"
2
1.2.1
-
1.3
503-733
1/4" PLASMA; GUSSET
2
1.3.1
-
ASSEMBLY GUIDE
XR01 & XR02 ASSY GUIDE
DRAWING NAME:
LAST UPDATED:
2017.OCT.19
DESCRIPTION:
MODEL:
XULT;RIG 6' CHIN BAR
XR01 & XR02
TOP SHELF
MEDICINE BALLS
SECOND SHELF
KETTLEBELLS
THIRD SHELF
DUMBBELLS
HORIZONTAL
SHELF
ANGLED
SHELF
ANGLED
SHELF
A1
B1
C1
DETAIL C1
SCALE 2 : 15
SHELF MOUNTING HEIGHT
HORIZONTAL
SHELF
SUGGESTED
MOUNTING
LOCATION
SUGGESTED
MOUNTING
LOCATION
SUGGESTED
MOUNTING
LOCATION
ASSEMBLY GUIDE
XULT XS-SHELF SERIES MOUNTING HEIGHT ASSY GUIDE.
DRAWING NAME:
LAST UPDATED:
2017.NOV.02
DESCRIPTION:
MODEL:
XS-SHELF SERIES
UPRIGHT
UPRIGHT
SEE STORAGE
BRACKET
ASSEMBLY GUIDE
SHELF
MEDICINE BALL 70" SHELF
W/MTG
A
DETAIL A
SCALE 1 : 6
MEDICINE BALL SHELF
HORIZONTAL MOUNTING
SEE STORAGE BRACKET
ASSEMBLY GUIDE
MEDICINE BALL 42" SHELF
W/MTG
TOOLS NEEDED:
3/4" WRENCHES X 2.
1 1/2" WRENCHES X2.
TORQUE SCREWS TO 57 ft-lbs
ASSEMBLE WITH PROVIDED BRACKET AND HARDWARE
(EXPLODED VIEW SHOWN BELOW FOR REFERENCE ONLY)
MEDICINE BALL SHELF
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-276
WELDMENT;SHELF MED BALL 42"
1
1.1
250-919
1 1/4"OD X .120 WALL;41.5"
2
1.2
200-771
1/2" CRR; 41 1/2"
1
1.3
503-732
1/4" PLASMA;PLATE 3" X 12"
2
2
161-303
RIG STORAGE BRACKET ASSEMBLY
2
2.1
503-741
SR BRACKET
1
2.2
818-026
WASHER;FLT;Φ1.062XΦ1.750;ZN
2
2.3
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
2.4
810-920
SCREW;HH;1.00-8 X5.00"ZN
1
2.5
810-806
SCREW;HH;.500-13 x 1.50;ZN;
2
2.6
817-820
NUT;NLK;.500-13;ZN;
3
3
862-354
DECAL;MB SHELF WARNING;XT
1
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-277
WELDMENT;SHELF MED BALL 70"
1
1.1
250-920
1 1/4"OD X .120 WALL;69.5"
2
1.2
200-772
1/2" CRR; 69 1/2"
1
1.3
503-732
1/4" PLASMA;PLATE 3" X 12"
2
2
161-303
RIG STORAGE BRACKET ASSEMBLY
2
2.1
503-741
SR BRACKET
1
2.2
818-026
WASHER;FLT;Φ1.062XΦ1.750;ZN
2
2.3
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
2.4
810-920
SCREW;HH;1.00-8 X5.00"ZN
1
2.5
810-806
SCREW;HH;.500-13 x 1.50;ZN;
2
2.6
817-820
NUT;NLK;.500-13;ZN;
3
3
862-354
DECAL;MB SHELF WARNING;XT
1
ASSEMBLY GUIDE
XS01 & XS02 ASSY GUIDE
DRAWING NAME:
LAST UPDATED:
2017.OCT.24
DESCRIPTION:
MODEL:
XULT;SHELF;MED BALL 70" W/MTG
XS01 & XS02
DUMBBELL/KETTLEBELL
42" SHELF W/MTG
DUMBBELL/KETTLEBELL
70" SHELF W/MTG
KETTLEBELL SHELF
HORIZONTAL MOUNTING
DUMBBELL SHELF
ANGLED SHELF
MOUNTING
SEE STORAGE BRACKET
ASSEMBLY GUIDE
HORIZONTAL MOUNTING
UPRIGHT UPRIGHT
HORIZONTAL MOUNTING
SHELF FRONT WITH DECAL
SEE STORAGE BRACKET
ASSEMBLY GUIDE
ANGLED MOUNTING
UPRIGHT
UPRIGHT
ANGLED MOUNTING
SHELF FRONT WITH DECAL
TOOLS NEEDED:
3/4" WRENCHES X 2.
1 1/2" WRENCHES X2.
TORQUE SCREWS TO 57 ft-lbs
ASSEMBLE WITH PROVIDED BRACKET AND HARDWARE
(EXPLODED VIEW SHOWN BELOW FOR REFERENCE ONLY)
DUMBBELL/KETTLEBELL SHELF
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-281
WELDMENT;70" DB SHELF
1
1.1
503-747
1/4" PLASMA;PLATE 13.75" x 70"
1
1.1.1
-
1.2
503-746
1/4" Plasma
2
1.3
300-994
1" x 1" Angle Iron - 69 1/2"
2
1.3.1
-
1.4
402-861
1" x 2" .083W;69 1/2"
1
2
161-303
RIG STORAGE BRACKET ASSEMBLY
2
2.1
503-741
SR BRACKET
1
2.1.1
-
2.2
818-026
WASHER;FLT;Φ1.062XΦ1.750;ZN
2
2.3
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
2.4
817-920
SCREW;HH;1.00-8 X5.00"ZN
1
2.5
810-806
SCREW;HH;.500-13 x 1.50;ZN;
2
2.6
817-820
NUT;NLK;.500-13;ZN;
3
3
862-356
DECAL;DB/KB SHELF WARNING;XT
1
ITEM NO.
PART NUMBER
English Part Name
QTY.
1
104-280
WELDMENT;42" DB SHELF
1
1.1
300-993
1" X 1" ANGLE IRON 41 1/2"
2
1.1.1
-
1.2
503-746
1/4" Plasma
2
1.3
503-745
14 GA PLASMA;SHELF 42"
1
1.3.1
-
2
161-303
RIG STORAGE BRACKET ASSEMBLY
2
2.1
503-741
SR BRACKET
1
2.1.1
-
2.2
818-026
WASHER;FLT;Φ1.062XΦ1.750;ZN
2
2.3
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
2.4
817-920
SCREW;HH;1.00-8 X5.00"ZN
1
2.5
810-806
SCREW;HH;.500-13 x 1.50;ZN;
2
2.6
817-820
NUT;NLK;.500-13;ZN;
3
3
862-356
DECAL;DB/KB SHELF WARNING;XT
1
ITEM
NO.
PART
NUMBER
English Part Name
Shelf Dumbell
angled
mounting/QTY.
1
104-281
WELDMENT;70" DB SHELF
1
2
161-303
RIG STORAGE BRACKET ASSEMBLY
2
3
862-356
DECAL;DB/KB SHELF WARNING;XT
1
ITEM
NO.
PART NUMBER
English Part Name
Shelf Dumbell
angled
mounting/QTY.
1
104-280
WELDMENT;42" DB SHELF
1
2
161-303
RIG STORAGE BRACKET ASSEMBLY
2
3
862-356
DECAL;DB/KB SHELF WARNING;XT
1
ASSEMBLY GUIDE
XS05 & XS06 ASSY GUIDE
DRAWING NAME:
LAST UPDATED:
2017.OCT.25
DESCRIPTION:
MODEL:
DUMBBELL/KETTLEBELL SHELF
XS05 & XS06
UPRIGHT
UPRIGHT
NUT;NYLOCK
0.500"-13
2 PLACES
WASHER;FLAT 0.500"
4 PLACES
SCREW;HEX HEAD 0.500-13
4 PLACES
UPRIGHT MOUNTING
BP STACKER 42"
W/MOUNTING
HARDWARE
BP STACKER 70"
W/MOUNTING
HARDWARE
MOUNTING
LOCATION
TOOLS NEEDED:
3/4" WRENCHES X 2.
TORQUE SCREWS TO 57 ft-lbs
HARDWARE FOR ASSEMBLY INCLUDED
(EXPLODED VIEW SHOWN BELOW FOR REFERENCE ONLY)
BUMPER PLATE STACKER
SUPPORTED
BY FLOOR
ITEM NO.
PART
NUMBER
English Part Name
Default/QTY.
1
104-283
WELDMENT;RIG 70" BP STACKER
1
2
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
3
817-820
NUT;NLK;.500-13;ZN;
2
4
810-818
SCREW;HH;.500-13 x 4.50;ZN;
2
5
862-358
Decal;BP Stacker WARNING;XT
1
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-282
WELDMENT;RIG 42" BP STACKER
1
2
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
3
817-820
NUT;NLK;.500-13;ZN;
2
4
810-818
SCREW;HH;.500-13 x 4.50;ZN;
2
5
862-358
Decal;BP Stacker WARNING;XT
1
ITEM NO.
English Part Name
QTY.
1
104-283
WELDMENT;RIG 70" BP STACKER
1
1.1
250-920
1 1/4"OD X .120 WALL;69.5"
2
1.2
503-732
1/4" PLASMA;PLATE 3" X 12"
2
1.2.1
-
1.3
200-773
1/2" CRR; 28 1/8"
4
1.4
503-776
1/4" PLASMA, GUSSET
2
2
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
3
817-820
NUT;NLK;.500-13;ZN;
2
4
810-818
SCREW;HH;.500-13 x 4.50;ZN;
2
5
862-358
Decal;BP Stacker WARNING;XT
1
ITEM NO.
PART
NUMBER
English Part Name
QTY.
1
104-282
WELDMENT;RIG 42" BP STACKER
1
1.1
250-919
1 1/4"OD X .120 WALL;41.5"
2
1.2
503-732
1/4" PLASMA;PLATE 3" X 12"
2
1.2.1
-
1.3
200-773
1/2" CRR; 28 1/8"
4
1.4
503-776
1/4" PLASMA, GUSSET
2
2
818-007
WASHER;FLT;USS;Φ0.500XΦ1.250X.063;ZN;
4
3
817-820
NUT;NLK;.500-13;ZN;
2
4
810-818
SCREW;HH;.500-13 x 4.50;ZN;
2
5
862-358
Decal;BP Stacker WARNING;XT
1
ASSEMBLY GUIDE
XS07 & XS08 ASSY GUIDE
DRAWING NAME:
LAST UPDATED:
2017.OCT.25
DESCRIPTION:
MODEL:
XULT;RIG BP STACKER 70" W/MTG HW
XS07 & XS08
PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. Exercise using no more weight than you can safely lift and control.
. In a controlled manner, perform exercise.
5. Return weight to its fully-supported start position.
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of Xult products to instruct all individuals, whether they are the end user or supervising personnel on
proper usage of the equipment.
It is recommended that all users of Xult exercise equipment be informed of the following information prior to its use.
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that Xult equipment be used
properly to avoid injury.
INSTALLATION
•STABLE AND LEVEL SURFACE: Xult exercise equipment must be installed on a stable base and properly leveled.
•SECURING EQUIPMENT: Manufacturer recommends that all stationary Xult strength equipment be secured to the floor to stabilize equipment
and eliminate rocking or tipping over. This must be performed by a licensed contractor. All floor anchor points must be able to withstand 750
lbs. (3.3 kN) pull-out force. All wall anchor points must be able to withstand a minimum pull-out force of 2.2 kN (500 LBS) from the walls
MAINTENANCE
•DO NOT use any equipment that is damaged and or has worn or broken parts.
•MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason.
•MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping your liability to a
minimum. Equipment needs to be inspected at regular intervals.
•Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
XULTFITNESS.COM
Action Frequency
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As needed
Maintenance Checkli t
Tech Spec
Max User Weight 136 kg / 300 lbs
Max Training Weight 318 kg / 700 lbs
Dimensions (L x D x H) 78.5" x 60" x 9 .25"
Product Weight 228 kg / 502 lbs
Product Specification
Frame 10 years
Finish 5 years
Accessories 3 years
Labor 1 year
Warranty
WARNING
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO
AVOID INJURY!
1. Keep children under the age of 1 away from this strength training equipment. Teenagers must be
supervised at all times while using this equipment.
2. This equipment is not intended for use by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the equipment by a person responsible for their safety.
3. All warnings and instructions should be read and proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
5. Do not exceed weight capacity of this equipment.
6. ALWAYS use a spotter if using free weights.
7. Balance the weight applied to this equipment and/or any barbell. Where applicable, use retention
devices to retain weight discs.
8. Injuries to health may result from incorrect or excessive training. Cease exercise if you feel faint or
dizzy. Obtain a medical exam before beginning an exercise program.
9. Keep body, clothing, hair, and fitness accessories free and clear of all moving parts.
10. Do not allow the lifting bar to drop suddenly.
11. Adjustable stops must be used at all times.
12. ALWAYS set both adjustable stops to the same height when using this machine.
13. Visually ensure lifting bar catches are fully engaged and seated in the hooks before releasing the
load and exiting the machine.
1 . PROPER adjustable stop height depends on the exercise performed. Adjust as follows:
• Remove weight from lifting bar.
• For squats, perform the exercise and determine the lowest comfortable position of the bar that
ensures no spinal compression. For other exercises, perform the movement and determine the
lowest point of bar travel that is comfortable without the bar contacting your body.
• Position both stop catches to stop the bar at this point. Ensure that they are fully engaged.
• Load weights onto the lifting bar and carefully perform the exercise.
15. Manufacturer requires this equipment to be secured to the floor to stabilize and eliminate rocking
or tipping over. Use a licensed contractor.
XULTFITNESS.COM
Table of contents
Other Xult Fitness Equipment manuals
