Xylem Sensus FlexNet CommandLink II User manual

FlexNet CommandLink II
Quick Guide
AQG-10087-04
The CommandLink® II wireless interface provides access to a complete
suite of functional controls within a gas, water, or electric SmartPoint®
transceiver. This Bluetooth® enabled device, coupled with a handheld,
can perform activations, deactivation, meter read, on demand reads and
audits of the SmartPoint module.
Warning: Risk of hot surface. Do not hold device longer than one (1) minute when
operating in an ambient temperature above 40°C (104°F).
Step 1: Charge the CommandLink II
You must charge the CommandLink II completely before first use.
1. Plug the charging adapter into a power outlet and connect to
the Charging Port located next to the Mag Loop on top of the
Command Link II.
Note: Make sure you have rechargeable batteries installed before using a power outlet.
Units that have non-rechargeable batteries should never be plugged into a power outlet
for charging.
2. The red LED indicator illuminates, indicating the unit is charging.
3. Unplug the unit when the red LED is no longer illuminated,
indicating the CommandLink II is fully charged.
Note: To power down the CommandLink II immediately, press and hold the power
button located on the side of the CommandLink II until the PWR LED turns off.
Step 2: Turn on the Command Link II
1. Press the power button.
2. The green LED light illuminates when the CommandLink II is
successfully powered.
Step 3: Create a Bluetooth Partnership
To use the CommandLink II, you must first establish a Bluetooth
partnership with a Windows Mobile, Android or iOS equipped handheld
device (HHD) or PC.
Package Contents
 FlexNet CommandLink II
 Bungee Straps (2)
 Charging Adapter (AC/DC)
 Vehicle Charging Adapter (DC/DC)
 Case
LED Description
CHG (Red) Charging
LNK (Blue) Bluetooth connected
PWR (Green) Solid: power on
Flash: needs charge/poor battery
connection/defective battery
Mag Loop Charging Port
Battery Cover
Strap Clip
LED Indicators
Power

AQG-10007-04
If using a Windows Mobile Hand-Held Device:
1. Select Start, then Settings.
2. Select Connections, then select
Bluetooth COM.
Power on the CommandLink II if
it is off.
3. Select Discover Devices.
A list of all the Bluetooth enabled
devices in range is generated and displayed.
If your CommandLink II does not appear in the list,
make sure that it is powered on. If it is powered on,
power cycle it and select Discover Devices again and
repeat this step.
4. Select your
CommandLink II from
the list and select
Connect.
5. If you are prompted to
Set the Bluetooth PIN,
enter 0000 and select
OK.
6. Select OK to exit.
7. Select X in the lower right corner to exit.
8. Select FieldLogic Tools from the Start menu.
9. From the FieldLogic
Tools main screen,
select Menu and select
Options.
10. Select the FlexNet
tab and select
CommandLink from
the Device type drop-
down list. Do not select
CLxxxxxxxx_BLE.
11. Select Get Status.
FieldLogic Tools
connects with the
CommandLink II and
displays a success
message.
12. Select OK.
13. Select OK again to return to the Connect screen.
If using an Android Device:
1. Select the Settings icon.
2. Select Options, then select FlexNet. FieldLogic
displays a list of available devices.
3. Select + to view the
system pairing screen.
4. Select your CommandLink II (CLxxxxxxxx) from the
list of available Bluetooth devices.
5. Select Pair. Your CommandLink II then displays in the
Paired Devices list.
6. Return to FieldLogic Tools.
7. Select the newly-paired CommandLink II in the list
and select the information symbol.
FieldLogic connects to the CommandLink II and
displays a success message.
8. Select Close.
9. Select the back arrow to return to the FieldLogic
main screen.

AQG-10007-04
If using an iOS Hand-Held Device:
1. Select the Settings icon.
2. Select Options, then select
FlexNet. FieldLogic scans for
the device and then displays
available devices. The list
refreshes automatically.
3. A permission pop-up window
displays. Select OK.
4. Select your CommandLink II
(CLxxxxxxxx) from the list of
available Bluetooth devices.
5. Select your CommandLink II
and then select the information
symbol.
6. FieldLogic connects to the
CommandLink II and displays a
success message.
7. Select Close to return to the Options screen.
8. Select the back arrow to return to the FieldLogic main
screen.
If using a PC:
1. Power up the CommandLink II.
2. Select the Bluetooth icon on your computer’s desktop
or from the Start menu.
3. From the Bluetooth Devices pane, select Add a
device.
4. Your computer searches for devices to add.
5. Select the icon containing the CommandLink II ID
number (CLxxxxxxxx).
Note: If two numbers appear, make sure you select CLxxxxxxxx.
Do not select CLxxxxxxxx_BLE.
6. Select Next.
7. Your computer confirms the successful addition of the
CommandLink II.
8. Select Close to continue.
9. Start FieldLogic Tools. From the main screen, select
Tools and select Options.
10. Select the FlexNet Settings expander and select
CommandLink from the Communication Device
drop-down list. Select your device from the Device
name drop-down list.
11. Select Get Status.
FieldLogic Tools connects with the CommandLink II
and displays a success message.
12. Select OK to return to the Options screen.
13. Select OK to return to the Connect screen.
Attach a Strap to the CommandLink II
To attach a strap, slide it in between the slots on the sides of
the unit.
