Xylem LOWARA e-SVE Manual

Smart Pump Range
e-SVE, VME, e-HME, e-SVIE
Additional Installation, Operation
and Maintenance Instructions
See also:
•Quick Startup Guide
•e-SVE, VME, e-HME, e-SVIE
Installation and Operation Manual

en – Original instructions
2
Table of Contents
1Introduction and Safety ..............................................................................................................................................4
1.1 Introduction........................................................................................................................................................4
1.2 Safety ................................................................................................................................................................ 4
1.2.1 Hazard levels and safety symbols................................................................................................................. 4
1.2.2 User safety ....................................................................................................................................................5
1.2.3 General safety rules ...................................................................................................................................... 6
1.2.4 Protection of the environment .......................................................................................................................7
1.2.5 Sites exposed to ionizing radiations..............................................................................................................7
1.3 Spare parts ........................................................................................................................................................ 7
1.4 Product warranty ............................................................................................................................................... 7
2Handling and Storage ................................................................................................................................................8
2.1 Unit handling .....................................................................................................................................................8
2.2 Storage............................................................................................................................................................10
3Technical Description...............................................................................................................................................11
3.1 Designation .....................................................................................................................................................11
3.2 Data plates ......................................................................................................................................................11
3.2.1 Motor ...........................................................................................................................................................11
3.2.2 e-HME and VME pumps .............................................................................................................................12
3.2.3 e-SVE pump ................................................................................................................................................14
3.2.4 e-SVIE pump ............................................................................................................................................... 15
3.3 Design and layout............................................................................................................................................17
3.4 Intended use.................................................................................................................................................... 19
3.4.1 Application alternatives ...............................................................................................................................19
3.5 Improper use ...................................................................................................................................................19
4Installation ................................................................................................................................................................20
4.1 Mechanical installation ....................................................................................................................................20
4.1.1 Installation area ...........................................................................................................................................20
4.1.2 Unit installation ............................................................................................................................................20
4.1.3 Outdoor unit installation .............................................................................................................................. 21
4.2 Hydraulic installation .......................................................................................................................................22
4.3 Electrical Installation .......................................................................................................................................23
4.3.1 Electrical requirements................................................................................................................................23
4.3.2Wire types and ratings................................................................................................................................. 24
4.3.3 Power supply connection ............................................................................................................................ 25
5Operation ................................................................................................................................................................. 29
5.1 Wait times........................................................................................................................................................ 29
6Programming ...........................................................................................................................................................30
6.1 Control panel ...................................................................................................................................................30
6.2 Description of the buttons ...............................................................................................................................31

en – Original instructions
3
6.3 LEDs description ............................................................................................................................................. 31
6.3.1 POWER (power supply) ..............................................................................................................................31
6.3.2 STATUS ......................................................................................................................................................31
6.3.3 SPEED (speed bar).....................................................................................................................................31
6.3.4 COM (communication) ................................................................................................................................32
6.3.5 Unit of measurement ...................................................................................................................................32
6.4 Display.............................................................................................................................................................33
6.4.1 Main visualization ........................................................................................................................................33
6.4.2 Parameters menu visualization ...................................................................................................................34
6.4.3 Alarms and errors visualization ...................................................................................................................35
6.5 Software parameters .......................................................................................................................................35
6.5.1 Status Parameters.......................................................................................................................................35
6.5.2 Settings Parameters....................................................................................................................................36
6.5.3 Drive Configuration Parameters..................................................................................................................37
6.5.4 Sensor Configuration Parameters...............................................................................................................39
6.5.5 RS485 Interface Parameters.......................................................................................................................40
6.5.6 Multi-pump configuration parameters..........................................................................................................40
6.5.7 Test Run Configuration Parameters............................................................................................................41
6.5.8 Special Parameters .....................................................................................................................................41
6.6 Technical references .......................................................................................................................................42
6.6.1 Example: ACT control mode with analog input ...........................................................................................42
6.6.2 Example: Ramp Settings.............................................................................................................................43
6.6.3 Example: Effective Required Value.............................................................................................................43
7Maintenance ............................................................................................................................................................45
8Troubleshooting ....................................................................................................................................................... 46
8.1 Alarm codes ....................................................................................................................................................46
8.2 Error codes......................................................................................................................................................46
9Technical Information...............................................................................................................................................48
9.1 Dimensions and weights .................................................................................................................................49
10 Disposal...............................................................................................................................................................52
10.1 Precautions .....................................................................................................................................................52
10.2 WEEE (EU/EEA) .............................................................................................................................................52
10.3 WEEE (UK) .....................................................................................................................................................52
11 Declarations ........................................................................................................................................................53
11.1 EC Declaration of Conformity (Original)..........................................................................................................53
11.2 EU Declaration of Conformity (No 19).............................................................................................................53
11.3 UKCA Declaration of Conformity (Original).....................................................................................................54
11.4 UKCA Declaration of Conformity (No 19) ....................................................................................................... 54

en – Original instructions
4
1 Introduction and Safety
1.1 Introduction
Purpose of this manual
The purpose of this manual is to provide necessary information for:
•Installation
•Operation
•Maintenance
CAUTION:
Before installing and using the product, make sure that you read and fully understand this manual
in all its parts. Improper use of the product can cause personal injuries and
damage to property,
as well as making the warranty null and void.
NOTE:
This manual is an integral part of the product. It must always be made available to the user,
stored in the proximity of the product, and well kept.
1.2 Safety
Before using the product, and in order to avoid the following risks, make sure that you carefully
read, understand and comply with the following danger warnings:
•Injuries and health hazards
•Damage to the product
•Product malfunction.
Hazard levels
Hazard level
Indication
DANGER:
It identifies a dangerous situation which, if not avoided, causes serious
injury, or even death.
WARNING:
It identifies a dangerous situation which, if not avoided, may cause
serious injury, or even death.
CAUTION:
It identifies a dangerous situation which, if not avoided, may cause small
or medium level injuries.
NOTE:
It identifies a situation which, if not avoided, may cause damage to
property but not to people.

en – Original instructions
5
Special symbols
Some hazard categories have specific symbols, as shown in the following table:
Symbol
Description
Electrical hazard
Magnetic hazard
Hot surface hazard
Ionizing radiation hazard
Potentially explosive atmosphere hazard (ATEX EU Directive)
Cut and abrasion hazard
Crushing hazard (limbs)
1.2.2 User safety
Strictly comply with current health and safety regulations.
WARNING:
This product must be used only by qualified users.
For the purposes of this manual, in addition to the provisions of any local regulations, qualified
personnel means any individuals who, due to their experience or training, are capable of
recognising any existing hazards and to avoiding dangers during the installation, the use and the
maintenance of the product.

en – Original instructions
6
Inexperienced users
WARNING:
FOR THE EUROPEAN UNION
•
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
•
Children shall not play with the appliance.
•
Cleaning and user maintenance shall not be made by children without supervision.
FOR OTHER COUNTRIES
•
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
•Children should be supervised to ensure that they do not play with the appliance.
1.2.3 General safety rules
WARNING:
•
Always keep the work area clean
•
Pay attention to the risks presented by gas and vapors in the work area
•Always bear in mind the risk of drowning, electrical accidents, and burn injuries.
DANGER: Electrical hazard
•
Avoid all electric dangers; pay attention to the risk of electric shock or electric arcs
•
Unintended rotation of motors creates voltage and can charge the unit, resulting in death,
serious injury, or equipment damage. Ensure that motors are blocked to prevent unintended
rotation.
Magnetic fields
The removal or installation of the rotor in the motor casing generates a strong magnetic field.
DANGER: Magnetic hazard
The magnetic field may be
dangerous for anyone wearing peacemakers, or any other medical
devices sensitive to magnetic fields.
NOTE
The magnetic field may attract metal debris on the rotor surface, causing damage to the same.
Electrical Connections
DANGER: Electrical hazard
•
The connection to the electric power supply must be completed by an electrician possessing
the technical-professional requirements outlined in the current regulations
Precautions before work
WARNING:
•
Install a suitable barrier around the working area, for example a guard rail
•
Make sure that all safety guards are in place and secure
•
Make sure that you have a clear path of retreat
•
Make sure that the product cannot roll or fall over and injure people or damage property
•
Make sure that the lifting equipment is in good condition
•Use a lifting harness, a safety line, and a breathing device as required

en – Original instructions
7
•Allow all pump system components to cool before handling them
•
Make sure that the product has been thoroughly cleaned
•
Disconnect and lock out power before you service the pump
•Check the explosion risk before you weld or use electric hand tools.
Precautions during work
WARNING:
•
Never work alone
•
Always wear personal protective equipment
•
Always use suitable working tools
•
Always lift the product by its lifting device
•
Stay clear of suspended loads
•
Beware of the risk of a sudden start if the product is used with an automatic level control
•
Beware of the starting jerk, which can be powerful
•
Rinse the components in water after you disassemble the pump
•
Do not exceed the maximum working pressure of the pump
•
Do not open any vent or drain valve or remove any plugs while the system is pressurized
•
Make sure that the pump is isolated from the system and that all pressure is released before
disassembling the pump, removing plugs, or disconnecting the piping
•Never operate the pump without a properly installed coupling guard.
In case of contact with chemical substances or dangerous liquids
Follow these procedures for chemicals or hazardous fluids that have come into contact with your
eyes or your skin:
Condition
Action
Chemicals or hazardous fluids in
eyes
1. Hold your eyelids apart forcibly with your fingers.
2. Rinse the eyes with eyewash or running water for at least 15 min.
3. Seek medical attention.
Chemicals or hazardous fluids on
skin
1. Remove contaminated clothing.
2. Wash the skin with soap and water for at least 1 min.
3. Seek medical attention, if necessary.
1.2.4 Protection of the environment
Disposal of packaging and product
Comply with the current regulations on sorted waste disposal.
1.2.5 Sites exposed to ionizing radiations
WARNING: Ionizing radiation hazard
If the product has been exposed to ionizing radiations, implement the necessary safety measures
for the protection of people. If the pro
duct needs to be despatched, inform the carrier and the
recipient accordingly, so that appropriate safety measures can be put in place.
1.3 Spare parts
Identify the spare parts with the product codes directly on the site www.lowara.com/spark.
Contact Xylem or the Authorised Distributor for technical information.
1.4 Product warranty
For information on the warranty refer to the documentation of the sale contract.

en – Original instructions
8
2 Handling and Storage
Packaging inspection
1. Check that quantity, descriptions and product codes match the order.
2. Check the packaging for any damage or missing components.
3. In case of immediately detectable damage or missing parts:
•Accept the goods with reserve, indicating any findings on the transport document, or
•Reject the goods, indicating the reason on the transport document.
In both cases, promptly contact Xylem or the Authorised Distributor from whom the product was
purchased.
Unpacking and inspection of the unit
1. Remove the packaging material from the product.
2. Release the product by removing the screws and/or cutting the straps, if fitted.
CAUTION: Cut and abrasion hazard
Always wear personal protective equipment.
3. Check the product for integrity and to make sure that there are no missing components.
4. In case of damage or missing components, promptly contact Xylem or the Authorised
Distributor.
2.1 Unit handling
The unit must be hooked and lifted as shown in the figure.
WARNING: Crushing hazard (limbs)
•
The product and its components may be heavy: risk of crushing
•
Always wear personal protective equipment
•
Manual handling of the product and its components must be in compliance with the current
regulations on "manual load handling", to avoid unfavourable ergonomic conditions causing
risks of back-spine injury.
•
Use cranes, ropes, lifting straps, hooks and clasps that comply with current regulations and
that are suitable for the specific use
•
Make sure that the harnessing does not damage the unit
•
During the lifting operations, always avoid sudden movements that could compromise the
stability of the load
•
During handling, make sure to avoid injury to people and animals, and/or damage to property.

en – Original instructions
9
1 x
1 x
VME
1 x
e-SVE
1 x
1 x
1 x
e-HME
1 x
ESM_M0002_D_sc
e-SVIE
1 x
1 x
1 x
1 x

en – Original instructions
10
2.2 Storage
The product must be stored:
•In a covered and dry place
•Away from heat sources
•Protected from dirt
•Protected from vibrations
•At an ambient temperature between -25°C and +65°C (-13°F and 149°F), and relative
humidity between 5% and 95%.
NOTE:
•
Do not place heavy loads on top of the product
•
Protect the product from collisions.

en – Original instructions
11
3 Technical Description
3.1 Designation
Variable speed pump unit, vertical/horizontal, multi-stage, non self-priming.
3.2 Data plates
The data plate is a label showing:
•The main product details
•The identification code
Approval and certifications
For the approvals see the motor data plate:
•only
•+
3.2.1 Motor
Data plate
1. Type definition code
2. Voltage rating
3.
Rated frequency
4.
Rated power [kW]
5.
Rated power [HP]
6.
Part number
7.
Insulation class
8.
Serial number
9.
Maximum ambient temperature
10.
Power factor
11.
Current rating
12.
Motor drive efficiency
13.
Full power speed range
14. Code letter for locked rotor
15. Duty type
16. Enclosure type (NEMA)
17.
Weight
18.
Protection class
19.
Shaft power
20.
Voltage
21.
Current
22.
Part number
23.
Serial number
24.
Power factor
25.
Rotation speed
26.
Power drive system efficiency class
(according to EN 50598-2)
27. Full load efficiency
Identification code

en – Original instructions
12
1. Series
ESM
2. Motor frame dimension
90R: Oversized Flange
80: Standard Flange
3. Shaft extension
□□: Standard shaft extension
S8: Custom Shaft extension
4. Power supply
1: single phase power supply
3: three phase power supply
5. Shaft power•10 [kW]
03: 0.37kW (0.50HP)
05: 0.55 kW (0.75 HP)
07: 0.75 kW (1.00 HP)
11: 1.10 kW (1.50 HP)
15: 1.50 kW (2.00 HP)
22: 2.20 kW (3.00 HP)
6. Motor frame arrangement
SVE: Flange with tapped holes and shaft w/o keyseat
B14: Flange with tapped holes
B5: Flange with free holes
HMHA:Suitable for 1÷5 e-HME monolithic pumps
HMHB: Suitable for 1÷5 e-HME pumps w/sleeve
HMVB:Suitable for 1÷5 VM pumps
HMHC:Suitable for 10÷22 e-HME pumps
HMVC:Suitable for 10÷22 VM pumps
LNEE: Suitable for In-Line pumps
56J: Compliant to NEMA 56 Jet standard
56C: Compliant to NEMA 56C standard
7. Reference market
□□: Standard
EU:EMEA
US: North America
8. Voltage
208-240 : 208-240VAC 50/60Hz
380-460 : 380-460VAC 50/60Hz
230/400: 208-240/380-460VAC 50/60Hz
3.2.2 e-HME and VME pumps
Data plate
1. Head range
2. Flow rate range
3.
Pump/electric pump unit type definition code
4.
Protection class
5.
Frequency
6.
Serial number (date+progressive number)
7.
Electric pump unit/pump part number
8. Maximum operating liquid temperature (uses as EN
60335-2-41)
9. Maximum operating ambient temperature
10. Minimum head (EN 60335-2-41)
11.
Maximum operating pressure
12.
Electric pump unit weight
13.
Electric pump unit absorbed power
14.
Electrical data
15.
Maximum operating liquid temperature (uses other
than as EN 60335-2-41)

en – Original instructions
13
e-HME type definition code
1. Rated flow rate
[10] = m
3
/h
2. Series name
[HM]
3. Motor operation
[E] = e-SM
4. Number of impeller
[03] = 3 impellers
5. Material pump
[S] = Stainless steel (AISI 304)
6. Motor rated power
kW x 10
7. Phase
[M] = Single-phase
[T] = Three-phase
8. Power Supply Voltage
e-SM Power supply
02 = 1x208-240 V
04 = 3x380-460 V
05 = 3x208-240/380-460 V
9. Rotating part
[Q] = Silicon Carbide (Q
1
)
[V] = Aluminium oxide (Ceramic)
10. Stationary part
[Q] = Silicon Carbide (Q
1
)
[B] = Carbon resin impregnated
11. Elastomers
[E] = EPDM
[V] = FPM
[K] = FFPM (Kairez®)
12. General characteristics
Null = None
Z = other
13. General characteristics
Null = None
14. Connections
Null = Threaded
15.
Null or letter assigned by the manufacturer
VME type definition code
1. Rated flow rate
[10] = m
3
/h
2. Series name
[VM]
3. Motor operation
[E] = e-SM
4. Number of impeller
[02] = 2 impellers
5. Material pump
[P] = Stainless steel AISI 304 with Noryl™ impellers
6. Motor rated power
kW x 10
7. Phase
[M] = Single-phase pump unit
[T] = Three-phase pump unit
8. Power Supply Voltage
[2] = 1x208-240 V
[4] = 3x380-460 V
[5] = 3x208-240/380-460 V
9. Rotating part
[V] = Aluminium oxide (Ceramic)
10. Stationary parts
Carbon resin impregnated
11. Elastomers
[E] = EPDM

en – Original instructions
14
3.2.3 e-SVE pump
Data plate
1. Pump / electric pump unit type
2. Serial number (date+progressive number)
3.
Flow rate range
4.
Minimum head (EN 60335-2-41)
5.
Maximum operating pressure
6.
Rated voltage range
7.
Frequency
8.
Minimum efficiency index
9.
Electric pump unit/ pump part number
10. Mechanical seal material identification code
11. Head range
12.
Motor rated power
13.
Maximum operating liquid temperature (uses as EN
60335-2-41)
14.
Protection class
15.
Current
16.
Electric pump unit absorbed power
17. Maximum operating liquid temperature (uses other
than as EN 60335-2-41)
Identification code
1. Rated flow rate
[22] = m
3
/h
2. Series name
[SV]
3. Motor operation
[E] = e-SM
4. Number of impeller
[02] = 2 impellers
5. Material pump
[F] = Stainless steel AISI 304, round flanges (PN 25)
[T] = Stainless steel AISI 304, oval flanges (PN 16)
[R] = Stainless steel AISI 304, discharge port above suction, round flanges (PN 25)
[N] = Stainless steel AISI 316, round flanges (PN 25)
6. Version
Empty = standard version
7. Motor rated power
kW x 10
8. Number of poles
[P] = e-SM
9. Frequency
[0] = e-SM
10. Phase
Null = pump
[M] = Single-phase pump unit
[T] = Three-phase pump unit
11. Power Supply Voltage
[2] = 1x208-240 V
[4] = 3x380-460 V
[5] = 3x208-240/380-460 V

en – Original instructions
15
3.2.4 e-SVIE pump
Data plate of models 1, 3, 5SVI (E) - 1~
1. Pump or pump unit type
2. Flow rate range
3.
Head range
4.
Minimum head
5.
Serial number + manufacturing date
6.
Product code
7.
Mechanical seal and O-ring materials identification
codes
8. Rated voltage range
9. Minimum liquid operating temperature
10. Maximum liquid operating temperature
11.
Frequency
12.
Maximum operating pressure
13.
Pump rated power
14.
Weight
15.
Protection class
16.
Minimum efficiency index
17. Electric pump unit absorbed power
Data plate of models 1, 3, 5SVI (E) - 3~ / 1, 3, 5, 10, 15, 22SVI (C, M)
1. Pump or pump unit type
2. Minimum liquid operating temperature
3.
Maximum liquid operating temperature
4.
Maximum operating pressure
5.
Flow rate range
6.
Head range
7.
Rotation speed
8.
Pump rated power
9. Weight
10. Product code
11. Mechanical seal materials identification code
12.
O-ring materials identification code
13.
Electric pump unit absorbed power
14.
Minimum head
15.
Minimum efficiency index
16.
Protection class
17.
Serial number + manufacturing date
SVI_M0019_A_sc
1234 5 67
8910 11 12 13 14 15 16 17
SVI_M0020_A_sc
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
917

en – Original instructions
16
Data plate of models 33, 46, 55, 92 (S, N)
1. Pump unit type
2. Product code
3.
Flow rate range
4.
Mechanical seal materials identification code
5.
Electric pump unit absorbed power
6.
Rotation speed
7. O-ring materials identification code
8. Head range
9. -
10.
Type of motor
11.
Manufacturing date + serial number
12.
Maximum liquid operating temperature
13.
Minimum head
14. Maximum operating pressure
Identification code for models 1, 3, 5, 10, 15 and 22
1. Flow rate in m3/h
2.
Series name
3.
Standard asynchronous motor with e-SM Drive [E]
4.
Number of impeller
5.
Number of stages
6.
Version with extended shaft [E], with cartridge seal [C], standard [M] or special [X] seal
7.
Material: AISI 304 [G] or AISI 316 [N]
8.
Rated motor power in kWx10
9.
2-pole [2], 4-pole [4] or e-SM Drive [P] motor
10.
Single-phase motor [M], three-phase motor [T] or bare shaft pump [ ]
11.
Power supply voltage with e-SM Drive: 1x208-240 V [02], 3x380-460 V [04] or 3x208-240/380-460 V [05]
12.
Mechanical seal and elastomers
13.
Other information: standard [ ], PTC [P], motor heater [S], UL approved (cURus) [U], other specifications [Z]
SVI_M0021_A_sc
8
9
1234567
12
13
14
10
11
ESM_M0040_A_sc
1 5 S V 0 6 - 0 6 C 5
IG 0 5 T 5 R Q Q E
133 5 6 7 9 101 2 4 8 11 12
E

en – Original instructions
17
Identification code for models 33, 46, 66 and 92
1. Series name
2.
Flow rate in m3/h
3.
Number of impeller
4.
Number of stages
5.
Version with coupling [S] or AISI 316 with coupling [N]
6.
Rated motor power in kWx10
7.
2-pole [ ] or 4-pole [4] motor
8.
Single-phase motor [M], three-phase motor [T] or bare shaft pump [ ]
9.
Other information
3.3 Design and layout
The unit can be fitted with the features the application requires.
SV I 4 0 9 / 2 - 0 36 9 S40 T / _
0
SVI_M0023_A_sc
5 72 4 8 93 61
5
2
3
6 4
5
9
1
7
3
9
1
6 4
10
2
1~ 3~
ESM_T0022_A_sc
8
ESM_M0005_B_sc
11

en – Original instructions
18
Position
number Description
Tightening torque ±15%
[Nm]
[in•lbs]
1
Screw
1.4
12.4
2
Terminal Box Cover
-
-
3
Optional module with strip
-
-
4
M12 I/O cable gland
2.0
17.7
5
M20 cable gland for power supply cables
2.7
23.9
6
M16 I/O cable gland
2.8
24.8
7
Drive (single-phase model)
-
-
8
Motor
-
-
9
Screw
6.0
53.1
10
Drive (three-phase model)
-
-
11
Spacer
-
-
Pre-assembled ex factory components
Component
Quantity
Notes
Plug for Cable Gland
M12
3
M16
1
M20
1
Cable gland and lock nut
M12
3
Cable Outer Diameter:
3.7 to 7.0 mm (0.145÷0.275 in)
M16
1
4.5 to 10.0 mm (0.177÷0.394 in)
Cable Gland
M20
1
7.0 to 13.0 mm (0.275÷0.512 in)
Optional components
Component
Description
Sensors
The following sensors can be used with the unit:
• Level-sensor
RS485 Module
For the connection of a multi-pump system to a supervision system, via cable (Modbus or BACnet
MS/TP protocol)
Adaptor
M20 Metric to 1/2" NPT Adapter (item is always supplied for US market)

en – Original instructions
19
3.4 Intended use
The product can be used to pump:
•Cold water
•Hot water
Refer to the standard Installation, Operation and Maintenance Manual for pump design
specification.
The variable speed pump units are made for the following applications:
•Pressure, level, and flow regulation (open loop systems)
•Single or multi pump irrigation systems.
3.4.1 Application alternatives
Actuator (constant speed)
The unit operates as an actuator according to speed set point; this is done through user
interface, the corresponding analog input or the communication bus.
Controller (constant pressure)
This mode is set as the default operating mode, and is used for single pump operating units.
Cascade serial / Cascade synchronous
The units are connected via the RS485 interface and communicate via the provided protocol.
The combination of the different units which are used in a multi-pump system depends on the
system requirements.
It is possible to run all pumps in cascade serial mode and cascade synchronous mode as well. If
one unit fails, then each pump of the system can become the lead pump and can take control.
3.5 Improper use
WARNING:
Improper product use can create dangerous conditions and cause personal injuries and damage
to property
Also refer to the “Quick Startup Guide” and the “Installation, Operation and Maintenance Manual”
of the e-SVE, VME, e-HME and e-SVIE pumps supplied with the product.

en – Original instructions
20
4 Installation
4.1 Mechanical installation
Also refer to the “Quick Startup Guide” and the “Installation, Operation and Maintenance Manual”
of the e-SVE, VME, e-HME and e-SVIE pumps supplied with the product.
4.1.1 Installation area
DANGER: Potentially explosive atmosphere hazard
The operation of the unit in environments with potentially explosive atmospheres or with
combustible dusts (e.g.: wood dust, flour, sugars and grains) is strictly forbidden.
WARNING:
•
Always wear personal protective equipment
•
Always use suitable working tools
•
When selecting the place of installation and connecting the unit to the hydraulic and electric
power supplies, strictly comply with current regulations.
•
Ensure that the input protection rating of the unit (IP 55, NEMA Type 1) is suitable for the
installation environment.
CAUTION:
•
Input protection: to ensure the IP55 (NEMA type 1) protection index make sure that the unit is
closed correctly.
•
Before opening the terminal box cover, make sure that there is no water in the unit
•
Make sure that all unused cable glands and cable holes are correctly sealed
•
Make sure that the plastic cover is correctly closed
•Do not leave the terminal box without cover: risk of damage due to contamination.
4.1.2 Unit installation
•See the Quick Startup Guide instructions (code 001080128)
•Position the unit as shown in the figure.
•Install the unit according to the systems liquid flow
•The arrows on the pump body indicate the flow and the rotation direction
•The standard rotation direction is clockwise (looking at the fan cover)
•Always install a check valve on the discharge side
•Always install the pressure sensor on the discharge side, after the check valve.
