INSTRUCTION

MANUAL

FOR

HOTAIR 852D

DIGITAL - DISPLAY

SMD REWORK SYSTEM

- 1 -

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Specification

- 2 -

Usage

Suitable for desoldering of

SMD components

such as SOIC, CHIP, QFP,

PLCC, BGA etc.

On the 852D front

panel, you will find an air control knob (sets air flow speed), temperature control knob, a numerical value

LED display and a “REAL TEMP” button. To set the temperature, press and hold the red button while

adjusting the temperature control know until the desired temperature is displayed – then release. The LED

display will now show actual temperature of output air. When the indicator light flickers on, the heating

element is being warming up, going off denotes that the preset temperature has been reached.

Power Voltage 100-120 Vac 220-240 Vac

Power Consumption (Max) 550W 550W

Pump Diaphragm Pump

Capacity 23L / Min (Max.)

Hot Air Temperature 100

℃

-480

℃

Dimensions 187(W)*135(H)*245(D) mm

Operation Setup

1. Select the Nozzle that matches the size of the IC. Attach the nozzle when both the element and

the nozzle are cool and the unit is turned off and unplugged.

2. Loosen the screw on the nozzle. Attach nozzle.

IMPORTANT: Do not force the nozzle or pull on the edge of the nozzle with a pliers. Also, do not tighten

the set-screw too tightly.

Operating instructions

QFP De-soldering

1. Plug the power cord into the power supply.

After connection, the automatic blowing function will start sending air through the pipe, but the Heating

Element remains cool.

2. Turn the power switch on.

The power switch may be turned on at any time while the automatic blowing function is operating. Once

the power switch is turned on, the heating element will begin to warm up.

3. Adjust the air flow and temperature control knobs.

After adjusting the air flow and temperature control knob, wait for the

temperature to stabilize for a short period of time.

4. Melt the solder.

Hold the iron so that the nozzle is located directly over, but not touching the IC and allow the hot air to

melt the solder. Be careful not to touch the leads of the IC with the nozzle.

5. Remove the IC.

Once the solder has melted, remove the IC by lifting the plier.

6. Turn the power switch off.

After the power switch is turned off, an automatic blowing function begins sending cool air through the

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

- 3 -

pipe in order to cool both the heating element and the handle. So do not disconnect the plug during this

cooling process. In case you don’t use the unit for a long time, disconnect the plug.

Note: After turn off the power switch of 852D about one minute later, power is automatically shut

off.

7. Remove any remaining solder.

After removing the IC, remove remaining solder with a wick or desoldering tool.

Note: In case of SOP, PLCC, desolder it by using tweezers, etc.

QFP Soldering

1. Apply the solder paste.

Apply the proper quantity of solder paste and flux (preferably no-clean) and place install the SMD on the

PCB.

2. Preheat SMD.

3. Soldering

Heat the lead frame evenly.

4. Washing

When soldering is completed, wash the area with a defluxer.

Note: While there are many advantages Hot Air SMD rework, its is also possible to have defects such as

solder balls and solder bridges. We recommend you to closely inspect all soldering joints.

Precautions

1. Before attaching the nozzle, make sure that both the heating tube and the

nozzle are cool.

2. Caution High Temperature Operation

Do not use the 852D near ignitable gases, or other inflammable materials. Both the nozzle and the

heating air are extremely hot and can cause painful burns. Never touch the heater assembly or allow the

heated air to blow against your skin. Initially, the iron may emit white smoke, but this will soon dissipate.

3. After use, be sure to cool the unit.

After turning off the power switch, the unit will automatically blow cooling air through the pipe for a short

period of time .Do not disconnect the plug during this cooling process.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

- 4 -

4. Never drop or sharply joint the unit.

The pipe contains quartz glass, which can break if the unit is dropped or jolted sharply.

5. Do not disassemble the pump.

If the pump or other critical internal components become faulty, discontinue its use immediately.

Please return to your vendor or its authorized repairers for proper servicing.

6. Disconnect the plug when the unit is not in use.

When the power cord is connected into the power supply, the unit has a little flow of electricity; even the

Power Switch is in off position. So when you don’t use the unit for a long period of time, disconnect the

plug.

Replacing the Heating Element

1. Remove the screws, slide the tube

Remove the 3 screws, which secure the handle and slide the cord tubing.

2. Open the Handle.

Disconnect the ground wire sleeve and remove the outer tube assembly.

Inside the tube a quartz glass/heat insulation layer is installed. Do not

drop or damage it.

3. Remove the Heating Element.

Disconnect the terminals and remove the heating element.

4. Insert a new Heating Element.

Handle the new heating element with care and do not touch the wire leads. Insert a new heating element

and reconnect the terminals. Reconnect the ground wire after replacing the element. Assemble the handle

in the reverse order of disassembly. .
