C4FM/FM 144/430 MHz
Dual Band Digital Transceiver
FT3DR/FT3DE
Introduction
This manual provides the technical information necessary for
servicing the FT3DR/FT3DE 144/430 MHz Dual Band Digital
Transceiver.
Servicing this equipment requires expertise in handing surface-
mount chip components. Attempts by non-qualified persons
to service this equipment may result in permanent damage not
covered by the warranty, and may be illegal in some countries.
While we believe the information in this manual to be correct,
YAESU assumes no liability for damage that may occur as a
result of typographical or other errors that may be present. Your
cooperation in pointing out any inconsistencies in the technical
information would be appreciated.
Contents
TECHNICAL SUPPLEMENT
EH072M90B
©2019 YAESU MUSEN CO., LTD.
Important Note
This transceiver was assembled using Pb (lead) free sol-
der, based on the RoHS specication.
Only lead-free solder (Alloy Composition: Sn-3.0Ag-0.5Cu)
should be used for repairs performed on this apparatus.
The solder stated above utilizes the alloy composition re-
quired for compliance with the lead-free specication, and
any solder with the above alloy composition may be used.

FT3DR/FT3DE Technical Supplement
Specications
SPECIFICATIONS-1
General
Frequency Range:
A Band RX
0.5 - 999.995 MHz
B Band RX
108 - 580 MHz
TX
144 - 148 MHz
430 - 440 MHz
Channel Spacing: 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 50, 100 kHz
(8.33 kHz: only for Air Band, 9 kHz: only for AM Radio)
Frequency Stability: ±2.5 ppm (–20 °C to +60 °C)
Emission Type: F1D, F2D, F3E, F7W
Supply Voltage: Nominal: 7.2 V DC, Negative Ground SBR-14LI
Nominal: 7.4 V DC, Negative Ground FNB-101LI
Operating: 4-14V,NegativeGround(BaeryConnect)
11 - 16 V, Negative Ground (EXT DC JACK, Charging)
Current Consumption: 140mA(MonobandReceive)
180mA(DualbandReceive)
86mA(MonobandReceive,Standby)
120mA(DualbandReceive,Standby)
67mA(MonobandReceive,Standby,SaverOn“SaveRatio1:10”)
67mA(DualbandReceive,Standby,SaverOn“SaveRatio1:10”)
+18 mA (GPS On)
+6 mA (Digital)
120 mA (AM/FM Radio)
900 μA(AutoPowerO)
1.6 A (5 W TX, 144 MHz 7.4 V DC)
1.9 A (5 W TX, 430 MHz 7.4 V DC)
Operating Temperature: –20 °C to +60 °C
Case Size (W x H x D): 62 x 100 x 32.5 mm
 (withSBR-14LI,w/oknob,antennaandbeltclip)
Weight: 282 g (with SBR-14LI and Antenna)
Transmier
RF Power Output: 5 W (@ 13.8 V or SBR-14LI)
(MID3: 2.5 W/LOW2: 1.0 W/LOW1: 0.3 W)
0.9 W (FBA-39)
(LOW1: 0.3 W)
Modulation Type: F1D,F2D,F3E:VariableReactancemodulation
F7W: 4 FSK (C4FM)
Spurious Emission: USA/EXP version
At least 60 dB below (@TX Power HI, LOW3)
At least 50 dB below (@TX Power LOW2, LOW1)

FT3DR/FT3DE Technical Supplement
Specications
SPECIFICATIONS-2
Receiver
Circuit Type: Double-Conversion Super heterodyne (FM, AM)
 Direct-Conversion (AM/FM Radio)
Intermodiate Frequencies: 1 st: A-Band 58.05 MHz
1 st: B-Band 57.15 MHz
2 nd: A-Band, B-Band 450 kHz
Sensitivity: 3 μV for 10 dB SN (0.5 - 30 MHz, @AM)*
0.35 μV TYP for 12 dB SINAD (30 - 54 MHz, @NFM)*
1 μV TYP for 12 dB SINAD (54 - 76 MHz, @NFM)*
1.5 μV TYP for 12 dB SINAD (76 - 108 MHz, @WFM)*
1.5 μV TYP for 10 dB SN (108 - 137 MHz, @AM)
0.2 μV for 12 dB SINAD (137 - 140 MHz, @NFM)
0.16 μV for 12 dB SINAD (140 - 150 MHz, @NFM)
0.2 μV for 12 dB SINAD (150 - 174 MHz, @NFM)
1 μV for 12 dB SINAD (174 - 222 MHz, @NFM)
0.5 μV for 12 dB SINAD (222 - 225 MHz, @NFM)
0.5 μV for 12 dB SINAD (300 - 350 MHz, @NFM)
0.2 μV for 12 dB SINAD (350 - 400 MHz, @NFM)
0.18 μV for 12 dB SINAD (400 - 470 MHz, @NFM)
1.5 μV for 12 dB SINAD (470 - 580 MHz, @NFM)
3 μV TYP for 12 dB SINAD (580 - 800 MHz, @NFM)*
1.5 μV TYP for 12 dB SINAD (800 - 999.995 MHz, @NFM)*
0.19 μV TYP for BER 1 % (Digital Mode)
* A-Band only
Selectivity: NFM, AM 12 kHz / 35 kHz (–6 dB / –60 dB)
AF Output: 700 mW (16 Ωfor 10 % THD 7.4 V) internal speaker
300 mW (8 Ωfor 10 % THD 7.4 V) external speaker
Bluetooth
Version: Version 4.2
Class: Class 2
Output Power: 2 dBm typ
Specications are subject to change without notice, and are guaranteed within the 144/430 MHz amateur
bands only.

EXPLODED VIEW-1 FT3DR/FT3DE Technical Supplement
Exploded View & Miscellaneous Parts
REF. YAESU P/N Description Qty.
①U9900277 PAN HEAD TAPTITE-B M2X3 #3 3KA 15 (Lot. 1-3)
20 (Lot. 4-)
②U9900004 PAN HEAD TAPTITE-B M2X4 4
③U07230102 PAN HEAD SCREW M2X3NI #1 6 (Lot. 1-3)
1 (Lot. 4-)
④U24114020 BIND HEAD TAPTITE-B M2X14SUS 4
⑤RA1084800 WASHER 4.3X2.0 4
⑥U9900300 TAPPING SCREW M2X4(3KA) 2
⑦RA6024200 SPECIAL SCREW(M1.4X4) 4
⑧U9900293 SPECIAL TAPTITE-B 2X3.5B(CAP) 2
Non-designated parts are available only as part of a designated assembly.
②
④
⑦
⑧
⑤
⑥
①
①
①
②
②
②
Q7000686
GPS MODULE
⑥
⑦
⑧
RA6267300
DOUBLE FACE(GPS)
CABLE-UNIT
Q9001004
ROTARY ENCODER
Q7000686
CAPTON TAPE(GPS)
RA6267300
DOUBLE FACE(GPS)
RA6055400
HOLDER(GPS)
①
①①
①①
①
①
①
①
①
①
①
①
①
①
③
RA624710A (Lot. 1-3)
RA624710B (Lot. 4-5)
RA624710C (Lot. 6-)
CHASSIS
RA6240100
SMA CONNECTOR
①
①
RA1037400
O RING (4.8X1.9)
RA1012800
PACKING PAD (POW)
RA6038800
MIC HOLDER RUBBER
M3290060
MICROPHONE ELEMENT
RA6295900
SPONGE RUBBER(MIC)
RA6248400
DOUBLE FACE (FRAME)
Q7000954
LCD MODULE
S5000228
SPRING CONECTOR
RA6270100
SPONGE RUBBER
RA6274100
SHEET (24X24)
RA6269900
SPONGE RUBBER
RA6247400
SPACER(SD)
RA6246500
HOLDER(PTT)
RA6246400
RUBBER(PTT)
RA625580A
FRONT CASE ASSY
w/ SP NET
RA6246300
SHEET(NAME)
RA6034900
SHEET
RA6251400
MASK SHEET (TOP)
RA6246600
RUBBER(KEY)
RA6247000
DOUBLE FACE(LCD)
RA624690B
PACKING PAD(LCD)
RA602280A
DOUBLE FACE(SP)
RA6022900
PLATE(SP)
RA604310A
SPACER(SP)
RA6022600
GASKET (SP)
M4090250
SPEAKER
④
④
④
⑤
⑤
⑤
⑦
⑦
RA1576700
BELT CLIP
RA0111300
KICK SPRING
RARA1236700
SHAFT
RA1584900
BASE (CLIP)
RA6247300
PACKING PAD(CASE)
RA6248100
SPACER(MICSP)
RA6247900
NUT(ANT)
RA6248000
RING(ANT)
RA6247800
NUT(VOL)
RA6124800
PACKING PAD(VOL)
RA6247700
KNOB(B)
RA6247500
KNOB ASSY (A)
RA6246800
COVER(DC)
RA6246700
COVER(DATA)
RA6023600
CAP(SW)
RA6247200
MASK SHEET(REAR)
RA6044100
SHEET
CQ0994001
FRONT CASE ASSY
CS2606702 (USA)
CS2606703 (EU)
CS2606704 (EXP)
CNTL-1 ASSY
CQ0992001
GPS ASSY
CS2610101
CHASSIS ASSY
CS2602702 (USA)
CS2602703 (EU)
CS2602704 (EXP)
RF-1 ASSY
RF-UNIT
CNTL-UNIT
FR203290C
Printed Circuit Board

BLOCK DIAGRAM-1 FT3DR/FT3DE Technical Supplement
Block Diagram

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-1
Introduction and Precautions
TheFT3DR/FT3DEhasbeencarefullyalignedat
thefactoryforperformanceacrossthespecified
amateur bands. Realignment should therefore
notbe necessaryexceptintheeventofacompo-
nentfailure.Allcomponentreplacement andser-
viceshouldbeperformedonlybyanauthorized
YAESUrepresentative,orthewarrantypolicymay
be voided.
Thefollowingprocedurescoverthesometimescrit-
icalandtediousadjustmentsthatarenotnormally
requiredoncethetransceiverhasleft the factory.
However,ifdamageoccursandsomepartsarere-
placed,realignment may be required. If a sudden
problemoccursduringnormaloperation,itislike-
lyduetocomponentfailure;realignmentshould
notbedoneuntilafterthefaultycomponenthas
beenreplaced.
Werecommend that servicingbeperformedonly
byauthorizedYAESUservicetechnicians,whoare
experiencedwiththecircuitryand fully equipped
for repair and alignment. Therefore, if a fault is
suspected,contactthedealerfromwhomthetrans-
ceiverwaspurchasedforinstructionsregardingre-
pair.AuthorizedYAESUservicetechniciansrealign
allcircuitsandmakecompleteperformancechecks
toensurecompliancewithfactoryspecifications
afterreplacinganyfaultycomponents.
Those who do undertake any of the following
alignmentsare cautionedto proceedat theirown
risk.Problemscausedbyunauthorizedaemptsat
realignmentare not coveredbythe warrantypol-
icy.Also,YAESUmustreservetherighttochange
circuitsandalignmentproceduresintheinterestof
improvedperformance,withoutnotifyingowners.
Underno circumstances should anyalignment be
attemptedunless the normalfunctionand opera-
tionof the transceiver areclearly understood, the
causeofthemalfunctionhasbeenclearlypinpoint-
edandanyfaultycomponentsreplaced,andthe
need for realignment determined to be absolutely
necessary.
Required Test Equipment
 RFSignalGeneratorwithcalibratedoutputlevel
at 500 MHz
 DeviationMeter(lineardetector)
 In-lineWameterwith5%accuracyat500MHz
50-ohm, 10-W RF Dummy Load
8-ohm AF Dummy Load
RegulatedDCPowerSupplyadjustablefrom
8 to 16 V DC, 3 A
FrequencyCounter:0.2-ppmaccuracyat
500 MHz
AF Signal Generator
AC Voltmeter
 DCVoltmeter:highimpedance
UHF Sampling Coupler
SINAD Meter
Alignment Preparation & Precautions
A 10-W RF dummy load and in-line wattmeter
mustbeconnectedtothemainantennajackinall
proceduresthatcallfortransmission;alignment
isnotpossiblewithanantenna.Aftercomplet-
ing one step, read the next step to see if the same
test equipment is required. If not, remove the test
equipment(exceptdummyloadandwattmeter,
ifconnected)beforeproceeding.Correctalign-
mentrequiresthetransceiverandtest equipment
bemaintainedat a constantambient temperature
between68~86°F (20~30 °C).When the transceiv-
erisbroughtintotheshopfromhotorcoldair,
itshouldbeallowedsometimetocometoroom
temperature before alignment. Whenever possible,
alignmentsshouldbemadewithoscillatorshields
andcircuitboardsrmlyaxedinplace.Also,the
test equipment must be thoroughly warmed up be-
fore beginning.
Note: Signal levels in dB referred to in the alignment
procedure are based on 0 dBμ=0.5 μV (closed circuit).
Important Notice
Donot adjust the alignmentmenus that are
not mentioned in this manual.

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-2
Internal System Alignment Routine
Thisusesaprogrammedroutineinthetransceiver
whichsimpliesmanypreviouslycomplexdiscrete
componentseings andadjustments withdigital-
ly-controlledsettingsvia front panelbuttonsand
LCDindications.
1. Tobegin,setthetransceiverto theVFOmode
on the "A-Band, FM-mode" and "B-Band, FM-
mode" in the "Mono" band mode.
2. Press the [A/B] key to set the A-band as the op-
erating band.
3. Press and hold the [A/B]key displays only the
operating band.
4. Program a password for the Alignment
(AH072M)accordingtothefollowingproce-
dure:
1) Press and hold the [DISP]keyforonesecond
to enter the Set mode.
2) Touch[DISPLAY]brieflytoenableadjust-
ment of this Set Mode Item.
3) Rotate the DIALknobtoselectSetModeItem
7: OPENING MESSAGE.
4) Press the [DISP]keybrieytoenableadjust-
ment of this Set Mode Item.
5) Rotate the DIALknobtoselectSetModeItem
MESSAGE.
6) Press the [DISP]keybrieytoenableadjust-
ment of this Set Mode Item.
7) Input the password "AH072M" (toggle the
alphabetinputscreen,andthenumberinput
screenwhennecessary).
8) Whenyouhavecompletedthepassword,
press the [DISP]key briefly, then press the
PTTswitchtoexittonormaloperation.
Note: Remember to delete the password "AH072M"
from the Set Mode Item 7: OPENING MESSAGE when
the alignment adjustments are nished by pressing and
holding in the [GM] key for two seconds (as in step 8
above).
5. Press the [PWR]switchforonesecondstoturn
thetransceiver"OFF".
6. Press and hold in the [GM]key while powering
thetransceiver"ON"again.Thetransceiverwill
entertheadjustmentmode,andthedisplay
willshow therst alignment seing. Thereaf-
ter,thefrequenciesusedduringalignmentwill
automaticallybesetwithoutactionbythetech-
nician.
Inthealignmentprocess,eachadjustmentisse-
lectedbyrotatingtheDIAL knob. The alignment
is performed by: pressing the [V/M]keyinjectinga
signaloftherequiredfrequencyandlevel;making
theadjustment;andthenpressingthe[V/M]key
again (the "Data" will disappear from the display),
tostoretheadjustment.
To exit the alignment routine, press the [GM]key.
After performing the system alignment in its en-
tirety,individualsettingscanbereturnedtoand
adjustedindividually,shouldtheneedarise.
Aseachtransceiverisindividuallyoptimizedat
thefactory,thepreciseseings for thetransceiver
onyourbenchmaybeslightlydierent.
PLL Reference Frequency Adjustment (PLL REF)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "PLL REF".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIALknobsothatthefrequencycounterseing
is 440.000 MHz (±100 Hz).
Release the PTTswitch,thenpressthe[V/M]
buon(the "Data"will disappear fromthe dis-
play).
Regulated
9.1 VDC P.S.
Sampling
Coupler
50-ohm RF
Dummy Load
In-Line
Wattmeter
Deviation
Meter
Frequency
Counter
Figure 1: TX Alignment Setup

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-3
A-Band 430 MHz Band Adjustment
ReceiverSensitivityAdjustment(TUNEDEV)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 435.100
MHz, at a level of -10.0 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIALknob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Regulated
9.1 VDC P.S.
SINAD
Meter
8-ohm
AF Load
RF Signal
Generator
AF Generator
Figure 2: RX Alignment Setup
SquelchThresholdAdjustment(THLDSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "THLD SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -11 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Threshold level
Press the [V/M]button (the "Data" will disap-
pear on the display).
TightSquelchAdjustment(TIGHSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterS-1Adjustment(S1LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterFull-ScaleAdjustment(S9LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-MeterFullScalelevel.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-4
TXPower(HI)Adjustment(HIPOWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "HI POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter reading is
5.0 W (±0.05 W).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
TXPower(L3)Adjustment(L3POWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "L3 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
2.5 W (±0.1 W).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
TXPower(L2)Adjustment(L2POWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "L2 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
0.85 W (+0.05/-0.1 W).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
TXPower(L1)Adjustment(L1POWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "L1 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
0.3 W (±0.05 W).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
DigitalTXDeviationAdjustment(DIGDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "DIG DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the [BAND]buttontoselectthe“PLL
REF”.
Press the PTTswitchtotransmitandrotatethe
DIALknobsothattheDeviationMeterseingis
4.5 kHz ± 0.1 kHz.
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
TXDeviationAdjustment(MAXDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "MAX DEV".
Set the AF Signal Generator output to 50 mVrms
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIALknobso thatthe Deviation Meterseing
is 4.2 kHz ± 0.05 kHz (USA version) or 4.5 kHz
± 0.05 kHz (EXP, EU versions).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-5
CTCSSTXDeviationAdjustment(TONEDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TONE DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitwithoutthe
microphoneinputandrotatetheDIAL knob so
thattheDeviationMeterseingis0.7kHz(±0.1
kHz).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
DCSTXDeviationAdjustment(DCSDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "DCS DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitwithoutthe
microphoneinputandrotatetheDIAL knob
so that the Deviation Meter setting is 0.7 kHz
(±0.1 kHz).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
A-Band 50 MHz Band Adjustment
Press the [BAND]key to select the50 MHzAma-
teur band.
Note: When the transceiver recalls Alignment Menu
"PLL REF", the [A/B]and [BAND] key operation is
ignored. In this case, rotate the DIAL knob to select an
Alignment Menu other than "PLL REF".
ReceiverSensitivityAdjustment(TUNEDEV)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 52.100
MHz, at a level of -8 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIALknob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
SquelchThresholdAdjustment(THLDSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "THLD SQL".
Set the RF Signal Generator output to 52.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestoreadtheSquelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-6
TightSquelchAdjustment(TIGHSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 52.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterS-1Adjustment(S1LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 52.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterFull-ScaleAdjustment(S9LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 52.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-MeterFullScalelevel.
Press the [V/M]button (the "Data" will disap-
pear on the display).
A-Band 144 MHz Band Adjustment
Press the [BAND]keytoselectthe144MHzAma-
teur band.
Note: When the transceiver recalls Alignment Menu
"PLL REF", the [A/B]and [BAND] key operation is
ignored. In this case, rotate the DIAL knob to select an
Alignment Menu other than "PLL REF".
ReceiverSensitivityAdjustment(TUNEDEV)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 145.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIALknob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
SquelchThresholdAdjustment(THLDSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "THLD SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -11 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-7
TightSquelchAdjustment(TIGHSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterS-1Adjustment(S1LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterFull-ScaleAdjustment(S9LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-MeterFullScalelevel.
Press the [V/M]button (the "Data" will disap-
pear on the display).
TXPower(HI)Adjustment(HIPOWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "HI POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
5.0 W (±0.05 W).
Release the PTTswitch,thenpressthe[V/M]
button (the "Data" will disappear on the dis-
play).
TXPower(L3)Adjustment(L3POWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "L3 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
2.5 W (±0.1 W).
Release the PTTswitch,thenpressthe[V/M]
button (the "Data" will disappear on the dis-
play).
TXPower(L2)Adjustment(L2POWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "L2 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
0.9 W (+0.05/-0.1 W).
Release the PTTswitch,thenpressthe[V/M]
button (the "Data" will disappear on the dis-
play).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-8
TXPower(L1)Adjustment(L1POWER)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "L1 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIAL knob so that the Power Meter setting is
0.3 W (±0.05 W).
Release the PTTswitch,thenpressthe[V/M]
button (the "Data" will disappear on the dis-
play).
DigitalTXDeviationAdjustment(DIGDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "DIG DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the [BAND]buttontoselectthe“DIG
DEV”.
Press the PTTswitchtotransmitandrotatethe
DIALknobsothattheDeviationMeterseingis
4.5 kHz ± 0.1 kHz.
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
TXDeviationAdjustment(MAXDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "MAX DEV".
Set the AF Signal Generator output to 50 mVrms
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitandrotatethe
DIALknobso thatthe Deviation Meterseing
is 4.2 kHz ± 0.05 kHz (USA version) or 4.5 kHz
± 0.05 kHz (EXP/EU versions).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
CTCSSTXDeviationAdjustment(TONEDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TONE DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitwithoutthe
microphoneinputandrotatetheDIAL knob so
thattheDeviationMeterseingis0.7kHz(±0.1
kHz).
Release the PTTswitch,andthenpressthe
[V/M]button (the "Data" will disappear on the
display).
DCSTXDeviationAdjustment(DCSDEV)
 ConnectthetestequipmentasshowninFigure1:
TX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "DCS DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTTswitchtotransmitwithoutthe
microphoneinputandrotatetheDIAL knob
so that the Deviation Meter setting is 0.7 kHz
(±0.1 kHz).
Release the PTTswitch,thenpressthe[V/M]
button (the "Data" will disappear on the dis-
play).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-9
B-Band 430 MHz Band Adjustment
NOTICE:DonottouchthefollowingAlignment
MenusinB-Band430MHzBandAdjustment:
"PLL REF "
"HI POWER"
"L3 POWER"
"L2 POWER"
"L1 POWER"
"MAX DEV"
"TONE DEV"
"DCS DEV"
Press the [A/B]key tochange theoperating band
to the "B-Band".
Press the [BAND]keytoselectthe430MHzAma-
teur band.
Note: When the transceiver recalls Alignment Menu
"PLL REF", the [A/B]and [BAND] key operation is
ignored. In this case, rotate the DIAL knob to select an
Alignment Menu other than "PLL REF".
ReceiverSensitivityAdjustment(TUNEDEV)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 435.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIALknob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
SquelchThresholdAdjustment(THLDSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "THLD SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -11 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
TightSquelchAdjustment(TIGHSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterS-1Adjustment(S1LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-10
FMS-MeterFull-ScaleAdjustment(S9LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-MeterFullScalelevel.
Press the [V/M]button (the "Data" will disap-
pear on the display).
B-Band 144 MHz Band Adjustment
NOTICE:DonottouchthefollowingAlignment
MenusinB-Band144MHzBandAdjustment:
"PLL REF"
"HI POWER"
"L3 POWER"
"L2 POWER"
"L1 POWER"
"MAX DEV"
"TONE DEV"
"DCS DEV"
Press the [BAND]keytoselectthe144MHzAma-
teur band.
Note:WhenthetransceiverrecallsAlignment
Menu "PLL REF", the [A/B]and [BAND]key oper-
ationisignored.Inthiscase,rotatetheDIAL knob
toselectanAlignmentMenuotherthan"PLL REF".
ReceiverSensitivityAdjustment(TUNEDEV)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 145.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIALknob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT3DR/DE Technical Supplement
Alignment
ALIGNMENT-11
SquelchThresholdAdjustment(THLDSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "THLD SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -11 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
TightSquelchAdjustment(TIGHSQL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]keytwotimestostoretheSquelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterS-1Adjustment(S1LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FMS-MeterFull-ScaleAdjustment(S9LEVEL)
 ConnectthetestequipmentasshowninFigure2:
RX Alignment Setup.
Rotate the DIALknobtoselecttheAlignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-MeterFullScalelevel.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Thiscompletestheinternalalignmentroutine
forallbands.Tosaveallsettingsandexit,touch
[WRITE].

FT3DR/FT3DE Technical Supplement
RF-1
Circuit Diagram
RF Unit (Lot. 1)

FT3DR/FT3DE Technical Supplement
RF-2
1
2
3
4
5
ABC
1
2
3
4
5
abc
Parts Layout
Side A Side B
RF Unit (Lot. 1)

FT3DR/FT3DE Technical Supplement
RF-3
Circuit Diagram
RF Unit (Lot. 2 - 3)

FT3DR/FT3DE Technical Supplement
RF-4
1
2
3
4
5
ABC
1
2
3
4
5
abc
Parts Layout
RF Unit (Lot. 2 - 3)
Side A Side B
