Yamaha 115 User manual

115
OWNER’S MANUAL
6N6-28199-1G
U.S.A.Edition
LIT-18626-07-84
6N6-9-1GHyoshi08.9.34:07PMページ1
©2019 Yamaha Motor Corporation, U.S.A.

EMU25061
ZMU01690
Read this owner’s manual carefully before operating or working on your
outboard motor. Keep this manual onboard in a waterproof bag when
boating. This manual should stay with the outboard motor if it is sold.
6N6-9-1GHyoshi08.9.34:07PMページ2
©2019 Yamaha Motor Corporation, U.S.A.

Important manual information
EMU31281
To the owner
Thank you for choosing a Yamaha outboard
motor. This Owner’s Manual contains infor-
mation needed for proper operation, mainte-
nance and care. A thorough understanding
of these simple instructions will help you ob-
tain maximum enjoyment from your new
Yamaha. If you have any question about the
operation or maintenance of your outboard
motor, please consult a Yamaha dealer.
In this Owner’s Manual particularly important
information is distinguished in the following
ways.
The Safety Alert Symbol means
ATTENTION! BECOME ALERT! YOUR
SAFETY IS INVOLVED!
WARNING
EWM00780
Failure to follow WARNING instructions
could result in severe injury or death to
the machine operator, a bystander, or a
person inspecting or repairing the out-
board motor.
CAUTION:
ECM00700
A CAUTION indicates special precautions
that must be taken to avoid damage to the
outboard motor.
NOTE:
A NOTE provides key information to make
procedures easier or clearer.
Yamaha continually seeks advancements in
product design and quality. Therefore, while
this manual contains the most current prod-
uct information available at the time of print-
ing, there may be minor discrepancies
between your machine and this manual. If
there is any question concerning this manu-
al, please consult your Yamaha dealer.
NOTE:
The 115TR and the standard accessories
are used as a base for the explanations and
illustrations in this manual. Therefore some
items may not apply to every model.
EMU25111
115
OWNER’S MANUAL
©2007 by Yamaha Motor Corporation, USA
1st edition, March 2008
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, USA
is expressly prohibited.
Printed in Japan
P/N LIT-18626-07-84
✩✩✬✤✳✤✲✣ ✤  
©2019 Yamaha Motor Corporation, U.S.A.

Table of contents
General information .......................... 1
Identification numbers record.......... 1
Outboard motor serial number .......... 1
Key number....................................... 1
Emission control information ........... 1
North American models..................... 1
Important labels............................... 2
Warning labels .................................. 2
Safety information............................. 4
Safety information ........................... 4
Rotating parts.................................... 4
Hot parts ........................................... 4
Electric shock.................................... 4
Power trim and tilt ............................. 4
Engine shut-off cord.......................... 4
Gasoline............................................ 4
Gasoline exposure and spills ............ 4
Carbon monoxide.............................. 5
Modifications ..................................... 5
Boating safety ................................. 5
Alcohol and drugs ............................. 5
Personal flotation devices ................. 5
People in the water ........................... 5
Passengers ....................................... 5
Overloading....................................... 5
Avoid collisions ................................. 5
Weather ............................................ 6
Accident reporting ............................. 6
Boat education and training .............. 6
Passenger training ............................ 6
Boating safety publications ............... 6
Laws and regulations ........................ 6
Boating organizations...................... 7
Basic boating rules (Rules of the
road) .............................................. 7
Steering and sailing rules and
sound signals.................................. 7
Rules when encountering vessels .... 8
Other special situations..................... 9
Basic requirements ......................... 12
Fueling instructions ....................... 12
Gasoline.......................................... 12
Engine oil ........................................ 12
Installation requirements ............... 13
Boat horsepower rating................... 13
Mounting motor ............................... 13
Remote control requirements.......... 13
Battery requirement......................... 13
Propeller selection........................... 13
Start-in-gear protection ................. 14
Basic components .......................... 15
Main components ......................... 15
Remote control ................................ 15
Remote control lever ....................... 16
Neutral interlock trigger ................... 16
Neutral throttle lever........................ 16
Choke switch ................................... 17
Throttle friction adjuster...................17
Engine shut-off switch ..................... 17
Choke knob for pull type .................18
Main switch ..................................... 18
Power trim and tilt switch on
remote control or tiller handle .......18
Power trim and tilt switch on bottom
engine cowling .............................. 19
Trim tab with anode.........................19
Tilt support lever for power trim
and tilt model................................. 20
Top cowling release lever ...............20
Flushing device ............................... 21
Tachometer ..................................... 21
Digital tachometer ........................... 21
Oil level indicators (three
indicators 2) .................................. 22
Oil level indicator (digital type) ........ 22
Overheat-warning indicator (digital
type) .............................................. 22
Speedometer (digital type) .............. 23
Trim meter ....................................... 23
Trim meter (digital type) .................. 24
Hour meter (digital type).................. 24
Trip meter ........................................ 24
Clock ............................................... 25
Fuel gauge ...................................... 25
Fuel warning indicator ..................... 25
Low battery voltage-warning
indicator ........................................ 26
Warning system ............................ 26
Overheat warning ............................ 26
Oil level warning and oil filter
✩✩✬✤✳✤✲✣ ✤  
©2019 Yamaha Motor Corporation, U.S.A.

Table of contents
clogging warning........................... 27
Operation ......................................... 29
Installation ..................................... 29
Mounting the outboard motor.......... 29
Breaking in engine ........................ 30
Gasoline and engine oil mixing
chart (50:1) ................................... 30
Procedure for oil injection models... 30
Pre-operation checks .................... 31
Fuel ................................................. 31
Oil.................................................... 31
Controls........................................... 31
Stop switches.................................. 31
Engine............................................. 31
Operation after a long period of
storage.......................................... 31
Filling fuel and engine oil............... 32
Filling fuel for models without a
fuel joint ........................................ 32
Ring Free Fuel Additive .................. 32
Filling oil .......................................... 32
Oil level indicator operation............. 34
Operating engine........................... 35
Feeding fuel .................................... 35
Starting engine................................ 35
Warming up engine ....................... 37
Choke start models ......................... 37
Shifting .......................................... 37
Stopping boat ................................ 38
Stopping engine ............................ 39
Procedure ....................................... 39
Trimming outboard motor.............. 39
Adjusting trim angle (Power trim
and tilt) .......................................... 40
Adjusting boat trim .......................... 40
Tilting up and down ....................... 41
Procedure for tilting up (power trim
and tilt models) ............................. 42
Procedure for tilting down (power
trim and tilt models) ...................... 43
Cruising in shallow water .............. 43
Power trim and tilt models............... 43
Cruising in other conditions........... 44
Maintenance..................................... 45
Specifications ................................ 45
Transporting and storing outboard
motor ........................................... 46
Storing outboard motor ...................46
Procedure........................................ 47
Lubrication (oil injection models)..... 48
Cleaning and anticorrosion
measures ...................................... 48
Battery care ..................................... 48
Flushing power unit ......................... 49
Cleaning the outboard motor........... 50
Checking painted surface of
motor............................................. 50
Periodic maintenance ................... 50
Replacement parts .......................... 50
Maintenance chart........................... 51
Greasing.......................................... 53
Cleaning and adjusting spark
plug ............................................... 53
Checking fuel system ...................... 54
Inspecting fuel filter .........................55
Cleaning fuel filter ...........................55
Inspecting idling speed.................... 56
Checking water in engine oil tank ...56
Checking wiring and connectors .....56
Exhaust leakage.............................. 56
Water leakage ................................. 57
Checking power trim and tilt
system........................................... 57
Checking propeller .......................... 58
Removing propeller ......................... 59
Installing propeller ........................... 59
Changing gear oil ............................ 59
Inspecting and replacing
anode(s)........................................ 60
Checking battery (for electric start
models) ......................................... 61
Connecting the battery .................... 62
Disconnecting the battery................ 62
Checking top cowling ......................62
Coating the boat bottom.................. 63
Trouble Recovery............................ 64
Troubleshooting ............................ 64
Temporary action in emergency ... 67
Impact damage ............................... 67
Replacing fuse ................................ 67
✩✩✬✤✳✤✲✣ ✥  
©2019 Yamaha Motor Corporation, U.S.A.

Table of contents
Power trim and tilt will not
operate.......................................... 68
Starter will not operate .................... 68
Emergency starting engine ............. 69
Engine fails to operate .................. 70
Low oil level warning activates........ 70
Top cowling does not unlock......... 71
Treatment of submerged motor..... 71
Procedure ....................................... 71
Consumer information.................... 73
Important warranty information for
U.S.A. and Canada ..................... 73
YAMAHA MOTOR
CORPORATION, U.S.A.
OUTBOARD MOTOR TWO
YEAR LIMITED WARRANTY ...... 75
IMPORTANT WARRANTY
INFORMATION IF YOU USE
YOUR YAMAHA OUTSIDE THE
USA OR CANADA ...................... 78
✩✩✬✤✳✤✲✣ ✦  
©2019 Yamaha Motor Corporation, U.S.A.

1
General information
EMU25170
Identification numbers record
EMU25183
Outboard motor serial number
The outboard motor serial number is
stamped on the label attached to the port
side of the clamp bracket.
Record your outboard motor serial number in
the spaces provided to assist you in ordering
spare parts from your Yamaha dealer or for
reference in case your outboard motor is sto-
len.
EMU25190
Key number
If a main key switch is equipped with the mo-
tor, the key identification number is stamped
on your key as shown in the illustration.
Record this number in the space provided for
reference in case you need a new key.
EMU25221
Emission control information
EMU25230
North American models
This engine conforms to U.S. Environmental
Protection Agency (EPA) regulations for ma-
rine SI engines. See the label affixed to your
engine for details.
EMU30390
Approval label of emission control certif-
icate
This label is attached to the bottom cowling.
Existing Technology; N/A
1. Outboard motor serial number location
1. Key number
1. Approval label location
1
ZMU04619
✩✩✬✤✳✤✲✣ ✤  
©2019 Yamaha Motor Corporation, U.S.A.

General information
2
EMU25262
Manufactured date label
This label is attached to the clamp bracket or
the swivel bracket.
EMU25382
Important labels
EMU25395
Warning labels
EMU25401
Label
WARNING
EWM01260
● Be sure shift control is in neutral before
starting engine. (except 2HP)
●
Do not touch or remove electrical parts
when starting or during operation.
●
Keep hands, hair, and clothes away
from flywheel and other rotating parts
while engine is running.
EMU25451
Label
ENGINE OIL ONLY
●
Pour the engine oil into this oil tank, not
gasoline.
RECOMMENDED OIL:
1. Manufactured date label location
EMISSION CONTROL INFORMATION
ENGINE FAMILY :
THIS ENGINE CONFORMS TO 2001 U.S. EPA REGULATIONS FOR MARINE SI ENGINES.
REFER TO THE OWNERS MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.
FELs :
SPARK PLUG :
DISPLACEMENT :
ADVERTISED POWER :
IDLE SPEED :
SPARK PLUG GAP (mm) :
FUEL : GASOLINE
VALVE LASH (mm) : IN : N/A EX : N/A
cm
kW
g/kW-hr rpm IN NEUTRAL
3
ZMU05230
1
ZMU04618
ZMU04620
ZMU01948
✩✩✬✤✳✤✲✣ ✥  
©2019 Yamaha Motor Corporation, U.S.A.

General information
3
YAMALUBE 2 STROKE OUTBOARD OIL or
an equivalent TC-W3 certified ouboard oil.
WARNING
EWM01270
Do not add gasoline to the oil tank. Fire
explosion could result.
✩✩✬✤✳✤✲✣ ✦  
©2019 Yamaha Motor Corporation, U.S.A.

4
Safety information
EMU33620
Safety information
Observe these precautions at all times.
EMU33630
Rotating parts
Hands, feet, hair, jewelry, clothing, PFD
straps, etc. can become entangled with inter-
nal rotating parts of the engine, resulting in
serious injury or death.
Keep the top cowling in place whenever pos-
sible. Do not remove or replace the cowling
with the engine running.
Only operate the engine with the cowling re-
moved according to the specific instructions
in the manual. Keep hands, feet, hair, jewel-
ry, clothing, PFD straps, etc. away from any
exposed moving parts.
EMU33640
Hot parts
During and after operation, engine parts are
hot enough to cause burns. Avoid touching
any parts under the top cowling until the en-
gine has cooled.
EMU33650
Electric shock
Do not touch any electrical parts while start-
ing or operating the engine. They can cause
shock or electrocution.
EMU33660
Power trim and tilt
Body parts can be crushed between the mo-
tor and the clamp bracket when the motor is
trimmed or tilted. Keep body parts out of this
area at all times. Be sure no one is in this
area before operating the power trim and tilt
mechanism.
The power trim and tilt switches operate
even when the main switch is off. Keep peo-
ple be away from the switches whenever
working around the motor.
Never get under the lower unit while it is tilt-
ed, even when the tilt support lever is locked.
Severe injury could occur if the outboard mo-
tor accidentally falls.
EMU33670
Engine shut-off cord
Attach the engine shut-off cord so that the
engine stops if the operator falls overboard
or leaves the helm. This prevents the boat
from running away under power and leaving
people stranded, or running over people or
objects.
Always attach the engine shut-off cord to a
secure place on your clothing or your arm or
leg while operating. Do not remove it to leave
the helm while the boat is moving. Do not at-
tach the cord to clothing that could tear
loose, or route the cord where it could be-
come entangled, preventing it from function-
ing.
Do not route the cord where it is likely to be
accidentally pulled out. If the cord is pulled
during operation, the engine will shut off and
you will lose most steering control. The boat
could slow rapidly, throwing people and ob-
jects forward.
EMU33810
Gasoline
Gasoline and its vapors are highly flam-
mable and explosive. Always, refuel ac-
cording to the procedure on page 35 to
reduce the risk of fire and explosion.
EMU33820
Gasoline exposure and spills
Take care not to spill gasoline. If gasoline
spills, wipe it up immediately with dry rags.
Dispose of rags properly.
If any gasoline spills onto your skin, immedi-
ately wash with soap and water. Change
clothing if gasoline spills on it.
If you swallow gasoline, inhale a lot of gaso-
line vapor, or get gasoline in your eyes, get
immediate medical attention. Never siphon
fuel by mouth.
✩✩✬✤✳✤✲✣ ✧  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
5
EMU33900
Carbon monoxide
This product emits exhaust gases which
contain carbon monoxide, a colorless, odor-
less gas which may cause brain damage or
death when inhaled. Symptoms include nau-
sea, dizziness, and drowsiness. Keep cock-
pit and cabin areas well ventilated. Avoid
blocking exhaust outlets.
EMU33780
Modifications
Do not attempt to modify this outboard mo-
tor. Modifications to your outboard motor
may reduce safety and reliability, and render
the outboard unsafe or illegal to use.
EMU33740
Boating safety
This section includes a few of the many im-
portant safety precautions that you should
follow when boating.
EMU33710
Alcohol and drugs
Never operate after drinking alcohol or tak-
ing drugs. Intoxication is one of the most
common factors contributing to boating fatal-
ities.
EMU33720
Personal flotation devices
Have an approved personal flotation device
(PFD) on board for every occupant. Yamaha
recommends that you must wear a PFD
whenever boating. At a minimum, children
and non-swimmers should always wear
PFDs, and everyone should wear PFDs
when there are potentially hazardous boat-
ing conditions.
EMU33730
People in the water
Always watch carefully for people in the wa-
ter, such as swimmers, skiers, or divers,
whenever the engine is running. When
someone is in the water near the boat, shift
into neutral and shut off the motor.
Stay away from swimming areas. Swimmers
can be hard to see.
The propeller can keep moving even when
the motor is in neutral. Shut off the engine
when a person is in the water near you.
EMU33750
Passengers
Consult your boat manufacturer’s instruc-
tions for details about appropriate passenger
locations in your boat and be sure all pas-
sengers are positioned properly before ac-
celerating and when operating above an idle
speed. Standing or sitting in non-designated
locations may result in being thrown either
overboard or within the boat due to waves,
wakes, or sudden changes in speed or direc-
tion. Even when people are positioned prop-
erly, alert your passengers if you must make
any unusual maneuver. Always avoid jump-
ing waves or wakes.
EMU33760
Overloading
Do not overload the boat. Consult the boat
capacity plate or boat manufacturer for max-
imum weight and number of passengers. Be
sure that weight is properly distributed ac-
cording to the boat manufacturers instruc-
tions. Overloading or incorrect weight
distribution can compromise the boats han-
dling and lead to an accident, capsizing or
swamping.
EMU33770
Avoid collisions
Scan constantly for people, objects, and
other boats. Be alert for conditions that limit
your visibility or block your vision of others.
Operate defensively at safe speeds and
keep a safe distance away from people, ob-
jects, and other boats.
●
Do not follow directly behind other boats or
waterskiers.
✩✩✬✤✳✤✲✣  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
6
●
Avoid sharp turns or other maneuvers that
make it hard for others to avoid you or un-
derstand where you are going.
●
Avoid areas with submerged objects or
shallow water.
●
Ride within your limits and avoid aggres-
sive maneuvers to reduce the risk of loss
of control, ejection, and collision.
●
Take early action to avoid collisions. Re-
member, boats do not have brakes , and
stopping the engine or reducing throttle
can reduce the ability to steer. If you are
not sure that you can stop in time before
hitting an obstacle, apply throttle and turn
in another direction.
EMU33790
Weather
Stay informed about the weather. Check
weather forecasts before boating. Avoid
boating in hazardous weather.
EMU33800
Accident reporting
Boat operators are required by law to file a
Boating Accident Report with their state
boating law enforcement agency if their boat
is involved in any of the following accidents:
1. There is loss of life or probable loss of
life.
2. There is personal injury that requires
medical attention beyond first aid.
3. There is property damage to boats or
other property over a certain amount.
4. There is complete loss of a boat.
Contact local law enforcement personnel if a
report is necessary.
EMU33870
Boat education and training
Operators should take a boating safety
course. This may be required in your state.
Many of the organizations listed in the next
section can provide information about cours-
es in your area.
You may also want to consider an Internet-
based program for basic boater education.
The Online Boating Safety Course provided
by the BoatU.S. Foundation, is approved by
the National Association of State Boating
Law Administrators (NASBLA) and recog-
nized by the United States Coast Guard.
Most, but not all, states accept this course to
meet their minimum requirements. While it
cannot replace an in-depth course such as
one offered by the U.S. Coast Guard, U.S.
Power Squadron, or other organization, this
online course does provide a general over-
view of the basics in boating safety, require-
ments, navigation, and operation. Upon
successful completion of the course, the
user can download a certificate of comple-
tion immediately or, for a small charge, re-
quest one by mail. To take this free course,
go to boatus.org.
EMU33880
Passenger training
Make sure at least one other passenger is
trained to operate the boat in the event of an
emergency.
EMU33890
Boating safety publications
Be informed about boating safety. Additional
publications and information can be obtained
from many boating organizations.
EMU33590
Laws and regulations
Know the marine laws and regulations where
you will be boating- and obey them. Several
sets of rules prevail according to geographic
location, but all are basically the same as the
International Rules of the Road. The rules
presented in the following section are con-
densed- and have been provided for your
convenience only.
Contact the U.S. Coast Guard, the National
Association of State Boating Law Adminis-
✩✩✬✤✳✤✲✣ ✩  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
7
trators, or your local Power Squadron for a
complete set of rules governing the waters in
which you will be using your boat.
EMU33680
Boating organizations
The following organizations provide boating
safety training and information about boating
safety and laws.
United States Coast Guard
Consumer Affairs Staff (G-BC)
Office of Boating, Public, and Consumer Af-
fairs
U.S. Coast Guard Headquarters
Washington, D.C. 20593-0001
Boating Safety Hotline: [phone]
www.uscgboating.org
United States Power Squadrons
1-888-FOR-USPS (1-888-367-8777)
www.usps.org
Boat Owners Association of The United
States
1-800-336-BOAT (1-800-336-2628)
www.boatus.com
National Association of State Boating
Law Administrators (NASBLA)
1500 Leestown Road, Suite 330
Lexington, KY 4051 859-225-9497
859-225-9497
www.nasbla.org
National Marine Manufacturers Associa-
tion (NMMA)
200 East Randolph Drive
Suite 5100
Chicago, IL 606001
www.nmma.org
Marine Retailers Association of America
155 N. Michigan Ave. Chicago,
IL 60601
www.mraa.com
EMU33690
Basic boating rules (Rules of
the road)
Just as there are rules that apply when you
are driving on streets and highways, there
are waterway rules that apply when you are
driving your boat. These rules are used inter-
nationally. (For USA: and are also enforced
by the United States Coast Guard and local
agencies.) You should be aware of these
rules, and follow them whenever you en-
counter another vessel on the water.
EMU33700
Steering and sailing rules and sound
signals
Whenever two vessels on the water meet
one another, one vessel has the right-of-
way; it is called the “stand-on”vessel. The
vessel that does not have the right-of-way is
called the “give-way”or “burdened”vessel.
These rules determine which vessel has the
right-of-way, and what each vessel should
do.
Stand-on vessel
The vessel with the right-of-way has the duty
to continue its course and speed, except to
avoid an immediate collision. When you
maintain your direction and speed, the other
vessel will be able to determine how best to
avoid you.
Give-way vessel
The vessel that does not have the right-of-
way has the duty to take positive and timely
action to stay out of the way of the Stand-On
✩✩✬✤✳✤✲✣ ✪  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
8
vessel. Normally, you should not cross in
front of the vessel with the right-of-way. You
should slow down or change directions brief-
ly and pass behind the other vessel. You
should always move in such a way that the
operator of the other vessel can see what
you are doing.
“The general prudential rule ”
This rule is called Rule 2 in the International
Rules and says,
“In obeying and construing these rules due
regard shall be had to all dangers of naviga-
tion and collision, and to any special circum-
stances, which may render a departure from
the above rules necessary in order to avoid
immediate danger.”
In other words, follow the standard rules ex-
cept when a collision will occur unless both
vessels try to avoid each other. If that is the
case, both vessels become “Give-Way ”
vessels.
EMU25521
Rules when encountering vessels
There are three main situations that you may
encounter with other vessels which could
lead to a collision unless the Steering Rules
are followed:
Meeting: (you are approaching another ves-
sel head-on)
Crossing: (you are traveling across the oth-
er vessel’s path)
Overtaking: (you are passing or being
passed by another vessel)
In the following illustration, your boat is in the
center. You should give the right-of-way to
any vessels shown in white area (you are the
Give-Way vessel). Any vessels in the shad-
ed area must yield to you (they are the Give-
Way vessels). Both you and the meeting
vessel must alter course to avoid each other.
Meeting
If you are meeting another power vessel
head on, and are close enough to run the risk
of collision, neither of you has the right-of-
way Both of you should alter course to avoid
an accident. You should keep the other ves-
sel on your port (left) side. This rule doesn’t
apply if both of you will clear one another if
you continue on your set course and speed.
Crossing
When two power driven vessels are crossing
each other’s path close enough to run the
risk of collision, the vessel which has the oth-
er on the starboard (right) side must keep out
of the way of the other. If the other vessel is
on your right, you must keep out of its way;
you are the Give-Way vessel. If the other
vessel is on your port (left) side, remember
that you should maintain course and direc-
tion, provided the other vessel gives you the
right-of-way as it should.
✩✩✬✤✳✤✲✣ ✫  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
9
Overtaking
If you are passing another vessel, you are
the “Give-Way”vessel. This means that the
other vessel is expected to maintain its
course and speed. You must stay out of its
way until you are clear of it. Likewise, if an-
other vessel is passing you, you should
maintain your speed and direction so that the
other vessel can steer itself around you.
EMU25531
Other special situations
There are three other rules you should be
aware of when driving your boat around oth-
er vessels.
Narrow channels and bends
When navigating in narrow channels, you
should keep to the right when it is safe and
practical to do so. If the operator of a power-
driven vessel is preparing to go around a
bend that may obstruct the view of other wa-
ter vessels, the operator should sound a pro-
longed blast on the whistle (4 to 6 seconds).
If another vessel is around the bend, it too
should sound the whistle. Even if no reply is
heard, however, the vessel should still pro-
ceed around the bend with caution. If you
navigate such waters with your boat, you will
need to carry a portable air horn, available
from local marine supply stores.
Fishing vessel right-of-way
All vessels that are fishing with nets, lines or
trawls are considered to be “fishing vessels”
under the International Rules. Vessels with
trolling lines are not considered fishing ves-
sels. Fishing vessels have the right-of-way
regardless of position. Fishing vessels can-
not, however, impede the passage of other
vessels in narrow channels.
Sailing vessel right-of-way
Sailing vessels should normally be given the
right-of-way. The exceptions to this are:
1. When the sailing vessel is overtaking
the power-driven vessel, the power-driv-
en vessel has the right-of-way.
2. Sailing vessels should keep clear of any
fishing vessel.
3. In a narrow channel, a sailing vessel
should not hamper the safe passage of
a power-driven vessel that can navigate
only in such a channel.
Reading buoys and other markers
The waters of the United States are marked
for safe navigation by the lateral system of
buoyage. Simply put, buoys and markers
have an arrangement of shapes, colors,
numbers and lights to show which side of the
buoy a boater should pass on when navigat-
ing in a particular direction. The markings on
these buoys are oriented from the perspec-
tive of being entered from seaward (the boat-
er is going towards the port). This means that
red buoys are passed on the starboard
(right) side when proceeding from open wa-
ter into port, and black buoys are to port (left)
side. When navigating out of port, your posi-
tion with respect to the buoys should be re-
versed; red buoys should be to port and
black buoys to starboard.
Many bodies of water used by boaters are
entirely within the boundaries of a particular
state. The Uniform State Waterway Marking
System has been devised for these waters.
✩✩✬✤✳✤✲✣ ✬  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
10
This system uses buoys and signs with dis-
tinctive shapes and colors to show regulato-
ry or advisory information. These markers
are white with black letters and orange
boarders. They signify speed zones, restrict-
ed areas, danger areas, and general infor-
mation.
Remember, markings may vary by geo-
graphic location. Always consult local boat-
ing authorities before driving your boat in
unfamiliar waters.
✩✩✬✤✳✤✲✣ ✤✣  
©2019 Yamaha Motor Corporation, U.S.A.

Safety information
11
ZMU01708
✩✩✬✤✳✤✲✣ ✤✤  
©2019 Yamaha Motor Corporation, U.S.A.

12
Basic requirements
EMU25540
Fueling instructions
WARNING
EWM00010
GASOLINE AND ITS VAPORS ARE HIGH-
LY FLAMMABLE AND EXPLOSIVE!
● Do not smoke when refueling, and keep
away from sparks, flames, or other
sources of ignition.
● Stop engine before refueling.
●
Refuel in a well-ventilated area. Refuel
portable fuel tanks off the boat.
● Take care not to spill gasoline. If gaso-
line spills, wipe it up immediately with
dry rags.
● Do not overfill the fuel tank.
●
Tighten the filler cap securely after re-
fueling.
● If you should swallow some gasoline,
inhale a lot of gasoline vapor, or get
gasoline in your eyes, get immediate
medical attention.
●
If any gasoline spills onto your skin, im-
mediately wash with soap and water.
Change clothing if gasoline spills on it.
●
Touch the fuel nozzle to the filler open-
ing or funnel to help prevent electro-
static sparks.
CAUTION:
ECM00010
Use only new clean gasoline which has
been stored in clean containers and is not
contaminated with water or foreign mat-
ter.
EMU33960
Gasoline
If knocking or pinging occurs, use a different
brand of gasoline or premium unleaded fuel.
Gasohol
There are two types of gasohol: gasohol con-
taining ethanol and that containing metha-
nol. Gasohol containing ethanol can be used
if ethanol content does not exceed 10% and
the fuel meets minimum octane ratings. E-85
is a fuel blend containing 85% ethanol and
therefore must not be used in your outboard
motor. All ethanol blends containing more
than 10% ethanol can cause fuel system
damage or engine performance problems.
Yamaha does not recommend gasohol-con-
taining methanol because it can cause fuel
system damage or engine performance
problems.
EMU25660
Engine oil
Use Yamalube 2-M outboard oil. If Ya-
malube 2-M is not available, use only anoth-
er outboard motor manufacturer’s factory-
brand oil with TC-W3 rating.
CAUTION:
ECM01290
Serious engine damage can result from
the use of lower quality oil, including
some commonly available oil brands with
“TC-W3”on their label. To avoid the risk,
use only Yamalube 2-M or, if necessary,
another outboard motor manufacturer’s
factory-brand TC-W3 oil.
Recommended gasoline:
Regular unleaded gasoline with a min-
imum octane rating of 86 (Pump Oc-
tane Number) = (R+M)/2
Recommended engine oil:
YAMALUBE 2 STROKE OUTBOARD
OIL
✩✩✬✤✳✤✲✣ ✤✥  
©2019 Yamaha Motor Corporation, U.S.A.

Basic requirements
13
EMU33550
Installation requirements
EMU33560
Boat horsepower rating
Before installing the outboard motor(s), con-
firm that the total horsepower of your mo-
tor(s) does not exceed the boats maximum
horsepower rating. See the boats capacity
plate or contact the manufacturer.
WARNING
EWM01560
Overpowering a boat can cause severe
instability.
EMU33570
Mounting motor
Your dealer or other person experienced in
proper rigging should mount the motor using
correct equipment and complete rigging in-
structions. For further information, see page
29.
WARNING
EWM01570
● Improper mounting of the outboard mo-
tor could result in hazardous condi-
tions such as poor handling, loss of
control, or fire hazards.
●
Because the motor is very heavy, spe-
cial equipment and training is required
to mount it safely.
EMU33580
Remote control requirements
The remote control unit must be equipped
with a start-in-gear protection device(s). This
device prevents the engine from starting un-
less it is in neutral.
WARNING
EWM01580
●
If the engine starts in gear, the boat can
move suddenly and unexpectedly, pos-
sibly causing a collision or throwing
passengers overboard.
● If the engine ever starts in gear, the
start-in-gear protection device is not
working correctly and you should dis-
continue using the outboard. Contact
your Yamaha dealer.
EMU25692
Battery requirement
CAUTION:
ECM01061
Do not use a battery that does not meet
the specified capacity. If a battery that
does not meet specifications is used, the
electric system could perform poorly or
be overloaded, causing electric system
damage.
For electric start models, choose a battery
which meets the following specifications.
EMU25712
Battery specifications
The engine cannot be started if battery volt-
age is too low.
EMU34190
Propeller selection
Next to selecting an outboard, choosing the
right propeller is one of the most important
purchasing decisions a boater can make.
The type, size, and design of your propeller
have a direct impact on acceleration, top
speed, fuel economy, and even engine life.
Yamaha designs and manufactures propel-
lers for every Yamaha outboard motor and
Minimum cold cranking amps (CCA/
SAE):
380.0 A
Minimum marine cranking amps (MCA/
ABYC):
502.0 A
Minimum reserve capacity (RC/SAE):
124 minutes
✩✩✬✤✳✤✲✣ ✤✦  
©2019 Yamaha Motor Corporation, U.S.A.

Basic requirements
14
every application.
Your outboard motor came with a Yamaha
propeller chosen to perform well over a
range of applications, but there may be uses
where a different propeller would be more
appropriate.
Your Yamaha dealer can help you select the
right propeller for your boating needs. Select
a propeller that will allow the engine to reach
the middle or upper half of the operating
range at full throttle with the maximum boat-
load. Generally, chose a larger pitch propel-
ler for a smaller operating load and a smaller
pitch propeller for a heavier load. If you carry
loads that vary widely, chose the propeller
that lets the engine run in the proper range
for your maximum load but remember that
you may need to reduce your throttle setting
to stay within the recommended engine
speed range when carrying lighter loads.
For instructions on propeller removal and in-
stallation, see page 58.
EMU25770
Start-in-gear protection
Yamaha outboard motors or Yamaha-ap-
proved remote control units are equipped
with start-in-gear protection device(s). This
feature permits the engine to be started only
when it is in neutral. Always select neutral
before starting the engine.
1. Propeller diameter in inches
2. Propeller pitch in inches
3. Type of propeller (propeller mark)
ZMU04608
-
x
123
✩✩✬✤✳✤✲✣ ✤✧  
©2019 Yamaha Motor Corporation, U.S.A.
