POCKETRAK CX Owner’s Manual
2
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE: DO NOT MOD-
IFY THIS UNIT!
This product, when installed as indicated in
the instructions contained in this manual,
meets FCC requirements. Modifications not
expressly approved by Yamaha may void
your authority, granted by the FCC, to use
the product.
2. IMPORTANT: When connecting this prod-
uct to accessories and/or another product
use only high quality shielded cables. Cable/
s supplied with this product MUST be used.
Follow all installation instructions. Failure to
follow instructions could void your FCC
authorization to use this product in the USA.
3. NOTE:
This product has been tested and
found to comply with the requirements listed
in FCC Regulations, Part 15 for Class “B”
digital devices. Compliance with these
requirements provides a reasonable level of
assurance that your use of this product in a
residential environment will not result in
harmful interference with other electronic
devices. This equipment generates/uses
radio frequencies and, if not installed and
used according to the instructions found in
the users manual, may cause interference
harmful to the operation of other electronic
devices. Compliance with FCC regulations
does not guarantee that interference will not
occur in all installations. If this product is
found to be the source of interference, which
can be determined by turning the unit “OFF”
and “ON”, please try to eliminate the prob-
lem by using one of the following measures:
Relocate either this product or the device
that is being affected by the interference.
Utilize power outlets that are on different
branch (circuit breaker or fuse) circuits or
install AC line filter/s.
In the case of radio or TV interference, relo-
cate/reorient the antenna. If the antenna
lead-in is 300 ohm ribbon lead, change the
lead-in to co-axial type cable.
If these corrective measures do not produce
satisfactory results, please contact the local
retailer authorized to distribute this type of
product. If you can not locate the appropriate
retailer, please contact Yamaha Corporation
of America, Electronic Service Division,
6600 Orangethorpe Ave, Buena Park,
CA90620
The above statements apply ONLY to those
products distributed by Yamaha Corporation
of America or its subsidiaries.
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B)
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interfer-
ence, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
CANADA
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est con-
forme à la norme NMB-003 du Canada.
• This applies only to products distributed by
Yamaha Canada Music Ltd.
• Ceci ne s’applique qu’aux produits dis-
tribués par Yamaha Canada Musique Ltée.
(class B)
prcxenom.book Page 2 Thursday, June 19, 2008 1:13 PM

POCKETRAK CX Owner’s Manual
3
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.
COMPLIANCE INFORMATION STATEMENT
(DECLARATION OF CONFORMITY PROCEDURE)
Responsible Party : Yamaha Corporation of America
Address : 6600 Orangethorpe Ave., Buena Park, Calif. 90620
Telephone : [phone]
Type of Equipment : POCKET RECORDER
Model Name : POCKETRAK CX
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1)
this device may not cause harmful interference, and
2) this device must accept any interference received including interference that may cause undesired oper-
ation.
See user manual instructions if interference to radio reception is suspected.
(FCC DoC)
* This applies only to products distributed
by YAMAHA CORPORATION OF AMERICA.
IMPORTANT
Please record the serial number of this unit in the space below.
Model
Serial No.
The serial number is located inside the battery compartment of the unit.
Retain this Owner’s Manual in a safe place for future reference.
(Ser.No)
About MP3
• Supply of this product does not convey a license nor imply any right to distribute content cre-
ated with this product in revenue-generating broadcast systems (terrestrial, satellite, cable
and/or other distribution channels), streaming applications (via Internet, intranets and/or other
networks), other content distribution systems (pay-audio or audio-on-demand applications
and the like) or on physical media (compact discs, digital versatile discs, semiconductor chips,
hard drives, memory cards and the like). An independent license for such use is required. For
details, please visit http://mp3licensing.com.
•MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
prcxenom.book Page 3 Thursday, June 19, 2008 1:13 PM
