Yamaha SR-C30A User manual

Sound Bar
User Guide
EN

CONTENTS
INTRODUCTION 5
About this User Guide................................................................................5
Features..................................................................................................6
Confirming the included items....................................................................8
PART NAMES AND FUNCTIONS 10
Part names of the sound bar (front/top).. ................................................... 10
Part names of the sound bar (rear).............................................................12
Part names of the subwoofer.. .................................................................. 13
Part names of the remote control..............................................................14
PREPARATION 16
Preparation............................................................................................16
Precautions for preparation......................................................................18
Installing the product.. ............................................................................ 20
Connecting a TV.. .................................................................................... 22
Connecting a TV to the sound bar.. .........................................................................................................................................22
Connecting a TV using only the included digital optical audio cable....................................................................................24
Connecting a TV using an HDMI cable (commercially available)...........................................................................................26
Connecting an audio device.. .................................................................... 30
Preparing the remote control....................................................................34
Turning on and off the sound bar...............................................................35
PLAYBACK 36
Basic control during playback...................................................................36
2
CONTENTS

Adjusting the sound to your preference......................................................38
Sound functions of this product..............................................................................................................................................38
Surround playback...................................................................................................................................................................40
Stereo playback........................................................................................................................................................................41
Adjusting the volume of the subwoofer..................................................................................................................................42
Playing back human voices clearly (CLEAR VOICE).. ..............................................................................................................43
Enjoying rich bass sound (BASS EXT).. ....................................................................................................................................44
Listening to audio from a Bluetooth® device................................................45
ADDITIONAL FEATURES 48
Changing the brightness of the indicators (Dimmer).....................................48
Using a TV’s remote control to control the sound bar (HDMI Control)..............49
Showing the type of audio signal and settings for functions.. ........................ 50
Controlling the sound bar with the smartphone app.....................................51
CONFIGURATION 52
Enabling/disabling the HDMI Control function.............................................52
Enabling/disabling the Auto Power Standby function................................... 53
Enabling/disabling the Child Lock function.. ............................................... 54
Enabling/disabling the Bluetooth Standby function.. ................................... 55
Enabling/disabling the Bluetooth function..................................................56
Setting the dynamic range compression level..............................................57
Setting the frequency characteristics of the sound according to how the sound
bar is installed........................................................................................59
Initializing the sound bar..........................................................................61
TROUBLESHOOTING 62
Check the following first when any problem occurs......................................62
When a problem occurs: Power or overall functionality.. .............................. 63
When a problem occurs: Audio...................................................................71
When a problem occurs: Bluetooth®...........................................................76
When a problem occurs: App.....................................................................78
3
CONTENTS

Other actions..........................................................................................79
How to connect AV devices such as BD/DVD players..............................................................................................................79
How to minimize standby power consumption.. ...................................................................................................................80
Precautions for remote control batteries.. .............................................................................................................................81
How to replace the remote control battery............................................................................................................................82
What to do if the sound bar and subwoofer are not paired automatically.. .........................................................................83
How to reset the sound bar.. ...................................................................................................................................................85
APPENDIX 86
Specifications.........................................................................................86
Supported digital audio signal formats.......................................................89
List of indicator displays.. ........................................................................ 90
About third party software programs.........................................................94
List of support centers.............................................................................95
4
CONTENTS

INTRODUCTION
About this User Guide
(This User Guide uses the following signal words for important information:
(WARNING
This content indicates “risk of serious injury or death.”
(CAUTION
This content indicates “risk of injury.”
(NOTICE
Indicates points that you must observe in order to prevent product failure, damage or malfunction and
data loss, as well as to protect the environment.
(NOTE
Indicates notes on instructions, restrictions on functions, and additional information that may be
helpful.
(The illustrations and screens in this User Guide are for instructional purposes only.
(The company names and product names in this User Guide are the trademarks or registered trademarks of
their respective companies.
(Various smartphones and tablet devices are collectively referred to as “mobile devices”. When necessary,
the type of mobile device is specified in the explanations.
(A [Search tag] is a keyword for searching. This serves as a link from the Quick Start Guide to the User
Guide.
NOTE
The Safety Brochure and the Quick Start Guide are included with this product. See the Safety Brochure first.
5
INTRODUCTION > About this User Guide

Features
This product is a bar-shaped speaker system for your TV that allows you to easily enjoy surround sound on
the TV with a rich sense of presence.
nProduce surround sound just by connecting to a TV
Related links
“Surround playback”(p.40)
nEasily play audio content from a Bluetooth device
6
INTRODUCTION > Features

Related links
“Listening to audio from a Bluetooth® device”(p.45)
nConfigure the sound to match the situation
Clear Voice
This function focuses on the acoustic image of human voices such as dialog and narration within the audio
and emphasizes the voices without changing the overall volume or individuality of the sound. Only the
human voices become easier to hear, and it gives a clear sense of localization to the human voices.
(“Playing back human voices clearly (CLEAR VOICE)”(p.43)
Bass Extension
This function focuses on the acoustic image of the bass portion and enhances bass sound. It allows you to
enjoy rich bass performance with a strong presence without disturbing the balance of the overall sound.
(“Enjoying rich bass sound (BASS EXT)”(p.44)
nMultiple control methods to suit various usage situations
In addition to the sound bar’s controls and the included remote control, the TV’s remote control and the
dedicated smartphone app “Sound Bar Remote” can also be used to control the sound bar.
Audio Return Channel (ARC) and HDMI Control function
An HDMI control function compatible TV allows for controlling the sound bar’s basic functions using the TV’s
remote control. An Audio Return Channel (ARC) compatible TV can be connected to the sound bar using a
single HDMI cable.
(“Using a TV’s remote control to control the sound bar (HDMI Control)”(p.49)
(“Connecting a TV using an HDMI cable (commercially available)”(p.26)
Dedicated smartphone app: “Sound Bar Remote”
The sound bar can also be controlled from your mobile device. The app allows you to check the current
sound mode, sound settings, and volume level of the sound bar.
nCertified as a Yamaha Eco-Product
Yamaha Eco-Label is a mark that certifies products of high environmental performance.
With an advanced energy saving design, this product achieves a low power consumption of 1.8 W or less
when in standby mode.
7
INTRODUCTION > Features

Confirming the included items
The following items are included with this product. Make sure that all of the included items are present.
nMain devices
(Sound bar (SR-CUC30A)
(Subwoofer (SR-WSWC30A)
nAccessories
(Remote control
* A Lithium battery (CR2025) has already been inserted into the remote control.
(AC adaptor (model number: ANAD-420FIOT-B)
(Power cords (×2)
(Digital optical audio cable
8
INTRODUCTION > Confirming the included items

(Non-skid pads (×4 on 1 sheet)
* Attach these to the bottom of the subwoofer.
(Mounting template
* Use when mounting the sound bar on a wall.
(Spacers (A: ×2, B: ×2 on 1 sheet)
* Use when mounting the sound bar on a wall.
(Quick Start Guide
(Safety Brochure
9
INTRODUCTION > Confirming the included items

PART NAMES AND FUNCTIONS
Part names of the sound bar (front/top)
This section describes the part names and functions of the front/top of the sound bar.
a
d
b
c
c
aIndicators
The indicators flash or glow to show the operation and setting status. During normal playback, the setting status is
indicated as follows:
TV, OPTICAL, BLUETOOTH, or ANALOG: Selected playback device
SURROUND: Surround playback (glowing) / Stereo playback (off)
NOTE
This document uses the following illustrations to show that indicators are off, glowing, or flashing.
Off
Glowing
Flashing
bControls
Touch the symbols with your fingertip to control the sound bar.
y (Input): Select an input source (p.36).
} / { (Volume +/-): Adjust the volume (p.36).
z (Power): Turn the sound bar on and off.
cSpeakers
dRemote control sensors
10
PART NAMES AND FUNCTIONS > Part names of the sound bar (front/top)

NOTE
(To prevent unintended operation, do not place anything on the controls of the sound bar.
Enabling the Child Lock function prevents accidental operation.
(The brightness of the indicators can be adjusted by pressing DIM.
Related links
(“Enabling/disabling the Child Lock function”(p.54)
(“Changing the brightness of the indicators (Dimmer)”(p.48)
(“List of indicator displays”(p.90)
11
PART NAMES AND FUNCTIONS > Part names of the sound bar (front/top)

Part names of the sound bar (rear)
This section describes the part names and functions of the rear of the sound bar.
a b c d e f
aUPDATE ONLY jack
Use to update the sound bar’s firmware.
Refer to the instructions supplied with the firmware for details.
bANALOG input jack (p.30)
cOPTICAL input jack (p.30)
dTV input jack (p.22)
eHDMI OUT/TV (ARC) jack (p.26)
fDC IN (20V) jack
Related links
(“Part names of the sound bar (front/top)”(p.10)
(“Part names of the remote control”(p.14)
12
PART NAMES AND FUNCTIONS > Part names of the sound bar (rear)

Part names of the subwoofer
This section describes the part names and functions of the subwoofer.
RearFront
af
b
c d e
aBass reflex port
bSpeaker
cPAIRING button
Use to pair the sound bar with the subwoofer manually. (p.83).
dSTANDBY indicator
Indicates the status of the subwoofer (p.72).
e* Indicator
Glows when the subwoofer is connected to the sound bar (p.35).
fAC power input connector
Use to connect the power cord of the subwoofer.
Related links
“List of indicator displays”(p.90)
13
PART NAMES AND FUNCTIONS > Part names of the subwoofer

Part names of the remote control
This section describes the part names and functions of the remote control.
b
c
f
h
a
d
e
i
g
j
az (Power) button
Turn the sound bar on and off (p.35).
bInput source buttons
Select an audio input source (p.36).
(TV button: Audio from a TV
(OPTICAL button: Audio from a device connected to the OPTICAL input jack
(BLUETOOTH button: Audio from a Bluetooth device
(ANALOG button: Audio from a device connected to the ANALOG input jack
cCLEAR VOICE button
Enable or disable the Clear Voice function (p.43).
dBASS EXT button
Enable or disable the Bass Extension function (p.44).
14
PART NAMES AND FUNCTIONS > Part names of the remote control

eSound mode buttons
Switch to your preferred sound mode (p.38).
(STEREO
(STANDARD
(3D MOVIE
(GAME
fINFO button
Check information such as the type of audio signal being played and the settings for the sound bar’s functions
(p.50).
gDIM button
Switch the brightness of the indicators of the sound bar (p.48).
hSUBWOOFER (+/-) button
Adjust the volume of the subwoofer (p.42).
iVOLUME (+/-) button
Adjust the volume of the sound bar (p.36).
j| (Mute) button
Mute the audio output (p.36). Press this button again, or press VOLUME (+/-) to unmute.
NOTE
Use the remote control within the range shown in the following illustration:
Within 6 m
Remote control sensor
Related links
“Part names of the sound bar (front/top)”(p.10)
15
PART NAMES AND FUNCTIONS > Part names of the remote control

PREPARATION
Preparation
Install the sound bar and connect a TV to it.
1Install the sound bar and subwoofer.
“Installing the product”(p.20)
2Connect a TV to the sound bar.
Connect the TV to the sound bar using a method suitable for the type of jacks on the TV and
the functions to be used.
“Connecting a TV using only the included digital optical audio cable”(p.24)
“Connecting a TV using an HDMI cable (commercially available)”(p.26)
3Connect an audio device (if required).
“Connecting an audio device”(p.30)
4Prepare the remote control.
“Preparing the remote control”(p.34)
5Turn on the sound bar.
When the sound bar is turned on, the subwoofer turns on at the same time.
“Turning on and off the sound bar”(p.35)
16
PREPARATION > Preparation

NOTE
(Connect AV devices (such as BD/DVD players and set top boxes) to the TV’s HDMI input jacks.
HDMI IN
This sound bar AV devices
(When playing audio from a TV or AV device via the sound bar, set the input sources as follows:
(Sound bar’s input source: TV
(TV’s input source: AV device playing the content
(Audio Return Channel (ARC) is a function that transmits audio signals from the TV’s HDMI input jack. This provides the same quality
of audio as when connected with an digital optical audio cable.
17
PREPARATION > Preparation

Precautions for preparation
Before installing the sound bar and connecting other devices, be sure to read the following precautions. Be
sure to follow the precautions.
nPrecautions for installation
WARNING
(Install as instructed in the User Guide. Failure to observe this may cause devices to fall and result in injury.
(Confirm that the finished installation is safe and secure. Also, carry out safety inspections periodically. Failure to observe this
may cause devices to fall and result in injury.
(Do not expose the product to rain, use it near water or in damp or wet conditions, or place on the product any containers (such
as vases, bottles or glasses) containing liquids which might spill into any openings or places where water may drop. A liquid
such as water getting into the product may cause a fire, electric shocks, or malfunctions.
(Do not place any burning items or open flames near the product, since they may cause a fire.
(Do not use this product near medical devices or inside medical facilities. Radio waves from this product may affect electro-
medical devices.
CAUTION
(Do not place the product in an unstable position where it might accidentally drop or fall over and cause injuries.
(When installing this product, do not obstruct heat dissipation. Failure to observe this may trap heat inside the product, causing
a fire or malfunctions.
(Avoid being near the product during a disaster, such as an earthquake. Since the product may turn over or fall and cause injury,
quickly move away from the product and go to a safe place.
NOTICE
(Do not install the product in places where it may come into contact with corrosive gases or salt air, or places that have
excessive smoke or steam. Doing so may result in malfunction.
(Do not press hard on the speaker units or fabric-covered portion of this product.
(Do not place any objects susceptible to magnetism (such as a hard disk drive or magnetic card) near the product. The magnetic
effect of the sound bar may cause damage to the object or its recorded data.
(Do not use this product in a location that becomes extremely hot, such as in direct sunlight or near a heater, or that becomes
extremely cold, or that is subject to excessive dust or vibration. Failure to observe this may cause this product’s panel to
become deformed, the internal components to malfunction, or for operation to become unstable.
(If using a wireless function, avoid installing this product near metal walls or desks, microwave ovens, or other wireless network
devices. Obstructions could shorten the transmission distance.
(Do not stack the sound bar and subwoofer directly on top of one another. Also, do not stack other AV devices directly on or
under this product. These devices may malfunction due to vibrations.
(Do not place the subwoofer in the following ways. Doing so may cause a loss in bass sound volume.
(With the speaker units (fabric-covered portion) placed tightly against the wall
(With the bass reflex port blocked
(Do not place furniture or other objects made of metal between the sound bar and subwoofer. Doing so may interfere with the
wireless connection.
18
PREPARATION > Precautions for preparation

nPrecautions for connections
WARNING
(Use this product with the power supply voltage printed on it. Failure to observe this may cause a fire, electric shocks, or
malfunctions.
(Be sure to use the included power cord and AC adaptor. Do not use the included power cord and AC adaptor for other devices.
Failure to observe this may cause a fire, electric shocks, or malfunctions.
(Never insert or remove an electric plug with wet hands. Do not handle this product with wet hands. Failure to observe this may
cause electric shocks or malfunctions.
(Do not touch the power plug or cord if there is a chance of lightning. Failure to observe this may cause electric shocks.
(When setting up the product, make sure that the AC outlet you are using is easily accessible. If some trouble or malfunction
occurs, immediately turn off the power switch and disconnect the plug from the AC outlet. Even when the power switch is
turned off, as long as the power cord is not unplugged from the wall AC outlet, the product will not be disconnected from the
power source.
(If not using the product for long periods of time, be sure to pull the power plug from the AC outlet. Failure to observe this may
cause a fire or malfunctions.
(Check the electric plug periodically and remove any dirt or dust which may have accumulated on it. Failure to observe this may
cause a fire or electric shocks.
CAUTION
(Do not use an AC outlet where the power plug fits loosely when inserted. Failure to observe this may cause a fire, electric
shocks, or burns.
(When disconnecting the power plug, always hold the plug itself and not the cord. Pulling by the cord can damage it and cause
electric shocks or a fire.
(Insert the power plug firmly all the way into the AC outlet. Using the product when it is not plugged in sufficiently can cause
dust to accumulate on the plug, causing a fire or burns.
NOTICE
(If connecting external devices, be sure to thoroughly read the User Guide for each device and connect them in accordance with
the instructions. Failure to properly handle a device in accordance with the instructions could cause malfunctions.
(Do not connect this product to industrial devices. This product has been designed to connect to consumer-use devices.
Connection to an industrial-use device could cause this product to malfunction.
19
PREPARATION > Precautions for preparation

Installing the product
(Before installing the sound bar, be sure to read the following precautions.
(“Precautions for preparation”(p.18)
Install the sound bar as shown in the following illustration.
Controls
nInstalling the subwoofer
There are two ways to install the subwoofer: upright and on its side. Attach the non-skid pads to the bottom
of the subwoofer according to how the subwoofer is installed.
Installing the subwoofer upright
20
PREPARATION > Installing the product
