INTRODUCTION
Yamaha developed the YHT-24 A/V Home Theater
package to turn your home into atheater. In addition
to enhancing the sound of avideo source, like your TV
or VCR, the YHT-24 also superbly reproduces audio
sources, such as a CD player or acassette deck.
This Quick-Connect
Guide will help you get started.
Study the speaker system plan (below), and then use
the interconnect
diagrams (on the following pages) to
connect the receiver
and speakers to your system.
TOOLS AND PARTS
The YHT-24 Home Theater package consists of
(1) HTR-5440 A/V receiver with a universal remote
control, (1) DV-S5350 DVD player, (1) NS-AP280
package containing (5) 2-way NS-AP280 speakers,
100' of speaker wire, (1) SW-201 powered subwoofer,
and related owner's manuals. You will also need:
•Wire
strippers (optional)
SPEAKER SYSTEM PUN
YHT-24 QUICK-CONNECT GUIDE
For the video portion, you will need atelevision or
monitor. Please refer to the Yamaha HTR-5440 Owner's
Manual, as well as the
owner's manuals that came with
your other components, for complete instructions and
cautions. Be sure to turn off all power while making
the connections.
Please keep this guide
handy for future reference.
NOTE: Label the end of each speaker wire (i.e., left rear, right
front, etc.) before connecting them to the AN receiver. For wire
runs over ,~o feet, use larger 18- or 16-gauge speaker wire.
•Toggle bolts, molly anchor screws, sheet metal screws,
and/ or speaker brackets (for securing the N5-AP280
speakers to walls)
NOTE: If you are unsure of how to securely and safely fasten
speakers to a wall, please contact a reliable source about the best
type of hardware for your particular wall's construction.
Secure installation is the purchaser's responsibility.
NS-AP280 D
(left side. same height as TV)
L
L6J
r- SW-201 Subwooler (on floor)
C
Sub NS-AP280
~D (,lgOt sid., "m. hOlght " TV(
NS-AP280 R
(on top or below TV)
B'-8' apart
L= Left Channel
U
+.
~
R= Right Channel
C= Center Channel
S= Surround Channel
Listening Area
S
NS-AP280 DC
(on stand or wall. at least
ear level or preferably higher)
o
S
8'-10' apart -----~ D NS-AP280
(on stand or wall. at least
ear level or preferably higher)

OYAMAHI{----- YHI-24 QUICK-CONNECT GUIDE
CONNECTING AUDIO COMPONENTS
Yamaha HIR-5440 Receiver (Rear Panel)
-.cOOTlEtS
~~o
rorA"
[[])
[[])
CUllER ®,~<D
AU~
.....
B nn 1.-----_---,
lo,oP£OANCE SHECTOA
I
<:€'W·-"'lrm .. ft1 ,
•
VI~OSIG""'l
i Ci 0R~ iOR:~O
OIGnA"
~
""'"
B
•
•
•
•
••••
NOTE: For your convenience, the Yamaha HTR-5440 receiver is equipped with
two switched ac outlets (100 W max.). If desired, use them to power on connected
components (e.g.,CD player) each time the receiver is turned on. However, do not
use them for components equipped with clocks (e.g.,VCR) .
Cassene Deck,
CD or MD Recorder
• Use Playback Or Line OUt
•• use Lileln
In**
r
Audio Interconnections
•
lo~
001
•
101
I§lOI
•L
Out* IJR Out*
Lln** R
CD Player (Changer) LOut
•
10
1
=1 ROut
•
1•
--- ~
l.-<l
Use RCA Audio Cables Fo
:-=-
L
I~
~~~l
R
CD MDiCO·R
- --
RCA Cable Color Codes
Yellow = Video
White = Len Audio
Red = Right Audio

OYAMAHI{ YHT-24 QUICK-CONNECT GUIDE
CONNECTING THE YHT·24 SPEAKERS
NS-AP280
(Front Right Ch.)
SW-201
(Subwoofer)
NS-AP280
(Front left Ch.)
Subwoofer Wiring
o@0
o0
Stripe
Wire
•• •
..
To AC Oullet
o@0
o0
Stripe
Wire
RCA
Audio Cable
Yamaha HTR-5440
AN Receiver
(Rear Panel)
Set IMPEDANCE Selector
to right position.
o
o
000
Stripe
Wire
NS-AP280
(Surround left)
•
•
•
Speaker
Wiring
o Strip 114" off ends of speaker wires.
@ Push and hold down levers.
@) Insert speaker wires and
release levers.
NS-AP280
(Center Channel)
o
o
000
Stripe
Wire
Stripe
Wire
NS-AP280
(Surround Right)
o

OYAMAHA
e
YHI-24 QUICK-CONNECT GUIDE
CONNECTING VIDEO CABLES FOR VIDEO COMPONENTS
Yamaha HTR-5440 Receiver (Rear Panel)
N:O\JTlETS
~~~Ff.
fOTAl
[[]]
[[]]
CENTER ® .~, <D
IMPEo.-.NCE SHEClOA
I flOffMf ... ..,".ufl< I
A~U
MAIN
B UU 1.-----_---,
•
•
@»
'SnUNBAL
•
•
•
NOTE: When using ahi-Ii stereo VCR, set the Tuner/Line switch
(on the VCR) to Line position to record from another source
connected to the Yamaha HTR-5440 receiver .
•
•
Monitor/TV
••
Optional 75-ohm
VIOEOSlGNA!. I
i ~V'S @~R~OU~l( ~-~."'''·-~~-ot-- I--V-id-eo-I-i
n
~~~~~=,J ~~~X::I Cable
I I
Satellite Receiver
(or Video Game)
Video Out
Hi-Fi Stereo VCR
RCA Cable Color Codes
Yellow = Video
White = Lett Audio
Red = Right Audio
Ilb
l
=dl-l:
'
ms:crBjll ANT Out
Video In IJ Video Out (RF Out)
Use RCA Video Cables And Jacks For Video Interconnections
o

OYAMAHAe YHT-24 QUICK-CONNECT GUIDE
CONNECTING THE YAMAHA OV-85350 OVD PLAYER
Yamaha HIR-5440 Receiver (Rear Panel)
I>l;OUTl£lS
SWITCHEO
°GOWMAX.
'0''''
lYF'fDo\NCe5eLECTQR
I (lnt"ffi!lr ..... :ttf'''''
Use the Included RCA Cables lor Analog and Video
Connections Between the DVD Player and Receiver.
A~~~
~N
B nn 1.------_---,
•
•
•
•
•
•
•
•
•
L I~
Analog Out· I:
R II(~("'-+----_
•
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
Connecting Optical Cable
.. R~"'. ~," oU' ,,"",",
and insert cable.
NOTES:
• On both ends of the optical cable, align and firmly insert
each plug into its mating terminal.
• During connection, do not bend the optical cable.
• Keep dust caps and reattach them if terminals are not used.
-;;c;- NOTE: Use the optical connection to enjoy 5.1-channel surround sound
'NGa
EiI found on DVDs recorded in the Dolby Digital or DTS Digital Surround format.
IIlla
Optical Cable (Included)
1"'>--------------:::,...,....,..,..,....,...,..,..-------11----11-------1.-+---------------(/
@YAMAHA
1I
Yamaha DV-S 5350 DVD Player (Rear Panel)
II
'AI/ala~ Alldio Olll COII/lcc/io", arc rcql/ired!or playback o!CD-R, a"d
r,'cordi"~f/,(}II/ DVD /0 VCR.
Oolby
Di~ital is a t mdclI/ark "r Dolby Labamloric, Lice",i,,~ Corl'0mliol/.
OTS
i.' a Imdt'lllclrk or DTS Tcclll/olo~y LLC.
o

eyAMAHJr----- YHI-24 QUICK-CONNECT GUIDE
CONNECTING AUDIO CABLES FOR VIDEO COMPONENTS
Yamaha HIR-5440 Receiver (Rear Panel)
J,(;OJTlHS
SWITC...eO
l00WMAX
TOTAL
[]J
[]J
CENTER ®.~©
AU'~
>.WN
BU U Ir----------:=---,
ItIIPE()I.,NCE SELECTOR
'W!!Fff!'fe2"f,f!j'
•
•
NOTE: When using ahi-Ii stereo VCR, set the Tuner/Line switch (on the VCR) to Line
position to record from another source connected to the Yamaha HTR-5440 receiver.
•
•
•
HI-FI Stereo VCR
Audio
Rln
•
II
I
•
AUdio
Audio Audio
•
LOut ROut Lin
•
•
Satellite Receiver
•
(or Video Game)
Audio LOut
~
L Use RCA Audio Cables And Jacks For Audio Interconnections.
10 c:=:::=J c:J c::z:::::K::lI c=J
:
IR
Audio ROut
~~¥!!
D-TY'CBL
VCR'
AUDIO SIGNAL
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
o

OYAMAHAe YHT-24 QUICK-CONNECT GUIDE
CABLE HOOK-UP (BASIC AND PREMIUM CHANNELS)
Yamaha H1R·5440 Receiver (Rear Panel)
ACOVTLETS
SWITCHED
100WMAX
TOTAL
IMPEDANCE SELECTOR
I >rr"ffOAEPQWf~Qty I
A~~
MAIN
ann 1..--_---,
[[]J
OIl [0 Dl
I L---==:=::::::::"'.---JL-_=..J
•
•
•
<®
!'iOUNBAl.
•
•
•
•
•
•
•
•
•
•
•
•
•
HHI Stereo VCR
ANTI n
Video In
•
IIII
RCA Video Cables 2S~<eJ
II 00 liB
Video Out
Audio Audio
AUdl~ II Audio R In
LOut ROut Lin
a<e
RCA Audio Cables
L
~ l~~ R
P
~
RCA Audio Cables
VCRl
OR
Basic Cable
(From Wall Jack)
NOTE: When using ahi-fi stereo VCR, set the Tuner/Line
switch (on the VCR) to Line position to record from another
source connected to the Yamaha HTR-5440 receiver.
Premium Cable
(From Wall Jack)
- Descrambler
Hi-FI Stereo VCR
(Tuner set to Channel 3 or 4)
ANT In
Video In
Converter
I I I I
RCA Video Cables S~8J
Box
II 00 liB
Video Out
(Channel 3 or 4
Audio Audio
AUdi~ II Audio R In
Output)
LOut ROut Lin
RCA Audio Cables
a,0
L
IIllI'j}j
l~~
R
r"
OUT
RCA Audio Cables
VCA \
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio

.YAMAH~ _
YHT-24 QUICK-CONNECT GUIDE
INITIAL ADJUSTMENT OF THE SW·201 SUBWOOFER
To achieve the optimum volume balance between the
SW-201 Subwoofer and the NS-AP280 Main Speakers,
perform the following procedure:
1. Insert the SW-201's power plug into anearby ac outlet.
2. Set the SW-201's VOLUME control to 0 (minimum
setting), the AUTO STANDBY switch to HIGH, and
the HIGH CUT switch to LOW.
3. Press the SW-201's POWER switch to ON and power
on all other components.
SW-201 Subwoofer
(Rear Panel)
4. Play an audio source and adjust the HTR-5440's
VOLUME control to a desired listening level.
5. On the SW-201, increase the volume gradually to
adjust the balance the
volume between the SW-201
Subwoofer and the NS-AP280 Main Speakers.
NOTE: Once the volume is balanced between the
subwoofer and the main speakers, you can adjust the
volume of your whole sound system by using the
HTR-5440's VOLUME control.
....... ~
•••••
o "+To AC Oullet

OYAMAHAe _
YHT-24 QUICK-CONNECT GUIDE
PROGRAMMING THE UNIVERSAL REMOTE CONTROL
~
~
4. Using the keypad, enter the four-digit setup code.
The indicator LED will flash twice after
your entry.
If the LED did not flash twice, repeat steps 3 and 4.
3. Press and hold both VOLUME buttons at least four
seconds until the indicator LED flashes twice.
SETTING Up COMPONENTS
Perform the procedure for each component you own.
At the
end of each step 5, the remote control's processor
will automatically assign the selected component's
control functions to its
own buttons, ready for your use.
SETTING Up YOUR TV
1. Turn on the television set and look up a setup code
for
your brand of television (codes are located at the
back of the HTR-5440 Owner's Manua/).
2. 0.\ the remote control, press TV
II ~f---- Use To Enter
Setup Mode
@YAMAHA
Use Keypad
To Enter
Setup Codes
Use To Enter -----a.+>
Setup Mode
Indicator LED ------f-~-~,...-.::j-. -'<<i' ~
~ ~ ~ ~:::::;nt
<f> ~ Buttons
~Tr,:TIi,;i:";ji~?(BJt,;ill[;BI--;:::::'--+--- Turns On
Component's
Power
The YHT-24 Home Theater package includes auniver-
sal pre-programmed remote control with factory codes
to control your HTR-5440 receiver and most Yamaha
audio components. To program other brands ofcompo-
nents (i.e.,
TV, VCR, etc.) or if your Yamaha unit does
not respond, you will need to program the remote
control with the manufacturer'scodes (listed
on the
back pages of the HTR-5440 Owner's
Manual).
NOTE: This remote control is designed to control most major
brands of audio and video components. For other units, use
the original remote control supplied with the product.
POWER ON
1. Load the supplied batteries into the remote control.
2. Aim the remote control at the HTR-5440, press
AMP /TUNER, and then press POWER.
3. The receiver should turn on.
TUNER MO/CO·R
V·AUX 6£>i INPUT
~
+10 +100
88
TEST AlBIC/OlE EFFECT
5. To verify the code works, aim the remote control at
the television set, press TV, and then press POWER.
The television set
should turn off. If it doesn't
respond, use another code for the same manufac-
turer
and repeat steps 3 through 5.

eyAMAHIf----- YHI-24 QUICK-CONNECT GUIDE
PROGRAMMING THE UNIVERSAL REMOTE CONTROL (CONTINUED)
SETTING Up YOUR CABLE Box (OR DSS)
1. Turn on the cable box (or DSS) and look up a setup
code for your brand of cable box (or DSS) (codes are
located at the back of the HTR-5440 Owner's Manual.
2. On the remote control, press CBL/SA T.
3. Press and hold both VOLUME buttons at least four
seconds until the indicator LED flashes twice.
4. Using the keypad, enter the four-digit setup code.
The indicator LED will flash twice after your entry.
If the LED did not flash twice, repeat steps 3 and 4.
5. To verify the code works, aim the remote control at
the cable box (or DSS), press CBL/SAT, and then
press POWER. The unit should turn off. If it doesn't
respond, use another code for the same manufac-
turer and repeat steps 3 through 5.
SETTING Up YOUR VCR
1. Turn on the VCR and look up a setup code for your
brand of VCR.
2. On the remote control, press VCR.
3.
Press and hold both VOLUME buttons at least four
seconds until the indicator LED flashes twice.
4. Using the keypad, enter the four-digit setup code.
The indicator LED will flash twice after your entry.
If the LED did not flash twice, repeat steps 3 and 4.
5. To verify the code works, aim the remote control at
the VCR, press VCR, and then press POWER. The
VCR should turn off. If it doesn't respond, use
another code for the same manufacturer and repeat
steps 3 through 5.
SETTING Up OTHER COMPONENTS
1. Turn on the component (e.g., CD player, tape deck,
or MD player) and look up a setup code for your
brand of component.
2. On the remote control, press the desired component
button (e.g., CD or T APE/MD).
3. Press and hold both VOLUME buttons at least four
seconds until the indicator LED flashes twice.
4.. Using the keypad, enter the four-digit setup code.
The
indicator LED will flash twice after your entry.
If the LED did not flash twice, repeat steps 3 and 4.
5. To verify the code works, aim the remote control
at the component, press the appropiate compo-
nent button, and then press POWER. The unit
should turn off. If it doesn't respond, use another
code for the same manufacturer and repeat steps 3
through 5.

OYAMAHAe YHT-24 QUICK-CONNECT GUIDE
OPERATING THE UNIVERSAL REMOTE CONTROL
3. Load aDVD (or LD) into the DVD (or LD) player.
4. Aim the remote control at the DVD (or LD) player,
and press> (forward button) to start play.
NOTE: The DVD player's controls are now assigned to
the remote control buttons, since DVD was the last
selected component.
3. Using the keypad, enter the code "0000".
4. The indicator LED will flash twice to confirm all
codes have been reset to factory values.
If the lED
does not flash twice, repeat steps 1 through 3.
5. For your convenience, the following reference chart
lists the factory codes:
Component Component Code
Selector Button
RESETTING THE REMOTE CONTROL To fACTORY CODES
You can reset the remote control to factory codes for all
components or a desired component, as follows:
RESETTING CODES FOR ALL COMPONENTS
1. Press any component selector button other than
AMP/TUNER.
2. Press and hold both VOLUME buttons at least four
seconds until the indicator
LED flashes twice.
3. Using the keypad, enter the code "9990".
4. The indicator LED will flash twice to confirm all
codes have been reset to factory values.
If the lED
does not flash twice, repeat steps 1 through 3.
RESETTING CODES FOR A DESIRED COMPONENT
1. Press a component selector button that matches the
component you wish to reset to factory codes.
2. Press and hold both VOLUME buttons at least four
seconds until the indicator LED flashes twice.
0101
0006
0002
0008 Yamaha
0005 Yamaha
0024 Yamaha
TV
Cable TV
VCR
DVD
player
CD player
MD recorder
TV
CBL/SAT
VCR
DVD/LD
CD
TAPE/MD
PLAYING ADVD
1. Aim the remote control at the HTR-5440, press AMP/
TUNER to select the component,
and then press
POWER to
turn the receiver on. Press DVD /lD (i.e., 4
on the keypad) as the input for the receiver.
2. Press DVD /lD and then press POWER to turn the
DVD (or
lD) player on.
NOTE: If the DVD player is plugged into the switched ac
outlet (on the back of the receiver) and its power switch
was already engaged, the unit will come on each time the
receiver is powered on.
OVERVIEW
The universal remote control will control up to seven
different types of components (including the HTR-5440
receiver), each of which becomes active
when you press
aselection (e.g., TV, VCR, etc.). We can only briefly
describe some functions here,
and we encourage you
use the HTR-5440 Owner's
Manual to gain additional
experience
with this powerful unit.
PLAYING A VIDEOCASSETTE
1. Aim the remote control at the HTR-5440, press
AMP
/TUNER to select the component, and then
press POWER to
turn the receiver on. Press VCR (i.e.,
6
on the keypad) as the input for the receiver.
2. Aim the remote control at the TV, press the TV to
select the component,
and then press POWER to
turn the television on. Press TV INPUT (or A/B) to
select the correct input.
3. Aim the remote control at the VCR, press VCR to
select the component,
and then press POWER to turn
the VCR on. Put atape in the VCR, press PLAY.
NOTE: At this point, the VCR controls are assigned to the
remote control, since VCR was the last selected compo-
nent. If you now press the VOLUME up (down) buttons,
the TV NCR volume will be raised (or lowered). To adjust
the receiver's volume, you must press AMP/TUNER to
activate its functions.
_YAMAHA-
©2001 YAMAHA ELECTRONICS CORPORA nON, USA
6660
Orange thorpe Avenue, Buena Park, CA 90620
PH: [phone];
FAX: [phone]
http://www.yamaha.com
