Yard Butler YARD TREE YT-5 User manual

YARD TREE
ASSEMBLY INSTRUCTIONS
Questions?
Let Lewis Tools Customer Service help!
Call 1-800-589-7058 or
Email cu[email protected]
PAGE 1 OF 2
ASSEMBLY INSTRUCTION PART NUMBER 5601019, Rev. 4
1
2
3
STEP 1
Insert bottom pole into base and
secure with set screw.
STEP 2
Slide gravity lock ring over
bottom pole then insert middle
pole and secure with set screw.
Repeat with top pole & ring.
STEP 3
Slide gravity lock hooks over top
pole. Position as desired and
secure with vinyl bumpers.

YARD TREE
ASSEMBLY INSTRUCTIONS
Questions?
Let Lewis Tools Customer Service help!
Call 1-800-589-7058 or
Email cu[email protected]
PAGE 2 OF 2
ASSEMBLY INSTRUCTION PART NUMBER 5601019, Rev. 4
ITEM
PART
NUMBER
DESCRIPTION
QTY
A
RPK-077
Gravity Lock Hooks
3
B
RPK-017
Top Pole Extension
1
C
N/A
Set Screws
3
D
RPK-037
Gravity Lock Ring
2
E
N/A
Clear Vinyl Bumper
5
F
RPK-030
Middle Pole Extension
1
G
RPK-039
Bottom Pole Extension
1
H
RPK-042
Balcony Base
1
FOR MORE PRODUCTS VISIT
WWW.YB-CATALOG.COM OR SCAN QR CODE
ADDITIONAL NOTES:
Gravity Lock Hooks and Rings will not slide
over the center trunk connection joints. Place
the Gravity Lock Hooks and Rings in the
desired section before the entire trunk is
assembled. Use vinyl bumpers for positioning if
desired.
For best results, balance the weight placed
on the Yard Tree evenly. Place the heaviest
items on the lowest hooks or rings.
The Yard Tree is designed to be very stable.
However, it may be necessary to anchor the
Yard Tree base in the event of high winds or
extreme weather.
