Yes Falcon-II User manual

1
#145, 7391 Vantage Way Delta, BC V4G 1M3
Canada Phone: 604-940-7007 ax: 604-940-7044
www.yestek.com
REV: A JUNE-2-2008
Falcon-II
Next Generation, Air Quality Monitor
CO2 & Temperature
OPERATION MANUAL
Critical Environment Technologies
Canada Inc.

2

3
IMPORTANT NOTE
READ AND UNDERSTAND THIS MANUAL PRIOR TO USING THIS
INSTRUMENT. CAREFULLY READ THE WARRANTY POLICY, SERVICE
POLICY, NOTICES, DISCLAIMERS AND REVISIONS ON THE FOLLOWING
PAGES.
THIS INSTRUMENT SHOULD BE INSPECTED AND CALIBRATED REGULARLY
BY A QUALIFIED AND TRAINED TECHNICIAN.
THIS INSTRUMENT HAS NOT BEEN DESIGNED TO BE INTRINSICALLY SAFE.
FOR YOUR SAFETY, DO NOT USE IT IN CLASSIFIED HAZARDOUS AREAS
(EXPLOSION-RATED ENVIRONMENTS).
INSTRUMENT SERIAL NUMBER:
____________________________________________________________________
PURCHASE DATE:
____________________________________________________________________
PURCHASED FROM:
____________________________________________________________________
WARRANTY POLICY
CRITICAL ENVIRONMENT TECHNOLOGIES CANADA INC. (FORMERLY YES
ENVIRONMENT TECHNOLOGIES INC.) WARRANTS THIS INSTRUMENT TO BE
FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP FOR A PERIOD
OF EIGHTEEN MONTHS, INCLUDING CO2 SENSOR, FROM THE DATE OF
PURCHASE BY THE ORIGINAL OWNER. IF THE PRODUCT SHOULD BECOME
DEFECTIVE WITHIN THIS WARRANTY PERIOD, WE WILL REPAIR OR
REPLACE, IT AT OUR DISCRETION.
THE WARRANTY STATUS MAY BE AFFECTED IF THE INSTRUMENT HAS NOT
BEEN USED AND MAINTAINED AS PER THE INSTRUCTIONS IN THIS MANUAL
OR HAS BEEN ABUSED, DAMAGED OR MODIFIED IN ANY WAY. THIS
INSTRUMENT IS ONLY TO BE USED FOR PURPOSES STATED HEREIN. THE
MANUFACTURER IS NOT LIABLE FOR AUXILIARY INTERFACED EQUIPMENT
OR CONSEQUENTIAL DAMAGE.
DUE TO ONGOING RESEARCH, DEVELOPMENT AND PRODUCT TESTING,
THE MANUFACTURER RESERVES THE RIGHT TO CHANGE SPECIFICATIONS
WITHOUT NOTICE. THE INFORMATION CONTAINED HEREIN IS BASED ON
DATA CONSIDERED ACCURATE. HOWEVER, NO WARRANTY IS EXPRESSED
OR IMPLIED REGARDING THE ACCURACY OF THIS DATA.
ALL GOODS MUST BE SHIPPED TO THE MANUFACTURER BY PREPAID
FREIGHT. ALL RETURNED GOODS MUST BE PRE-AUTHORIZED BY
OBTAINING A RETURN MERCHANDISE AUTHORIZATION (RMA) NUMBER.
CONTACT THE MANUFACTURER FOR A NUMBER AND PROCEDURES
REQUIRED FOR PRODUCT TRANSPORT.

4
SERVICE POLICY
CRITICAL ENVIRONMENT TECHNOLOGIES CANADA INC. (CETCI) MAINTAINS
AN INSTRUMENT SERVICE FACILITY AT THE FACTORY. SOME CETCI
DISTRIBUTORS / AGENTS MAY ALSO HAVE REPAIR FACILITIES, HOWEVER,
CETCI ASSUMES NO LIABILITY FOR SERVICE PERFORMED BY ANYONE
OTHER THAN CETCI PERSONNEL. REPAIRS ARE WARRANTED FOR 90 DAYS
AFTER DATE OF SHIPMENT. SHOULD YOUR INSTRUMENT REQUIRE NON-
WARRANTY REPAIR, YOU MAY CONTACT THE DISTRIBUTOR FROM WHOM IT
WAS PURCHASED OR YOU MAY CONTACT CETCI DIRECTLY.
IF CETCI IS TO DO THE REPAIR WORK, YOU MAY SEND THE INSTRUMENT,
PREPAID, TO CRITICAL ENVIRONMENT TECHNOLOGIES CANADA INC. , #145,
7391 VANTAGE WAY, DELTA, B.C. V4G 1M3, ATTENTION: SERVICE
DEPARTMENT. ALWAYS INCLUDE YOUR RMA #, ADDRESS, TELEPHONE
NUMBER, CONTACT NAME, SHIPPING / BILLING INFORMATION AND A
DESCRIPTION OF THE DEFECT AS YOU PERCIEVE IT. YOU WILL BE
CONTACTED WITH A COST ESTIMATE FOR EXPECTED REPAIRS, PRIOR TO
THE PERFORMANCE OF ANY SERVICE WORK. FOR LIABILITY REASONS,
CETCI HAS A POLICY OF PERFORMING ALL NEEDED REPAIRS TO RESTORE
THE INSTRUMENT TO FULL OPERATING CONDITION.
PRIOR TO SHIPPING EQUIPMENT TO CETCI, CONTACT OUR OFFICE FOR AN
RMA # (RETURNED MERCHANDISE AUTHORIZATION). ALL RETURNED
GOODS MUST BE ACCOMPANIED WITH AN RMA NUMBER.
PACK THE EQUIPMENT WELL (IN IT’S ORIGINAL PACKING IF POSSIBLE), AS
WE CANNOT BE HELD RESPONSIBLE FOR ANY DAMAGE INCURRED DURING
SHIPPING TO OUR FACILITY.
NOTICES
COPYRIGHTS: THIS MANUAL IS SUBJECT TO COPYRIGHT PROTECTION; ALL
RIGHTS ARE RESERVED. UNDER INTERNATIONAL AND DOMESTIC
COPYRIGHT LAWS, THIS MANUAL MAY NOT BE COPIED OR TRANSLATED, IN
WHOLE OR IN PART, IN ANY MANNER OR FORMAT, WITHOUT THE
WRITTEN PERMISSION OF CRITICAL ENVIRONMENT TECHNOLOGIES
CANADA INC.
ALL SOFTWARE WHICH CETCI UTILIZES AND/OR DISTRIBUTES, HOLDS A
PROPRIETARY INTEREST AND IS ALSO SUBJECT TO COPYRIGHT
PROTECTION AND ALL RIGHTS ARE RESERVED. NO PARTY MAY USE OR
COPY SUCH SOFTWARE IN ANY MANNER OR FORMAT, EXCEPT TO THE
EXTENT THAT CETCI GRANTS THEM A LICENSE TO DO SO. IF THIS
SOFTWARE IS BEING LOADED ONTO MORE THAN ONE COMPUTER, EXTRA
SOFTWARE LICENSES MUST BE PURCHASED.

5
DISCLAIMER
UNDER NO CIRCUMSTANCES W ILL CRITICAL ENVIRONMENT
TECHNOLOGIES CANADA INC. (CETCI) BE LIABLE FOR ANY CLAIMS, LOSSES
OR DAMAGES RESULTING FROM OR ARISING OUT OF THE REPAIR OR
MODIFICATION OF THIS EQUIPMENT BY A PARTY OTHER THAN CETCI
SERVICE TECHNICIANS, OR BY OPERATION OR USE OF THE EQUIPMENT
OTHER THAN IN ACCORDANCE WITH THE PRINTED INSTRUCTIONS
CONTAINED WITHIN THIS MANUAL OR IF THE EQUIPMENT HAS BEEN
IMPROPERLY MAINTAINED OR SUBJECTED TO NEGLECT OR ACCIDENT.
ANY OF THE FORGOING WILL VOID THE WARRANTY.
REVISIONS
THIS MANUAL WAS WRITTEN AND PUBLISHED BY CRITICAL ENVIRONMENT
TECHNOLOGIES CANAD A INC. (THE MANUFACTURER). THE
MANUFACTURER MAKES NO WARRANTY OR REPRESENTATION,
EXPRESSED OR IMPLI ED INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR PURPOSE, WITH RESPECT TO THIS
MANUAL. ALL INFORMATION CONTAINED IN THIS MANUAL IS BELIEVED TO
BE TRUE AND ACCURATE AT THE TIME OF PRINTING. HOWEVER, AS PART
OF IT’S CONTINUING EFFORTS TO IMPROVE IT’S PRODUCTS AND THEIR
DOCUMENTATION, THE MANUFACTURER RESERVES THE RIGHT TO MAKE
CHANGES AT ANY TIME WITHOUT NOTICE. REVISED COPIES OF THIS
MANUAL CAN BE OBTAINED BY CONTACTING CRITICAL ENVIRONMENT
TECHNOLOGIES CANADA INC.
SHOULD YOU DETECT ANY ERROR OR OMISSION IN THIS MANUAL, PLEASE
CONTACT THE COMPANY AT THE FOLLOWING ADDRESS:
CRITICAL ENVIRONMENT TECHNOLOGIES CANADA INC.
UNIT 145, 7391 VANTAGE WAY
DELTA, BC V4G 1M3
CANADA
TOLL FREE: 1-877-940-8741
PHONE: 604-940-8741
FAX: 604-940-8745
E-MAIL: FBRITTON@CETCI.COM
WEBSITE: WWW.YESTEK.COM
WEBSITE: WWW.CRITICAL-ENVIRONMENT.COM
IN NO EVENT WILL CRITICAL ENVIRONMENT TECHNOLOGIES CANADA INC.,
OR IT’S OFFICERS OR EMPLOYEES BE LIABLE FOR ANY DIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY
DEFECT IN ANY MANUAL, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.

6
INDEX
SECTION DESCRIPTION PAGE
IMPORTANT NOTE AND WARRANTY POLICY 3
SERVICE POLICY AND NOTICES 4
DISCLAIMER AND REVISIONS 5
INDEX 6
WELCOME 7
1.0 GENERAL 8
2.0 SPECIFICATIONS 8 - 9
3.0 DIMENSIONS 10
4.0 INSTRUMENT FEATURES 11-12
5.0 OPERATION 13
5.1 OPERATING MODES 13
5.2 DETAILED OPERATING INSTRUCTIONS 13-16
5.22 OPERATION - MODE ADJUSTMENT 14 - 16
1.0 ALTI MODE 14
2.0 ALARM MODE 14
3.0 OUTSIDE MODE 15
4.0 CALI MODE 15
5.0 DATA LOGGER MODE 16
6.0 MAX / MIN. MODE 16
7.0 fcFS MODE 16

7
WELCOME
Thank you for purchasing the FALCON-II indoor air quality monitor. The FALCON-II
is an easy to use, portable, monitoring device for monitoring trends that pertain to
indoor air quality.
The FALCON-II is equipped with integral CO2 and temperature sensors to aid in
verifying readings providing an indication of air quality. Information readings are
temporarily written to built-in memory. The instrument may be hand-held or will
easily stand on a flat surface.
The FALCON-II instruments are manufactured to provide good value to the end
user. Calibration and repair is available at our manufacturing facility and through
some of our authorized and trained distributors.
If after reading through the manual, you have any questions, please do not hesitate
to contact our service department for technical support.
WHAT YOU GET
* INSTRUMENT
* 4 X “AA” ALKALINE BATTERIES
* WALL ADAPTER (NORTH AMERICAN WALL PLUG
CONFIGURATION)
OPERATION MANUAL
WHITE, FOAM-LINED CARDBOARD STORAGE—SHIPPING BOX

8
1.0 GENERAL
The Falcon-II is a rugged, hand-held, battery powered instrument for measuring and
displaying Carbon Dioxide (CO2) and Temperature. It operates from internal alkaline
batteries or it’s own (supplied) wall adapter.
2.0 SPECIFICATIONS
Dimensions
:
0.96” X 3.19” X 6.50” (24.3mm X 81.1mm X 165 mm)
Weight: 9.65 oz (273.6 grams) including batteries
General Operating Conditions:
Operating Temperature: 32-122°F (0-50°C) 0-95% RH, non-
condensing
Storage Temperature: -4 to 140°F (-20 to 60°C))
Power: Two power supply types:
Battery type: Alkaline, AA X 4 (80 hours)
External: 6 VDC from external AC/DC adapter which is included
in package (North American wall configuration only)
Power Requirement: 160 mA Peak, 15 mA average from 6V
Outputs: Normally Low,100mA max. @ 24 VDC. Adjustable set-point,
factory setting is 1000ppm, hysteresis is 50ppm.
One RJ-45 Connector
Sample Method: Diffusion or flow through (50 ~200 ml/min)
Warranty: 18-months parts & labour (when returned to factory prepaid
freight)
Display: LCD: Independent CO2 & Temperature readings. Calculates &
displays ventilation rates
Certifications: CE
LCD Error Messages:
ITEM DESCRIPTION
「 」
Error 3, it is displayed when the temperature being meas-
ured is outside of the measurement range.
「 」
「 」
Error 5~6, it is necessary to reset the device. To reset it,
turn the instrument off, remove the battery and wait for a
minimum of one minute, reinsert the battery and turn on. If
the error message remains please contact the Service
Department for further assistance.

9
2.0 SPECIFICATIONS, CONT’D…..
Sensors: CO2 (Carbon Dioxide): NDIR (Non-Dispersive Infrared)
Temperature:
CO2 SENSOR - NDIR DESCRIPTION
Measurement Range 0 - 10,000 ppm
Display Resolution 1ppm at 0~1,000ppm; 5ppm at 1,000~2,000ppm;
10ppm at 2,000~4,000ppm, 20ppm at
4,000~6,000ppm, 40ppm at 6,000~10,000ppm
Accuracy ±50 ppm or ±5% of reading
Repeatability ±20 ppm
Temperature Dependence ±0.1% of reading per °C or ±2 ppm per °C,
whichever is greater, referenced to 25°C
Pressure Dependence 0.13% of reading per mm Hg (Corrected via user
input for altitude)
Response Time <2min for 63% of step change
Warm-Up Time <60 seconds at 22°C
Calibration Interval 12 months, offset adjustment using single gas
at 0-1000 ppm CO2. Full factory calibration
available
TEMPERATURE SENSOR DESCRIPTION
Temperature Range Display 32 to 122°F (0 to 50°C)
Display Resolution 0.1°F (0.1°C)
Display Options °F / °C, or Off. Set with Up / Down button
Accuracy ±2°F (±1°C)
Response Time 20-30 minutes (case must equilibrate with envi-
ronment)

10
3.0 DIMENSIONS
6.50”
165mm
3.19”
81.1mm
0.96”
24.3mm

11
4.0 INSTRUMENT FEATURES
FUNCTION PUSH-BUTTONS: “MODE”, “UP”, “DOWN”, “ENTER”. (left to right)
ON / OFF PUSH-BUTTON
LED INDICATOR
LCD DISPLAY
TEST GAS INLET OPENING
FLIP-DOWN STAND
ALKALINE BATTERY ACCESS DOOR
WALL
ADAPTER
SOCKET

12
4.0 INSTRUMENT FEATURES, CONT’D…..
Changing Alkaline Batteries:

13
5.0 OPERATION
The Falcon-II is a rugged, hand-held, battery powered instrument for measuring and
displaying Carbon Dioxide (CO2) and Temperature. It operates from internal alkaline
batteries or it’s own (supplied) wall adapter.
5.1 OPERATING MODES
MODE DESCRIPTION LCD DISPLAY
ALTI Compensate for the effect
of pressure changes by
inputting the appropriate
altitude of the location
where the instrument is
being used.
ALARM Alarm when CO2 concen-
tration exceeds one
threshold alarm. Alarm
level can be changed
through the keypad /
menu. The audible alarm
can be switched on/off
through the keypad / menu
when the speaker icon
flashes
OUTSIDE Modify the concentration of
outside CO2 for defining
the ventilation rate
CALI Calibrate the sensor when
the reading deviates from
the actual CO2
concentration
DATA LOGGER Show CO2 and
temperature records in the
past 24-hours
MAX-MIN Show the Max and Min
readings before being
cleared off or before
switching off
rcFS Recover the factory
Settings, if the device
cannot show accurate
readings

14
5.2 DETAILED OPERATING INSTRUCTIONS
PowerOn
Press the Power button (
①)
to turn on the device after placing 4 AA batteries into
the battery holder or AC adapter plug into the DC socket . Once instrument has
been powered up, the CO2 reading will show after 15 seconds of warm up.
WarmUp
It takes approximately 1-minute before “WARM-UP” disappears from the LCD. All
the functions will not respond during the warm up period.
UserMode
After warm up, the device will stabilize and display the normal CO2 reading in the
upper part of the LCD) and remain visible at all times. Temperature and Ventilation
Rates will be shown in the lower portion of the LCD. The Up/Down button (
④/③)
allows you to scroll through the Temperature and Ventilation Modes. When pressing
the Up button, the lower display will go through the following sequence: “TempºC ->
TempºF -> Vent Rate lps -> Vent Rate cfm/p”.
NOTE: “lps” refers to Liter Per Second Per Person; “cfm/p” refers to Cubic Feet Per
Minute Per Person
5.22 OPERATION - MODE ADJUSTMENT
1.0 ALTI Mode
1.1. Press the Mode Button (
⑤),
“ALTI” flashes
1.2. Press Mode (
⑤)
to alter between “m” (meters) and “ft” (feet).
1.3. Press Up/Down (
④/③)
to adjust the altitude (Step=100m/500ft)
1.4. Press the Enter Button (
②),
save or leave the ALTI Mode, and return to User
Mode.
2.0 ALARM Mode
2.1. Adjust the alarm level
2.1.1. Press the Mode button (
⑤),
until ALARM flashes
2.1.2. Press the Enter Button (
②), “
CO2” icon flashes.
2.1.3. Press Up/Down (
④/③)
to adjust the alarm level (
≧
1,000 ppm, interval is
±
100ppm;
<
1,000 ppm, interval is
±
50 ppm)
2.1.4. Press the Enter (
②),
save the setting and return to the User Mode.
2.2. Turn ON/OFF the ALARM
2.2.1. Press the Mode button (
⑤),
until “Speaker Icon” flashes
2.2.2. Press Enter Button (
②)
2.2.3. Press Up/Down (
④/③)
to turn the ALARM on or off
2.2.4. Press the Enter (
②),
save the setting and return to the User Mode.

15
5.2 DETAILED OPERATING INSTRUCTIONS, CONT’D…..
5.22 OPERATION - MODE ADJUSTMENT, CONT’D…..
3.0 OUTSIDE Mode
NOTE: Ventilation Rate
Ventilate rate represents how much air is introduced into the indoor space from the
outside. Low values indicate low ventilation rates and potentially poor air quality.
High levels indicate excessive ventilation and potential excessive energy usage.
To obtain an accurate measurement, readings should be taken 2~3 hours after
occupancy has stabilized in a space or at a peak in daily CO2 concentrations.
With indoor air quality control, CO2 value is an indicator of ventilation rate. 400 ppm
(Parts Per Million) is the default CO2 concentration outside (according to
ASHRAE: American Society of Heating, Refrigeration and Air conditioning
Engineers).
3.1. Press the Mode button (
⑤),
until OUTSIDE flashes.
3.2. Press Enter (
②),
to show OUTSIDE CO2 and PPM flashes. Press Up/Down (
④/
③)
to adjust the reading.
3.3. Press the Enter (
②),
save the setting and return to the User Mode. After
modification, the VENT Rate will change.
4.0 CALI Mode
The CO2 monitor has been calibrated at the factory and should be recalibrated
every 12-months with a specified concentration of CO2. Sensor drift usually occurs
in linearity. To perform calibration, follow the steps below.
4.1. If battery icon shows low power, replace batteries before attempting to
calibrate or use AC adapter.
4.2. Press the Mode button (
⑤),
until CALI flashes.
4.3. Press Enter (
②),
“CALI” is shown on the display
4.4. Adjust the lower display to ambient CO2 value by pressing the Up/Down (
④/
③)
Button.
4.5. Press Mode button (
⑤)
for more than 10 seconds. “CALIBRATING” flashes.
Calibration will be finished after 5-minutes and the LCD will indicate
“PASS”. If LCD indicates “FAIL”, repeat the calibration.
4.6. Press Enter (
②),
and return to the User Mode

16
5.2 DETAILED OPERATING INSTRUCTIONS, CONT’D…..
5.0 DATA LOGGER Mode
The Falcon-OO has a built-in data logger, which can provide users with CO2 and
temperature readings within the past 24 hours.
5.1. Press the Mode button(
⑤),
until DATALOGGER flashes
5.2. Press Enter(
②),
CO2 and Temperature shows up
Press Up/Down(
④/③)
to page up/down the reading .
5.3. Press the Enter(
②),
return to User Mode
6.0 MaxMin Mode
The Falcon-II has a built-in Max-Min mode, which can provide users with the
Maximum and Minimum CO2 readings since the instrument was last switched on.
6.1. Press the Mode button(
⑤),
until MAX MIN flashes.
6.2. Press Enter button(
②),
MAX and MIN CO2 reading shows alternating.
6.3. “CLR” will flash if press Up/Down(
④/③).
Press Enter(
②),
to CLEAR the MAX and MIN record .
6.4. Press Mode or Enter(
⑤),
return to the User Mode.
7.0 rcFSMode:
If the user sets or calibrates the sensor wrong, you can recover the factory setting.
7.1. Press the Mode button(
⑤),
until rcFS flashes on the lower
display
7.2. Press Enter(
②), “
no” shows on the upper display
7.3. Press Up/Dow(
④/③), “
no” change to “yes”, Press Enter(
②),
Factory Setting
will reload, return to the User Mode;
7.4. Press Mode(
⑤),
leave rcFS Mode, return to the User Mode
SPECIFICATIONS (Preliminary Version)

17

18

19

20
Table of contents
