Burkert 8077 User manual

Operating Instructions
Bedienungsanleitung
Manuel d‘utilisation
Type 8077
Flowmeter with oval rotors
Durchfluss-Messgerät mit Ovalrädern
Débitmètre à roues ovales

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© 2016 Bürkert SAS
Operating Instructions 1602/00 EU-ML_567834_ORIGINAL_FR

3
Contents
Type 8077
1. ABOUT THIS MANUAL ................................................................................4
1.1. Definition of the word "device" ...................................................4
1.2. Symbols used ......................................................................................4
2. INTENDED USE ...............................................................................................5
3. BASIC SAFETY INFORMATION ..............................................................5
4. GENERAL INFORMATION .......................................................................... 7
4.1. Manufacturer's address and international contact...........7
4.2. Warranty conditions ..........................................................................7
4.3. Information on the Internet ...........................................................7
5. DESCRIPTION ..................................................................................................7
5.1. Area of application ............................................................................ 7
5.2. General description ..........................................................................7
5.3. Description of the engraving .......................................................8
5.4. Available versions ..............................................................................9
6. TECHNICAL DATA ....................................................................................... 10
6.1. Conditions of use ............................................................................ 10
6.2. Mechanical data ............................................................................... 10
6.3. Fluid data ............................................................................................. 10
6.4. Electrical data ................................................................................... 11
6.5. Dimensions ........................................................................................ 11
6.6. K factor (in pulse/l) ........................................................................ 11
7. INSTALLATION AND WIRING ................................................................ 12
7.1. Safety instructions.......................................................................... 12
7.2. Installation instructions ............................................................... 13
7.3. Wiring ..................................................................................................... 13
8. COMMISSIONING ....................................................................................... 14
8.1. Safety instructions.......................................................................... 14
9. MAINTENANCE AND TROUBLESHOOTING ................................. 15
9.1. Safety instructions.......................................................................... 15
9.2. Maintenance of the strainer ...................................................... 15
9.3. Maintenance of the device ......................................................... 16
9.4. Replace the rotors .......................................................................... 16
9.5. Replace the cover with electronic module ........................ 17
9.6. If a problem occurs ........................................................................ 18
10. SPARE PARTS AND ACCESSORIES .............................................. 19
11. PACKAGING, TRANSPORT .................................................................. 19
12. STORAGE ...................................................................................................... 19
13. DISPOSAL OF THE PRODUCT .......................................................... 20
English

4
About this manual
Type 8077
1 ABOUT THIS MANUAL
This manual describes the entire life cycle of the device. Please
keep this manual in a safe place, accessible to all users and any new
owners.
This manual contains important safety information.
Fully read this manual. In particular, observe the "Basic safety
information" and "Intended use".
▶Whatever the version of the device, this manual must be read and
understood.
1.1 Definition of the word "device"
The word "device" used within this manual refers to the flowmeter
type 8077.
1.2 Symbols used
DANGER
Warns against an imminent danger.
▶Failure to observe this warning can result in death or in serious
injury.
WARNING
Warns against a potentially dangerous situation.
▶Failure to observe this warning can result in serious injury or
even death.
ATTENTION
Warns against a possible risk.
▶Failure to observe this warning can result in substantial or minor
injuries.
NOTE
Warns against material damage.
Important advice or recommendations.
refers to information contained in this manual or in other
documents.
▶Indicates a procedure to execute to avoid a danger.
→Indicates a procedure to be carried out.
English

5
Intended use
Type 8077
2 INTENDED USE
Use of the device that does not comply with the instructions
could present risks to people, nearby installations and the
environment.
The flowmeter type 8077 is intended to measure the flow rate of
fluids, especially of viscous fluids.
▶Use this device in compliance with the characteristics and the
conditions of commissioning and use specified in the contrac-
tual documents and in this manual.
▶Protect the device against electromagnetic interference, ultra-
violet rays and, when installed outdoors, against the effects of
climatic conditions
▶Only operate a device in perfect working order.
▶Properly transport, store, install and operate the device.
▶Only use the device as intended.
3 BASIC SAFETY INFORMATION
This safety information does not take into account:
• any contingencies or occurrences that may arise during assembly,
use and maintenance of the devices.
• the local safety regulations that the operator must ensure the staff
in charge of installation and maintenance observe.
Risk of injury due to high pressure in the installation.
Risk of injury due to electrical voltage.
Risk of injury due to high temperatures of the fluid.
Risk of injury due to the nature of the fluid.
Various dangerous situations
To avoid injury take care:
▶not to use the device for the measurement of gas flow rates.
▶not to use this device in explosive atmospheres.
▶not to use this device in an environment incompatible with the
materials it is made.
▶not to make any internal or external modifications to the device.
English

6
Basic safety information
Type 8077
Various dangerous situations
To avoid injury take care:
▶not to subject the device to any mechanical stresses.
▶to prevent any unintentional power supply switch-on.
▶to ensure that installation and maintenance work are carried out
by qualified, authorised personnel in possession of the appropri-
ate tools.
▶to guarantee a set or controlled restarting of the process after a
power supply interruption.
▶to observe the general technical rules.
NOTE
The device may be damaged by the fluid in contact with.
▶Systematically check the chemical compatibility of the compo-
nent materials of the device and the fluids likely to come into
contact with it (for example: alcohols, strong or concentrated
acids, aldehydes, alkaline compounds, esters, aliphatic com-
pounds, ketones, halogenated aromatics or hydrocarbons,
oxidants and chlorinated agents).
NOTE
Elements / Components sensitive to electrostatic discharges
▶This device contains electronic components sensitive to electro-
static discharges. They may be damaged if they are touched by
an electrostatically charged person or object. In the worst case
scenario, these components are instantly destroyed or go out of
order as soon as they are activate
▶To minimise or even avoid all damage due to an electrostatic
discharge, take all the precautions described in the standard
EN 61340-5-1
▶Also ensure that you do not touch any of the live electrical
components.
English

7
General information
Type 8077
4 GENERAL INFORMATION
4.1 Manufacturer's address and
international contact
To contact the manufacturer of the device, use following address
Bürkert SAS
Rue du Giessen
BP 21
F-67220 TRIEMBACH-AU-VAL
You may also contact your local Bürkert sales office.
The addresses of our international sales offices are available on the
internet at:
www.burkert.com
4.2 Warranty conditions
The condition governing the legal warranty is the conforming use of
the device in observance of the operating conditions specified in this
manual.
4.3 Information on the Internet
You can find the user manuals and the technical data sheets
regarding the type 8077 at:
www.burkert.com
5 DESCRIPTION
5.1 Area of application
The device is intended to measure, thanks to its oval rotors, the flow
rate of viscous fluids. It must be combined with a remote instrument
(refer to data sheet of the type 8077) which converts the pulse
frequency due to oval rotors rotation.
5.2 General description
5.2.1 Construction
The device is built of a fitting which includes oval rotors and of a
cover including the electronic module with Hall effect sensor and
Reed switch.
The oval rotors of the fitting contain magnets.
All the device versions provide an NPN transistor output and a Reed
switch output.
The electrical connection is made by a 1 meter 5-wire cable.
English

8
Description
Type 8077
5.2.2 Measuring principle
When the fluid flows through the pipe, the oval rotors which contain
magnets turn (see Fig. 1). The displacement of magnets lead to
a variation of magnetic field. The sensor measures the variation of
the magnetic field and converts the signal into a frequency. The
frequency is available at both the NPN transistor and Reed switch
outputs.
Fig. 1 Running/displacement of oval rotors
The remote instrument converts the frequency into a flow rate by
using the correct K factor.
5.3 Description of the engraving
1
2
3
4
5
Model
Flow Range
Max Pressure
Max Temp
K Factor
Type 8077 Flow Sensor
567206N
2-100LPH
1000kPa/55Bar
120°C
999.3 ppL
Serial No D12345
6
Fig. 2 Engraving of the device
1. Order code of the device
2. Flow rate measuring range
3. Max. pressure
4. Max. temperature
5. K factor (specific)
6. Serial number
English

9
Description
Type 8077
5.4 Available versions
Process
connection
Flow rate range Materials Max.
pressure 1) Order code 2)
Viscosity
> 5 mPa.s
Viscosity
< 5 mPa.s Meter body Rotors / axis Meter cover gasket
G 1/8'' 0.5-100 l/h 2-100 l/h Aluminium Stainless steel FEP / PTFE 55 bar 567 202
Stainless steel Stainless steel FEP / PTFE 55 bar 567 203
NPT 1/8'' 0.5-100 l/h 2-100 l/h Aluminium Stainless steel FEP / PTFE 55 bar 567 204
Stainless steel Stainless steel FEP / PTFE 55 bar 567 205
G 1/4'' 0.5-100 l/h 2-100 l/h Stainless steel Stainless steel FEP / PTFE 55 bar 567 206
15-500 l/h 40-500 l/h Stainless steel Stainless steel FEP / PTFE 55 bar 567 207
15-500 l/h for viscosity > 1 Pa.s Stainless steel Stainless steel FEP / PTFE 55 bar 567 208
NPT 1/4'' 0.5-100 l/h 2-100 l/h Stainless steel Stainless steel FEP / PTFE 55 bar 567 209
15-500 l/h 40-500 l/h Stainless steel Stainless steel FEP / PTFE 55 bar 567 210
15-500 l/h for viscosity > 1 Pa.s Stainless steel Stainless steel FEP / PTFE 55 bar 567 211
1) High pressure versions available on request
2) Other high viscosity versions available on request
English

10
Technical data
Type 8077
6 TECHNICAL DATA
6.1 Conditions of use
Ambient temperature –15...+60°C
Fluid temperature (operating)
• Aluminium body • –20...+80°C
• stainless steel body • –20...+120°C
Air humidity < 85%, non condensated
Protection rating IP67, IP66, NEMA 6
Directives
• EMC • EN 61326-1
• Pressure • Complying with article 3 of
§3 from the pressure equipment
directive 97/23/CE*
* According to this directive the device can only be used under fol-
lowing conditions (dependent on max. pressure, pipe diameter and
fluid):
Type of fluid Conditions
Fluid group 1, § 1.3.a Forbidden
Fluid group 2, § 1.3.a DN ≤ 32 or DN > 32 and
PN*DN≤ 1000
Fluid group 1, § 1.3.b PNxDN ≤ 2000
Fluid group 2, § 1.3.b DN≤200
6.2 Mechanical data
Part Material
Meter body • Aluminium
• Stainless steel 316L (1.4401)
Rotors Stainless steel 316L (1.4401)
Axis Stainless steel 316L (1.4401)
Meter cover gasket FEP / PTFE
Electronic module
with tag plate
PP (20% glass fiber)
aluminium
6.3 Fluid data
Max. fluid pressure
• Aluminium or stainless
steel meter body
• 55 bar (550 bar on request)
Viscosity 1 Pa.s max.
(higher on request)
English

11
Technical data
Type 8077
Flow rate measuring range depends on the version (see chap. 5.4)
• Measurement deviation
with standard K factor ≤ ± 1 % of reading
with specific factor ≤ ± 0,5 % of reading
• Repeatability ≤ ± 0,03 % of reading
Max. size of particles 75 µm
6.4 Electrical data
Supply voltage 4,5- 24 V DC
Transistor output
• Type of output
• Hall sensor max. intensity
• Recommended load
• Frequency on open collector,
NPN, max. 25 mA,
4,5 to 24 V DC
• 25 mA
• 1,8 Kohm Pull up at 24 V DC
Reed switch output
• Type
• Max. switching voltage
• Max. switching current
• Max. operating current
• Number of cycles (typical)
• Frequency
• 30 V DC
• 0,5 A
• 0,5 A
• 500 x 106 cycles (at 10 V DC
and 10 mA)
Electrical connection 5-wire cable, 1m long
6.5 Dimensions
You can find these informations in the technical data sheet regarding
type 8077 at: www.burkert.com
6.6 K factor (in pulse/l)
Flow rate range Standard K factor (in pulse/l)
0.5- 100 l/h 1000
15- 500 l/h 400
In all cases, you can use these standard K factors.
→To improve the measurement deviation, use the spe-
cific K factor, engraved on each device (see chap. 5.3).
If the device is combined with an instrument which does not
automatically convert the K factors, make the conversion
using one of the following formulae:
K factor in pulse/gallon US = K factor in pulse/l x 3,785 to
obtain flow rate in gallon US / time unit
K factor in pulse/gallon UK = K factor in pulse/l x 4,546 to
obtain flow rate in gallon UK / time unit.
English

12
Installation and wiring
Type 8077
7 INSTALLATION AND WIRING
7.1 Safety instructions
DANGER
Risk of injury due to electrical voltage.
▶Disconnect the electrical power source for all the conductors
and isolate it before carrying out work on the system.
▶Observe all applicable accident protection and safety regula-
tions for electrical equipment.
Risk of injury due to high pressure in the installation.
▶Stop the circulation of fluid, cut off the pressure and drain the
pipe before loosening the process connections.
Risk of injury due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Stop the circulation of fluid and drain the pipe before loosening
the process connections.
Risk of injury due to the nature of the fluid.
▶Respect the regulations on accident prevention and safety relating
to the use of aggressive fluid.
WARNING
Risk of injury due to non-conforming installation.
▶The electrical and fluid installation can only be carried out by
qualified and authorized personnel with the appropriate tools.
▶Install overload devices that are appropriate to the electrical
installation.
Risk of injury due to unintentional switch on of power supply
or uncontrolled restarting of the installation.
▶Take appropriate measures to avoid unintentional activation of
the installation.
▶Guarantee a set or controlled restarting of the process subse-
quent to the installation of the device.
English

13
Installation and wiring
Type 8077
7.3 Wiring
DANGER
Risk of injury due to electrical voltage.
▶Disconnect the electrical power for all the conductors and iso-
late it before carrying out work on the device.
▶Observe all applicable accident protection and safety regula-
tions for electrical equipment.
• Use a filtered and regulated electrical power supply.
• Make sure the installation is equipotential.
Red wire Power supply (+)
Black wire Power supply (-)
White wire NPN transistor output
Yellow wire Reed switch
Green wire Reed switch
Table 1: Connection wire assignment
7.2 Installation instructions
NOTE
The oval rotors may be damaged if particles with
diameter > 75 µm go into the fitting.
▶Install a strainer of 75 µm upstream and as close as possible to
the device.
→Install a by-pass line on your installation to service the device
and the strainer without stopping the process (see Fig. 3).
valve
direction of flow
strainer
8077
Fig. 3 Installation of a by-pass line
→Install the device onto the pipe so that the shafts of the rotors
are in a horizontal plane.
Seal the external threads of the fitting with a product com-
patible with the materials from which the device housing
and the pipe are made.
→Screw the device onto the pipe.
English

14
Commissioning
Type 8077
7.3.1 Wiring the NPN transistor output and
the Reed switch output
X
V DC
L+ (4,5 - 24 V DC)
(red wire)
L- (black wire)
NPN transistor out-
put (white wire)
Ryellow wire
green wire
R=1,8 kW pull-up at 24 V DC
Fig. 4 Wiring of NPN transistor output and the Reed switch
output
8077
X
V DC
NPN
L-
L+
+-
IN
Remote transmitter
IN = pulse input on remote transmitter
Fig. 5 Example for the connection of the NPN transistor output
to a remote transmitter
8 COMMISSIONING
8.1 Safety instructions
WARNING
Risk of injury due to nonconforming commissioning.
Non conforming commissioning could lead to injuries and damage
the device and its surroundings.
▶Before commissioning, make sure that the staff in charge have
read and fully understood the contents of the manual.
▶In particular, observe the safety recommendations and intended
use.
▶The device/installation must only be commissioned by suitably
trained operators.
Protect this device against electromagnetic interference,
ultraviolet rays and, when installed outdoors, the effects of
the climatic conditions.
The pipe must be full of liquid without air bubbles.
→Drain air from the pipe by gradually filling the pipe with fluid.
→Make sure the installation is tight.
English

15
Maintenance and troubleshooting
Type 8077
9 MAINTENANCE AND
TROUBLESHOOTING
9.1 Safety instructions
DANGER
Risk of injury due to high pressure in the installation.
▶Stop the circulation of fluid, cut off the pressure and drain the
pipe before loosening the process connections.
Risk of injury due to electrical voltage.
▶Shut down and isolate the electrical power source before carry-
ing out work on the system.
▶Observe all applicable accident protection and safety regula-
tions for electrical equipment.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and
safety relating to the use of aggressive fluids.
Risk of injury due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Stop the circulation of fluid and drain the pipe before loosening
the process connections.
▶Keep all easily flammable material and fluid away from the
device.
WARNING
Risk of injury due to non-conforming maintenance.
▶Maintenance must only be carried out by qualified and skilled
staff with the appropriate tools.
▶Guarantee a set or controlled restarting of the process, after a
power supply interruption.
9.2 Maintenance of the strainer
→After the circulation of 200 litres of fluid, examine the strainer
for particles. If necessary clean the strainer with a product com-
patible with the materials from which it is made.
→Regularly examine the strainer for good condition, in particular
when the flow rate decreases. If necessary clean the strainer
with a product compatible with the materials from which it is
made.
English

16
Maintenance and troubleshooting
Type 8077
9.3 Maintenance of the device
→Regularly examine the gasket and the oval rotors for good con-
dition. Follow the instructions on chap. 9.4.
Clean the device with a cloth slightly dampened with water or a
cleaning liquid compatible with the materials the device is made of.
Your Bürkert supplier is at your disposal for any further information.
16
5
7
4
3
2
9
8
1. Screws 5. Gasket
2. Cover 6. Body
3. Rotor shafts 7. Cam
4. Rotors 8. Circlip
41. Active rotor (with magnet) 9. Electronic module
42. Neutral rotor (no magnet) 10. Dimple
Fig. 6 Exploded view of the device
9.4 Replace the rotors
Disassembly
→Ensure the fluid supply to the meter has been disconnected, and
the line pressure has been released.
→Remove the screws [1] and the cover [2].
→Remove the gasket [5] and inspect; replace if damaged.
→Remove rotors [4], clean and inspect; replace if damaged.
41
10
42
Active Rotor
(smooth side)
6
Fig. 7 Correct position of the rotors
English

17
Maintenance and troubleshooting
Type 8077
9.5 Replace the cover with electronic
module
The electronic module [9] includes a Hall effect sensor and a Reed
switch.
Disassembly
→Turn the electronic module [9] counter-clockwise with an angle
of about 90° to unlock it.
→Remove the electronic module [9].
Reassembly
→Place the electronic module [9] in the cam [7].
→Turn the electronic module [9] clockwise with an angle of about
90° to lock it.
The electronic module is locked with the complete device.
Reassembly
→Identify the active rotor [41] by running a metal object over the
face (smooth side).
The neutral rotor [42] is the other one (without magnet).
→Replace the active rotor [41]:
- nearest the dimple [10],
- smooth side in the body meter [6].
→Replace the neutral rotor [42] at 90° to the active rotor [41]
(see Fig. 7).
→Lightly rotate the rotors by hand; they must turn freely.
→Install gasket [5].
→Replace the cover [2].
→Replace screws [1] and fasten in an alternating pattern with a
torque of 6,5 Nm.
English

18
Maintenance and troubleshooting
Type 8077
9.6 If a problem occurs
Problem Cause Solution
Fluid does not
flow through the
device any more
Blocked device →Remove and clean the oval rotors (see chap. "9.4 Replace the rotors").
→Add a strainer of 75 µm upstream of the device.
Blocked strainer (if present) →Clean the strainer.
Rotors damaged →Replace the rotors (see chap. "10 Spare parts and accessories" and "9.4
Replace the rotors").
Reduced flow
rate through the
device
Strainer (if present) partially blocked →Clean the strainer.
Fluid too viscous →Use rotors for fluids with a viscosity > 1000 mPa.s.
Incoherent
measurement
Flow rate range not adapted →Verify specifications, adjust the device or the flow rate (see chap. "6.3 Fluid
data").
Air within the pipe →Slowly drain air from the pipe.
Friction due to an incorrect assembly
of the device →Verify the assembly of the rotors in the fitting (see chap. "9.4 Replace the
rotors").
No frequency
output
Incorrect wiring of the outputs →Make sure that the device has been wired correctly (see chap. "7.3 Wiring").
Hall sensor or Reed switch defective →Replace the cover with electronic module (see chap. "10 Spare parts and
accessories" and "9.5 Replace the cover with electronic module").
Rotors incorrectly mounted →Disassemble the device and modify the position of the rotors (see chap. "9.4
Replace the rotors").
Magnet damaged →Replace the rotors (see chap. "10 Spare parts and accessories" and "9.4
Replace the rotors").
English

19
Spare parts and accessories
Type 8077
10 SPARE PARTS AND
ACCESSORIES
CAUTION
Risk of injury and damage caused by the use of unsuitable
parts.
Incorrect accessories and unsuitable spare parts may cause
injuries and damage the device and the surrounding area.
▶Use only original accessories and original spare parts from
Bürkert.
Spare part Order code
Set of 2 oval rotors in stainless steel, flow rate
range of 0.5-100 l/h
567 766
Set of 2 oval rotors in stainless steel, flow rate
range of 15-500 l/h
567 767
FEP / PTFE seal range of 0.5-100 l/h 567 768
FEP / PTFE seal range of 15-500 l/h 567 769
Electronic module including Hall effect sensor
and Reed switch
567 770
11 PACKAGING, TRANSPORT
NOTE
Damage due to transport
Transport may damage an insufficiently protected device.
▶Transport the device in shock-resistant packaging and away
from humidity and dirt.
▶Do not expose the device to temperatures that may exceed the
admissible storage temperature range.
▶Protect the electrical interfaces using protective plugs.
12 STORAGE
NOTE
Poor storage can damage the device.
▶Store the device in a dry place away from dust.
▶Storage temperature: -15...+60 °C.
English

20
Disposal of the product
Type 8077
13 DISPOSAL OF THE PRODUCT
→Dispose of the device and its packaging in an environmental-
ly-friendly way.
NOTE
Damage to the environment caused by parts contaminated by
the fluid.
▶Comply with the national and/or local regulations which concern
the area of waste disposal.
English
