YITELA YTL-A01 User manual
CONTENTS
1
HELMET CHARACTERISTICS............................ 1PACKING DETAILS.............................................. 1HELMET & REMOTE CONTROLLER.................. 2HELMET FUNCTIONS........................................... 3HOW TO WEAR YOUR HELMET.......................... 4REMOTE CONTROLLER INSTALLATION........... 7 PRODUCT INTRODUCTION...............................
ENGLISH
TECHNOLOGY PARAMETERS...........................8
ENGLISH
This smart helmet is suitable for bicycle riders.
The streamlined design of helmet design, with hollow-out workmanship, is not only beautiful and lightweight, but also makes riding refreshing and breathable. The remote control signal lamp which is easy to control brings you a new riding experience.
HELMET CHARACTERISTICSPACKING DETAILS
1*Smart Helmet1*Remote Controller1*Charging WireSmart Helmet1*Fixing Rubber Ring1*User Manual
1PRODUCT INTRODUCTION
Thanks for buying this smart helmet. It will give you new feeling of safetyby cycling on the road. It can not only protect users’ life safety, but also provides versatile functions of LED turning signals for you. Meanwhile, the fashion design of smart helmet gives riders wonderful experience and excellent feelings as a beautiful landscape on the road.
Type-C Charging PortRight-turning Signal LampLeft-turning Signal LampHead VentilationHelmet Power ON/OFF
Rear Flashing Warning Lamp
HELMETREMOTE CONTROLLER
Type-C Charging Port
Status Indicators
Remote Controller Body
Left-turning Signal Control Key
Rear Flashing Warning Light Control Key
Remote Controller Power ON/OFF Key
Right-turning Signal Control Key
ENGLISH
2
Long press the helmet power button to turn on the helmet. Long press again to turn off the helmet. In addition, the helmet will automatically shut down after 4 hours without any operation.
HELMET FUNCTIONSHelmet Power ON/OFF
When the helmet power indicator flashes slowly, which means it’s time to charge.
Helmet Indicator
The warning light has four working modes, which can be switched through the remote control.
Helmet Warning Lights
The turn signal is controlled ON/OFF by the remote controller. When it is turned on, the corresponding turn signal group flashes.
Left/Right Turn Signal
Long press the power button of the remote control to turn on the remote control. Long press again to turn off the remote control. In addition, the remote control will shut down automatically after 2 hours of continuous working without any operation.
Remote Controller
Press the turn signal button on the remote control to control the corresponding helmet turn signal to flash.
Left/Right Turn Button
Press the warning light button on the remote control to cycle the helmet warning light working mode.
Remote Control Warning Light Button & Indicator
The blue indicator is ON during charging and OFF when charging finished.
Helmet & Remote Control Charging
ENGLISH
3
HOW TO WEAR YOUR HELMET1. Adjust Lining Cushion
The inner side of the helmet is provided with a pad, which can cushion and absorb sweat. You can gently tear it off and clean it. Please paste it carefully during installaon.
2. Tighten the Buckle
The buckle is the main way to fix the helmet. Before wearing, be sure to ghten the buckle and fix it at one end of the helmet. The reserved length of the buckle is recommended to be determined by yourself according to your needs.
3. Adjust the Tightness
Aer wearing the helmet, you will touch a knob at the back of the helmet. Turn the knob to adjust the ghtness of the helmet. The comfortable handle of the knob will make you more focused on the ghtness experience.
4. Test for Tightness
Aer adjusng the rear knob, lower your head and lt your body forward with the buckle unfastened. If the helmet does not fall stablly, it indicates that your adjustment is appropriate enough.
5. Adjusting Y-buckle
Next, let's adjust the Y-buon on the e. It has a great impact on the comfort of wearing the helmet. You can pull up and down the Y-buon to the appropriate posion. It is recommended to be close to the lower part of the ear as far as possible without affecng the comfort of the ear.
6. The Pulling & Inserting of Fasteners
The helmet adopts a bolt type connecon mode. The connecon can be realized by inserng the male head of the bolt into the female seat and fastening it. When unlocking, just press the elasc buckle rod on the side of the male head of the bolt.
7. Adjust the Tightness of the Chin
Aer the fastener is buckled, the ghtness of the whole buckle can be adjusted. Holding one end and pulling the tail of the belt at the other end can easily fasten the buckle
8. Recommended Tightness
If the buckle is too ght, it will cause discomfort, but if it is too loose, it will not work. We suggest that two fingers can be inserted between the buckle and your chin.
ENGLISH
4
HOW TO WEAR YOUR HELMET9. Fix the Buckle
Finally, there is the extra part of the fixed buckle. A rubber band used to fix the excess buckle can be seen on the buckle connected with the bolt. Remove the helmet, pass the excess part of the buckle through the rubber band, and then adjust the rubber band to the appropriate fixed position.
10. Correct Wearing Position
The correct wearing posion can generally be determined easily. The distance between theupper edge of the eyebrow and the lower edge of the helmet is one finger, and the forehead is exposed too much, which can not achieve the due protecve effect. If the helmet is worn too forward, it will affect the line of sight. For your safety, we strongly recommend you to wear the helmet correctly.
1. Adjust Lining Cushion2. Tighten the Buckle3. Adjust the Tightness4. Test for Tightness
ENGLISH
5
HOW TO WEAR YOUR HELMET7. Adjust the Tightness of the Chin8. Recommended Tightness5. Adjust Y-buckle
6. The Pulling & Inserting of Fasteners
9. Fix the Buckle10. Correct Wearing Position
ENGLISH
6
REMOTE CONTROLLER INSTALLATION 1. Prepare
Prepare the remote control and fixing rubber band
2. Install
First put the rubber band around the hook on one side of the remote control, then wrap the rubber band around the handlebar rod, and finally put the rubber band on the hook on the other side of the remote control.
1. Prepare2. Install3. Adjust3. Adjust
Aer the remote controller is installed on the handlebar, it can rotate properly around the rod or translate the remote controller and rubber band along the rod to adjust it to a comfortable posion.
ENGLISH
7
TECHNOLOGY PARAMETERSModelMaterialSizeWeightSuitable forWaterproofCerficaonBaery CapacityMax. Power ConsumponWorking DuraonCharging PowerCharging TimeTurning Signal LightWarning LightsWireless TransmissionYTL-A01EPS PC ABS Silicone27*21*17CMHelmet 360g/ Controller 30g59cm-62cmIPX4CE EN1078/CPSC/RoHs/FCC420mAh Lithium Polymer42mAh/4.2V24Hours/3-4Weeks5V 210mAhAbout 2 HoursMax. 3.14lmMax:9.42lm2404MHz-2479MHz 6dBm
ENGLISH
8
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction
