Yli Electronic YM-180M User manual

Specification
Installation
SIZE(UNIT:MM) VOLTAGE
180kg(350Lbs)
12/24VDC
12/24VDC
280kg(600Lbs)
CURRENT HOLDING FORCE
12/24VDC
12/24VDC
12/24VDC 500kg(1200Lbs)
232Lx42Wx24.5H
254Lx65.8Wx39H
190Lx32Wx22.5H
232Lx42Wx24.5H
180kg(350Lbs)
280kg(600Lbs)
For example: YM-280M (Unit:mm)
MODEL
12V/300mA
24V/150mA
12V/500mA
24V/250mA
12V/420mA
24V/210mA
12V/300mA
24V/150mA
12V/500mA
24V/250mA
190Lx32Wx22.5H
12/24VDC 500kg(1200Lbs)
254Lx65.8Wx39H
YM-180M
YM-180M-S
YM-280M
YM-280M-S
YM-500M
YM-500M-S 12V/420mA
24V/210mA
DOOR
Single Door
Single Door
Single Door
Single Door
Single Door
Single Door
!NOTES:
Please read specification before installing magnetic lock
A. Handle the equipment carefully. The holding force can be reduced by damaging the lock body or
armature plate.
B. The magnetic lock should be fixed tightly on the door frame and the armature plate on the door leaf.
Kit provided allows the armature plate to pivot its center, thus compensating misalignment caused by
other factors.
C. Template can only be used with the door in normally closed circumstance.
D. Please fix screws of magnetic lock firmly.
E. Detect signal of door state: the limit of reed switch and dry contact is 0.5A/30VDC. Don't overload.
tested
Germany
EMC
R
Mortise Mount Magnetic Lock
(1) Dig the hole (2)Fix screws
Armature plate
(3)Dig the hole (4)Fix screws
Door Frame
180
38
21.5
217.6
195.6
41.6
19

Circuit board diagram
Wire Connection
Cautions:
A. The screw of armature plate should not be fixed too tight. Proper elasticity
should be guaranteed for the rubber ring so that the armature plate can adjust
itself to the appropriate position.
B. Check the jumper's position before connecting. Figure out it represents 12VDC
or 24VDC.
!
Power Selector
Jumper
Red: Black: Blue:NC Green:NO White:COM
POWER
RED(+)
BLACK (-)
12VDC
24VDC
12VDC
24VDC
BLACK
BLACK (COM)
(NO)
YM-180M-S YM-180M,YM-280M,YM-500M YM-280M-S,YM-500M-S
Power Selector
Jumper
Power Selector
Jumper
POWER
RED(+)
BLACK (-)
