YOKOGAWA IS8000 User manual

User’s
Manual IS8000
Integrated Software
High-speed Camera Synchronization
Feature (FS1 option)
IM IS8000-61EN
7th Edition

i
IM IS8000-61EN
This manual explains the High-speed Camera Synchronization feature (/FS1 or -FS1 option) of the
IS8000 Integrated Software (hereafter referred to as the IS8000 Software). To ensure correct use,
please read this manual thoroughly before operation. To use this option, you need to perform the
following procedure on the IS8000 Software that is installed in your personal computer (PC).
• For the /FS1 option, you need to activate the IS8001 or IS8002.
• For the -FS1 option, you need to activate the IS8001EX or IS8002EX.
* For details on how to activate the software, see the Installation Manual, IM IS8000-04EN.
After reading this manual, keep it in a safe place. This software comes with various manuals that
are listed under “Manuals” in the User’s Manual (IM IS8000-01EN). Please read all manuals.
You can open the above manuals from the launcher and Help menu of this software. For details on the
procedures, see section 9.3 in the User’s Manual, IM IS8000-01EN.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Document No. Description
PIM 113-01Z2 List of worldwide contacts
Notes
• The contents of this manual are subject to change without prior notice as a result of
improvements to the instrument’s performance and functionality. Refer to our website to view
our latest manuals.
• The figures given in this manual may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your
nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of
YOKOGAWA is strictly prohibited.
• The license management section of this licensee application is based on one or more of the
following copyrights:
Sentinel® RMS © 2005 SafeNet, Inc. All rights reserved.
Sentinel® EMS © 2009 SafeNet, Inc. All rights reserved.
Trademarks
• Microsoft, Internet Explorer, Windows, Windows 10, and Windows 11 are registered trademarks
or trademarks of Microsoft Corporation in the United States and/or other countries.
• Adobe and Acrobat are either registered trademarks or trademarks of Adobe Systems
Incorporated.
• Sentinel is a registered trademark of SafeNet, Inc.
• FASTCAM and FASTCAM NOVA are registered trademarks of PHOTRON LIMITED.
• In this manual, the TM and ® symbols do not accompany their respective registered trademark
or trademark names.
• Other company and product names are trademarks or registered trademarks of their respective
holders.
7th Edition: August 2022 (YMI)
All Rights Reserved, Copyright © 2021 Yokogawa Test & Measurement Corporation

ii IM IS8000-61EN
Revisions
• 1st Edition: March 2021
• 2nd Edition: July 2021
• 3rd Edition: September 2021
• 4th Edition: January 2022
• 5th Edition: March 2022
• 6th Edition: June 2022
• 7th Edition: August 2022

iii
IM IS8000-61EN
Conventions Used in This Manual
Prefixes k and K
This manual distinguishes prefixes k and K used before units as follows:
k: Denotes 1000. Example: 100 kS/s (sample rate)
K: Denotes 1024. Example: 720 KB (file size)
Displayed Characters
Bold alphanumeric characters in procedural explanations indicate characters that appear in the
menus on the screen.
Notes
This manual uses the following symbol to indicate notes.
Note Calls attention to information that is important for the proper operation of the
software.

iv IM IS8000-61EN
Check the Following before Use
This option is provided according to the specifications specified at the time of purchase.
When Purchased As an Option to the IS8001 or IS8002 (/FS1 option)
The option is integrated into the IS8001 or IS8002 software. Product information and inquiry
documents for this option are not provided.
When Purchased As an Add-on Package to the IS8001EX or IS8002EX
(-FS1 option)
Product information and inquiry documents for this add-on package are provided. Check the
following information. If the wrong items have been delivered or if items are missing, contact your
nearest YOKOGAWA dealer.
Inquiries
(PIM 113-01Z2) 1 sheet
Product Information
(PI IS8000-01) 1 sheet
Product Information
The following items are indicated. Please keep this sheet in a safe place.
• Model (IS8001EX or IS8002EX) and suffix code (-FS1) of this option
• License code
You need to enter this license code to add this option. For instructions on how to enter the
license code, see the Installation Manual, IM IS8000-04EN.
• Download page URL
You can download the software installer from this URL.
For details on the product’s model, suffix code, license model, and manuals, see the
Installation Manual.

v
IM IS8000-61EN
Notes on Usage
Notes on Using This Option
• This option can be used on two PCs per license. It can be used on two PCs simultaneously.
• To allow communication between a DL950 (hereafter referred to as the measuring instrument)
and a PC through its USB interface, you need to install a dedicated USB driver in the PC. For
details, see the Installation Manual, IM IS8000-04EN.
You can download the USB driver from the following web page:
https://tmi.yokogawa.com/library/
• This option can control a single high-speed camera and a measuring instrument.
• It is not possible to connect to the same measuring instrument from multiple PCs at the same
time.
• When you connect a measuring instrument to a PC and use this option to control the instrument,
you cannot use multiple types of communication interface at the same time.
• Do not perform panel operations on the measuring instrument while data is being recorded.
• The option may not be able to continue if the PC enters standby or hibernation mode. Disable
standby and hibernation modes when you use the software.
• If a connection error occurs, turn off the measuring instrument and then turn it back on.
Feature Restrictions
For the functional restrictions of each license, see the Installation Manual, IM IS8000-04EN.

vii
IM IS8000-61EN
Contents
Conventions Used in This Manual ................................................................................................... iii
Check the Following before Use......................................................................................................iv
Notes on Usage ................................................................................................................................v
Chapter 1 Explanation of Functions
1.1 System Configuration..................................................................................................... 1-1
1.2 Video and Waveform Synchronization and Saved Range ............................................. 1-2
Chapter 2 Recording and Saving Videos and Waveforms
2.1 Connecting a Camera to the DL950............................................................................... 2-1
2.2 Searching for the Camera and DL950 on the IS8000.................................................... 2-2
2.3 Configuring the Camera ................................................................................................. 2-3
2.4 Synchronizing the Camera to the DL950 ....................................................................... 2-4
2.5 Recording and Saving Videos and Waveforms.............................................................. 2-5
Chapter 3 Displaying Saved Videos and Waveforms
3.1 Loading Video Data and Waveform Data....................................................................... 3-1
3.2 Controlling the Video Display ......................................................................................... 3-2
Chapter 4 Offline Synchronization of Videos and Waveforms
4.1 Loading Video Data and Waveform Data....................................................................... 4-1
4.2 Setting the Synchronization Information of Videos and Waveforms .............................. 4-4
Chapter 5 Specifications
5.1 Features ......................................................................................................................... 5-1
5.2 PC System Requirements.............................................................................................. 5-1
5.3 YOKOGAWA Measuring Instrument Supporting This Option......................................... 5-2

1-1
IM IS8000-61EN
Chapter 1
Explanation of Functions
1.1 System Configuration
PC
Waveform (signal) measuring instrument2
High-speed
camera1
Signal input terminal
Waveform
measurement
(analog signals)
Shooting/
measurement
target
Trigger signal
A signal is generated when a trigger occurs.
Sample clock
(Sync signal)
Configuration change
and measurement
control
Waveform data
Configuration change
and shooting control
Video data files (.avi)3
Shooting
Project files (.anpjt)
Waveform data files (.mf4)
The High-speed Camera Synchronization Option is a video and waveform viewer software that
displays waveforms measured by a waveform measuring instrument and video shot by a high-
speed camera in sync based on triggers and enables analysis of the data.
The trigger signal and sample clock generated by the measuring instrument is applied to the high-
speed camera.
The waveforms and video are displayed in sync on a PC monitor by loading the measured
waveform data and the high-speed camera’s video and shooting information data.
1 For information on compatible high-speed cameras, see section 5.1 in this manual.
2 For information on compatible YOKOGAWA waveform measuring instruments, see section 5.3 in this
manual.
3 The maximum size of a video data file (.avi) that can be loaded from a camera into the PC is less than
4 GB. A video data file greater than 4 GB can be loaded using offline synchronization.

1-2 IM IS8000-61EN
1.2 Video and Waveform Synchronization and Saved Range
Video and Waveform (Measuring Signal) Synchronization
Trigger
Sample clock
(Sync signal)
Start
Measured waveform
Video frames
Trigger frame
Stop
Recording standby start
(endless recording)
Pre-trigger section Post-trigger section
Pre-trigger
frames
Post-trigger
frames
Saved video
Trigger signal
Video frames are recorded in
sync with the sample clock.
Measuring instrument outputs
Camera output
A
C D
B
Video frames of the high-speed camera are recorded in sync with the sample clock received from
the measurement instrument.
When the measurement instrument triggers, it measures the waveform and at the same time
outputs a trigger signal to the camera. The camera records video and shooting information before
and after this trigger output.
Saved Range
Range of Saved Waveform Data
The range of waveform data that is saved is the recording time (T/div×10) of the DL950
measurement instrument (the range between points A and B). Set this longer than the video to
be saved.
For details on the number of waveform data points that can be saved and measurement
conditions using online synchronization, see appendix 2 in the User’s Manual, IM IS8000-01EN.
Range of Saved Video
The range of video that is saved is the range between the pre-trigger frame and post-trigger
frame (the range between points C and D) specified on the camera in reference to the trigger
frame. Set the number of frames so that the pre-trigger frame and post-trigger frame fit
between the pre-trigger and post-trigger of the measured waveform.
