Yolink YS4909-UC Operation manual

Installation & User Guide
Valve Controller 1
YS4909(S)-UC
KITS:
YS4909(S)-UC & BULLDOG
YS4909(S)-UC & DN##
Revision May. 31, 2023

. Welcome!
. Before You Begin
. What's Included
. Required Items
. Get to Know Your Valve Controller 1
. Power Up
. Install the App
. Add Your Valve Controller 1 to the App
. Install the Valve Controller 1
. Get to Know Your Bulldog Valve Robot
. Install the Bulldog Valve Robot
. Final Connections
. Manual Operation
. Testing
. Troubleshooting
. Get to Know Your Motorized Valve
. Install the Motorized Valve
. Final Connections
. Manual Operation
. Testing
. Troubleshooting
. Control-D2D Device-to-Device Pairing
. Using the App & 3rd-Party Services
. Factory Reset
. Firmware Update
. Battery Replacement
. Warnings
. Warranty
. FCC Statement
. IC Statement
. Contact Us
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
AA
AB
AC
AD
AE
01
02
04
06
08
09
10
11
13
15
16
22
23
24
25
27
28
32
32
33
34
35
38
38
39
40
42
44
45
47
48
TABLE OF CONTENTS

01
Welcome!
Thank you for purchasing YoLink products! We
appreciate you trusting YoLink for your smart
home & automation needs. Your 100%
satisfaction is our goal. If you experience any
problems with your installation, with our
products or if you have any questions that this
manual does not answer, please contact us right
away. See the Contact Us section for more info.
Thank you!
Eric Vanzo
Customer Experience Manager
A
User Guide Conventions
The following icons are used in this guide to
convey specific types of information:
Very important information
(can save you time!)
Good to know info but may not
apply to you

02
Download the most current version of the user
guide by scanning the QR code:
Before You Begin
Visit our Valve Controller 1 support page on our
website, for the latest installation guides,
additional resources, information and videos by
visiting:
www.shop.yosmart.com/pages/valve-
controller-1-product-support
Or by scanning the QR code:
B

03
Please note: the existing ball valve must be in
good working order. It must open and close
smoothly, with minimal effort, and it must close
fully, shutting off the water completely. The
Bulldog Valve Robot is not able to correct
mechanical issues of the ball valve.
Your Valve Controller connects to the internet via
a YoLink Hub or SpeakerHub, and it does not
directly connect to your WiFi or local network. In
order for remote access to the device from the
app, and for full-functionality, a YoLink hub is
required. This guide assumes the YoLink app
has been installed on your phone, and a YoLink
Hub or SpeakerHub is installed and online.
If installing the Valve Controller and Bulldog
Valve Robot outdoors, please refer to the
environmental range specifications found on the
Valve Controller product support page. While
these devices can be installed outdoors, it
should be protected from rain and direct sunlight
by an enclosure or overhead cover, such as a
rain hood.
Before You Begin, Continued
B

04
What's Included
C
Valve Controller 1
4 x AA Batteries (Pre-Installed)
Quick Start Guide
YS4909(S) Items:

05
Bulldog Valve Robot Large & Small Brackets
24-36x50 36-52x54
Motorized Valve
What's Included, Continued
C
Bulldog Valve Robot Kit Items:
Motorized Valve Kit Items:

06
These tools or items may be required:
Required Items
D
Wall Anchors
Drill with Drill Bits Medium Phillips Screwdriver
Medium Phillips Screwdriver
These items will be required to install the
Bulldog Valve Robot:

07
Locking PliersPipe Wrench
Copper Pipe Cutting Tool
SandpaperThread Seal Tape
Marker or Pencil
Pipe Fittings/Adapters
These items may be required to install the
motorized valve:
Required Items, Continued
D

08
Get to Know Your Valve
Controller 1
E
Mounting Hole
Enclosure Clamp Latches
Combination SET Button &
Status LED
Cable Connector
LED Behaviors
Blinking Red Once,
Then Green Once
Device Start-Up
Blinking Red And Green
Alternately
Restoring to Factory
Defaults
Blinking Red Once
Valve Closing
Quick Blinking Red
Twice
Valve is Closed
Blinking Green Once
Valve Opening
Quick Blinking Green
Control-D2D Pairing in
Progress
Quick Blinking Red
Control-D2D Unpairing
in Progress
Slow Blinking Green
Updating
Fast Blinking Red Once
Every 30 Seconds
Low Battery, Replace
Batteries Soon

09
Power Up
F
Power up the Valve Controller 1 by briefly
pressing the SET button, until the LED flashes
(red, then green).
SET button

10
Install the App
G
Open the app and tap Sign up for an account.
You will be required to provide a username and a
password. Follow the instructions, to set up a
new account. Allow notifications, when
prompted.
You will immediately receive a welcome email
from no-r[email protected] with some helpful
information. Please mark the yosmart.com
domain as safe, to ensure you receive important
messages in the future.
Log in to the app using your new username and
password.
The app opens to the Favorite screen. This is
where your favorite devices and scenes will be
shown. You can organize your devices by room,
in the Rooms screen, later.
If you are new to YoLink, please install the app
on your phone or tablet, if you have not already.
Otherwise, please proceed to the next section.
Scan the appropriate QR code below or find the
“YoLink app” on the appropriate app store.
Apple phone/tablet
iOS 9.0 or higher
Android phone/tablet
4.4 or higher

11
1. Tap Add Device (if shown) or tap the scanner
icon:
Scanner icon
2. Approve access to your phone’s camera, if
requested. A viewfinder will be shown on the
app.
3. Hold the phone over the QR code so that the
code appears in the viewfinder. If successful, the
Add Device screen will be displayed.
Add Your Valve Controller 1
to the App
H

12
Add Your Valve Controller 1 to
the App, Continued
H
4. You can change the device name and assign it
to a room later. Tap Bind device.
5. If successful, the screen will appear as shown.
Tap Done.

13
Install the Valve Controller 1
I
Preparing for installation:
Determine where you will mount the valve
controller. The Valve Controller 1 was designed
to be wall-mounted, at an indoor or outdoor
location.
If installing your Valve Controller 1 and/or valve
device at an outdoor location, please first refer to
the environmental range specifications, found on
the Valve Controller 1 product support page of
our website. Also, while the Valve Controller 1,
the Bulldog Valve Controller and our motorized
valves are rated for outdoor use, to ensure years
of dependable operation, provide protection from
rain and direct sunlight with overhead cover, in
the form of an enclosure or rain hood.�
Do not install your valve controller or valve
device at a location where it will be submerged
in water.
With the use of optional extension cables, the
valve controller can be installed remotely from
the Bulldog or motorized valve. In some cases
this may allow placing the controller at a more
convenient or more accessible location (for
battery replacement, etc.). The location of the
valve controller must be within the limits of the
cables. If in doubt, connect all applicable cables
between the controller and the valve device and
choose an appropriate location for the controller.
(Extension cables can be purchased on our
website.)

14
Install the Valve Controller 1,
Continued
I
Determine how you will mount the valve
controller to the wall, and ensure you have the
appropriate mounting hardware (screws,
anchors, etc.) for the wall surface.
Install the Valve Controller 1:
1. Holding the valve controller at the desired
location, and using a marker or pencil, transfer
the valve controller’s top mounting hole location
to the wall surface.
2. If using wall anchors, install one at the top
mounting hole location, per the manufacturer’s
instructions (drill a pilot hole first, etc.)
3. Insert a screw in the top mounting hole
location, but do not screw it flush with the wall;
leave space on the end of the screw for the valve
controller.
4. Hang the valve controller on this screw, and it
should be level on the wall. Optionally, you can
verify the valve controller is level with a level tool
at this time.
5. Tighten the screw, and confirm the valve
controller is secured to the wall surface.
To install a motorized valve, go to page 28. To
install a Bulldog Valve Robot, proceed to the next
page.

15
Get to Know Your Bulldog
Valve Robot
J
Clutch Pin
Handle and Position Indicator
Mounting Tab
Rocker Arm
Handle-Supporting Bolt
Output Shaft of Bulldog
Brackets
Valve Control Cable
Valve Status Cable
(Do not use this 3-pin connector,
if present)
Please note: the existing ball valve must be in
good working order. It must open and close
smoothly, with minimal effort, and it must close
fully, shutting off the water completely. The
Bulldog Valve Robot is not able to correct
mechanical issues of the ball valve.

16
Install the Bulldog Valve Robot
K
1. Select the appropriate bracket for your
application. The appropriate bracket fits over the
ball valve (where it is connected to the pipe) and
can subsequently be tightened securely to the
ball valve. If the bracket does not fit over the ball
valve, or seems to be too loose, try the other
bracket.
2. Loosen the two screws on the bracket, to
allow for separating it into two pieces, as shown.

17
Install the Bulldog Valve Robot,
Continued
K
3. Place the upper bracket and lower bracket on
the valve, as shown, and loosely tighten the
screws.
Important! The bracket must be mounted to the
ball valve, not to the pipe. The ball valve should
have at least one side shaped like a nut or bolt
head. The brackets will not tighten to pipe or to a
round portion of the ball valve.

18
Install the Bulldog Valve Robot,
Continued
K
4. Position the bracket so that it is aligned with
the pivot point of the ball valve, by visualizing a
line between the tab slot and the pivot point, as
shown.
5. Remove the screw from the tab slot, then
attach the Valve Robot to the bracket.
Pivot Point
Tab Slot
