Yolink Smart Lock M1 User manual

YoLink Smart Lock M1
User Guide
YS7606-UC

Contents
Package List···································································1
General Warning & Cautions···············································2
Installation·····································································11
Introduction···································································4
Features·······································································6
Set Up YoLink Smart Lock M1···············································7
Using YoLink App with Smart Lock M1·························17YoLink
Unlock the Door······························································21
Set the Admin Password··················································20
Product Requirements······················································6
Lock the Door································································24
Troubleshooting·····························································29
Specifications································································28
Maintaining the YoLink Smart Lock M1··································26
Customer Service & Warranty············································31

Package List
1
A.B.
D.G.H.
C.E.F.F1 F2 F3

GENERAL WARNING & CAUTIONS
The back module (part B) needs to be protected
from weather.
DO NOT USE
POWER DRILL
Tools Required (not included)
Left Handed & Right Handed Setting
When entering the doorway, if the hinges are
on the left, turn the button into 1 on back
module. If the hinges are on the left, turn the
button into 2 on back module (Part B).
2
C S 1 2
12

Battery Precautions
Do not mix old with new batteries.
Do not use rechargeable batteries.
Remove batteries from product when storing for extended periods of time.
Do not dispose of batteries in fire as they may explode. Please follow your local battery
disposal procedure.
Do not puncture batteries. Electrolyte leakage from the batteries is corrosive and can
cause serious harm to the eyes or skin. If swallowed, the electrolyte can be toxic.
Do not allow conductive materials such as jewelry or metal tools to make contact with
the batteries which may cause a short circuit. With a short circuit, the batteries and
conductive material can become extremely hot and cause burns.
3

Introduction
Along with the YoLink App, connect the Smart Lock M1 to your home network. After set up the
Smart Lock M1, you will be able to lock or unlock your door, manage different user password with
internet connection.
4
BACK MODULE
C S 1 2
SET BUTTON
LEFT HANDED OR
RIGHT HANDED
KEYPAD
0~9 DIGITAL BUTTON
LOCK BUTTON
UNLOCK BUTTON
FRONT MODULE

LED light can show you the current status. See the explanation below:s
5
Blue
Entering password.
KEYPAD LIGHT
Red Once
Door is locked.
LOCK BUTTON LIGHT
Blinking Red
Factory Resetting.
Green Once
Door is unlocked.
UNLOCK BUTTON LIGHT
Blinking Green
Connecting to cloud.

Product Requirements
Features
A Screwdriver.
A YoLink Hub.
A smartphone or tablet running iOS 9 or higher; Android 4.4 or higher.
Three Ways to Unlock - YoLink App, password and key.
Control from Anywhere - CONVENIENTLY OPEN AND CLOSE your door with your mobile
device anywhere, anytime.
User Management - Set user password or visitor password via YoLink App when the account
is an admin account.
Scramble PIN Code - Random digits BEFORE, AFTER, or IN THE MID of the right
password.
Battery Status - Update surplus of battery power and send low battery alert.
Continuous Incorrect Password Alert - Remind you with beeps and 5 minutes of keypad locked
when entering incorrect password 5 times in 5 minutes.
Automation - Set up rules for “If this then that” function.
6

Set Up YoLink Smart Lock M1
Follow the steps below to set up your YoLink Smart Lock M1 via YoLink App.
7
Step 1: Set up YoLink App
Get the YoLink App from the Apple App Store or Google Play.

If you don’t have a YoLink account, tap Sign up for an account and follow the steps
to sign up an account.
Open the App. Use your YoLink account to log in.
Step 2: Log in or sign up with YoLink account
8

Step 3: Add device to YoLink App
b. Room - Choose a room for YoLink Smart Lock M1.
a. Name - Name YoLink Smart Lock M1.
You can customize the name, set the room, add to/remove from favourite.
Tap the “ ” in YoLink App. Scan the QR Code on the device.
Tap the “Bind Device” to add the device to your YoLink account.
9
Follow the following page to install the device, power it on. And the device is ready to go.
c. Favourite - Click “ ” icon to add/remove from Favourite.
a
b
c

Step 4: Connect to the cloud
Follow the Installation to install the device first.
Power on the smart lock using the supplied batteries and your device will connect to the cloud
automatically.
Note
Make sure you hub is connected to internet.
10
Cloud
Internet

Installation
Step 1: Adjust Latch Backset
Rotate the buckle anticlockwise to adjust the
latch backset.
E.
60mm(23/8′′)
70mm(23/4′′)
11

F3
Step 2: Install Door Latch
12

Step 3: Mount Front Module
13

Step 4: Fasten Back Mounting Plate
F1
D.
14

Step 5: Mount & Fasten Back Module
F2
4X
AA
12
C
S
12
C
S
12
S
C
RIGHT HANDED LEFT HANDED
15

Step 6: Install Battery Cover
12
C
S
16

Using YoLink App with YoLink Smart Lock M1
Details
a. Name - Name YoLink Smart Lock M1.
b. Room - Choose a room for YoLink Smart Lock M1.
You can customize the name, set the room, add to/ remove from favourite, check device history.
e. Delete - The device will be removed from your
account.
d. History - Check the history log for the YoLink Smart
Lock M1.
Tap the “YoLink Smart Lock M1” in App to go to
its controls.
Tap the icon for each of the setting you want to
personalize.
Tap the “ ” icon at the top-right corner to go to
details.
c. Favourite - Click “ ” icon to add/remove from
Favourite. a
b
c
d
e
17

Set the User Password or Visitor Password
Tap the “YoLink Smart Lock M1” in App to go to
its controls.
Within the Add Password screen, enter a 4-8
digits password or get a visitor password, set
the member's name, you preferred valid time for
the password.
Tap “ ” to add a new password.
Tap “Password” and get the authorization with
admin password to open the Password screen.
Note
Support 1 visitor password and maximum 30 user
passwords.
Visitor password can use only once, and will be
invalid after 24 hours.
18
Not support admin password setting.
