YOODA 35R User manual

INSTRUCTION FOR 'R' TYPE MOTORS: 35R AND 45R
Non-compliance with the specification might cause risk for life or health and can determine proper work of the roller shutter.
We strongly recommend to comply with the specification.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license.
www.sukcesgroup.pl
R type motors with built-in radio receiver are wireless and can
be controlled with a remote. Motor is designed to automate
roller shutters or roller gates. Motors are equipped with
microswich, that makes transmitter programming much
easier. Mechanically set limit positions allow roller shutter to
stop on desired level. Motors are compatible with all YOODA
brand remotes.
Radio receiver memory:
up to 20 transmitters.
Max time of continous work:
4 min.
Power supply:
230 V / 50 Hz
Operating temperature:
od -25°C from to 50°C
Stopień ochrony:
IP 44
Maximal time of continuous work is 4 minutes. After that time thermal protection will be activated preventing motor form overheating.
After that motor will be disabled for about 20 minutes until it cools down.
Safety measures
Before installing or using motor please read the following instruction. Installation of the tubular motor should be performed by special-
ists with 1kV or higher SEP-certified electrician's licence (SEP - Association of Polish Electrical Engineers) or equal license. Montage
should be done by a qualified installer with compliance with all requirements and norms implemented in the country of installation as
well as should transfer all information concerning usage and maintenance of the device to the user. Non-compliance to this instruction
of installation and usage can present risks to health and safety of installer and/or user and may cause failures in correct operation of
the roller shutter. Negligence of mentioned safety measures may lead to the lapse of liability for damages in the event of damage or
loss.
Motors torque parameter should be adequate to the
weight of the roller shutter curtain.
Wiring should be mounted in a way preventing
water from entering the tubular motor.
Electrical system control should be performed
regularly to detect any signs of use or damage
of the motor.
Electrical supply needs to be disconnected before
conducting any maintenance, cleaning and/or repair
work.
power supply cable radio receiver
limit switches
limit position
regulators
motor brake gear
antenna
microswitch
capacitor
General information

Safety measures
Motor should be mounted in places protected from unfavourable weather conditions.
All contact of the motor with any liquids should be
reduced to minimum.
No tools should be used when placing motor
in the tube.
During the adapter montage special attention must be
paid not to damage the motor.
Motor and its control system should be kept out
or reach of children.
INSTRUCTION FOR 'R' TYPE MOTORS: 35R AND 45R
Non-compliance with the specification might cause risk for life or health and can determine proper work of the roller shutter.
We strongly recommend to comply with the specification.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license.
Placing motor in the tube
www.sukcesgroup.pl
1. Cut the tube
to the proper length.
2. Deburr the edges
and remove the metal residue.
3. Place the adaptation
on the motor.
4. Measure the distance (L)
between the inner edge of motors head
and the end of the motors adaptor.
5. Insert the motor into the tube
up to the point of connection
between the edge of the tube
and the inner edge of the motors head.
6. Secure the tube to the
coupling part of the adaptation
using 4 screws or rivets, placed
at L-7 mm distance from the
inner edge of the motors head.

Connection
230 V AC
phaze wire neutral wire protective wire
LN
INSTRUCTION FOR 'R' TYPE MOTORS: 35R AND 45R
Non-compliance with the specification might cause risk for life or health and can determine proper work of the roller shutter.
We strongly recommend to comply with the specification.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license.
Range
Radio receiver range is a variable value and can differ from declared values depending on conditions in which device
operates. Possible sources of changes in range are building construction, interference caused by other radio transmitters
etc.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license. Device is designed to operate in places shielded from
unfavourable weather conditions. Motor should be installed in accordance with all provisions of regional law and profes-
sional standards. All cables connecting power receiver with electric source should be protected from overload and
short-circuits effects with devices automatically disconnecting power. Device should be powered with a separate source
and protected only with a fast-blow fuse (never slow-blow fuse). Creating electrical system using inadequate fuse may
result in loosing rights under the provisions of warranty. When connecting device to power source with cables with
adequate cross-section should be used. Long-lasting output load capacity table should be the ground for choosing
adequate cables.
www.sukcesgroup.pl
brown wire - phaze
Adequate way to place cables,
antenna and microswitch.
230 V / 50 Hz
yellow-green wire - protective
blue wire - neutral
230 V / 50 Hz 200 m 35 m 433,92 MHz
L1
outdoor L2 indoor Operating frequency
20
Roller shutter with remotely controlled motor
L2L1

Setting limit positions
Limit positions need to be set manually using supplied regulator.
Decrease of the range
Increase of the range
Motors spin direction
Direction of limit position
switches regulation
For setting bottom or top limit position roller shutter needs to be
started (opening or closing direction) until it stops at the factory
set height. For increasing the range of limit position turn the
rotary regulator in the ‘+’ direction. Analogically, for decreasing
the range, turn in the ‘-‘ direction.
Changing motors direction
Programming first transmitter
INSTRUCTION FOR 'R' TYPE MOTORS: 35R AND 45R
Non-compliance with the specification might cause risk for life or health and can determine proper work of the roller shutter.
We strongly recommend to comply with the specification.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license.
www.sukcesgroup.pl
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
Turn on power supply or press
microswitch (approx. 2 sec.)
when power is on.
Motor will make a sound.
Roller shutter will make
an up/down move.
Motor will make
a sound.
Press
programming button (P2)
on the remote.
or
Roller shutter will
make an up/down
move as the motor will
make few sounds.
Motor will make
a sound.
Press
programming button
(P2) on the remote.
Press UP button
on the remote.
When pressing DOWN
button roller shutter
moves up.
When pressing DOWN
button roller shutter
moves down.
Roller shutter will make an up/down
move as the motor will make
few sounds.
Press microswitch
for aprox. 6 seconds.

Receiver can be controlled by up to 20 transmitters.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
Programming another transmitter
Deleting memory of motors radio receiver will cause for all programmed transmitters to be lost.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
To reverse this procedure please repeat the instruction.
Deleting radio receiver memory
Activating impulse mode
INSTRUCTION FOR 'R' TYPE MOTORS: 35R AND 45R
Non-compliance with the specification might cause risk for life or health and can determine proper work of the roller shutter.
We strongly recommend to comply with the specification.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license.
www.sukcesgroup.pl
Motor will
make a sound.
Roller shutter
will make an
up/down move.
Motor will
make a sound.
Roller shutter will
make an up/down
move as the motor will
make few sounds.
Press
programming button (P2)
on already programmed
and working remote (A).
Press
programming button (P2)
on already programmed
and working remote (A).
Press
programming button (P2)
on new remote (B).
Both remotes
controll motor.
Motor will
make a sound.
Roller shutter
will make an
up/down move.
Motor will
make a sound.
Roller shutter will
make an up/down
move as the motor will
make few sounds.
All previously programmed
and working remotes have
been deleted.
Press
programming button (P2)
on already programmed
and working remote.
Press
STOP button
on previously
used remote.
Press
programming button (P2)
on used remote.
Motor will
make a sound.
Roller shutter
will make an
up/down move.
Press
programming button (P2)
on already programmed
and working remote.
Press
programming button (P2)
on previously used remote.
Roller shutter will
make an up/down
move as the motor will
make few sounds.
When motor is in impulse
mode single push of a button
on the remote will cause
motor to make
1/16 of a full turn.
Press
UP button
on previously
used remote.
Motor will
make a sound.

When programming key-ring remotes that do not have additional P2 programming button the same function is substituted
with simultaneous push of STOP and UP buttons.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
Programming key-ring remotes
INSTRUCTION FOR 'R' TYPE MOTORS: 35R AND 45R
Non-compliance with the specification might cause risk for life or health and can determine proper work of the roller shutter.
We strongly recommend to comply with the specification.
Installation of the tubular motor should be performed by specialists with 1kV or higher SEP-certified electrician's licence
(SEP - Association of Polish Electrical Engineers) or equal license.
www.sukcesgroup.pl
Turn on power supply or press
microswitch (approx. 2 sec.)
when power is on.
Motor will make a sound.
Roller shutter will make an
up/down move.
Motor will
make a sound.
or
Roller shutter will
make an up/down
move as the motor will
make few sounds.
Motor will
make a sound.
Press
UP button
on the remote.
Simultaneously
press STOP
and UP
programming buttons.
Simultaneously
press STOP
and UP
programming buttons.
