YOODA 18LE Series User manual

LE type motors equipped with a radio receiver are wireless
and can be controlled with a remote. They are designed for
automation of roller shutters. They have electronic limit
switches which are programmed by the remote control.
Built-in battery allows motor installation without power
supply. LE type motores are compatible with all YOODA trans-
mitters.
Radio receiver memory:
up to 20 transmitters
Power supply:
12 V DC
Operating temperature:
from -5°C to 50°C
Protection degree:
IP 40
Load:
up to 1,5 kg
Illustrations (from the top):
Fig. 1. 18 LE motor with radio receiver (for roller blind in the cassette)
Fig. 2. 18 LE motor with radio receiver (for roller blind free-hanging)
Non-compliance with the specification might cause risk for life or health and can determine proper work of the blind.
We strongly recommend to comply with the specification.
18LE SERIES TUBULAR MOTOR
www.sukcesgroup.pl
1. General information
1
battery
charging socket
programming button
motor gear
antenna
radio receiver,
limit switches system

Motor should be mounted in places protected from unfavourable weather conditions. Do not pull the motor head when
removing it from the tube.
1. Cut the tube
to the proper length.
2. Deburr the edges
and remove the metal residue.
3. Place the adaptation
on the motor.
4. Measure the distance (L)
between the inner edge of motors head
and the end of the motors adaptor.
5. Insert the motor into the tube
up to the point of connection
between the edge of the tube and
the inner edge of the motors head.
Attach the tube to the
coupling part of the adaptation
2. Safety measures
3. Placing motor in the tube
Before installing or using motor please read the following instruction. The installer must comply with the standards and regulations in
force in the country where the appliance will be installed and provide information to users about the conditions and maintenance of the
device. Failure to follow these instructions can present risk to life and health, or invalid functioning of the roller shutter. This also
results in the loss of warranty rights.
Motors torque parameter should be adequate to the
weight of the roller shutter curtain.
Do not hit the motor. Reduce the vibration of the
motor to a minimum.
Electrical system control should be performed
regularly to detect any signs of use or damage
of the motor.
All contact of the motor with any liquids should be
reduced to minimum.
No tools should be used when placing motor
in the tube.
During the adapter montage special attention must
be paid not to damage the motor.
Motor and its control system should be kept out
or reach of children.
4. Charging
1. It is recommended to charge the battery by min. 3 hours.
2. Ensure that the drive is fully charged before initial startup.
3. Charge the battery at least once every 6 months.
4. Use only power supply, dedicated to the device. Using another power supply may damage the motor.
2

Connect the motor
to the power supply.
During charging, the LED diode
on the power supply light is red.
When the battery is fully charged,
the LED diode will turn to green.
5. Range
6. Programming first transmitter
7. Changing motors direction
Radio receiver range is a variable value and can differ from declared values depending on conditions in which device
operates. Possible sources of changes in range are building construction, interference caused by other radio transmitters etc.
12 V DC 200 m 35 m 433,92 MHz
L1
outdoor L2 indoor Operating frequency
20
Blind with remotely controlled motor
L2L1
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
Press and hold for about
2 seconds programming button
on the motor head.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Press programming button
P2 on the remote control.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Press programming
button P2 on the
remote control.
Press up button.
When pressing DOWN
button blind
moves up.
When pressing DOWN
button blind
moves down.
Blind will
make up/down
movement.
Press and hold
for about 6 seconds
programming button
on the motor head.
3

8. Programming limit positions
9. Removing limit positions
10. Programming the third limit position
4
To set the upper and lower limit position press the programming button P2 during the motor movement, it causes the work displace-
ment. Then you can precisely set the limit positions. Pressing the P2 button again motor will run continuously.
Press
programming
button P2.
Press
UP button.
Press
programming
button P2 again.
Upper limit position
Press
UP button.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
When the roller shutter
reaches upper limit
position press STOP
button.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Press STOP button
5 times at 0.5 sec intervals
to confirm the upper
limit position.
Press STOP button
5 times at 0.5 sec intervals
to confirm the lower limit
position.
Press
DOWN button.
Limit positions
has been programmed.
Lower
limit position.
When
the blind
reaches lower
limit position
press STOP button.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Limit positions
has been removed.
Press
programming
button P2.
Press
programming
button P2 again.
Press
DOWN button.
1. After setting the upper and lower limit positions, it is possible to set the third position (favorite) between those positions.
2. Hold the STOP button for 3 seconds to set the blind in third limit position.
3. When the motor is in pulse mode, hold the STOP button for 3 seconds, blind reaches lower limit position, and then to the set third
position.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Favourite position
has been set.
Press
STOP button
once.
Press
STOP button
once.
Blind
will make up/down
movement.
Upper limit position
has been set.
Lower limit position
has been set.
An example of the third
limit position
Set the blind
in favourite position.
Press
programming
button P2.

11. Removing third limit position
12. Programming another transmitter
13. Deleting another transmitter
14. Deleting motor memory
5
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Favourite position
has been removed.
Press
programming
button P2.
Press
STOP button
once.
Press
STOP button
once.
Receiver can be controlled by up to 20 transmitters.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from programming
mode without saving any changes.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Press
programming
button P2
on the A remote control.
Press
programming
button P2
on the A remote control.
Press
programming
button P2
on the B remote control.
Remote control
has been programmed.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Press
programming
button P2
on the A remote control.
Press
programming
button P2
on the A remote control.
Press
programming
button P2
on the B remote control.
Remote control
has been removed.
Deleting memory of motors radio receiver will cause for all programmed transmitters to be lost.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from programming
mode without saving any changes.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
All active transmitters have
been removed from memory.
Press
programming
button P2
on any remote control.
Press
STOP button.
Press
programming
button P2
on remote control.

15. Activating impulse mode
16. Programming key-ring remotes
6
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from programming
mode without saving any changes. To reverse this procedure please repeat the instruction
Blind
will make up/down
movement.
Press
programming
button P2
on any remote control.
Press
DOWN button.
Blind
will make up/down
movement.
When motor is in
impulse mode
single push of a button
on the remote will cause
motor to make
1/16 of a full turn.
Press
UP button.
Blind
will make up/down
movement.
When programming key-ring remotes that do not have additional P2 programming button the same function is substituted with
simultaneous push of STOP and UP buttons.
Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from programming
mode without saving any changes.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Blind
will make up/down
movement.
Press
UP button.
Press simultaneously
STOP and UP
programming buttons.
Press simultaneously
STOP and UP
programming buttons.
Press and hold
for about 2 seconds
programming button
on the motor head.
