TECHNICAL GUIDE
HORIZONTAL DISCHARGE
SPLIT SYSTEM
AIR CONDITIONERS
14 SEER – R-410A – 1 PHASE
2, 3, 4 NOMINAL TONS
MODELS: TCHE24, 36, 48
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.york.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Standard 10-Years limited compressor warranty.
Extended 10-Years limited parts warranty when product is
registered online within 90 days of purchase for replacement
or closing for new home construction.
*Does not apply to 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed
®
5371951-YTG-A-0517
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The 14 SEER TCHE Series condensing unit is the outdoor part
of a versatile system of air conditioning. Optimized for the new
14 SEER Regional Minimum Efficiency and the high EER
required in the Southwest US, these outdoor units are specifi-
cally designed to be matched with York indoor coils, furnaces,
and air handlers to provide a complete system solution.
These remarkably compact units require only minimal service
and airflow clearances, allowing them to be positioned as close
as six inches (6") from the wall. This design allows the unit to be
located virtually anywhere – on the ground, roof, balcony, or
mounted to an outside wall. When installation footprint is lim-
ited, these units can be stacked two-high using the approved
stacking kit.
FEATURES
•Performance - Optimized for the US DOE Southwest
Region and valid for installation in all US DOE Regions.
•Small Footprint - Compact “slim-line” design allows for easy
installation in tight spaces. Units can be stacked two-high
with approved stacking kit.
•QuietDrive™ System - The combination of a swept-wing
fan, rigid base pan, isolated compressor compartment, and
quiet scroll compressor reduce sound to as low as 70 dBA.
•Low Operating Sound Levels - The swept-wing condenser
fan in blow-through configuration provides for whisper-quiet
operation by allowing air to flow smoothly and efficiently
across the fan blades.
•Quality Condenser Coils - The coil is constructed of alumi-
num microchannel tubing and enhanced aluminum fins for
compact size and increased efficiency.
•Environmentally Friendly Refrigerant - The next genera-
tion refrigerant R-410A delivers environmentally friendly per-
formance with zero ozone depletion.
•Durable Cabinet - Heavy-gauge steel cabinet and tubular
base rails provide added support.
•Aesthetic Appearance - Powder paint “Champagne” color
provides an attractive retail finish.
•Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.
• Other Features:
– Factory installed spun copper filter drier
– High pressure and low pressure switches
– Accumulator and crankcase heater in all sizes
– Up to 200’ line set out of the box
– Zero lot line - only 6” minimum clearance from structure

5371951-YTG-A-0517
2 Johnson Controls Unitary Products
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4
COOLING CAPACITY - With Air Handler Coils . . . . . . . . . . . . . . . 5
COOLING CAPACITY - Upflow, Downflow &
Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 6
COOLING CAPACITY - With High Efficiency Motor Furnaces . . . 6
APPLICATIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . 12
SOUND POWER RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 13
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MOUNTING HOLE GRAPHIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 18
PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 20
NOMENCLATURE
BRAND TT= Factory Branded
PRODUCT TYPE CC= Air Conditioner
(US Northern or Southeast Region)
AIRFLOW HH= Horizontal Discharge
NOMINAL
SERIES EFFICIENCY
AND STAGING EE= 14 SEER High EER
(US DOE Southwest Region)
NOMINAL
UNIT CAPACITY
(MBH) 36 24 = 2 Ton
36 = 3 Ton
48 = 4 Ton
STAGING SS = Single Stage Compressor
REFRIGERANT 44 = R-410A Refrigerant
VOLTAGE
(Voltage-Phase-Hertz) 11= 208/230-1-60
3= 208/230-3-60
4= 460-3-60
CONNECTION TYPE SS = Sweat Connect
GENERATION
(MAJOR REVISION) 11= 1st Gen
2= 2nd Gen
etc
STYLE LETTER
(MINOR REVISION)
NOT USED
FOR ORDERING
A
A= Style A
B= Style B
etc

5371951-YTG-A-0517
Johnson Controls Unitary Products 3
.All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of mounting feet to top of unit.
Overall length and width include mounting feet and screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL TCHE24S41S1 TCHE36S41S1 TCHE48S41S1
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
187 to 252
Minimum Circuit Ampacity 18.3 19.1 24.6
Max. Overcurrent Device Amps 2
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
30 30 40
Min. Overcurrent Device Amps 3
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
20 20 25
Compressor Amps Type Scroll Scroll Scroll Rated Load 13.5 14.1 18.5
Locked Rotor 58.3 72.2 124.0
Crankcase Heater Yes Yes Yes
Factory External Discharge Muffler No No No
Factory External Check Valve No No No
HS Kit Required with TXV 4
4. See Hard Start Kit Accessory Installation Manual for Hard Start Kit part number for each model.
No No No
Fan Diameter Inches 23 23 23
Fan Motor
Rated HP 1/4 1/4 1/4
Rated Load Amps 1.3 1.3 1.3
Nominal RPM 850 850 850
Nominal CFM 3200 3200 3050
Coil Face Area Sq. Ft. 11.96 11.96 13.96 Rows Deep 1 1 1
Fins / Inch 23 23 23
Refrigerant Lines5
5. When more than 50 feet of interconnecting tubing and more than 30 feet of vertical lift is used, consult the Application Data (part number 247077). For long-line
applications, interconnecting lines over 100 feet must be installed with liquid line solenoid.
Max. Length 200 200 200
Max. Lift 65 65 65
Max. Drop 150 150 150
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 3/4 3/4 7/8
Unit Charge (Lbs. - Oz.) 6
6. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-
tract the amount of refrigerant, using the difference in length multiplied by the per foot value.
5 - 0 6 - 6 7 - 4
Charge Per Foot, Oz. 0.62 0.62 0.67
Operating Weight Lbs. 195 215 240
B
C
A
DIMENSIONS
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A B C Liquid Vapor
TCHE24S41S1 37-1/4 20 45 3/8 3/4
TCHE36S41S1 37-1/4 20 45
TCHE48S41S1 43-1/4 20 45 7/8

5371951-YTG-A-0517
4 Johnson Controls Unitary Products
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the outdoor unit, the smallest matched indoor unit, and 15 feet of interconnecting line tubing.
2. Verify the TXV and additional charge required for specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For indoor matches requiring additional charge, the refrigerant needs to be weighed in for specific matched indoor unit and lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + charge adder for matched indoor unit +
charge adder for line set.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
System Charge for Various Matched Systems
Outdoor Unit TCHE24S41S1 TCHE36S41S1 TCHE48S41S1
Required TXV 1,2 BA1 BA2 BA2
Indoor Unit 3,4,5Additional Charge, Oz
CF/CM/CU30(B,C,D) 0 – –
CF/CM/CU36(A,B,C,D) 7 – –
FC38C – 0 –
FC49D – – 0
AP30B 0 – –
AP36C 7 – –
AE30B 0 – –
AE36(B,C) 7 – –
AVC30B 0 – –
AVC36(B,C) 7 – –
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil
only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:
1. For applications requiring a TXV use S1-1TVM*** series kit.
2. A TXV kit must be used with these indoor units to obtain system performance.
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require blower Time Delay Kit S1-2FD06700224.
4. CF and FC coils cannot be used in horizontal applications.
5. Refer to Cooling Performance Data tables for actual system performance for specified system matches.

5371951-YTG-A-0517
Johnson Controls Unitary Products 5
— = Not applicable.
MP Modular Air Handlers use Coil Only Ratings.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TCHE24S41S AE30BX21 17.5 – 800 24.0 18.5 15.50 12.75
TCHE24S41S AE36BX21 17.5 – 800 24.0 18.7 15.75 13.00
TCHE24S41S AE36CX21 21.0 – 800 24.0 18.7 16.00 13.00
TCHE24S41S AP30BX21 17.5 – 800 23.8 18.5 14.00 12.25
TCHE24S41S AVC30BX21 17.5 – 825 24.0 18.6 15.75 13.00
TCHE24S41S AVC36BX21 17.5 – 800 24.0 18.7 16.00 13.00
TCHE24S41S AVC36CX21 21.0 – 800 24.0 18.6 16.00 13.00
TCHE24S41S ME08BN21 17.5 CF/CM30B 825 24.0 18.6 15.50 12.75
TCHE24S41S ME08BN21 17.5 CF/CM36B 775 24.0 18.4 15.75 13.00
TCHE24S41S ME12BN21 17.5 CF/CM30B 825 24.0 18.6 15.50 12.75
TCHE24S41S ME12BN21 17.5 CF/CM36B 825 24.0 19.1 15.75 13.00
TCHE24S41S ME14DN21 24.5 CF/CM30D 825 24.0 18.5 15.75 13.00
TCHE24S41S ME14DN21 24.5 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S ME16CN21 21.0 CF/CM30C 800 24.0 18.5 15.00 12.50
TCHE24S41S ME16CN21 21.0 CF/CM36C 825 24.0 19.0 15.00 12.50
TCHE24S41S MVC08BN21 17.5 CF/CM30B 725 24.0 18.0 15.75 13.00
TCHE24S41S MVC08BN21 17.5 CF/CM36B 750 24.0 18.3 15.25 12.75
TCHE24S41S MVC12BN21 17.5 CF/CM30B 775 24.0 18.4 15.25 12.75
TCHE24S41S MVC12BN21 17.5 CF/CM36B 775 24.0 18.5 15.50 12.75
TCHE24S41S MVC14DN21 24.5 CF/CM30D 750 24.0 18.0 15.50 12.75
TCHE24S41S MVC14DN21 24.5 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S MVC16CN21 21.0 CF/CM30C 850 24.0 19.0 15.00 12.50
TCHE24S41S MVC16CN21 21.0 CF/CM36C 850 24.0 19.0 15.25 12.75
TCHE36S41S ME16CN21 21.0 FC38C 1200 36.0 27.2 16.00 13.00
TCHE36S41S MVC16CN21 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE48S41S ME14DN21 24.5 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S ME20DN21 24.5 FC49D 1425 46.5 34.6 15.50 12.50
TCHE48S41S MVC14DN21 24.5 FC49D 1175 45.5 31.8 15.50 12.75
TCHE48S41S MVC20DN21 24.5 FC49D 1375 46.5 34.2 15.50 12.75
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.

5371951-YTG-A-0517
6 Johnson Controls Unitary Products
— = Not Applicable.
MP Modular Air Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER 1EER
TOTAL SENS.
TCHE24S41S CF/CM/CU30B 17.5 600 - 1000 800 24.0 17.5 14.00 12.20
TCHE24S41S CF/CM/CU30B 17.5 600 - 1000 800 24.0 17.5 14.00 12.20
TCHE24S41S CF/CM/CU30C 21.0 600 - 1000 800 23.6 18.1 14.00 12.20
TCHE24S41S CF/CM/CU30C 21.0 600 - 1000 800 23.6 18.1 14.00 12.20
TCHE24S41S CF/CM/CU30D 24.5 600 - 1000 800 23.6 18.1 14.00 12.20
TCHE24S41S CF/CM/CU30D 24.5 600 - 1000 800 23.6 18.1 14.00 12.20
TCHE24S41S CF/CM36A 14.5 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM36A 14.5 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM/CU36B 17.5 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM/CU36B 17.5 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM/CU36C 21.0 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM/CU36C 21.0 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM/CU36D 24.5 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF/CM/CU36D 24.5 600 - 1000 800 23.6 18.3 14.00 12.20
TCHE24S41S CF42B 17.5 600 - 1000 800 23.6 18.0 14.00 12.20
TCHE24S41S CF42B 17.5 600 - 1000 800 23.6 18.0 14.00 12.20
TCHE36S41S FC38C 21.0 1000 - 1400 1200 35.6 27.2 14.00 12.20
TCHE36S41S FC38C 21.0 1000 - 1400 1200 35.6 27.2 14.00 12.20
TCHE48S41S FC49D 21.0 1400 - 1800 1425 46.0 33.8 14.00 12.15
TCHE48S41S FC49D 21.0 1400 - 1800 1425 46.0 33.8 14.00 12.15
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Requires a S1-2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
COOLING CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TCHE24S41S TM8V060A12MP11 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S TM8V080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S TM8V080B12MP11 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S TM8V080C16MP11 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S TM8V080C16MP11 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S TM8V080C16MP11 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S TM8V080C16MP11 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S TM8V100C16MP11 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S TM8V100C16MP11 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S TM8V100C16MP11 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S TM8V100C16MP11 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S TM8X060A12MP11 14.5 CF/CM36A 775 24.0 18.5 15.50 12.75
TCHE24S41S TM8X080B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 15.50 12.75
TCHE24S41S TM8X080B12MP11 17.5 CF/CM/CU36B 800 24.0 18.7 15.75 13.00
TCHE24S41S TM8X080C16MP11 21.0 CF/CM/CU30C 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8X080C16MP11 21.0 CF/CM/CU30D 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8X080C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8X080C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8X100C16MP11 21.0 CF/CM/CU30C 825 24.0 18.5 16.00 13.00
Continued on next page.

5371951-YTG-A-0517
Johnson Controls Unitary Products 7
TCHE24S41S TM8X100C16MP11 21.0 CF/CM/CU30D 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8X100C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8X100C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8X100C20MP11 21.0 CF/CM/CU30C 825 23.8 18.3 14.50 12.25
TCHE24S41S TM8X100C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S TM8X100C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S TM8X100C20MP11 21.0 CF/CM/CU36D 825 24.0 19.1 14.50 12.25
TCHE24S41S TM8X120C20MP11 21.0 CF/CM/CU30C 825 23.8 18.3 14.50 12.25
TCHE24S41S TM8X120C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S TM8X120C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S TM8X120C20MP11 21.0 CF/CM/CU36D 825 24.0 19.1 14.50 12.25
TCHE24S41S TM8Y060A12MP11 14.5 CF/CM36A 775 24.0 18.5 15.50 12.75
TCHE24S41S TM8Y080B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 15.50 12.75
TCHE24S41S TM8Y080B12MP11 17.5 CF/CM/CU36B 800 24.0 18.7 15.75 13.00
TCHE24S41S TM8Y080C16MP11 21.0 CF/CM/CU30C 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8Y080C16MP11 21.0 CF/CM/CU30D 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8Y080C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8Y080C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8Y100C16MP11 21.0 CF/CM/CU30C 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8Y100C16MP11 21.0 CF/CM/CU30D 825 24.0 18.5 16.00 13.00
TCHE24S41S TM8Y100C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8Y100C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TM8Y100C20MP11 21.0 CF/CM/CU30C 825 23.8 18.3 14.50 12.25
TCHE24S41S TM8Y100C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S TM8Y100C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S TM8Y100C20MP11 21.0 CF/CM/CU36D 825 24.0 19.1 14.50 12.25
TCHE24S41S TM8Y120C20MP11 21.0 CF/CM/CU30C 825 23.8 18.3 14.50 12.25
TCHE24S41S TM8Y120C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S TM8Y120C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S TM8Y120C20MP11 21.0 CF/CM/CU36D 825 24.0 19.1 14.50 12.25
TCHE24S41S TM9E040A10MP11 14.5 CF/CM36A 775 24.0 18.4 14.75 12.50
TCHE24S41S TM9E060B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 14.75 12.25
TCHE24S41S TM9E060B12MP11 17.5 CF/CM/CU36B 825 24.0 19.1 14.75 12.25
TCHE24S41S TM9E080B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 14.75 12.25
TCHE24S41S TM9E080B12MP11 17.5 CF/CM/CU36B 825 24.0 19.1 14.75 12.25
TCHE24S41S TM9E080C16MP11 21.0 CF/CM/CU30C 750 24.0 18.0 16.00 13.00
TCHE24S41S TM9E080C16MP11 21.0 CF/CM/CU30D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9E080C16MP11 21.0 CF/CM/CU36C 750 24.0 18.2 16.00 13.00
TCHE24S41S TM9E080C16MP11 21.0 CF/CM/CU36D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9E100C16MP11 21.0 CF/CM/CU30C 750 24.0 18.0 16.00 13.00
TCHE24S41S TM9E100C16MP11 21.0 CF/CM/CU30D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9E100C16MP11 21.0 CF/CM/CU36C 750 24.0 18.2 16.00 13.00
TCHE24S41S TM9E100C16MP11 21.0 CF/CM/CU36D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9E100C20MP11 21.0 CF/CM/CU30C 800 24.0 18.5 15.00 12.50
TCHE24S41S TM9E100C20MP11 21.0 CF/CM/CU30D 800 24.0 18.5 15.00 12.50
TCHE24S41S TM9E100C20MP11 21.0 CF/CM/CU36C 800 24.0 18.6 15.00 12.50
TCHE24S41S TM9E100C20MP11 21.0 CF/CM/CU36D 800 24.0 18.6 15.00 12.50
TCHE24S41S TM9E120D20MP11 24.5 CF/CM/CU30D 825 24.0 18.6 15.25 12.75
TCHE24S41S TM9E120D20MP11 24.5 CF/CM/CU36D 825 24.0 19.1 15.25 12.75
TCHE24S41S TM9V060B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S TM9V060B12MP11 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S TM9V080B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S TM9V080B12MP11 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371951-YTG-A-0517
8 Johnson Controls Unitary Products
TCHE24S41S TM9V080C16MP11 21.0 CF/CM/CU30C 850 24.0 19.0 15.50 12.75
TCHE24S41S TM9V080C16MP11 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S TM9V080C16MP11 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S TM9V080C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TM9V100C16MP11 21.0 CF/CM/CU30C 850 24.0 19.0 15.50 12.75
TCHE24S41S TM9V100C16MP11 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S TM9V100C16MP11 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S TM9V100C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TM9Y040A10MP11 14.5 CF/CM36A 775 24.0 18.4 14.75 12.50
TCHE24S41S TM9Y060B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 14.75 12.25
TCHE24S41S TM9Y060B12MP11 17.5 CF/CM/CU36B 825 24.0 19.1 14.75 12.25
TCHE24S41S TM9Y080B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 14.75 12.25
TCHE24S41S TM9Y080B12MP11 17.5 CF/CM/CU36B 825 24.0 19.1 14.75 12.25
TCHE24S41S TM9Y080C16MP11 21.0 CF/CM/CU30C 750 24.0 18.0 16.00 13.00
TCHE24S41S TM9Y080C16MP11 21.0 CF/CM/CU30D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9Y080C16MP11 21.0 CF/CM/CU36C 750 24.0 18.2 16.00 13.00
TCHE24S41S TM9Y080C16MP11 21.0 CF/CM/CU36D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9Y100C16MP11 21.0 CF/CM/CU30C 750 24.0 18.0 16.00 13.00
TCHE24S41S TM9Y100C16MP11 21.0 CF/CM/CU30D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9Y100C16MP11 21.0 CF/CM/CU36C 750 24.0 18.2 16.00 13.00
TCHE24S41S TM9Y100C16MP11 21.0 CF/CM/CU36D 775 24.0 18.4 16.00 13.00
TCHE24S41S TM9Y100C20MP11 21.0 CF/CM/CU30C 800 24.0 18.5 15.00 12.50
TCHE24S41S TM9Y100C20MP11 21.0 CF/CM/CU30D 800 24.0 18.5 15.00 12.50
TCHE24S41S TM9Y100C20MP11 21.0 CF/CM/CU36C 800 24.0 18.6 15.00 12.50
TCHE24S41S TM9Y100C20MP11 21.0 CF/CM/CU36D 800 24.0 18.6 15.00 12.50
TCHE24S41S TM9Y120D20MP11 24.5 CF/CM/CU30D 825 24.0 18.6 15.25 12.75
TCHE24S41S TM9Y120D20MP11 24.5 CF/CM/CU36D 825 24.0 19.1 15.25 12.75
TCHE24S41S TMLV060A12MP11 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S TMLV080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S TMLV080B12MP11 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S TMLV080C16MP11 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S TMLV080C16MP11 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S TMLV080C16MP11 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S TMLV080C16MP11 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S TMLV100C16MP11 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S TMLV100C16MP11 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S TMLV100C16MP11 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S TMLV100C16MP11 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S TMLX060A12MP11 14.5 CF/CM36A 775 24.0 18.5 15.50 12.75
TCHE24S41S TMLX080B12MP11 17.5 CF/CM/CU30B 800 24.0 18.5 15.50 12.75
TCHE24S41S TMLX080B12MP11 17.5 CF/CM/CU36B 800 24.0 18.7 15.75 13.00
TCHE24S41S TMLX080C16MP11 21.0 CF/CM/CU30C 825 24.0 18.5 16.00 13.00
TCHE24S41S TMLX080C16MP11 21.0 CF/CM/CU30D 825 24.0 18.5 16.00 13.00
TCHE24S41S TMLX080C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S TMLX080C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TMLX100C16MP11 21.0 CF/CM/CU30C 825 24.0 18.5 16.00 13.00
TCHE24S41S TMLX100C16MP11 21.0 CF/CM/CU30D 825 24.0 18.5 16.00 13.00
TCHE24S41S TMLX100C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S TMLX100C16MP11 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TMLX100C20MP11 21.0 CF/CM/CU30C 825 23.8 18.3 14.50 12.25
TCHE24S41S TMLX100C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S TMLX100C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371951-YTG-A-0517
Johnson Controls Unitary Products 9
TCHE24S41S TMLX100C20MP11 21.0 CF/CM/CU36D 825 24.0 19.1 14.50 12.25
TCHE24S41S TMLX120C20MP11 21.0 CF/CM/CU30C 825 23.8 18.3 14.50 12.25
TCHE24S41S TMLX120C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S TMLX120C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S TMLX120C20MP11 21.0 CF/CM/CU36D 825 24.0 19.1 14.50 12.25
TCHE24S41S TP9C060B12MP12 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S TP9C060B12MP12 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S TP9C080B12MP12 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S TP9C080B12MP12 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S TP9C080C16MP12 21.0 CF/CM/CU30C 850 24.0 19.0 15.50 12.75
TCHE24S41S TP9C080C16MP12 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S TP9C080C16MP12 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S TP9C080C16MP12 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TP9C100C16MP12 21.0 CF/CM/CU30C 850 24.0 19.0 15.50 12.75
TCHE24S41S TP9C100C16MP12 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S TP9C100C16MP12 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S TP9C100C16MP12 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S TPLC060A12MP12 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S TPLC080B12MP12 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S TPLC080B12MP12 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S TPLC080C16MP12 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S TPLC080C16MP12 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S TPLC080C16MP12 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S TPLC080C16MP12 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S TPLC100C16MP12 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S TPLC100C16MP12 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S TPLC100C16MP12 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S TPLC100C16MP12 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S YP9C060B12MP12 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S YP9C060B12MP12 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S YP9C080B12MP12 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S YP9C080B12MP12 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S YP9C080C16MP12 21.0 CF/CM/CU30C 850 24.0 19.0 15.50 12.75
TCHE24S41S YP9C080C16MP12 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S YP9C080C16MP12 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S YP9C080C16MP12 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S YP9C100C16MP12 21.0 CF/CM/CU30C 850 24.0 19.0 15.50 12.75
TCHE24S41S YP9C100C16MP12 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S YP9C100C16MP12 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S YP9C100C16MP12 21.0 CF/CM/CU36D 825 24.0 19.1 16.00 13.00
TCHE24S41S YPLC060A12MP12 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S YPLC080B12MP12 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S YPLC080B12MP12 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S YPLC080C16MP12 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S YPLC080C16MP12 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S YPLC080C16MP12 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S YPLC080C16MP12 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
TCHE24S41S YPLC100C16MP12 21.0 CF/CM/CU30C 900 24.0 19.1 15.00 12.50
TCHE24S41S YPLC100C16MP12 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S YPLC100C16MP12 21.0 CF/CM/CU36C 875 24.0 19.3 15.25 12.75
TCHE24S41S YPLC100C16MP12 21.0 CF/CM/CU36D 900 24.0 19.5 15.25 12.75
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371951-YTG-A-0517
10 Johnson Controls Unitary Products
TCHE36S41S TM8V080C16MP11 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S TM8V100C16MP11 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S TM8V100C20MP11 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S TM8V120C20MP11 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S TM8X080C16MP11 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE36S41S TM8X100C16MP11 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE36S41S TM8X100C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM8X120C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM8Y080C16MP11 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE36S41S TM8Y100C16MP11 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE36S41S TM8Y100C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM8Y120C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9E080C16MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9E100C16MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9E100C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9V080C16MP11 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S TM9V100C16MP11 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S TM9V100C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9Y080C16MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9Y100C16MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TM9Y100C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TMLV080C16MP11 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S TMLV100C16MP11 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S TMLV100C20MP11 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S TMLV120C20MP11 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S TMLX080C16MP11 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE36S41S TMLX100C16MP11 21.0 FC38C 1200 35.8 27.2 15.50 12.75
TCHE36S41S TMLX100C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TMLX120C20MP11 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TP9C080C16MP12 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S TP9C100C16MP12 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S TP9C100C20MP12 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S TPLC080C16MP12 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S TPLC100C16MP12 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S TPLC100C20MP12 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S TPLC120C20MP12 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S YP9C080C16MP12 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S YP9C100C16MP12 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S YP9C100C20MP12 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S YPLC080C16MP12 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S YPLC100C16MP12 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S YPLC100C20MP12 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S YPLC120C20MP12 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE48S41S TM8V080C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S TM8V100C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S TM8V100C20MP11 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S TM8V120C20MP11 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S TM8X080C16MP11 21.0 FC49D 1400 46.0 34.0 14.75 12.25
TCHE48S41S TM8X100C16MP11 21.0 FC49D 1400 46.0 34.0 14.75 12.25
TCHE48S41S TM8X100C20MP11 21.0 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S TM8X120C20MP11 21.0 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S TM8Y080C16MP11 21.0 FC49D 1400 46.0 34.0 14.75 12.25
Continued on next page.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371951-YTG-A-0517
Johnson Controls Unitary Products 11
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
TCHE48S41S TM8Y100C16MP11 21.0 FC49D 1400 46.0 34.0 14.75 12.25
TCHE48S41S TM8Y100C20MP11 21.0 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S TM8Y120C20MP11 21.0 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S TM9E080C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 11.75
TCHE48S41S TM9E100C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 11.75
TCHE48S41S TM9E100C20MP11 21.0 FC49D 1400 46.0 34.0 15.00 12.50
TCHE48S41S TM9E120D20MP11 24.5 FC49D 1400 46.5 34.4 15.10 12.50
TCHE48S41S TM9V100C20MP11 21.0 FC49D 1350 46.0 33.6 14.75 12.25
TCHE48S41S TM9V120D20MP11 24.5 FC49D 1375 46.0 33.8 15.10 12.50
TCHE48S41S TM9Y080C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 11.75
TCHE48S41S TM9Y100C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 11.75
TCHE48S41S TM9Y100C20MP11 21.0 FC49D 1400 46.0 34.0 15.00 12.50
TCHE48S41S TM9Y120D20MP11 24.5 FC49D 1400 46.5 34.4 15.10 12.50
TCHE48S41S TMLV080C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S TMLV100C16MP11 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S TMLV100C20MP11 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S TMLV120C20MP11 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S TMLX080C16MP11 21.0 FC49D 1400 46.0 34.0 14.75 12.25
TCHE48S41S TMLX100C16MP11 21.0 FC49D 1400 46.0 34.0 14.75 12.25
TCHE48S41S TMLX100C20MP11 21.0 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S TMLX120C20MP11 21.0 FC49D 1425 46.5 34.6 15.10 12.50
TCHE48S41S TP9C100C20MP12 21.0 FC49D 1350 46.0 33.6 14.75 12.25
TCHE48S41S TP9C120D20MP12 24.5 FC49D 1375 46.0 33.8 15.10 12.50
TCHE48S41S TPLC080C16MP12 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S TPLC100C16MP12 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S TPLC100C20MP12 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S TPLC120C20MP12 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S YP9C100C20MP12 21.0 FC49D 1350 46.0 33.6 14.75 12.25
TCHE48S41S YP9C120D20MP12 24.5 FC49D 1375 46.0 33.8 15.10 12.50
TCHE48S41S YPLC080C16MP12 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S YPLC100C16MP12 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S YPLC100C20MP12 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S YPLC120C20MP12 21.0 FC49D 1425 46.0 34.2 15.00 12.50
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. High Efficiency Motor Furnaces have B.O.D (Blower Off Delay) standard.
2. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371951-YTG-A-0517
12 Johnson Controls Unitary Products
APPLICATIONS AND ACCESSORIES
Refer to Price Manual for specific model numbers.
* For Low Ambient and/or Long Lineset Applications, please see the acces-
sories listed below.
Non-Standard Lineset Applications - For installations with
reduced diameter or long linesets, refer to the current version of
the Piping Application Guide P/N 247077, available in the Appli-
cation Bulletins section on www.upgnet.com.
OD Unit Anti Short Cycle Kit (10 Pack) S1-2TD08700124BK:
A time delay that prevents rapid compressor restarting as a
result of power interruption, limit switch operation, or thermostat
resetting. Not required for HP models, or for AC models with
factory electronic controls.
Standard Low Ambient Control Kit S1-2LA06700424: Allows
the use of air conditioning at low outdoor ambient temperatures
down to +20°F (-7°C). For use with all R-410A single stage AC
& HP models.
Advanced Low Ambient Control Kit S1-2LA04701024: Con-
tains the necessary components and controls to allow cooling
operation down to -20ºF (-29ºC). For use with all R-410A single
stage AC & HP models.
Low Pressure Switch Kit S1-2PS06700524: Provides field
installed low pressure (loss of charge) protection. Not required
for HP models, or for AC models with factory electronic con-
trols.
High Ambient Condenser Fan Motor S1-FHM****HT: Class F
70°C motor to allow cooling operation up to 160ºF air entering
the condenser. For use with all R-410A single stage AC & HP
models containing R-410A refrigerant only.
Outdoor Communicating Board Kit (S1-33102952310): Elec-
tronic control upgrade for standard AC & HP units to provide
compatibility with the Residential Touch Screen Communicating
Control.
Start Assist Kit S1-2SA067*****: Provides increased compres-
sor starting torque for areas with low supply voltage. Required
for units with recip compressors when applied with indoor TXV,
and for all units when applied with long linesets or low ambient
kits. May be factory installed on select AC & HP units (see
Physical & Electrical Table). See Price Pages or Source1
SmartSearch for the correct kit for each application.
Compressor Crankcase Heater Kit (S1-025********): A wrap-
around electrical resistance heater that warms the compressor
sump, reducing the chance of liquid slugging on startup.
Required on all long lineset and low ambient applications. See
Price Pages or Source1 SmartSearch for the correct part for
each application.
Indoor Blower-Off Delay Kit S1-2FD06700224: Provides a 1-
minute blower-off delay at the end of the cooling cycle. May be
required for retrofits with non-Johnson Controls Unitary Prod-
ucts indoor units. This feature is factory-provided on all JCUP
indoor products.
Indoor TXV Kit S1-1TVM***: Thermal expansion valves pre-
cisely meter refrigerant for optimum performance over a wide
range of conditions. See System Charge Table, Price Pages, or
Source1 Smart Search for TXV part number for each AC & HP
model.
Cold Weather Charging Tent S1-CHGTENT01: Provides
warm environment to accurately service AC & HP systems in
ambient conditions 55ºF (13ºC) or colder.
Touch-up Paint S1-5130153****: Color matched aerosol paint
for touching up unit chassis and panels. See Price Pages or
Source1 SmartSearch for the correct color for each application.
Compressor Sound Blanket S1-01007xxx000: A field
installed dense foam cover that provides 2dBA sound level
reduction. See Price Pages or Source1 SmartSearch for the
correct blanket for each application.
Thermostat - Compatible thermostat controls are available
through accessory sourcing. For optimum performance, these
outdoor units are fully compatible with the York Hx™ Touch-
screen Thermostat (S1-THXU280*) available through Source1.
For more information, see the thermostat section of the Product
Equipment Catalog.
SOUND POWER RATINGS
Rated in accordance with ARI Standard 270.
Standard Application Limits*
Maximum Lineset Equivalent Length 200 Ft
Outdoor Ambient Temperature Limits
Cooling Operation Maximum DB 120°F
Minimum DB 50°F
Cooling Octave Band Sound Power Level (db re. 1-pW)
Model Number 63 125 250 500 1000 2000 4000 8000 dBA SQI
TCHE24S41S1 73 78 69 67 65 60 57 58 70 19.1
TCHE36S41S1 74 77 68 67 66 61 58 58 71 19.1
TCHE48S41S1 75 81 70 68 66 61 58 58 72 19.0

5371951-YTG-A-0517
Johnson Controls Unitary Products 13
MECHANICAL SPECIFICATIONS
MANUFACTURE AND CERTIFICATIONS
• Units shall be manufactured in an ISO 9001 certified facility.
• Units shall be certified by CSA to UL 1995 / CSA 22.2 and
performance certified to ANSI/AHRI Standard 210/240.
• Units shall be sound tested according to ANSI/AHRI Stan-
dard 270.
• Certified matched system ratings will be available for down-
load from the AHRI online directory at www.ahridirectory.org
• Unit packaging shall be marked, “Assembled in the USA”
UNIT APPLICATION
• Units shall be approved for cooling operation between 50ºF
and 120ºF without modification.
• Units shall be approved for linesets up to 200 feet equivalent
length without modification.
• Units shall be approved for installation within 6 inches of a
flat vertical wall without modification, according to the
instructions in the technical literature.
• Units shall be certified for seismic applications in accordance
with CBC 2007 and IBC 2006.
• Units shall be designed to 72dBA or less to minimize sound
pollution.
UNIT ACCESS
• Units shall have a fan guard that can be removed inde-
pendently of the cabinet for access to the condenser coil.
• Units shall have blow-through airflow for the condensing coil.
• Units shall have a separate compartment for electrical con-
trols that can be accessed without disturbing the unit airflow.
UNIT CONSTRUCTION
• Units shall be shipped completely wired, piped and assem-
bled. Wiring pigtails shall be provided for field control wiring
connections. Service valves shall be provided for field refrig-
erant line connections.
• Units shall be factory leak checked, run tested, and shipped
with a holding charge of R-410A refrigerant.
• Unit cabinet components shall be G90 equivalent steel fin-
ished with powder-coat paint rated at a minimum of 1,000
hours under ASTM B117 testing.
• Unit base pan shall be stamped G90 equivalent steel fin-
ished with powder-coat paint rated at a minimum of 1,000
hours under ASTM B117 testing.
• Units shall have a factory installed spun copper filter-drier for
faster installation and improved system reliability.
• Units shall be constructed with a high pressure switch and a
low pressure switch for system protection.
UNIT COMPONENTS
• Compressor shall be hermetic with internal electrical over-
load protection and internal overpressure protection.
• Compressor shall be mounted on rubber vibration isolators
that do not require the removal of transportation clips or
brackets.
• Units shall be constructed with scroll compressors.
• Condenser fan shall be direct drive with horizontal air dis-
charge.
• Condenser fan shall be direct drive with swept-wing blades
for low sound levels.
• Condenser coil shall be air cooled and constructed of zinc-
coated aluminum microchannel construction for small size
and low weight.
UNIT WARRANTIES
• Unit manufacturer shall provide a 10-Year compressor war-
ranty without a requirement for unit registration.
• Unit manufacturer shall provide a 5-Year parts warranty with-
out a requirement for unit registration.

5371951-YTG-A-0517
14 Johnson Controls Unitary Products
TYPICAL INSTALLATION
MOUNTING HOLE GRAPHIC
TYPICAL FIELD WIRING
THERMOSTAT
WEATHERPROOF
DISCONNECT
SWITCH
6” CLEARANCE
AROUND PERIMETER
MINIMUM 18” CLEARANCE
FOR CONTROL ACCESS PANELS SEAL OPENING(S) WITH
PERMAGUM OR EQUIVANT
TO INDOOR UNIT
NEC CLASS 2 WIRING
TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 1 WIRING
NOTES:
ALL OUTDOOR WIRING MUST BE WEATHERPROOF.
CAN BE STACKED TWO-HIGH WITH APPROVED STACKING KIT.
AIRFLOW
DIRECTION
28.06 7.50
18.73
LARGE CABINET
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
208/230-1-60
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2)
FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*

5371951-YTG-A-0517
Johnson Controls Unitary Products 15
PERFORMANCE DATA - 2 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
CONDENSER-ONLY DATA (OUTDOOR UNIT)
MODEL SATURATEDSUCTION
@ COMPRESSOR Outdoor Ambient Temperature
55 °F 65 °F 75 °F 85 °F 95 °F 105 °F 115 °F 120 °F
T (°F) P (PSIG) MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
TCHE24S41S1
35 107 22.3 2.31 21.2 2.36 20.1 2.36 19.0 2.36 17.8 2.36 16.5 2.36 15.1 2.36 14.4 2.36
40 118 24.6 2.34 23.5 2.34 22.2 2.34 21.0 2.34 19.6 2.34 18.2 2.34 16.8 2.34 16.0 2.34
45 130 27.2 2.33 25.8 2.33 24.5 2.33 23.1 2.33 21.6 2.33 20.1 2.33 18.6 2.33 17.8 2.33
50 142 29.9 2.32 28.4 2.32 26.9 2.32 25.4 2.32 23.8 2.32 22.2 2.32 20.5 2.32 19.7 2.32
55 156 32.8 2.22 31.1 2.31 29.5 2.31 27.8 2.31 26.1 2.31 24.3 2.31 22.5 2.31 21.6 2.31
Notes:
1. For Outdoor Unit (Condenser) performance only. Data does not include the effects of air handler power or heat.
2. Performance based on 15°F subcooling and 15°F superheat at the Outdoor Unit base valves.
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
3. Maximum recommended condensing temperature is 140°F.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCHE24S41S1
INDOOR COIL MODEL NO. CF/CM/CU30B
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 22.0 24.2 30.2 26.6 27.5 23.6 25.3 28.1 27.1 28.2 25.3 26.3 26.0 27.5 28.9 S.C. 22.0 20.2 17.6 17.2 14.2 23.6 22.7 19.4 18.6 15.0 25.2 25.1 21.3 20.0 15.9
K.W. 1.32 1.32 1.65 1.36 1.31 1.39 1.39 1.55 1.41 1.39 1.46 1.46 1.46 1.46 1.46
65 T.C. 24.6 23.6 26.5 25.8 27.4 24.6 24.6 25.9 26.5 28.2 24.7 25.5 25.3 27.2 29.0 S.C. 21.8 20.0 17.3 17.1 14.1 23.2 22.5 19.3 18.8 15.1 24.7 24.9 21.2 20.5 16.1
K.W. 1.68 1.44 1.61 1.46 1.43 1.63 1.52 1.60 1.52 1.51 1.58 1.59 1.58 1.58 1.59
75 T.C. 27.2 22.9 22.8 24.9 27.3 25.6 23.9 23.7 25.9 28.2 24.1 24.8 24.7 26.9 29.1 S.C. 21.7 19.8 17.0 17.0 14.1 22.9 22.3 19.1 18.9 15.2 24.1 24.8 21.2 20.9 16.4
K.W. 2.04 1.57 1.57 1.57 1.56 1.87 1.64 1.64 1.64 1.63 1.71 1.71 1.71 1.71 1.71
85 T.C. 23.4 21.9 21.9 24.1 26.4 23.4 22.9 22.8 25.1 27.2 23.4 24.0 23.7 26.0 28.0 S.C. 20.7 19.4 16.6 16.6 13.7 22.0 21.6 18.7 18.6 14.9 23.4 23.9 20.8 20.7 16.2
K.W. 1.98 1.74 1.74 1.74 1.71 1.93 1.81 1.81 1.81 1.79 1.87 1.88 1.88 1.88 1.87
95 T.C. 19.7 20.9 21.0 23.4 25.5 21.2 22.0 21.8 24.3 26.2 22.7 23.1 22.7 25.2 27.0
S.C. 19.6 18.9 16.2 16.3 13.4 21.1 21.0 18.4 18.4 14.6 22.7 23.0 20.5 20.4 15.9
K.W. 1.92 1.92 1.92 1.92 1.87 1.98 1.98 1.99 1.98 1.95 2.04 2.05 2.05 2.05 2.04
105 T.C. 18.6 19.6 19.6 22.0 24.0 20.0 20.6 20.4 22.8 24.7 21.5 21.7 21.2 23.6 25.5 S.C. 18.6 18.2 15.5 15.7 12.8 20.0 19.9 17.7 17.7 14.1 21.4 21.6 19.8 19.8 15.3
K.W. 2.22 2.21 2.20 2.23 2.19 2.29 2.28 2.27 2.29 2.26 2.36 2.36 2.33 2.35 2.33
115 T.C. 17.6 18.3 18.3 20.6 22.6 19.0 19.3 19.1 21.4 23.3 20.3 20.3 19.8 22.1 24.0 S.C. 17.6 17.6 14.8 15.1 12.2 18.9 18.9 17.0 17.2 13.5 20.3 20.3 19.1 19.2 14.8
K.W. 2.52 2.49 2.47 2.54 2.50 2.59 2.58 2.54 2.60 2.56 2.66 2.66 2.60 2.65 2.62
120 T.C. 16.6 17.1 17.0 19.2 21.1 17.9 18.0 17.7 19.9 21.8 19.1 19.0 18.4 20.6 22.5 S.C. 16.6 16.9 14.2 14.5 11.7 17.8 17.9 16.3 16.6 12.9 19.1 18.9 18.4 18.6 14.2
K.W. 2.82 2.77 2.75 2.85 2.81 2.89 2.87 2.81 2.90 2.86 2.96 2.96 2.88 2.95 2.90
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.

5371951-YTG-A-0517
16 Johnson Controls Unitary Products
COIL MULTIPLIERS - 2 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU30B 1.00 1.00 1.00
– CF/CM/CU30C 0.98 1.03 0.98
– CF/CM/CU30D 0.98 1.03 0.98
– CF/CM36A 0.98 1.05 0.98
– CF/CM/CU36B 0.98 1.05 0.98
– CF/CM/CU36C 0.98 1.05 0.98
– CF/CM/CU36D 0.98 1.05 0.98
– CF42B 0.98 1.03 0.98
AE30BX21 – 1.00 1.05 0.96
AE36BX21 – 1.00 1.06 0.94
AE36CX21 – 1.00 1.07 0.94
AHE30B3X(H,T)21 – 1.00 1.04 0.96
AHE36C3X(H,T)21 – 1.00 1.07 0.94
AHV30B3X(H,T)21 – 1.00 1.04 0.96
AHV36C3X(H,T)21 – 1.00 1.02 0.94
AP30BX21 – 0.99 1.06 0.99
AVC30BX21 – 1.00 1.06 0.94
AVC36BX21 – 1.00 1.07 0.94
AVC36CX21 – 1.00 1.06 0.94
ME08BN21 CF/CM30B 1.00 1.06 0.96
ME08BN21 CF/CM36B 1.00 1.05 0.94
ME12BN21 CF/CM30B 1.00 1.06 0.96
ME12BN21 CF/CM36B 1.00 1.09 0.94
ME14DN21 CF/CM30D 1.00 1.06 0.94
ME14DN21 CF/CM36D 1.00 1.09 0.94
ME16CN21 CF/CM30C 1.00 1.06 0.98
ME16CN21 CF/CM36C 1.00 1.08 0.98
MVC08BN21 CF/CM30B 1.00 1.02 0.94
MVC08BN21 CF/CM36B 1.00 1.05 0.96
MVC12BN21 CF/CM30B 1.00 1.05 0.96
MVC12BN21 CF/CM36B 1.00 1.05 0.96
MVC14DN21 CF/CM30D 1.00 1.03 0.96
MVC14DN21 CF/CM36D 1.00 1.09 0.94
MVC16CN21 CF/CM30C 1.00 1.08 0.98
MVC16CN21 CF/CM36C 1.00 1.08 0.96
FURNACE MULTIPLIERS - 2 TON
Furnaces Coil T.C. S.C. KW
TM8V060A12MP11 CF/CM36A 1.00 1.05 0.96
TM8V080B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TM8V080B12MP11 CF/CM/CU36B 1.00 1.05 0.96
TM8V080C16MP11 CF/CM/CU30C 1.00 1.09 0.98
TM8V080C16MP11 CF/CM/CU30D 1.00 1.09 0.98
TM8V080C16MP11 CF/CM/CU36C 1.00 1.10 0.96
TM8V080C16MP11 CF/CM/CU36D 1.00 1.11 0.96
TM8V100C16MP11 CF/CM/CU30C 1.00 1.09 0.98
TM8V100C16MP11 CF/CM/CU30D 1.00 1.09 0.98
TM8V100C16MP11 CF/CM/CU36C 1.00 1.10 0.96
TM8V100C16MP11 CF/CM/CU36D 1.00 1.11 0.96
TM8X060A12MP11 CF/CM36A 1.00 1.05 0.96
TM8X080B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TM8X080B12MP11 CF/CM/CU36B 1.00 1.06 0.94
TM8X080C16MP11 CF/CM/CU30C 1.00 1.06 0.94
TM8X080C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TM8X080C16MP11 CF/CM/CU36C 1.00 1.09 0.94
TM8X080C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TM8X100C16MP11 CF/CM/CU30C 1.00 1.06 0.94
TM8X100C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TM8X100C16MP11 CF/CM/CU36C 1.00 1.09 0.94
TM8X100C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TM8X100C20MP11 CF/CM/CU30C 0.99 1.04 0.99
TM8X100C20MP11 CF/CM/CU30D 1.00 1.06 1.00
TM8X100C20MP11 CF/CM/CU36C 0.99 1.08 0.99
TM8X100C20MP11 CF/CM/CU36D 1.00 1.09 1.00
TM8X120C20MP11 CF/CM/CU30C 0.99 1.04 0.99
TM8X120C20MP11 CF/CM/CU30D 1.00 1.06 1.00
TM8X120C20MP11 CF/CM/CU36C 0.99 1.08 0.99
TM8X120C20MP11 CF/CM/CU36D 1.00 1.09 1.00
TM8Y060A12MP11 CF/CM36A 1.00 1.05 0.96
TM8Y080B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TM8Y080B12MP11 CF/CM/CU36B 1.00 1.06 0.94
TM8Y080C16MP11 CF/CM/CU30C 1.00 1.06 0.94
TM8Y080C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TM8Y080C16MP11 CF/CM/CU36C 1.00 1.09 0.94
TM8Y080C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TM8Y100C16MP11 CF/CM/CU30C 1.00 1.06 0.94
TM8Y100C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TM8Y100C16MP11 CF/CM/CU36C 1.00 1.09 0.94
TM8Y100C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TM8Y100C20MP11 CF/CM/CU30C 0.99 1.04 0.99
TM8Y100C20MP11 CF/CM/CU30D 1.00 1.06 1.00
TM8Y100C20MP11 CF/CM/CU36C 0.99 1.08 0.99
TM8Y100C20MP11 CF/CM/CU36D 1.00 1.09 1.00
TM8Y120C20MP11 CF/CM/CU30C 0.99 1.04 0.99
TM8Y120C20MP11 CF/CM/CU30D 1.00 1.06 1.00
TM8Y120C20MP11 CF/CM/CU36C 0.99 1.08 0.99
TM8Y120C20MP11 CF/CM/CU36D 1.00 1.09 1.00
TM9E040A10MP11 CF/CM36A 1.00 1.05 0.98
TM9E060B12MP11 CF/CM/CU30B 1.00 1.06 1.00
TM9E060B12MP11 CF/CM/CU36B 1.00 1.09 1.00
TM9E080B12MP11 CF/CM/CU30B 1.00 1.06 1.00
TM9E080B12MP11 CF/CM/CU36B 1.00 1.09 1.00
TM9E080C16MP11 CF/CM/CU30C 1.00 1.03 0.94
TM9E080C16MP11 CF/CM/CU30D 1.00 1.05 0.94
TM9E080C16MP11 CF/CM/CU36C 1.00 1.04 0.94
TM9E080C16MP11 CF/CM/CU36D 1.00 1.05 0.94
TM9E100C16MP11 CF/CM/CU30C 1.00 1.03 0.94
TM9E100C16MP11 CF/CM/CU30D 1.00 1.05 0.94
TM9E100C16MP11 CF/CM/CU36C 1.00 1.04 0.94
TM9E100C16MP11 CF/CM/CU36D 1.00 1.05 0.94
TM9E100C20MP11 CF/CM/CU30C 1.00 1.06 0.98
TM9E100C20MP11 CF/CM/CU30D 1.00 1.06 0.98
TM9E100C20MP11 CF/CM/CU36C 1.00 1.06 0.98
TM9E100C20MP11 CF/CM/CU36D 1.00 1.06 0.98
TM9E120D20MP11 CF/CM/CU30D 1.00 1.06 0.96
TM9E120D20MP11 CF/CM/CU36D 1.00 1.09 0.96
TM9V060B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TM9V060B12MP11 CF/CM/CU36B 1.00 1.09 0.96
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. KW

5371951-YTG-A-0517
Johnson Controls Unitary Products 17
TM9V080B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TM9V080B12MP11 CF/CM/CU36B 1.00 1.09 0.96
TM9V080C16MP11 CF/CM/CU30C 1.00 1.08 0.96
TM9V080C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TM9V080C16MP11 CF/CM/CU36C 1.00 1.09 0.96
TM9V080C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TM9V100C16MP11 CF/CM/CU30C 1.00 1.08 0.96
TM9V100C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TM9V100C16MP11 CF/CM/CU36C 1.00 1.09 0.96
TM9V100C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TM9Y040A10MP11 CF/CM36A 1.00 1.05 0.98
TM9Y060B12MP11 CF/CM/CU30B 1.00 1.06 1.00
TM9Y060B12MP11 CF/CM/CU36B 1.00 1.09 1.00
TM9Y080B12MP11 CF/CM/CU30B 1.00 1.06 1.00
TM9Y080B12MP11 CF/CM/CU36B 1.00 1.09 1.00
TM9Y080C16MP11 CF/CM/CU30C 1.00 1.03 0.94
TM9Y080C16MP11 CF/CM/CU30D 1.00 1.05 0.94
TM9Y080C16MP11 CF/CM/CU36C 1.00 1.04 0.94
TM9Y080C16MP11 CF/CM/CU36D 1.00 1.05 0.94
TM9Y100C16MP11 CF/CM/CU30C 1.00 1.03 0.94
TM9Y100C16MP11 CF/CM/CU30D 1.00 1.05 0.94
TM9Y100C16MP11 CF/CM/CU36C 1.00 1.04 0.94
TM9Y100C16MP11 CF/CM/CU36D 1.00 1.05 0.94
TM9Y100C20MP11 CF/CM/CU30C 1.00 1.06 0.98
TM9Y100C20MP11 CF/CM/CU30D 1.00 1.06 0.98
TM9Y100C20MP11 CF/CM/CU36C 1.00 1.06 0.98
TM9Y100C20MP11 CF/CM/CU36D 1.00 1.06 0.98
TM9Y120D20MP11 CF/CM/CU30D 1.00 1.06 0.96
TM9Y120D20MP11 CF/CM/CU36D 1.00 1.09 0.96
TMLV060A12MP11 CF/CM36A 1.00 1.05 0.96
TMLV080B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TMLV080B12MP11 CF/CM/CU36B 1.00 1.05 0.96
TMLV080C16MP11 CF/CM/CU30C 1.00 1.09 0.98
TMLV080C16MP11 CF/CM/CU30D 1.00 1.09 0.98
TMLV080C16MP11 CF/CM/CU36C 1.00 1.10 0.96
TMLV080C16MP11 CF/CM/CU36D 1.00 1.11 0.96
TMLV100C16MP11 CF/CM/CU30C 1.00 1.09 0.98
TMLV100C16MP11 CF/CM/CU30D 1.00 1.09 0.98
TMLV100C16MP11 CF/CM/CU36C 1.00 1.10 0.96
TMLV100C16MP11 CF/CM/CU36D 1.00 1.11 0.96
TMLX060A12MP11 CF/CM36A 1.00 1.05 0.96
TMLX080B12MP11 CF/CM/CU30B 1.00 1.05 0.96
TMLX080B12MP11 CF/CM/CU36B 1.00 1.06 0.94
TMLX080C16MP11 CF/CM/CU30C 1.00 1.06 0.94
TMLX080C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TMLX080C16MP11 CF/CM/CU36C 1.00 1.09 0.94
TMLX080C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TMLX100C16MP11 CF/CM/CU30C 1.00 1.06 0.94
TMLX100C16MP11 CF/CM/CU30D 1.00 1.06 0.94
TMLX100C16MP11 CF/CM/CU36C 1.00 1.09 0.94
TMLX100C16MP11 CF/CM/CU36D 1.00 1.09 0.94
TMLX100C20MP11 CF/CM/CU30C 0.99 1.04 0.99
TMLX100C20MP11 CF/CM/CU30D 1.00 1.06 1.00
TMLX100C20MP11 CF/CM/CU36C 0.99 1.08 0.99
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. KW TMLX100C20MP11 CF/CM/CU36D 1.00 1.09 1.00
TMLX120C20MP11 CF/CM/CU30C 0.99 1.04 0.99
TMLX120C20MP11 CF/CM/CU30D 1.00 1.06 1.00
TMLX120C20MP11 CF/CM/CU36C 0.99 1.08 0.99
TMLX120C20MP11 CF/CM/CU36D 1.00 1.09 1.00
TP9C060B12MP12 CF/CM/CU30B 1.00 1.05 0.96
TP9C060B12MP12 CF/CM/CU36B 1.00 1.09 0.96
TP9C080B12MP12 CF/CM/CU30B 1.00 1.05 0.96
TP9C080B12MP12 CF/CM/CU36B 1.00 1.09 0.96
TP9C080C16MP12 CF/CM/CU30C 1.00 1.08 0.96
TP9C080C16MP12 CF/CM/CU30D 1.00 1.06 0.94
TP9C080C16MP12 CF/CM/CU36C 1.00 1.09 0.96
TP9C080C16MP12 CF/CM/CU36D 1.00 1.09 0.94
TP9C100C16MP12 CF/CM/CU30C 1.00 1.08 0.96
TP9C100C16MP12 CF/CM/CU30D 1.00 1.06 0.94
TP9C100C16MP12 CF/CM/CU36C 1.00 1.09 0.96
TP9C100C16MP12 CF/CM/CU36D 1.00 1.09 0.94
TPLC060A12MP12 CF/CM36A 1.00 1.05 0.96
TPLC080B12MP12 CF/CM/CU30B 1.00 1.05 0.96
TPLC080B12MP12 CF/CM/CU36B 1.00 1.05 0.96
TPLC080C16MP12 CF/CM/CU30C 1.00 1.09 0.98
TPLC080C16MP12 CF/CM/CU30D 1.00 1.09 0.98
TPLC080C16MP12 CF/CM/CU36C 1.00 1.10 0.96
TPLC080C16MP12 CF/CM/CU36D 1.00 1.11 0.96
TPLC100C16MP12 CF/CM/CU30C 1.00 1.09 0.98
TPLC100C16MP12 CF/CM/CU30D 1.00 1.09 0.98
TPLC100C16MP12 CF/CM/CU36C 1.00 1.10 0.96
TPLC100C16MP12 CF/CM/CU36D 1.00 1.11 0.96
YP9C060B12MP12 CF/CM/CU30B 1.00 1.05 0.96
YP9C060B12MP12 CF/CM/CU36B 1.00 1.09 0.96
YP9C080B12MP12 CF/CM/CU30B 1.00 1.05 0.96
YP9C080B12MP12 CF/CM/CU36B 1.00 1.09 0.96
YP9C080C16MP12 CF/CM/CU30C 1.00 1.08 0.96
YP9C080C16MP12 CF/CM/CU30D 1.00 1.06 0.94
YP9C080C16MP12 CF/CM/CU36C 1.00 1.09 0.96
YP9C080C16MP12 CF/CM/CU36D 1.00 1.09 0.94
YP9C100C16MP12 CF/CM/CU30C 1.00 1.08 0.96
YP9C100C16MP12 CF/CM/CU30D 1.00 1.06 0.94
YP9C100C16MP12 CF/CM/CU36C 1.00 1.09 0.96
YP9C100C16MP12 CF/CM/CU36D 1.00 1.09 0.94
YPLC060A12MP12 CF/CM36A 1.00 1.05 0.96
YPLC080B12MP12 CF/CM/CU30B 1.00 1.05 0.96
YPLC080B12MP12 CF/CM/CU36B 1.00 1.05 0.96
YPLC080C16MP12 CF/CM/CU30C 1.00 1.09 0.98
YPLC080C16MP12 CF/CM/CU30D 1.00 1.09 0.98
YPLC080C16MP12 CF/CM/CU36C 1.00 1.10 0.96
YPLC080C16MP12 CF/CM/CU36D 1.00 1.11 0.96
YPLC100C16MP12 CF/CM/CU30C 1.00 1.09 0.98
YPLC100C16MP12 CF/CM/CU30D 1.00 1.09 0.98
YPLC100C16MP12 CF/CM/CU36C 1.00 1.10 0.96
YPLC100C16MP12 CF/CM/CU36D 1.00 1.11 0.96
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. KW

5371951-YTG-A-0517
18 Johnson Controls Unitary Products
PERFORMANCE DATA - 3 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
CONDENSER-ONLY DATA (OUTDOOR UNIT)
MODEL SATURATEDSUCTION
@ COMPRESSOR Outdoor Ambient Temperature
55 °F 65 °F 75 °F 85 °F 95 °F 105 °F 115 °F 120 °F
T (°F) P (PSIG) MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
TCHE36S41S1
35 107 33.3 3.24 31.8 3.24 30.2 3.24 28.6 3.24 26.9 3.24 25.0 3.24 23.0 3.24 21.9 3.24
40 118 36.6 3.22 35.0 3.22 33.3 3.22 31.6 3.22 29.7 3.22 27.7 3.22 25.5 3.22 24.4 3.22
45 130 40.1 3.20 38.4 3.20 36.7 3.20 34.8 3.20 32.8 3.20 30.6 3.20 28.3 3.20 27.0 3.20
50 142 43.9 3.18 42.1 3.18 40.2 3.18 38.2 3.18 36.0 3.18 33.7 3.18 31.2 3.18 29.8 3.18
55 156 47.8 3.09 45.9 3.16 43.9 3.16 41.8 3.16 39.4 3.16 36.9 3.16 34.3 3.16 32.9 3.16
Notes:
1. For Outdoor Unit (Condenser) performance only. Data does not include the effects of air handler power or heat.
2. Performance based on 15°F subcooling and 15°F superheat at the Outdoor Unit base valves.
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
3. Maximum recommended condensing temperature is 140°F.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCHE36S41S1
INDOOR COIL MODEL NO. FC38C
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 800 1000 1200
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 34.2 37.0 36.9 39.9 42.2 35.6 38.1 37.9 40.9 42.9 37.1 39.1 38.9 41.9 43.7 S.C. 34.1 32.8 28.0 27.5 21.8 35.6 35.6 30.1 29.4 22.8 37.0 38.4 32.3 31.3 23.7
K.W. 1.89 1.91 1.88 1.90 1.92 1.97 1.98 1.96 1.98 2.01 2.04 2.06 2.05 2.06 2.09
65 T.C. 33.2 35.8 35.8 38.8 41.5 34.7 36.9 36.8 39.8 42.3 36.2 37.9 37.7 40.8 43.1 S.C. 33.2 32.1 27.6 27.3 21.8 34.7 34.8 29.9 29.4 22.9 36.2 37.6 32.2 31.5 24.1
K.W. 2.07 2.10 2.07 2.08 2.08 2.15 2.17 2.15 2.16 2.17 2.22 2.24 2.22 2.23 2.25
75 T.C. 32.3 34.5 34.6 37.7 40.8 33.8 35.7 35.6 38.6 41.6 35.4 36.8 36.6 39.6 42.5 S.C. 32.2 31.4 27.1 27.1 21.8 33.8 34.1 29.6 29.4 23.1 35.3 36.8 32.0 31.7 24.4
K.W. 2.26 2.29 2.26 2.26 2.25 2.33 2.35 2.33 2.33 2.33 2.40 2.42 2.39 2.40 2.40
85 T.C. 31.4 33.5 33.2 36.3 39.4 32.9 34.6 34.1 37.2 40.2 34.3 35.7 35.0 38.1 41.0 S.C. 31.4 31.1 26.5 26.5 21.2 32.8 33.4 29.0 28.9 22.7 34.3 35.6 31.4 31.3 24.1
K.W. 2.50 2.54 2.52 2.51 2.49 2.57 2.60 2.58 2.58 2.57 2.64 2.67 2.65 2.65 2.65
95 T.C. 30.6 32.4 31.8 35.0 38.0 31.9 33.5 32.6 35.8 38.8 33.3 34.6 33.4 36.7 39.5
S.C. 30.5 30.7 25.9 25.9 20.7 31.9 32.6 28.3 28.4 22.3 33.2 34.5 30.8 31.0 23.8
K.W. 2.74 2.79 2.78 2.77 2.74 2.81 2.86 2.84 2.83 2.81 2.87 2.92 2.90 2.90 2.89
105 T.C. 29.3 30.9 30.2 33.2 36.2 30.6 32.0 30.9 34.0 36.9 32.0 33.2 31.7 34.8 37.6 S.C. 29.2 29.7 25.1 25.2 20.1 30.6 31.4 27.5 27.7 21.6 31.9 33.2 30.0 30.2 23.2
K.W. 3.17 3.20 3.21 3.14 3.08 3.19 3.23 3.25 3.19 3.15 3.22 3.26 3.29 3.25 3.22
115 T.C. 28.0 29.4 28.5 31.5 34.5 29.3 30.7 29.3 32.3 35.2 30.7 31.9 30.0 33.0 35.8 S.C. 28.0 28.8 24.3 24.5 19.4 29.3 30.3 26.7 27.0 21.0 30.6 31.9 29.1 29.5 22.6
K.W. 3.58 3.60 3.63 3.50 3.42 3.57 3.60 3.65 3.55 3.48 3.56 3.60 3.67 3.59 3.55
120 T.C. 26.8 27.9 26.9 29.8 32.8 28.1 29.3 27.6 30.5 33.4 29.4 30.6 28.3 31.2 34.0 S.C. 26.7 27.8 23.5 23.9 18.8 28.0 29.2 25.9 26.3 20.4 29.3 30.6 28.3 28.8 22.0
K.W. 4.00 4.00 4.04 3.87 3.75 3.95 3.96 4.05 3.90 3.82 3.90 3.93 4.05 3.92 3.88
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.

5371951-YTG-A-0517
Johnson Controls Unitary Products 19
COIL MULTIPLIERS - 3 TON
Air Handler Coil T.C. S.C. KW
– FC38C 1.00 1.00 1.00
ME16CN21 FC38C 1.01 1.00 0.95
MVC16CN21 FC38C 1.01 1.00 0.96
FURNACE MULTIPLIERS - 3 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP11 FC38C 1.00 0.99 0.98
TM8V100C16MP11 FC38C 1.00 0.99 0.98
TM8V100C20MP11 FC38C 1.01 0.99 0.94
TM8V120C20MP11 FC38C 1.01 0.99 0.94
TM8X080C16MP11 FC38C 1.01 1.00 0.96
TM8X100C16MP11 FC38C 1.01 1.00 0.96
TM8X100C20MP11 FC38C 1.00 0.99 0.96
TM8X120C20MP11 FC38C 1.00 0.99 0.96
TM8Y080C16MP11 FC38C 1.01 1.00 0.96
TM8Y100C16MP11 FC38C 1.01 1.00 0.96
TM8Y100C20MP11 FC38C 1.00 0.99 0.96
TM8Y120C20MP11 FC38C 1.00 0.99 0.96
TM9E080C16MP11 FC38C 1.00 0.99 0.96
TM9E100C16MP11 FC38C 1.00 0.99 0.96
TM9E100C20MP11 FC38C 1.00 0.99 0.96
TM9V080C16MP11 FC38C 1.01 0.99 0.96
TM9V100C16MP11 FC38C 1.01 0.99 0.96
TM9V100C20MP11 FC38C 1.00 0.99 0.96
TM9Y080C16MP11 FC38C 1.00 0.99 0.96
TM9Y100C16MP11 FC38C 1.00 0.99 0.96
TM9Y100C20MP11 FC38C 1.00 0.99 0.96
TMLV080C16MP11 FC38C 1.00 0.99 0.98
TMLV100C16MP11 FC38C 1.00 0.99 0.98
TMLV100C20MP11 FC38C 1.01 0.99 0.94
TMLV120C20MP11 FC38C 1.01 0.99 0.94
TMLX080C16MP11 FC38C 1.01 1.00 0.96
TMLX100C16MP11 FC38C 1.01 1.00 0.96
TMLX100C20MP11 FC38C 1.00 0.99 0.96
TMLX120C20MP11 FC38C 1.00 0.99 0.96
TP9C080C16MP12 FC38C 1.01 0.99 0.96
TP9C100C16MP12 FC38C 1.01 0.99 0.96
TP9C100C20MP12 FC38C 1.00 0.99 0.96
TPLC080C16MP12 FC38C 1.00 0.99 0.98
TPLC100C16MP12 FC38C 1.00 0.99 0.98
TPLC100C20MP12 FC38C 1.01 0.99 0.94
TPLC120C20MP12 FC38C 1.01 0.99 0.94
YP9C080C16MP12 FC38C 1.01 0.99 0.96
YP9C100C16MP12 FC38C 1.01 0.99 0.96
YP9C100C20MP12 FC38C 1.00 0.99 0.96
YPLC080C16MP12 FC38C 1.00 0.99 0.98
YPLC100C16MP12 FC38C 1.00 0.99 0.98
YPLC100C20MP12 FC38C 1.01 0.99 0.94
YPLC120C20MP12 FC38C 1.01 0.99 0.94

5371951-YTG-A-0517
20 Johnson Controls Unitary Products
PERFORMANCE DATA - 4 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
CONDENSER-ONLY DATA (OUTDOOR UNIT)
MODEL SATURATEDSUCTION
@ COMPRESSOR Outdoor Ambient Temperature
55 °F 65 °F 75 °F 85 °F 95 °F 105 °F 115 °F 120 °F
T (°F) P (PSIG) MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
TCHE48S41S1
35 107 45.1 4.13 42.9 4.22 40.7 4.22 38.5 4.22 36.2 4.22 33.7 4.22 31.1 4.22 29.8 4.22
40 118 49.5 4.20 47.0 4.20 44.7 4.20 42.3 4.20 39.9 4.20 37.2 4.20 34.4 4.20 33.0 4.20
45 130 54.0 4.17 51.5 3.99 48.9 4.17 46.4 4.17 43.8 4.17 40.9 4.17 37.9 4.17 36.4 4.17
50 142 58.8 4.14 56.1 4.05 53.4 4.14 50.6 4.14 47.8 4.14 44.9 4.14 41.7 4.14 39.9 4.14
55 156 64.1 4.10 61.1 4.01 58.2 4.10 55.1 4.10 52.1 4.10 49.0 4.10 28.8 4.10 43.8 4.10
Notes:
1. For Outdoor Unit (Condenser) performance only. Data does not include the effects of air handler power or heat.
2. Performance based on 15°F subcooling and 15°F superheat at the Outdoor Unit base valves.
a. Increase capacity by 1% for each 2°F increase in subcooling.
b. Decrease capacity by 1% for each 2°F decrease in subcooling.
3. Maximum recommended condensing temperature is 140°F.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCHE48S41S1
INDOOR COIL MODEL NO. FC49D
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 1225 1425 1625
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 45.8 48.3 47.9 49.5 51.6 47.0 49.2 48.8 50.3 52.5 48.3 50.2 49.7 51.0 53.4 S.C. 44.9 40.0 34.6 31.9 26.4 46.1 42.0 36.0 33.0 27.2 47.4 43.9 37.4 34.1 28.0
K.W. 2.51 2.54 2.53 2.55 2.61 2.60 2.62 2.62 2.64 2.70 2.68 2.70 2.70 2.73 2.79
65 T.C. 44.7 47.1 47.4 49.7 52.4 46.2 48.2 48.4 50.5 53.2 47.7 49.3 49.5 51.4 54.1 S.C. 43.8 40.3 34.7 32.8 27.0 45.3 42.9 36.6 34.3 28.0 46.8 45.5 38.5 35.7 29.0
K.W. 2.78 2.80 2.80 2.81 2.85 2.86 2.88 2.88 2.90 2.94 2.94 2.96 2.95 2.99 3.04
75 T.C. 43.5 46.0 46.8 49.8 53.1 45.3 47.2 48.0 50.8 54.0 47.1 48.4 49.2 51.7 54.8 S.C. 42.7 40.6 34.7 33.7 27.6 44.5 43.9 37.2 35.6 28.8 46.2 47.1 39.6 37.4 30.0
K.W. 3.04 3.06 3.07 3.08 3.10 3.12 3.13 3.14 3.16 3.19 3.19 3.21 3.21 3.24 3.28
85 T.C. 42.2 44.1 44.9 48.0 51.7 44.0 45.3 46.0 48.9* 52.6 45.7 46.4 47.2 49.9 53.4 S.C. 41.4 39.9 34.0 33.2 27.1 43.1 42.7 36.6 35.3 28.4 44.8 45.4 39.1 37.4 29.7
K.W. 3.41 3.43 3.44 3.44 3.45 3.48 3.50 3.52 3.52 3.54 3.55 3.58 3.60 3.60 3.63
95 T.C. 40.9 42.2 43.0 46.1 50.3 42.6 43.3 44.1 47.1 51.2 44.3 44.4 45.2 48.0 52.0
S.C. 40.1 39.3 33.3 32.6 26.6 41.8 41.4 36.0 35.0 28.0 43.5 43.6 38.6 37.4 29.5
K.W. 3.77 3.80 3.82 3.80 3.81 3.84 3.87 3.90 3.87 3.89 3.91 3.94 3.98 3.95 3.98
105 T.C. 39.0 40.2 40.8 44.1 48.2 40.8 41.5 42.0 45.0 49.0 42.5 42.9 43.1 45.9 49.9 S.C. 38.3 38.0 32.3 31.9 25.8 40.0 40.0 35.0 34.3 27.3 41.7 42.1 37.7 36.8 28.8
K.W. 4.34 4.40 4.43 4.32 4.30 4.38 4.42 4.49 4.39 4.38 4.42 4.44 4.54 4.45 4.45
115 T.C. 37.2 38.2 38.7 42.1 46.1 39.0 39.8 39.9 43.0 46.9 40.8 41.4 41.1 43.9 47.8 S.C. 36.5 36.8 31.4 31.2 25.0 38.2 38.7 34.1 33.7 26.6 40.0 40.6 36.8 36.2 28.1
K.W. 4.89 4.97 5.03 4.84 4.78 4.90 4.95 5.06 4.89 4.85 4.91 4.92 5.09 4.94 4.92
120 T.C. 35.4 36.2 36.6 40.1 44.0 37.2 38.1 37.8 41.0 44.8 39.0 40.0 39.0 41.9 45.6 S.C. 34.7 35.5 30.4 30.5 24.3 36.5 37.4 33.2 33.1 25.9 38.3 39.2 35.9 35.6 27.4
K.W. 5.44 5.55 5.62 5.35 5.26 5.42 5.48 5.63 5.39 5.32 5.40 5.40 5.63 5.42 5.38
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
