Young Lin aquaMAX-Basic 360 Series User manual

Contents
Chapter 1. Introduction 1
1-1. Introduction 1
1-2. Operation Principle 2
1-3. Flow diagram 3
1-4. Configuration 4
1-5. System Configuration 5
1-6. Specifications 7
Chapter 2. Installation 9
2-1. Packing 9
2-2. CE Specification 12
2-3. Installing Filters 12
2-4. The Connection of Feed Water 13
2-5. The Connection of the Produced Water 14
2-6. The Connection of the Rejection Water 16
2-7. How to Connect Feed Water Kit 17
2-8. The Connection of Reservoir Tank Sensor (Optional) 17
Chapter 3. Operation 18
3-1. Operation Mode 18
3-2. Initial Operation 19
3-3. Initial Flushing 19
3-4. Operation of the Keys 20
3-5. Normal Operation and Standby Mode 22
3-6. Measuring Point Display 23
3-7. Service Operation 24
3-8. Errors and its Display 25
3-9. System Shut Down 26
Chapter 4. Maintenance 27
4-1. Maintenance and Solutions 27
4-2. Filter Replacement 29
4-3. Trouble Shooting 30
4-4. Fuse Replacement 31

Figure Lists
［Figure 1-1 ] Standard System of the Basic 360 Series 1
［Figure 1-2 ] Flow Diagram 3
［Figure 2-1］Components of aquaMAX Basic. 9
［Figure 2-2］How to connect filters 12
［Figure 2-3］The Connection of Feed Water 13
［Figure 2-4］The Connection of the Produced Water 1(aquaMAX 360, 362) 14
［Figure 2-5］The Connection of the Produced Water 2(aquaMAX 361, 363) 14
［Figure 2-6］The Connection of the Rejection Water 15
［Figure 4-1］Filters in the aquaMAX Basic 27
［Figure 4-2］Filter Replacement 29
〔Figure 4-3〕The Fuse Replacement 31
Table Lists
［Table 1-1］System Configuration 5
［Table 1-2］Water Contaminants and its Effective Removal 5
［Table 1-3］Comparison of Water Quality according to Water Purification Method 6
［Table 1-4］Water Classification According to CAP, ASTM Standards 6
［Table 1-5］The Specification of aquaMAX 7
［Table 1-6］Feed Water Requirements 7
［Table 1-7］Dimension, Power and Weight 8
〔Table 3-1〕Display and Causes of System Troubles 25

aquaMAXTM-Basic 360 Series
Chapter 1. Introduction
1-1. Introduction
The Young Lin Basic 360 Series is the water purification system that produces pure water from tap or
underground water. The purified water by the Basic 360 Series is adequate to use as a laboratory grade water or
supply for ultra-pure water production system. The components of the Basic 360 Series are as follows.
[ Figure 1-1 ] Standard System of the Basic 360 Series
1

aquaMAXTM-Basic 360 Series
2
1. Control panel
2. Door
3. RO Membrane Pack
4. RO Pre Pack
5. RO Post Pack
6. Switch of Tank Level
7. Power On/Off Switch
8. Fuse Holder
9. Power Socket
10. Name Tag
11. Connection part of feed water
12. Display Light
13. Keypad Name tag
14. LCD Display
1-2. Operation Principle
The Basic 360 Series Water Purification System produces decontaminated pure water by using reverse
osmosis to filter particles, inorganics, organics and bacteria from water supply. The water supply is fed through a
prefilter to get rid of the large particles and the pre-filtered water flows to a carbon filter to be removed chlorine.
Then the produced water is pressurized by a booster pump and delivered to the RO Membrane Pack to be
purified. The purified water is used as laboratory grade water or feed water for ultra-high pure water.
In use of the aquaMAXTM-Basic 361 or 362 System,it produces 2nd grade distilled water removed cation and
anion through an ion exchange pack.

aquaMAXTM-Basic 360 Series
1-3. Flow diagram
[ Figure 1-2 ] Flow Diagram
3

aquaMAXTM-Basic 360 Series
1-4. Configuration
1-4-1. R.O. Membrane Pack and Prefilter(PRE PACK)
The Water supply(tap water or treated municipal water) is fed through a pre-filter to be separated large and small
particles by filtration. The permeate water then enters the RO Pack housing and permeates through the
spiral-wound RO membrane. For the Basic 360 Series, when RO membrane is pressurized at 5.5 Kg/cm2,
approximately 70% of the input water is continuously withdrawn from the system through a reject valve and the
remaining 30% of the water permeates through the membrane to be filtered. The productivity of RO membrane
is varied depending on pressure and used time.
1-4-2. Booster Pump
The booster pump of the Basic 360 Series is a silent diaphragm pump. It can transfer water flow rate of
maximum 60 liter/hour, however the purified water can be produced at maximum 10 liter/hour when supplied
with RO pressure of 5.5 Kg/cm2. The amount of the purified water can be varied by temperature, used time and
pressure of RO membrane.
1-4-3. Pressure Switch
If the inlet pressure of a water supply is less than 0.8 Kg/m2, the pressure switch automatically stops the
booster pump to prevent the pump from damage and if it is more than 7.0 Kg/cm2, it stops the operation to
prevent the filter from damage. The inlet pressure of water supply should be more than 1.0 Kg/cm2, because the
pressure drops down after passing through the prefilter. In case the switch stops the booster pump at low
pressure (less than 0.8 Kg/m2), you should raise the inlet pressure first to drive the booster pump again.
※It is required to install an extra external pump if the pressure of water supply is less than average 0.8 Kg/m2..
1-4-4. Drain Valve and Automatic Flushing
The drain valve consisted of a needle valve and a solenoid valve is designed to control the backpressure of RO
membrane. The reverse osmosis is displayed on the pressure gauge mounted inside of the system. The Basic
360 Series automatically turns on the drain valve every 30 minutes for 1 minute so that the contaminants
collected on the RO membrane surface can be flushed away by a high velocity flush of water.
1-4-5. Water Quality Monitoring
The Basic 360 Series monitors water quality by measuring conductivity at 3 different points. The measured
value indicates ion drain ratio and time of filter replacement.
4

aquaMAXTM-Basic 360 Series
1-5. System Configuration
aquaMAX 360 : Standard Type (10L/h)
aquaMAX 361 : Ion Exchange Addition Type (10L/h)
aquaMAX 362 : Extended Capacity Type (20L/h)
aquaMAX 363 : Extended Capacity and Ion Exchange Addition Type(20L/h)
［Table 1-1］System Configuration
aquaMAX 360 aquaMAX 361 aquaMAX 362 aquaMAX 363
R.O Membrane 1 Pack
(Standard Type for RO) 1 ea 1 ea * *
R.O Membrane 2 Pack
(Extended Capacity Type for RO) * * 1 ea 1 ea
R.O Pre Pack
(Prefilter, Carbon filter) 1 ea 1 ea 1 ea 1 ea
R.O Post Pack
(Ion Exchange Fileter) * 1 ea * 1 ea
［Table 1-2］Water Contaminants and its Effective Removal
Contaminant Excellent Good Bad
Inorganic ion Ion Exchange Distillation R.O
Organics R.O. Distillation Carbon
Particles Membrane R.O. Distillation
Bacteria Membrane R.O. Distillation
5

aquaMAXTM-Basic 360 Series
［Table 1-3］Comparison of Water Quality according to Water Purification Method
Tap Water Distilled
Water
Ion
Exchange
Water
Ultra Pure
Water aquaMAX CAP/ASTM
Dissolved
Inorganics
(CaCO3, ppm)
170 0.3 0.1 0.05∼0.025 20 -
Resistivity
(MΩ·cm, 25℃) 0.003 2 0.1 10∼18.2 0.1 0.5∼0.1 1.0∼
Silica(ppm) 1 0.05 <0.01 <0.01 0.1 <0.01
Heavy Metal
(ppm) 1 0.05 <0.01 <0.01 0.1 <0.01
Dissolved
Organics(ppm) - <1 <1 <1 <1 -
Bacteria(cfu/㎖) >100 <10 >100 * <10 -
Small
Particles(>5 ㎛/㎖) >10,000 <100 >10,000 * <10 -
［Table 1-4］Water Classification According to CAP, ASTM Standards
Water Quality Resistivity
(MΩ·cm) Conductivity(μS)
aquaMAX R.O Type 0.1 0.5∼2.0∼5
aquaMAX Ion Exchange addition Type 2.0 1∼0 0.1 0.5∼
Laboratory-Grade 0.1 1.0∼1.0 10∼
Analytical-Grade 1.0 2.0∼0.5 1.0∼
Reagent-Grade 10 0.05∼
CAP : The College of American Pathologists
ASTM : American Society for Testing and Materials
6

aquaMAXTM-Basic 360 Series
1-6. Specifications
［Table 1-5］The Specification of aquaMAX
Ion Removal 95-99% Organics
Removal 99%
Particle
Rejection 99%
Bacteria
Removal 99.99%
Pure Water
Production Rate
(25℃,8Kg/cm2)
Standard : 10L/hour
Extension : 20L/hour
Pyrogen
Reduction 99% Material Polyamide Complex
The Young Lin aquaMAX can reject more than 99% of inorganic and organic contaminants in the feed water.
Thus, after permeation of the reverse osmosis membrane, the purified water contains less than 1% of the
contaminants present in the feed water. The aquaMAX uses 5.0 ㎛prefilter to filter large and small particles in
order to prevent clogging or fouling of the RO membrane.
［Table 1-6］Feed Water Requirements
pH Range 3.0 10.0∼Pressure(Kg/cm2) 1 - 5
TDS 〈500 ppm Temperature 4-35℃
Conductivity 〈800 μS Turbidity 1.0 NTU
Residual Chlorine < 0.1 ppm
(After Carbon filter)
The others If the feed water contains a
lot of bacteria, it adversely
affects the purified water
quality and damages the RO
membrane.
7

aquaMAXTM-Basic 360 Series
［Table 1-7］Dimension, Power and Weight
Width 435 mm
Depth 370 mm
Dimension
Height 580 mm
aquaMAX 360 24.0 Kg
aquaMAX 361 24.5 Kg
aquaMAX 362 24.5 Kg
Weight
aquaMAX 363 25.0 Kg
Consumption 100 W
Power AC 110V/230V, 50/60Hz
Power
Fuse Littlefuse 250V 1A
Part NO. 218001
8

aquaMAXTM-Basic 360 Series
Chapter 2. Installation
※Handle with care not to change up side down at delivery.
2-1. Packing
The standard type of aquaMAX-Basic is consisted of following items. The filters are mounted inside of the
system.
［Figure 2-1］Components of aquaMAX Basic.
9

aquaMAXTM-Basic 360 Series
1. Water Purification System (Fuse 250V, 1A : mounted on the fuse holder) 1 system
: 1 ea of PRE PACK, RO PACK, POST PACK(Included aquaMAXTM-Basic 361/363 only)
2. Seal Hose Kit(Ø6 tubing :3m, Kit for connection of tab water) 1 ea
3. Tubings for the produced water and the drain water Ø6 : 3m each 2 ea
4. Tool kit for filter replacement 1 kit
5. Filter Cartridge (PRE PACK, POST PACK, RO PACK) 1 ea
: Filters are separately packed to avoid damage on delivery. Mount the filters
after installation of system
6. Operating manual 1 ea
7.Powercord 1ea
2-2. CE Specification
2-2-1. Installation Requirements
Environmental conditions
- Indoor use only
- Altitude up to 2000m
- Temperature 5 to 40℃℃
- Maximum relative humidity 80% for temperature up to 30 decreasing linearly to 50% relative℃
humidity at 40℃
- Pollution degree 2
If the equipment is used in a manner not specified by the manufacturer, the protection provided by the
equipment may be impaired.
10

aquaMAXTM-Basic 360 Series
2-2-2. Safety Indication
An explanation of symbols related to safety, which are used on the equipment.
a)
-> Protective Earth
b) and -> Power On and Power Off
c) -> Caution, risk of electric shock
2-2-3. WEED GUIDE
This marking shown on the product or its literature, indicates that it should not be disposed
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
11

aquaMAXTM-Basic 360 Series
2-3. Installing Filters
［Figure 2-2］How to connect filters
1. Check there are 6 fittings for one-touch clip on upper part of where filters have been installed.
>Press down the clip connected to the fitting making a sound like "click".
: The fitting has been already pressed down at the first installation.
: If it's not pressed down, filter can't be fit in.
2. Insert the filter to fix into the marked fitting by making "click" sound.
>After inserted, check the installation by pressing down the up-side head of filter.
>There is a indicating mark at the lower part of filter not to install the filter upside down.
☞CAUTION : Filter installation upside down causes the system malfunction and water quality problem.
3. For the R.O membrane pack, the one-touch fitting is on the lower part.
Press down the clip by making a sound like "click" and connect the fitting to the external exposed tubing by
making "click" sound.
4. Follow same direction as above 1 and 2 to connect R.O. Pre Pack and R.O. Post Pack except R.O
membrane pack.
12

aquaMAXTM-Basic 360 Series
2-4. The Connection of Feed Water
［Figure 2-3］The Connection of Feed Water
Cut the Ø6 seal hose tubing supplied with the system properly and connect to the one-touch type of FEED
fitting on the back-side. Then please connect the other side to the tap water.
2-5. The Connection of the Produced Water
For the aquaMAX 360, 362 type, close the one touch fitting on ION (PRODUCT 2) on the back side with a
supplied plug and insert Ø6 tube into the one touch fitting at R.O.(PRODUCT 1) as following ［Figure 2-3.］
Connect the other side of tubing to the reservoir tank
For the aquaMAX 361, 363 type, connect tubings to both R.O.(PRODUCT 1) and ION (PRODUCT2) as following
［Figure 2-3-1］. It can produce either R.O water or De-ionized water by selection from a service menu. It’s
available to connect a sensor to check the level of water in a tank when you connect a reservoir tank.
13

aquaMAXTM-Basic 360 Series
［Figure 2-4］The Connection of the Produced Water 1(aquaMAX 360, 362)
［Figure 2-5］The Connection of the Produced Water 2(aquaMAX 361, 363)
14

aquaMAXTM-Basic 360 Series
2-6. The Connection of the Rejection Water
Connect by pushing the supplied Ø6 tubing to the REJECT on the back side and place the other side of the
tubing on the nearest waste hole.
［Figure 2-6］The Connection of the Rejection Water
15

aquaMAXTM-Basic 360 Series
2-7. How to Connect Feed Water Kit
1. Purpose of Installation
On installation of water purification system, there are some difference at water pressure depending of location,
time and area. So, a decompression valve is built in the unit to prevent housing damage, pump error and fitting
separation. When you install water purification system, you must connect a tap water connector.
2. Details
1) Connection of tap water connector
a. Insert a bushing (1-1) of tap water connector(1) into a tap, and
then tighten a screw(+).
b. Turn a nipple (1-2) counterclockwise up to bushing completely.
-There is a rubber-ring to protect from leakage and helps installation.
3. Caution
The use with a booster pump is required when the water pressure of installation area is lower than
0.5kg/㎠~ 1kg/㎠to meat the product flow rate on the specification.
16

aquaMAXTM-Basic 360 Series
2-8. The Connection of Reservoir Tank Sensor (Optional)
1. Purpose
With use of a reservoir tank, it protects from overflowing of the produced water.
2. Details
1) Install a tank sensor on the cap of 20L or 50L PE tank.
2) Connect one side of connector of Level Switch Outer Cable to the other connector of which connected to a
tank sensor. The direction of Level Switch Outer Cable doesn’t matter.
3) Connect the other side of connector of installed reservoir tank to Level S/W at the rear side of the system.
3. Caution
The system keeps on 「Standby」mode when the level of water is up at installation of Level Switch. You’re
only able to re-operate the system after reduce the produced water in the tank.
17

aquaMAXTM-Basic 360 Series
Chapter 3. Operation
3-1. Operation Mode
To operate the aquaMAX, use a keyboard on upper of the front side. There are following modes available on
LCD.
Basic Mode
「Operate/Standby」Select the 「Operate」or 「Standby」mode.
「Measure」Use to measure following values during operation
- Temperature
- Conductivity of both the feed water and the produced water from RO
membrane
- Resistivity of Ion Exchange Filter / Ion Rejection Ratio of R.O membrane and
Ion Exchange Filter
「Service」Select the following function on「Standby」mode.
- For the aquaMAX 361/363, select the rejection water(RO/ION) with Measure
button.
- Drain the low-grade water during initial flushing or operation.
- Use for decreasing inner pressure of filter.
- Notice for filter replacement.
「Select」Usetoperform 「Measure」or 「Service」
LED Display
Power Confirm if power is supplied normally.
Operate Lights on 「Operate」or 「Service」.
Standby Lights on 「Standby」or 「Service」.
Fault Lights when normal operation is not possible.
18
