INSTRUCTION MANUAL
MOTION SENSOR
FIBARO SYSTEM
Sold In India By Youtomatic Solutions

Technical support
Should youneed any assistance in connecting or configuring your Home Center, please use our guides
and technical presentations which can be found on our website:
http://www.fibaro.com/en/support
Sold In India By Youtomatic Solutions

AccelerometerTemperature sensor
Motion sensor Light sensor
Functional features
Sold In India By Youtomatic Solutions

Download FIBARO app for smartphone
Sold In India By Youtomatic Solutions

Start the device
Open the casing by turning
it clockwise.
Take off the casing.
STEP 1
STEP 2
Sold In India By Youtomatic Solutions

Start the device
The device will blink red.
Remove the battery blocker
“I’m ready”.
STEP 3
Check if the battery is
placed correctly.
STEP 4
Sold In India By Youtomatic Solutions

Your Motion Sensor is ready to be added
to the Home Center.
Motion Sensormust be in range of the Home Center because it requires
a direct communication with the controller.
Sold In India By Youtomatic Solutions

Start inclusion mode
Start your FIBARO application.
Go to Settings.
STEP 5
Sold In India By Youtomatic Solutions

STEP 7
STEP 6
Start inclusion mode
Press “Next”.
Press “add device”.
Sold In India By Youtomatic Solutions

Inclusion mode has been launched
Sold In India By Youtomatic Solutions

Add your device
Quickly, triple click the button in order
to add your device to the system.
STEP 8
Sold In India By Youtomatic Solutions

Processing your congurations
Sold In India By Youtomatic Solutions

Wake up the device
Sometimes waking up the device is not required
so it will be omitted automatically.
Quickly, triple click the button
in order to wake up the device.
STEP 9
Sold In India By Youtomatic Solutions

The device has been added
Name the device
and assign it to the room.
STEP 10
Sold In India By Youtomatic Solutions

Network range test
STEP 11
Hold the button for a few
seconds until LED
diode blinks violet.
It is recommended to check if the device’s destination
is in range of your Home Center.
STEP 12
Release the button,
and press it again.
The quality of the network range will be
indicated by different
colours of the LED diode.
Sold In India By Youtomatic Solutions

Press the button in order
to leave testing mode.
STEP 13
Direct
communication
Routed
communication
Limited
communication
No signal! The device
will not work correctly!
Network range test – quality indicator
Sold In India By Youtomatic Solutions

Installation
Close the casing.
Dots on the casing will show that
the device is closed correctly.
During the installation it is recommended to wake up the device.
STEP 14
Sold In India By Youtomatic Solutions

Install the sensor’s holder
in desired location.
Installation
Motion Sensor’s range.
STEP 15
Insert the Motion Sensor
in its holder.
STEP 16
Sold In India By Youtomatic Solutions

Motion Sensor’s light signals
Sabotage alarm
LED will flash in alarm mode (red-blue-white colours).
Motion
Everytime the movement is
detected, Motion Sensor
will glow in different
colour depending on the
temperature and user’s
configurations.
Sold In India By Youtomatic Solutions

www.fibaro.com
