Yujin Robot iCLEBO O5 User manual

User Manual
iCLEBO O5
■ Please read "Precautions for Safety" carefully before use and use correctly.
■ The user manual includes the product warranty.
■ Product appearance and specifications are subject to change for product
improvement without notice.
33, Harmony-ro, 187 beon-gil, Yeonsu-gu, Incheon, Republic of Korea
en.yujinrobot.com
Product Specifications
Input Power
Standby Power
Main Unit Consumption Power
Battery
Size
Height
Weight
Speed
Charging Time
Usage Time
(General Floor Standard)
Suction Power Level 1
Suction Power Level 2
Suction Power Level 3
100~240 V
Below 0.6 W
53 W
Lithium Ion
13.9 x 13.6 in
3.4 in
7.1 lbs
350 mm/s (Max)
120 min.
90 min.
70 min.
240 min.
en.yujinrobot.com
2103306230
iOMN.w.En.V0

Product Composition
Preparation for Use
Using the Cleaning Robot
Components
Specific Names for Each Part
6
6
8
8
8
9
10
11
12
12
13
14
16
16
17
18
18
19
21
23
24
Open Source Software
Product Warranty
Troubleshoot
Empty Dustbin and Change Filter
Side Brush Care
Main Blade Care
Sensor Care
Front Wheel Care
Mop Care
Storage
Parts Exchange Period
Reset Settings
Care and Maintenance
To Start/Stop Cleaning
Choosing Cleaning Mode
Choosing Cleaning Option
Suction Power Setting and Smart Turbo
Moving/Manual Cleaning
Automatic Charging
Mop Cleaning
Entry Prevention Tape Installation
Side Brush Installation
Battery Station Installation
Initial Power Switch On/Off
Charging
Power Related Issues
Preparation Before Use
Using the Cleaning Robot
Maintenance After Use
Precautions for Safety
Contents
2
3
5
4
15
21
Resolving Inspection Messages
Notice Messages
Items to Check Before Reporting a Problem 22
19
19
20
15
1

This is for the user's safety and to prevent property damage. Please read the following carefully
and use safely. We recommend keeping this manual for future reference.
Precautions for Safety
Warning Caution Reference
Failure to follow these
instructions could result in
serious injury or death.
Failure to follow the
instructions may result in
minor injury or product
damage.
Failure to follow the
instructions may result in
minor injury or product
damage.
Power Related Issues
Please be aware that there is a risk of electric shock or fire in case of carelessness.
Do not touch the adapter with wet hands.
Be sure to hold the adapter while unplugging it.
Do not insert of unplug the plug/jack unreasonably.
Do not use damaged plug/cord/outlet.
Use 5A outlets or ones with a higher wattage capacity.
Do not use the adapter for other products or for other purposes.
Check that the contact terminals are correctly connected.
If there is any foreign material on the adapter pins, wipe it off before use.
2

More than 4 cm
Attach
about 5 cm
away
Preparation Before Use
Please read carefully for the safe and correct use of the product.
Remove fragile and small objects in advance.
If there is any water, oil, or animal waste on the floor, clean it before using the product.
Do not place the product near a heating device (such as a heater and electric pot).
Please arrange the cords neatly before use.
If you operate the product on a staircase or an area where there is a risk of falling from a
height greater than 4 cm, please use after installing the entry prevention tape (sold separately).
Please refrain from using the product around children or animals.
Please inform the people in the house before you start cleaning.
Please refrain from using in a room where a person or animal is asleep.
Long fringes of carpets should be arranged inward before you start cleaning.
Please refrain from using if the carpet fiber is long or easily damaged.
Please make sure that the main parts of the device are assembled well.
Please empty the dustbin before operating.
Guarantee space around the charging station by removing any obstacles.
Please open the door to the rooms for cleaning beforehand.
Please take care of small items that are not fixed beforehand.
Please leave shoes at a distance from the edge of the shoe compartment so the cleaning
robot doesn’t get on the shoe and slide down.
Entry Prevention
Tape
3

Using the Cleaning Robot
over10
Please read carefully for the safe and correct use of the product.
Be careful to not let foreign objects such as plastic bags, blades, tackles, and the like
get inside the cleaning robot.
Be careful that the cleaning robot does not touch or ingest volatile substances.
Please be careful not to get a part of your body under the cleaning robot.
If the cleaning robot makes strange noises, smells, or smokes, stop using it immediately.
Turn off the power switch on the side and contact the service center (855-926-1601).
Do not use on floors with a slope greater than 10 degrees.
Do not apply strong force or drop the cleaning robot.
Do not use at high altitudes where there is a risk of falling.
Do not let children play with the cleaning robot.
If left unused for long time, please charge the robot for 2 hours before using it.
Please do not disturb the cleaning robot while it is on.
If damage occurs on materials such as wooden floors, please discontinue using the robot
on such surfaces.
4
If the inlet is clogged by vinyl or the like, please remove the blockage immediately.

Maintenance After Use
Please be aware that there is a risk of electric shock and fire in cases of carelessness.
Do not disassemble or modify the cleaning robot.
Do not allow metal objects to come into contact with the product or the charging terminal.
When cleaning or managing the product, turn off the power or remove the plug.
Do not sprinkle water on the cleaning robot or wipe it with volatile materials.
When disposing of the battery, please do not throw it near a fire.
Regularly clean the sensor to prevent malfunctions.
If the cleaning robot and components are damaged, please contact the service
center.
5

Cleaning Robot
Remote Control
(Includes Batteries)
Side Brush -RSide Brush -LMop Plate Mops (2)
User Guide Quick GuideCharging
Station
Cleaning
Brush
Adapter If the plug of the adapter is not fully
assembled, there is a risk of fire.
Product Composition
Components
Specific Names of Each Part
* The specifications and the form of the components may change due to the circumstances of the company.
Side Brush
Charging Pin
Top
Side
Bottom
Lithium Ion Battery
Wheels
Front Wheel
Camera
Display
Window
Manual Charging Port
Power Switch
Bumper
Front Sensor Unit
Air Outlet
Main Blade
Separately Purchased
Component
Entry Prevention Tape
Dustbin
Remote
Control
Receiver
User Manual
iCLEBO O5
■ Please read "Precautions for Safety" carefully before use and use correctly.
■ The user manual includes the product warranty.
■ Product appearance and specifications are subject to change for product
improvement without notice. en.yujinrobot.com
6

Navi
Mode
Max
Mode
Camera Spot
Mode Threshold Mode
Smart Turbo Mode
Reservation Display Battery
App Connection Display
Time Display
Change
Mode
Status
Display
Section
Button
Section
Anti-slip
Pad
Inductive Charging Sensor
Charging Terminal
EPA filter Mesh Filter Dust Bin
Start/
Stop
Power
Choose
Mode
Charge
Suction
Power Setting
Voice Guide
Power
Threshold
Mode
Direction
Control Start/Stop
Adapter
Jack
Charging Jack
Handle
Please assemble and use the two AAA batteries
included with the remote control at the time of
purchase.
1. Slide the cover on the back of the remote control
downward to open it.
2. Check the positive (+) and negative (-) terminals
of the battery and assemble them accordingly.
3. Align the cover with the groove and slide it shut
till it clicks into place.
Installing the Remote Control Batteries
Charging Station
Display Window
Remote Control
Dust Bin
7
※ The remote control does not work
when the cleaning robot’s main
power switch is off (O). Turn on the
power switch (I) on the side of the
main unit and use the remote control.
※ Please use the remote control pointed
toward the cleaning robot.

Turn on (I) the power switch on the side of the main unit.
It turns off when O is pushed.
(Please press ON for products with an ON / OFF switch.)
Side Brush Fixing Pin Side Brush Groove
Side Brush Installation
Charging Station Installation
+
Prepare for Use
Align the side brush marked L towards the groove with the same marking (L).
Align the side brush marked R with the groove with the same marking (R). Then,
push the fixing pins in firmly to secure the side brush.
Connect the adapter jack to
the charging station.
ON OFF
Connect the power plug into
the outlet.
Install the charging station
with 0.5m of space to the left
and right and 1.5m of space to
the front.
adapter jack
Initial Power Switch On / Off
ㆍYou can put the adapter cord in the space behind the charging station.
ㆍYou can reduce the scratching on the top plate by laying a soft cloth on the floor.
ㆍIf the side brush is not fully seated in the groove, it may come off during cleaning.
1 2 3
8

ㆍCharge fully before using the product.
Display Window Red Light
Charging
Green Light
Charging Status Display Charging Charging Complete
Refer to P8 <Initial Power Switch On/Off>
Yellow Light
Display Window Red Light
Battery Charging
Status Below 10%
Red Light
Below 11-20%
Yellow Light
Below 21-50%
Green Light
Above 51%
1. Make sure that the switch on the side of the product is turned on.
2. Start charging the battery by aligning the charging pin on the
bottom of the main unit with the terminal of the charging station.
1
2
33. Check the charging status. When charging, the lamp blinks in the
display window. When charging is completed, the battery status
lights up green.
Initial Charging
Manual Charging
Connect the charging jack of the adapter directly
to the main unit.
9
