Zünd PN Series User manual

Digital flatbed cutter
PN Series
(S-800, M-800, M-1200, M-1600, L-800, L-1200, LR-1600, XL-800, XL-1200)
Operating manual
EN

003
4.11
11-2009
6010800ff
Original operating instructions
Author Technical Editorial Department,
Zünd Systemtechnik AG
Composition and
publication
Zünd Systemtechnik AG
Copyright ©Zünd Systemtechnik AG
Version:
Menu version:
Date:
Doc. no.:

PN series frame version
0-1
110002,001,11-2009, jmu
0
Contents
1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1 Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Using the documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2.1 Structure of the operating manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2.2 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Points to note when reading this operating manual . . . . . . . . . . . . . . . . . . 4
1.4 Care of the documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Current status of documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6 Standardisation, tests, marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6.1 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6.2 CE marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.7 Legal notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.8 Troubleshooting, hints and tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.9 Documented cutter models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.10 Publishing details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
2.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2.2 Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.4 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.5 Layout and function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.7 Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.7.1 Dimensions and weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.7.2 Mains connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.7.3 Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.7.4 Control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.7.5 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.7.6 Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
3.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
3.2 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.3 Examples of improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.4 Hazard warnings, important instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.4.1 Explanation of the hazard warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.4.2 Structure of the hazard warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.5 Areas of responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.6 Personnel requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.7 Rules and safety at work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.8 Procedure in case of malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.9 Danger areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.9.1 Danger areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.9.2 Danger area during processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.9.3 Danger area during initialisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.10 Working and traffic area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.11 Safety signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.11.1 Responsibility of the operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

PN series frame version
0-2
110002,001,11-2009, jmu
0
3.11.2 Position of the safety signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.12 Safety and monitoring devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.13 Personal protective equipment, clothing . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.14 Mechanical hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.14.1 Gathering, retraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.14.2 Gathering, impacts of foreign objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.14.3 Cuts and stab wounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.15 Risk of burns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.16 Electrical hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.17 Risks arising from the emission of toxic dust . . . . . . . . . . . . . . . . . . . . . . 20
3.18 Risks arising from the processing of toxic/hazardous materials . . . . . . . . 20
3.19 Environmental hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.20 Handling and storage of chemicals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.21 Risk of fire and explosion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.22 Danger caused by laser beam (laser pointer) . . . . . . . . . . . . . . . . . . . . . . 24
3.23 Safety instructions for operators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.24 Safety precautions for service personnel . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.25 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4Controls and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
4.1 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
4.2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4.3 Operating unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.3.1 Description of keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.3.2 Description of the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.3.3 Command input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.3.4 Setting the language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3.5 Setting unit of length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3.6 User-defined function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.3.7 User parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.4 Command menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4.2 Menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4.3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4.4 Service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5 Command description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5.1 Job setup (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5.2 Tool (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.5.3 Functions (3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.5.4 User (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.5.5 Basic setting (5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.6 Operating the cutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.6.1 Checks before switching on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.6.2 Switching on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.6.3 Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.6.4 Checks before processing operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

PN series frame version
0-3
110002,001,11-2009, jmu
0
5Malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
5.1 Troubleshooting for after-sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
5.2 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
5.3 Failures in the distribution box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.4 Electronic box fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
6.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
6.2 Safe maintenance of the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
6.3 Operating resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
6.3.1 Handling operating materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
6.3.2 Cleaning fluids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6.3.3 Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6.3.4 Adhesives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6.4 Steps for maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6.5 Maintenance jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.5.1 Maintenance position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.5.2 Visually inspect machine for damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.5.3 Clean the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.6 Instructions for disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.7 Starting up after periods at a standstill . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.8 Transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.8.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.8.2 Transport damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.8.3 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.9 Accessories, spare and wearing parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.9.1 Supplied accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.9.2 Recommended spare and wearing parts . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.10 Information on installation and commissioning . . . . . . . . . . . . . . . . . . . . . 13
7Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
8Tool heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
9Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
10 Material feed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
11 Additional specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
12 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
13 Annex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
13.1 After-sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
13.2 Service and maintenance works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

PN series frame version
0-4
110002,001,11-2009, jmu
0

PN series frame version Introduction
Foreword
1-1
110003,001,11-2009, jmu
1
1 Introduction
Zünd Systemtechnik AG
Altstätten, Switzerland
1.1 Foreword
Dear customer,
By purchasing our product you are participating in the worldwide success of Zünd
cutter systems.
The modular design of our systems ensures:
• A system solution that is suited to your individual requirements in terms of speed
and quality
• The availability of the most up-to-date technology thanks to constant develop-
ments
Our approach
Constant and intensive cooperation with successful users is a prerequisite for inno-
vative and practical solutions. We are therefore grateful for any comments or sug-
gestions on how we can improve.
Contact
Zünd Systemtechnik AG Industriestrasse 8 CH - 9450 Altstätten
Tel. ++41 71-757 8181
Fax ++41 71-757 8191
E-
mail
[email protected]
www zund.com

Introduction PN series frame version
Using the documentation
1-2
110003,001,11-2009, jmu
1
1.2 Using the documentation
The instruction handbook supplied is intended to help you to:
– Operate the machine safely
– Perform routine machine maintenance
– Use the machine optimally in all permitted areas
To do this, you need to be able to find what you want within the documentation.
The instruction handbook comprises:
Volume 1 - Operating manual
This volume contains information on the engineering, installation, operation and
maintenance of the basic machine.
The technical documentation for the service personnel is contained in volumes 2 and
3:
Volume 2 - Service manual *
This volume contains information on the structure of the machine and on servicing
by authorised service personnel
Volume 3 - Spare parts catalogue * (See Zünd homepage)
1.2.1 Structure of the operating manual
The operating manual consists of individual, consecutively numbered chapters. The-
se sections are arranged according to the ring binder tabs.
The table of contents provides information on the structure of the individual chapters.
The numbers of pages and certain large graphics are prefixed with the number of the
relevant chapter. Page number "2-10", for example, means the tenth page of chapter
2 "Product description".

PN series frame version Introduction
Using the documentation
1-3
110003,001,11-2009, jmu
1
1.2.2 Symbols
Illustration
Text structuring
Optional accessories
There are a number of optional accessories available for the machine. Any descrip-
tion relating to an optional accessory is identified in the operating manual by the *
symbol.
Close, fix, tighten, in
Open, release, loosen, out
Higher
Lower
Task: Steps to perform
Result: Outcome of the tasks performed.
Prerequisites for performing a task
List of tools

Introduction PN series frame version
Points to note when reading this operating manual
1-4
110003,001,11-2009, jmu
1
1.3 Points to note when reading this operating manual
Text references
Chapter headings are numbered consecutively, with the first figure corresponding to
the chapter number. Where reference is made to sections outside the current chap-
ter, note the first figure and turn to the corresponding chapter, which contains the ci-
ted section. See chapter 2-4 "Overview of the machine", for example, leads to
chapter 2 "Product description", which contains section 4 "Overview of the machine".
Sketches and schematic representations
These are provided for general information and do not necessarily correspond to the
latest version of the machine.
Dimensional information
Dimensional information is listed in the SI/US unit system according to the place of
installation.
1.4 Care of the documentation
Volume 1 "Instruction manual" must always be kept in close vicinity of the workstati-
on.
Volume 2 "Service manual" must be made available to maintenance and service per-
sonnel when required.

PN series frame version Introduction
Current status of documentation
1-5
110003,001,11-2009, jmu
1
1.5 Current status of documentation
Act accordingly to make sure that the documentation is complete and up-to-date at
all times:
– Do not remove parts of the documentation
– Request copies of missing or illegible pages from the manufacturer, or download
and print them from the Zünd homepage
– If any new documentation is delivered as a result of conversions taking place, file
it away immediately
– If documentation is changed, file the new information and destroy the old
– If the documentation exists in more than one language, ensure that all languages
are kept up-to-date
1.6 Standardisation, tests, marking
1.6.1 Standards
Scope of the documentation supplied
Volume 1: Operating manual
Volume 2: Service manual *
Volume 3: Spare parts catalogue *
Execution
This operating manual makes reference to the following standards:
• EN 62079
• EN 62023
• ANSI Z535-6
• EN ISO 12100-2
Important !
EU standards and guidelines which are applied are listed in the declaration of con-
formity.
In the interests of our customers, we reserve the right to make changes as a result
of technical improvements. This document therefore corresponds to the technical
status of the product supplied and not the manufacturer's current state of develop-
ment.
1.6.2 CE marking
Within the EU, the cutter system is delivered with CE marking and an EC declaration
of conformity according to Annex II A of the EC Machinery Directive 2006/42/EC (see
chapter "Documents")
Important !
If the purchaser adds additional devices to the cutter system or if the system is inte-
grated into an larger system, the device is supplied with a "Declaration for the instal-
lation of an incomplete machine" according to Appendix II A of the EU Machinery

Introduction PN series frame version
Standardisation, tests, marking
1-6
110003,001,11-2009, jmu
1
Directive 2006/42/EC and/or without CE marking. As a result, the declaration of con-
formity must be issued again by the purchaser.

PN series frame version Introduction
Legal notice
1-7
110003,001,11-2009, jmu
1
1.7 Legal notice
The information contained in this publication is intended for information purposes
only and is subject to change without notice at any time. This does not constitute an
obligation on the part of Zünd Systemtechnik AG.
No part of this document may be copied, distributed, used or disclosed to third parties
without express permission. Offenders will be liable for damages.
1.8 Troubleshooting, hints and tips
Important !
You can find information about troubleshooting and useful hints and tips on the Zünd
homepage. (www.zund.com)
1.9 Documented cutter models
This documentation applies for the following types of PN series cutters.
1.10 Publishing details
Name
Operating manual for PN series cutters, side-support version.
Composition, illustration and publication
Zünd Systemtechnik AG - Technical Editorial Department
©Copyright
Zünd Systemtechnik AG
PN Series
S-line M line L line XL line
S-800 M-800 L-800 XL-800
M-1200 L-1200 XL-1200
M-1600 LR-1600

Introduction PN series frame version
Publishing details
1-8
110003,001,11-2009, jmu
1

PN series frame version Product description
General
2-1
110004,001,11-2009, jmu
2
2 Product description
2.1 General
This chapter contains information on the following:
– Representational conventions in the operating manual
– Possible uses of the machine
– Structure of the main components
– Important technical data
– General technical description of the device
Directional information
Directions such as "right, left" or "front, back" are specified according to the opera-
tor's view of the machine during operation.
Fig. 2-1 Directional information
Important information
Important !
Refers to user tips and useful information which enhance the usability and prolong
the service life of the machine and make the work significantly easier.
1 Front 3 Left
2 Back 4 Right
Y Y axis X X axis

Product description PN series frame version
Product identification
2-2
110004,001,11-2009, jmu
2
2.2 Product identification
Important !
The rating plate is used to uniquely identify your machine.
Fig. 2-2 Position of rating plate
2.3 Intended use
The cutter system can be used for the following purposes:
– As an output device for CAD/CAM data
– For processing and labelling materials arranged on the table
Aside from this, the intended use and the limits of the application are as follows:
– Depending on the tools and material feed system available,
– Described in the chapters "Tools", "Modules" and "Material transport".
1 Manufacturer
2 Machine type
3 Serial number
4 Voltage
5 Power
6 Frequency
7 Total weight
8 Year of manufacture (YYYY/MM)
9 CE symbol *
10 Manufacturer's address

PN series frame version Product description
Overview
2-3
110004,001,11-2009, jmu
2
2.4 Overview
Fig. 2-3 Overview
1 Beam
2 Head carriage with tool head, right
side panelling
3 Side panelling
4 Operating unit
5 Table
6 On/off switch
7 Distribution box
8 Side parts
9 Compressor
10 Electronics unit
11 Removable cover
12 Vacuum pump(s)
13 Vacuum cleaner
14 Boom
15 Maintenance unit

Product description PN series frame version
Layout and function
2-4
110004,001,11-2009, jmu
2
2.5 Layout and function
The cutter is constructed on a stable, welded frame construction.
Upper cutter part The upper cutter part comprises:
– Base frame with table
– Beam with carriage
– Beam drive
– Side covers with operating unit
The beam is driven by a DC-servo motor. The patented drive system:
– Has superb precision, reliability and durability (low maintenance)
– Consists of a slip-free steel band drive with torsion shaft and with hardened and
ground linear guides.
The robust beam is designed to accept all tool systems available. Beam and tool
head are monitored by a safety shut-down system consisting of light barriers and sa-
fety trip switches.
The carriage is part of the beam and is used for carrying the tool heads. A central
locking screw enables quick and trouble-free head exchange.
The carriage drive is integrated into the beam and comprises:
– A servo-controlled DC motor
– A slip-free steel band drive
The standard tabletop is made from easy-care plastic. In practical use, it is a proven
solution with low noise emission and it protects the tools. The material to be pro-
cessed is put on the table and held down by vacuum.
Principle for fixing the material:
Small holes in the vacuum plate are connected to a vacuum pump via air ducts. The
suction area of the table can be adjusted and controlled depending on the application
and material feeding system.
The two side covers encase the beam drive.
The control panel:
– Is integrated into a side cover
– Consists of an LCD display and keypad
– Enables user-friendly input of settings and menu commands

PN series frame version Product description
Intended use
2-5
110004,001,11-2009, jmu
2
Lower cutter part The lower cutter part comprises:
– Side parts
– Covering panels
– Electronic unit and distribution box
– Vacuum pump(s)
The two side parts
– Are attached to the base frame
– Can be adapted to uneven floors using the levelling screws.
Between the side parts
– Braces are fastened for the assembly of the electronics box and the vacuum
pump(s)
– Two removable covering panels are hung.
The electronic control box:
– Is fitted on pull-out rails for ease of servicing
– Contains the main processor, the servo processor for the 4-axis control system
and the power supply unit
– Can be adapted to the available mains voltage using a voltage selector
The distribution box is operated using the On/Off switch and enables:
– All components of the plotter system to be switched on/off simultaneously
– Consumer loads to be switched on by the software
– Distribution of individual consumers to different mains phases
Compressor, extractor and vacuum pump(s) with accessories:
– Are adapted to the plotter version and to the material feed system,
– Are located under the plotter if there is enough space
Large vacuum pumps are installed in sound-proof boxes or in an adjoining room.
Extractors are used only for milling operations.
2.6 Intended use
The plotter system is to be used:
– As output device for CAD/CAM systems
– For processing materials arranged on the table
The intended use and the limits of the application:
– Depend on the tools and material feed system available
– Are specified in sections 3 and 4
2.7 Technical information

Product description PN series frame version
Technical information
2-6
110004,001,11-2009, jmu
2
2.7.1 Dimensions and weights
Fig. 2-4 Dimensions
* Working area and material clearance width are dependent on the tool heads used.
Plotter line Type Working area *
(W x L)
Overall dimensions Weight
approx.
Material Clea-
rance Width*
S-line S-800 800 x 800 mm 1355 x 1246 x 995 mm 250 kg 1,060 mm
M line
M-800
M-1200
M-1600
1300 x 800 mm
1300 x 1,200
mm
1300 x 1,620
mm
1841 x 1246 x 995 mm
1841 x 1646 x 995 mm
1841 x 2066 x 995 mm
310 kg
370 kg
460 kg
1,550 mm
1,550 mm
1,550 mm
L line
L-800
L-1200
LR-1600
1800 x 800 mm
1800 x 1,200
mm
1800 x 1,650
mm
2361 x 1246 x 995 mm
2361 x 1646 x 995 mm
2400 x 2280 x 1060 mm
490 kg
500 kg
570 kg
2,050 mm
2,050 mm
2,050 mm
XL line
XL-800
XL-1200
2200 x 800 mm
2200 x 1,200
mm
2760 x 1246 x 995 mm
2760 x 1646 x 995
430 kg
720 kg
2,460 mm
2,460 mm
