1. Introduction
This Z-Wave USB Dongle enables you to access your USB devices without limitation
caused by wire. This Dongle is designed to adapt your regular USB 2.0 interface to a
Wireless USB interface. Simply plug this dongle to your USB socket then the notebook
turns into a wireless USB enabled platform, access your Z-Wave USB devices such as
printer, scanner freely without boundary up to 10 meters. Just plug the dongle in, then
enjoy the freedom and take the advantage of operation wirelessly with the latest
Wireless USB technology.
Features
Simply plug in PC/Notebook USB port with driver installation
Fully compatible with Z-wave enable network that can communicate with
any Z-wave certified device.

Z-Wave USB Dongle
2
Package Contents
Z-Wave USB Dongle x1
CD (Driver and User’s Manual) x1
Quick Installation Guide x1
System Requirements
Windows2000, XP, Vista, Windows7
Applicable For Serial Product of Z-Wave
Z-Wave dongle is Z-WaveR-Certified software and is compatible with Z-Wave
Cerfied devices. Z-Wave standard is designed to ensure that Z-Wave-Certified
devices work together, regardless of manufacturer. Z-Wave devices can also act
as repeaters, re-transmitting RF signals around obstacles and radio dead spots to
help ensure that messages are successfully delivered.

Z-Wave USB Dongle
2. Installation
On Windows XP and 2000
To install Driver:
1. Insert the provided CD into disk drive. Click Next to the Next step for
installation.
3

Z-Wave USB Dongle
4
2. Click Install to begin the installation.
3. Click Finish to exit the wizard.
4. Please Plug in Z-Wave USB Dongle to the USB Port on your PC.

Z-Wave USB Dongle
On Windows Vista and 7
To install Driver:
1. Insert the provided CD into your disc drive, locate and double-click the
Setup.exe file under E:\Driver where E is your disc drive letter. Click Next to
the next step for installation.
5

Z-Wave USB Dongle
6
2. Click Finish to exit the wizard.
3. Please Plug in Z-Wave USB Dongle to the USB Port on your PC.

Z-Wave USB Dongle
3. Specifications
Protocol Z-Wave
User Interface USB A-Type Plug
USB Compliance USB 2.0 specification; backward compatible with USB
1.1
Power USB bus powered
Frequency 908.42MHZ( US) /868.42MHz (EU)
Data Rate 9.6 kbps and 40kbps
RF range 15m indoor, 30m outdoor
Housing Plastic
Dimension 59(L)X26(W)X12.4(H)mm
( Not include USB A-Type Plug)
Weight Approximately 11g
Operation temperature 10-40°C
Storage temperature -10~80°C
Relative Humidity 0~80% non-condensing
7

Z-WaveUSBDongle
4. Regulatory Compliance
FCC Conditions
This equipment has been tested and found to comply with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received. Including interference
that may cause undesired operation.
Important! Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s authority to
operate the equipment. Use an approved phone set.
CE
This equipment is in compliance with the requirements of the following
regulations: EN 55 022: CLASS B
WEEE Information
For EU (European Union) member users:
According to the WEEE (Waste electrical and electronic equipment) Directive, do
not dispose of this product as household waste or commercial waste. Waste electrical
and electronic equipment should be appropriately collected and recycled as
required by practices established for your country. For information on recycling of
this product, please contact your local authorities, your household waste disposal
service or the shop where you purchased the product.
