ZALMAN CNPS7700 LED User manual

* Applies to all versions of CNPS7700 LED.
* Please read before installation.
http://www.zalman.co.kr http://www.zalmanusa.com
CNPS7700
Intel Pentium 4
Socket 775 CPU
Grip (S-Type)
Grip (L-Type)
Inner Hole
Grip (L-Type)
Outer Hole
Intel Pentium 4
Socket 478 CPU
AMD Sempron/AMD64 (Athlon 64/Opteron)
Socket 754/939/940 CPU
(English version)
User
’’
s Manual

※
The specifications of any product may change without prior notice to improve performance.
1
Fan
Clip
Fan Fixing Screw
Grip (S-Type)
Grip (L-Type)
Fan Support Fixing Screw
Fan Support
FHS
1. Features
1) Flower Heatsink (FHS)
CNPS7700-AlCu CNPS7700-Cu
Model
Spec.
Weight (g)
T.R.
(°C/W )
Silent Mo e
Normal Mo e
600(1)
0.28
0.21
136 (L) X 136 (W) X 67 (H)
3,268
918(1)
0.24
0.19
Dimensions (mm)
Dissipation Area ( ㎠ )
2. Specifications
2) Fan
- Bearing Type : 2-Ball
- Rotation Spee : 1,000 ~ 1,400rpm 10 % (Silent Mo e)
1,400 ~ 2,000rpm 10 % (Low-noise Mo e)
- Noise Level : 20 ~ 25 B 10% (Silent Mo e) - measure at 1m istance from noise source
25 ~ 32 B 10% (Low-noise Mo e) - measure at 1m istance from noise source
3) FAN ATE 2
- Output Voltage : 5V ~ 11V 2 %
- Allowable Power : 6W or lower
Note 1)
The maximum weight for a cooler is specifie as 450g for Intel Socket 775/478 an AMD Socket 754/939/940
Special care shoul be taken when moving a computer equippe with a cooler which excee s the relevant
weight limit. Zalman is not responsible for any amage that occurs when moving a computer.
3. Exploded View
1) Does not generate noise or vibration in Silent Mo e.
2) Pure copper an /or pure aluminum base materials ensure excellent heat issipation.
3) Intel Pentium 4 (Socket 775), Intel Pentium 4 (Socket 478), an AMD Sempron / AMD64 (Socket
754/939/940) compatible esign for broa compatibility.
4) The large 120mm fan insi e the FHS maximizes cooling performance by provi ing sufficient airflow
even at slow rotation spee s.
5) The large 120mm fan provi es air flow over a large area, cooling not only the CPU, but the VGA car ,
Northbri ge, FET, an RAM.
6) The high intensity blue LEDs on CNPS7700 LED coolers stay bright even in Silent Mo e.
7) The a justable fan spee controller (FAM MATE 2) enables control of noise an fan performance.

※
The specifications of any product may change without prior notice to improve performance.
2
󱆍
󱆎
󱆏
❿
❾
❶
❸
❺
❹
❻
❽
❼
󱆌
󱆐
❷
󳣍Korean Patent Application No. 00-54635
󳣍Korean Design Applications Nos. 04-16030 etc.
󳣍Patent Applications pen ing in over 20 nations aroun the worl , inclu ing USA, EU, an Japan
4. Patents
Precautions
1) If excessive force is exerte on the fan, it may malfunction an result in amage to the pro uct an /or the computer.
2) Do not put your finger in the fan while it is running.
3) Keep the pro uct away from chil ren.
4) Check the components list an con ition of the pro uct before installing. If there is any problem, contact the shop
where you purchase it an get a replacement or refun .
N TICE) Zalman Tech Co., Lt . is not responsible for any amages ue to external causes, inclu ing but not
limite to, improper use, problems with electrical power, acci ent, neglect, alteration, repair,
improper installation, or improper testing.
1) Common Components
❶ FHS Assembly (CNPS7700-AlCu/Cu)
❷ Four (4) Grips (2 each for S-Type an L-Type)
❸ Four (4) Bolts (for installing the FHS)
❹ Thermal Grease
❺ Fan Spee Controller (FAN MATE 2)
❻ Double - si e Tape (for installing FAN MATE 2)
❼ Cable for FAN MATE 2
❽ User’s Manual (in English an Korean)
5. Components
2) Components for Intel Pentium 4 (Socket 775)
❾ One (1) Clip Support for Socket 775
❿ One (1) Backplate for Socket 775
󱆌 Four (4) Clip Support Fixing Bolts
3) Components for Intel Pentium 4 (Socket 478)
󱆍 Two (2) Clip Supports for Socket 478
4)
Components for AMD Sempron / AMD64 (Socket 754/939/940)
󱆎 Two (2) Nipples
󱆏 One (1) Backplate for AMD64
󱆐 One (1) set of Washers

※
The specifications of any product may change without prior notice to improve performance.
3
TC
TD
CPU Die TD> TC
IHS
10.2mm Motherboar component height restriction
4mm
Grip
Motherboar
Component
Grip
Motherboar Component
Figure 1
Compatible
Figure 2
Not Compatible
Northwood
3.4
68 69.1
2.8A/E, 3.0E 3.2E, 3.4E 520, 530, 540 550, 560
Prescott - 478 Prescott - 775
CPU
TC_MAX
73.2 67.7 72.7
6. Compatible CPUs
1) Intel Pentium 4 - Socket 775/478
All CPUs conforming to Socket 775/478 platform
Cautions)
①No components higher than 39mm (possible examples : PSU, graphics
car , RAM etc.) shoul be present within a 68mm ra ius from the center
of the CPU.
②For Socket 478, as shown in Figure 2, a motherboar that is not compliant
with the "10.2mm Motherboar component height restriction" stan ar ,
intro uce by Intel, may create interference between components an the grip of CNPS7700. Please o not
install the CNPS7700 if this interference is observe .
③For more information, please visit the Zalman website (http://www.zalman.co.kr) an click on the links of
"CNPS7700 Compatible Socket 775 Motherboar s List" an "Compatibility between CNPS7700 an
Socket 478 Pentium 4 Motherboar s".
Notes)
3.4GHz Northwoo , Prescott-478 of 2.8A/E GHz or higher, an Prescott-775 of up to mo el 560 issipate
an exorbitant amount of heat (84W ~ 115W). Refer to the table below an a just the fan spee so that the
CPU-Case temperature (TC) is lower than the maximum CPU-Case temperature
(T C_MAX ) .
※ Har ware monitoring programs report CPU-Die temperature (T D )
as the CPU temperature. CPU-Die temperature (T
D ) is measure
about 4 ~ 10
℃ higher than CPU-Case temperature (T C ) epen ing
on the motherboar an /or BIOS.
Refer to the Zalman website for more information.
2) A D Sempron / A D64 - Socket 754/939/940
All CPUs conforming to Socket 754/939/940 platform
Cautions )
①No components higher than 39mm (possible examples: PSU,
graphics car , RAM etc.) shoul be present within a 68mm
ra ius from the center of the CPU.
②For more information, please visit the Zalman website
(http://www.zalman.co.kr) an refer to “CNPS7700 Compatible Socket
754/939/940 Motherboar s List”
link.

※
The specifications of any product may change without prior notice to improve performance.
4
Clip Support Fixing Bolt
Socket Lever Hinge
Lever Slot
Lever Slot
Socket Lever
Clip Support for Socket 775
Motherboar
Backplate for Socket 775
Backplate Support
CPU (IHS)
Bolt Grip (S-Type)
Grip (S-Type)
Clip Support for
Socket 775
Socket
775
478
754/939/940
Grip
S - Type
L - Type
L - Type
Hole
Hole
Inner Hole
Outer Hole
7. Installation
※ CNPS7700 must be use with a grip specific to
each CPU socket. Refer to the table on the
right to choose the correct grip for use.
1) Intel Pentium 4 - Socket 775
①①Install Clip Support for Socket 775
Align the clip support for socket 775 an the backplate for socket 775 with the mounting holes on the motherboar
an fasten them together using the clip support fixing bolts. The lever slot on the clip support shoul be properly
oriente on the hinge si e of the socket lever when installing.
* The backplate support is use for the convenience of installation. You can remove it if it is not eeme necessary.
②②Apply Thermal Grease
Clean off particles an resi ue from the top of the
CPU then sprea a generous amount of the inclu e
thermal grease thoroughly on top of the CPU.
※Unlike the flat-mille base of the FHS, the top surface of the LGA775 CPU may have minute ips an peaks
causing pockets of non-contact between the FHS an CPU. Please apply a generous amount of thermal grease
on the top of the CPU.
③③Install Grips and Bolts
Interlock the S-type grips with the clip. Insert the two
bolts into the holes of the grips.
④④Place FHS
Set the FHS at the center of the CPU. Screw the bolts
in slightly, then tighten each bolt a few turns at a time while
alternating between the two until the clip support is
completely presse against the grips.
⑤⑤Connect Power (How to use FAN ATE 2)
◆Please refer to FAN MATE 2 Installation an Usage on page 7.

※
The specifications of any product may change without prior notice to improve performance.
5
②②
Install Clip Supports for Socket 478
Install the clip supports for socket 478 on both si es
of the retention gui e as shown in the iagram.
③③Install Grips and Bolts
Interlock the L-type grips with the clip. Insert the two bolts
into the inner holes of the grips.
④④
Place FHS
Set the FHS at the center of the CPU. Screw the bolts
in slightly, an then tighten each bolt a few turns at a
time while alternating between the two until the clip
supports are completely presse against the grips.
Retention Gui e
Clip Support for Socket 478
󳦈
󳦇
󳦊
⑤⑤Connect Power (How to use FAN ATE 2)
◆Please refer to FAN MATE 2 Installation an Usage on page 7.
Bolt Grip (L-Type)
Inner Hole
Grip (L-Type)
Clip Support for
Socket 478
2) Intel Pentium 4 - 478
①①
Apply Thermal Grease
Clean off particles an resi ue from the top of the
CPU then sprea a thin layer of the inclu e thermal
grease thoroughly on top of the CPU.
CPU (IHS)

※
The specifications of any product may change without prior notice to improve performance.
6
①①
Fasten Nipples
Place a small washer on the motherboar . Then, put a nipple over it an fasten the nipple until the
Backplate for AMD64 is firmly attache to the motherboar on the opposite si e of the CPU.
* A Retention Gui e is not necessary for installing CNPS7700 on Socket 754/939/940.
③③Install Grips and Bolts
Interlock the L-Type grips with the clip. Insert the two bolts
into the outer holes of the grips.
④④
Place FHS
Set the FHS at the center of the CPU. Screw the bolts
in slightly, an then tighten each bolt a few turns at a
time while alternating between the two until the nipples
are completely presse against the grips.
⑤⑤Connect Power (How to use FAN ATE 2)
◆Please refer to FAN MATE 2 Installation an Usage on page 7.
②②
Apply Thermal Grease
Clean off particles an resi ue from the top of the
CPU then sprea a thin layer of the inclu e thermal
grease thoroughly on top of the CPU.
Bolt Grip (L-Type)
Outer Hole
Grip (L-Type)
Nipple
3) A D Sempron/A D64 - 754/939/940
CPU (Li )
Nipple
Motherboar
Small Washer
Backplate for AMD64

※
The specifications of any product may change without prior notice to improve performance.
7
Fan Connector
(CNPS7700)
Motherboar
Double-si e Tape
FAN MATE 2
6-Pin Connector
※FAN MATE 2 Installation and Usage
1) Installing FAN MATE 2 on the Insi e of the System 2) Installing FAN MATE 2 on the Outsi e of the System
Connect the appropriate 3-pin connector on the
cable to the motherboar fan hea er an the
CNPS7700’s fan connector.
Pull the 6-pin connector out of the system through
the back an connect it to FAN MATE 2, which
shoul be installe on the case using the inclu e
ouble-si e tape.
◆ When the spee control knob on FAN MATE 2 is turne fully counter-clockwise, the fan operates in Silent Mo e.
Turne fully clockwise, it operates in Normal Mo e. You can select the esire fan spee by turning the knob.
Note) FAN MATE 2 has been specifically esigne for the fan of this pro uct. Zalman Tech Co., Lt . is not
responsible for any amage to systems or CPUs cause by using it with other types of fans.
8. Notes on Usage
1) Checking CPU Compatibility
Please refer to “Compatible CPUs” on page 3 to confirm that your CPU is compatible before using the CPU cooler.
2) Cautions During Booting
When booting the computer, it may automatically power own after an alarm soun by a system
monitoring program to in icate that the the CPU fan is rotating slowly. If this happens, turn the spee
control knob fully clockwise to increase the fan spee . Then set ‘CPU Fan Detecte ’ to ‘Disable ’ in
BIOS settings, or set the slowest rotational spee of the CPU fan in the system monitoring program to
less than or equal to 900rpm.
Note) Some motherboar s o not boot if the rotational spee of the CPU fan is below a certain
rpm. If the BIOS settings are up ate , Silent Mo e can be use . For more information on
up ating your BIOS, please refer to your motherboar manufacturer's website. Disabling
CPU fan spee etection in BIOS settings oes not affect computer performance.
3) OVERCLOCKING
The fan shoul be set to Normal Mo e if OVERCLOCKING.
(Zalman Tech Co., Lt . is not responsible for any amage resulting from CPU OVERCLOCKING.)

※
The specifications of any product may change without prior notice to improve performance.
8
When buil ing a noiseless computer, use Zalman’s Noiseless Power Supply, Noiseless Case Fan,
Fanless Northbri ge Cooler, Heatpipe HDD Cooler, Heatpipe VGA Cooler, an Fan Controller to achieve
stable performance an maintain a noiseless environment.
9. Zalman Noise Prevention System
The TNN 500AF is the worl 's first absolutely noiseless, anti-dust computer case for high-en systems that
has been evelope with Heatpipe Technology, HSC (Heat Source Contact) Power Technology, High
Capacity Extrusion Technique, an FMS (Flexible Mounting Structure) Design Technology by ZALMAN
Tech Co., Lt .
The TNN 500AF package inclu es a high performance aluminum computer case with an absolutely
noiseless cooling solution that oes not require the use of a fan, making it i eal for:
1. Digital Audio Workstations (DAW) in broa casting, recor ing, an postpro uction stu io control rooms.
2. ulti edia & Storage Servers for offices, e ucational facilities, an hotels.
3. Home Theater and ulti edia Systems for living rooms.
4. High Performance Noiseless Workstations & Servers for SOHO (Small Office Home Office) systems.
For more information, please visit the Zalman website at www.zalman.co.kr
10. TNN (Totally No Noise) Computer Case
Noiseless Power Supply Fanless Northbridge Cooler Heatpipe HDD Cooler
Noiseless Case Fan Heatpipe VGA Cooler Fan Controller
