ZALMAN ZM400-ST User manual

User’s Manual
ZM400-ST
Ver. 1.0
www.ZALMAN.com
To ensure safe and easy installation,
please read the following precautions.
All manuals and user guides at all-guides.com
all-guides.com

11
1. Warnings and Safety Precautions
2. Components
Power Supply Unit
AC Power Cord
Five (5) Cable Ties Four (4) Fixing Bolts
User’s Manual
▶Opening the cover of the product while the power cord is plugged into an outlet
may cause electrocution or critical damage to the product.
▶Handling the power cord with wet hands may cause electrocution.
▶Inserting fingers or metallic objects into the cooling fan may cause injury or
electrocution.
▶Operating the product in an extremely cold or hot environment can degrade
product performance and lifespan.
▶Exposure to liquids may cause malfunction.
▶Operation in a humid or non-ventilated environment may reduce product lifespan.
▶Plugging the main power connector P1 into the motherboard while the product is
connected to the AC power source may cause damage to the motherboard.
▶Make sure that the connectors are connected to their designated locations, and
that the connectors are not oriented in the wrong direction when connecting the
DC output connectors.
▶Please use gloves to prevent injuries during installation.
▶Product designs and specifications may be revised without prior notification to
improve quality and performance.
Neglecting the following may cause serious injury or death.
Neglecting the following may cause minor injuries, degrade product
conditions or cause malfunction.
Caution
Warning
Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due
to external causes, including but not limited to, improper use,
problems with electrical power, accident, neglect, alteration,
repair, improper installation, or improper testing.
All manuals and user guides at all-guides.com

22
3. Specifications
1) Electrical & Physical Specifications
2) Output Power Cable Specifications
AC Input Range
Voltage 100 ~ 240VAC DC OUTPUT
Frequency 50 ~ 60㎐
Vout
Output Load Rating
Combined Combined
Power
AC Input Currnet
Power (Rated)
115VAC 8A Imin Imax
230VAC 5A +3.3VDC 0.3A 24A 120W
400W
PFC Type Active PFC +5VDC 0.5A 15A
Power Factor MAX 99% +12V1DC 0.5A 20A 384W
Inrush Current Limit
(@ Cold start at 25℃)
115VAC 60A +12V2DC 0.5A 20A
230VAC 120A -12VDC 0.0A 0.3A 3.6W
Efficiency MAX 86% @ 230VAC, Typical load +5VSB 0.0A 3A 15W
DC Output Voltage
Regulation
Vout Stable Range
At
Full
Load
Ambient Temperature
+3.3VDC ±5% +3.14 ~ +3.47V Operation 10 ~ 40℃
+5VDC ±5% +4.75 ~ +5.25V Stored -40 ~ 70℃
+12V1DC ±5% +11.4 ~ +12.6V Ambient Humidity
+12V2DC ±5% +11.4 ~ +12.6V Operation 20 ~ 85%RH
-12VDC ±10% -10.8 ~ -13.0V Stored 5 ~ 95%RH
+5VSB ±5% +4.75 ~ +5.25V Over-Voltage Protection & Over-Current Protection
DC Output Ripple
&
Noise
Vout Standard Range
At
Full
Load
Over-Voltage Protection(OVP)
+3.3VDC 50mV Over-Current Protection(OCP)
+5VDC 50mV Under-Voltage Protection(UVP)
+12V1DC 120mV Short-Circuit Protection(SCP)
+12V2DC 120mV Over Power Protection(OPP)
-12VDC 120mV Dimensions
+5VSB 50mV 140(L) ×150(W) ×86(H) ㎜
PCI Express1
Power Connector
Motherboard Power
Connector
CPU Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
ODD/HDD Power
Connector
ODD/HDD Power
Connector
ODD/HDD Power
Connector
ODD/HDD Power
Connector
ODD/HDD Power
Connector
FDD Power
Connector
All manuals and user guides at all-guides.com

33
4. Certifications
