Zamil PS036 Instruction manual

INSTALLATION,
OPERATION
&
MAINTENANCE
MANUAL
SINGLE PACKAGED ROOF TOP AIR CONDITIONERS
'PS' SERIES
MODELS: PS036 - PS360 Part Number: 800-213-04

Contents Page
General
Model decoding...................................................................................................................................................... 2
General statement.................................................................................................................................................. 3
Warranty................................................................................................................................................................. 3
Safety issues .......................................................................................................................................................... 3
Inspection for damage............................................................................................................................................ 3
Installation instructions
General................................................................................................................................................................... 4
Location of unit....................................................................................................................................................... 4
Service clearance................................................................................................................................................... 5
Rigging instructions................................................................................................................................................ 5
Condensate drain connection ................................................................................................................................ 6
Duct connection ..................................................................................................................................................... 6
Electric heater ........................................................................................................................................................ 6
Cable size .............................................................................................................................................................. 6
Unit weight & weight distribution ............................................................................................................................ 6
Unit dimensions.................................................................................................................................................7-11
Operation instructions
Start-up inspection & check list ............................................................................................................................ 12
Electrical data..................................................................................................................................................13-17
Performex controller, operation & functions....................................................................................................18-19
Crankcase heater................................................................................................................................................. 19
Pump down control .............................................................................................................................................. 19
Maintenance instructions
Airflow adjustment ................................................................................................................................................ 20
Crankcase heater................................................................................................................................................. 20
Cleaning of coils & filters...................................................................................................................................... 20
Belt tension testing procedure ........................................................................................................................20-21
Field wiring connections....................................................................................................................................... 21
Preventive maintenance schedule ....................................................................................................................... 22
Trouble shooting chart ....................................................................................................................................23-24
Typical schematic wiring diagram ...................................................................................................................25-48
Parts list...........................................................................................................................................................49-50
INDEX
CONTINUING RESEARCH RESULTS IN STEADY IMPROVEMENTS.
THEREFORE, THESE SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
1

C : 1.5 HP ODP D: 2 HP ODP D: 2 HP ODP E: 3 HP ODP F: 3 HP TEFC G: 5 HP ODP H: 5 HP TEFC J: 7.5 HP ODP K: 7.5 HP TEFC J: 7.5 HP ODP K: 7.5 HP TEFC L: 10 HP ODP M: 10 HP TEFC L: 10 HP ODP M: 10 HP TEFC N: 15 HP ODP P: 15 HP TEFC
MODELS: PS075 - PS360 (BELT DRIVEN MOTOR)
1& 2
BASIC 3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
8
BLOWER
MOTOR
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
10
HEATER
OPTIONS
(kW/STAGE)
12
CONDENSER
COIL
PS
PACKAGED
UNIT
036 048 060
U: 0.5 HP ODP
W: 0.75 HP ODP
H:208/230-3-60 M:380-3-60 (4 WIRE) F : 460-3-60
N: NOHEATER A: 5/1 B: 6/1 C: 7.5/1 D: 10 /2 E: 12/2
J: IGT + ENHANCED
AL. FINS
K:IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
9
DRIVE
OPTIONS
N: DIRECT
DRIVE
11
EVAPORATOR
COIL
J:IGT + ENHANCED
AL. FINS
K :IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
15
UNIT
ACCESSORIES
N: STANDARD UNIT C:FRESH AIR
MANUAL DAMPER
MODELS: PS036 - PS060 (DIRECT DRIVE MOTOR) MODEL DECODING
7
REFRIGERA-
TION CIRCUIT
S:SINGLE
14
OTHER
OPTIONS
N: STANDARD UNIT I: ANTI-ICE U:UVM V: VOLT FREE
CONTACT
13
PDS
OPTION
N:NO PDS
OPTION
P:PDS OPTION
1& 2
BASIC 3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
8
BLOWER
MOTOR
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
10
HEATER
OPTIONS
(kW/STAGE)
12
CONDENSER
COIL
PS
PACKAGED
UNIT
075 090 100 120 180 215 240 300 360
H:208/230-3-60 M:380-3-60 (4 WIRE) F : 460-3-60
N: NOHEATER A: 5/1* B: 6/1* C: 7.5/1 D: 10 /2 E: 12/2 F: 15 /2 G: 20 /2 C: 7.5/1 D: 10 /2 E: 12/2 F: 15 /2 G: 20 /2 H: 25/2 J: 30/2**
J: IGT + ENHANCED
AL. FINS
K:IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
9
DRIVE
OPTIONS
J:ALT. I K:ALT. II
11
EVAPORATOR
COIL
J:IGT + ENHANCED
AL. FINS
K :IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
15
UNIT
ACCESSORIES
N: STANDARD UNIT C:FRESH AIR
MANUAL DAMPER
7
REFRIGERA-
TION CIRCUIT
S:SINGLE
14
OTHER
OPTIONS
N: STANDARD UNIT I: ANTI-ICE U:UVM V: VOLT FREE
CONTACT
13
PDS
OPTION
N:NO PDS
OPTION
P:PDS OPTION
NOTE:*– Applicable for PS075 models only.
** – Applicable for models PS180 & above only.
D:DUAL
2

GENERAL
GENERAL STATEMENT
This unit is from the PS series that was designed & built for the optimum performance. However, it is required that you become well
acquainted with good practices for the proper installation/operation/and maintenance procedures in order to ensure a safe trouble free
operation, year after year.
Please read through the whole manual contents before you attempt to install/operate/ and maintain the unit.
Mostoftheproceduresdescribedinthismanualrequirecertainskillsandexperience.Theinstallationandothermaintenanceprocedures
should be performed only by highly skilled and experienced technicians. The end user’s role should be limited to the cleaning of the
filter.
Please consult your nearest “Zamil” representative for further information.
The PS units can be supplied, depending on the End User requirement, as the basic “Cool Only” version, or the “Heat & Cool” version
(with electric heater module).
WARRANTY
All of the PS series of Packaged Roof Top Units are covered by the standard warranty terms against any manufacturer defect. Should
you encounter any problem that falls under the warranty terms please contact your nearest “Zamil” representative.
SAFETY ISSUES
There are three degrees of safety hazards that are identified throughout this manual as WARNING (where the situation will result in
personal injury), CAUTION (where personal injury might occur), and ATTENTION (where minor personal injury and/or property dam-
age could happen). Please understand and respect those identifications.
WARNING: The PS units operate on a high voltage with moving parts (at high speed) which can lead to serious injuries and/
or damage to the unit. Never attempt to service the unit unless the main electrical power supply has been disconnected.
CAUTION: Extra care should be observed when installing, test running, adjusting, servicing, or maintaining the unit as the
hazard of explosion, fire, electrical shock, and potential personal injury and property damage are present.
When performing any task pertaining to the installation and maintenance of the unit, the skilled technician should observe all the
applicable safety measures (wear of safety helmet, boots, gloves, and goggles. Use of proper handling materials for brazing and use
of wet cloth for quenching. A fire extinguisher should be easily accessible etc.). He should also read all the instructions and information
in this Manual prior to attempting to perform any installation or servicing of the unit.
All applicable local codes should also be observed.
INSPECTION FOR DAMAGE
The unit should be carefully inspected visually for any sign of physical damage due to mishandling. Whenever a damage is detected,
please indicate it on the corresponding delivery note before you sign it and inform your nearest “Zamil” office.
3

GENERAL
These units are shipped completely assembled, charged, and wired. They do not require any field installation of refrigerant tubing.
Units require external power, thermostat wiring, condensate drain piping and ducting as applicable.
Size of unit for an installation should be based on a heat gain calculation made according to applicable standards. Units must also be
installedin accordance with regulationsofthe "National Fire ProtectionAssociation"and local electrical codes.Wherelocalregulations
conflicts with the instructions in this manual, installer should adhere to local standards.
Prepare your concrete pad or steel stand based on the corresponding dimensions. Remove shipping protective covers and wooden
crating and lift unit from base and place in position with suitable rubber vibration isolators.
All field installed accessories are to be installed by the customer with necessary reinforcements as required.
LOCATION OF UNIT
When selecting the location for the unit, the following points should be kept in mind:
1. Provisions for a concrete pad or steel stand base.
2. That the terrain allows for drainage away from the unit.
3. If the unit is to be roof mounted, inspect the roof for load bearing capacity. The roof should have sufficient structural strength to
carry the weight of the unit.
4. Install unit on vibration isolation pads, i.e. on rubber mounting pads.
5. Availability of electric power.
6. To position the unit for unrestricted air circulation of the condenser air inlet and to prevent any possibility of air recirculation from the
condenser fan discharge air (see figure on next page).
7. Check minimum clearances required for your unit, with regard to walls, or other obstructions (see figure on next page).
8. Air cooled equipment should not be installed under low structural overhangs which can cause condenser air recirculation or
restriction. Observe minimum of clearance (see figure on next page).
9. Care should be taken to prevent air from other sources from entering condenser, if this air is at a high temperature.
10.Level the unit on its final location and be sure that the levelling tolerance is ±5 mm per linear meter in any direction.
CAUTION: Do not install the unit as indoor unit, install it in an open area, and unit air inlets must not be located near exhaust
vents or other source of contaminated air.
INSTALLATION INSTRUCTIONS
4

B
C
A
E
D
B
C
D
A
SPREADERBAR
NOMINAL PIPE THRU UNIT FOR SLINGS TO AVOID BASE DAMAGE.
END
PROPER CLEARANCE TO BE
PROVIDED.
COMPRESSOR
LIFT LIFT
2. PIPE DIA 2" FOR PT090 TO PT360 MODELS
1 .PIPE DIA 1 1/2" FOR PT036 TO PT075 MODELS
Note:
SERVICE CLEARANCE
MODEL DIMENSIONS
NUMBER A B C D
PS036 85 105 85 150
PS048 85 105 85 150
PS060 85 105 85 150
PS075 90 105 90 200
PS090 90 105 90 200
PS100 90 105 90 200
PS120 90 105 90 200
NOTE: All dimensions are in cm.
A :Clearance dimension from condenser coil
B :Clearance dimension from compressor, control box, blower, evaporator coil & filter
C :Clearance dimension from condenser coil & filter
D :Clearance dimension over the condenser fan
MODEL DIMENSIONS
NUMBER A B C D E
PS180 120 120 115 250 90
PS215 120 120 115 250 90
PS240 120 120 115 250 90
PS300 120 120 115 250 90
PS360 120 120 115 250 90
A : Clearance dimension from condenser coil
B : Clearance dimension from compressor, control box & evaporator coil
C : Clearance dimension from condenser coil & blower
D : Clearance dimension over the condenser fan
E : Clearance dimension from filter access panel
MODELS: PS036 - PS120 MODELS: PS180 - PS360
ATTENTION TO RIGGERS
•Insert 2" nominal pipe through holes in the base rail as shown in the figure below for slings.
•Holes in base rail are centered around the unit center of gravity.
•Use wooden pallet or spreader bar when rigging, to prevent the slings from damaging the unit.
•Rollers may be used to move the unit on the roof or ground.
CAUTION: All panels should be in place when rigging.
RIGGING INSTRUCTIONS
MODELS: PS036 - PS360
NOTE: Only two condenser fans for models PS180 - PS240.
5

CONDENSATE DRAIN CONNECTION
•Use standard PVC pipe with NPT connection for the condensate drain. Provide a 'P' trap immediately at the condensate drain connection.
•Piping has to be sloped away from the unit.
•Remember to remove the drain hole plug before operating the unit. Avoid bends & elbows.
DUCT CONNECTION
The units can be connected to the ducting in horizontal configuration. Connect ducting using flexible duct connection. The duct should
be properly designed and the drive package should match the required CFM & corresponding external static pressure.
ATTENTION: Avoid abrupt changes in size and/or direction of duct to ensure proper unit performance.
UNIT WEIGHT & WEIGHT DISTRIBUTION
ELECTRIC HEATERS
Electric heater kit is installed in the unit at the supply air opening space.
CABLE SIZE
•All wiring should be in accordance with local and NEC standards.
• Before making any connection, check the electric power supply, it must have the same characteristics as what is displayed in the nameplate.
•For selecting cable size, refer to wire ampacity table at different MCA (Minimum Circuit Amps) provided in unit electrical data, which
is listed as a guideline.
•Wiring connection to the unit must have suitable insulation of a minimum temperature of 900C.
MODEL
NUMBER
WEIGHT (Kg.)
JKML
PS036
PS048
PS060
PS075
PS090
PS100
PS120
PS180
PS215
PS240
PS300
PS360
51
57
62
70
94
96
97
150
93
95
195
216
33
39
41
45
72
71
72
84
101
102
141
151
-
-
-
-
-
-
-
107
175
178
214
249
PQ
-
-
-
-
-
-
-
104
102
104
151
175
JP K
MQ L
CONDENSER SECTION
66
72
75
85
115
131
134
154
181
183
219
256
36
41
45
52
92
89
91
98
88
92
123
145
6
SUPPLY AIR/
RETURN AIR
!
!

UNIT DIMENSIONS
PS036 - PS075
ABCDEFGHJKLM
PS036 - PS060 1460(57.48) 1025(40.35) 1430(56.3) 700(27.56) 163(6.42) 373(14.68) 250(9.84) 500(19.69) 57(2.24) 304(11.96) 343(13.49) 340(13.39)
PS075 1775(69.88) 1150(45.28) 1745(68.7) 800(31.5) 175(6.89) 480(18.9) 325(12.8) 672(26.46) 80(3.15) 280(11.02) 275(10.83) 600(23.62)
MODEL DIMENSIONS
NOTE:
1. All dimensions are in mm (dimensions in brackets are in inches).
2. Service clearance should be 1200mm (4 feet) on all sides.
7
CONDENSATE DRAIN OUTLET [BOTH ENDS]
MOUNTING HOLES Ø
13 [0.5] [ 4 EACH]
K
J
286 [11.27]
90 [3.53]
51 [2.00] 15 [0.59]
61 [2.41]
850 [33.46]
FRESH AIR
OPENING
POWER SUPPLY INLET
DRAIN OUTLET
[BOTH ENDS]
FILTER ACCESS
PANEL [BOTH ENDS]
CONDENSER COIL
CONDENSER COIL
COMPRESSOR/CONTROLS
ACCESS PANEL
ACCESS PANEL
FOR BLOWER
AND MOTOR
AIR IN
RETURN AIR
SUPPLY AIR
AIR OUT
AIR IN
SIDE VIEW
COMPRESSOR/CONTROL
COMPARTMENT
SIDE VIEW
FRONT VIEW
TOP VIEW
RETURN AIR
OPENING
SUPPLY
AIR
OPENING

UNIT DIMENSIONS
PS090 - PS120
NOTE:
1. All dimensions are in mm (dimensions in brackets are in inches).
2. Service clearance should be 1200mm (4 feet) on all sides.
8
SIDE VIEW SIDE VIEWFRONT VIEW
TOP VIEW

UNIT DIMENSIONS
PS180
NOTE:
1. All dimensions are in mm (dimensions in brackets are in inches).
2. Service clearance should be 1200mm (4 feet) on all sides.
9
SIDE VIEW SIDE VIEWFRONT VIEW
TOP VIEW

UNIT DIMENSIONS
PS215 - PS240
NOTE:
1. All dimensions are in mm (dimensions in brackets are in inches).
2. Service clearance should be 1200mm (4 feet) on all sides.
10
SIDE VIEW SIDE VIEW
FRONT VIEW
TOP VIEW

UNIT DIMENSIONS
PS300 - PS360
NOTE:
1. All dimensions are in mm (dimensions in brackets are in inches).
2. Service clearance should be 1200mm (4 feet) on all sides.
11
SIDE VIEW SIDE VIEW
FRONT VIEW
TOP VIEW

OPERATION INSTRUCTIONS
START-UP, INSPECTION & CHECK LIST
After the installation is completed in all respect, the following points should be covered before the system is switched on for operation.
1. Check unit location as per installation instructions.
2. Make sure all electrical fasteners/connections are tight and clean.
3. All controls are set according to manufacturer's instructions (low & high pressure switch, pump down solenoid, etc...)
4. Make sure all valves are open (compressor suction & discharge service valves, liquid line, etc.).
5. Follow all the instructions from the warning tags and stickers.
6. Check if condenser & blower fan are free to turn without wobbling.
7. Remove straps & wooden pieces that holds the compressor in place during transportation.
8. Compressor crankcase heater should be energizedfor24hours(special attention should be taken todisablecompressorcontactor
before energizing the unit.
9. Expansion valve bulb is strapped properly at correct location (applicable for PS075 - PS360 only).
10. Circuit breaker/fused disconnect switch.
11. Blower fan belt is properly tightened and pulleys are properly aligned (applicable for PS075 - PS360 only).
12. All refrigerant service valve caps are installed.
13. All piping, piping insulation and piping supports are properly installed.
14. Thermostat is the right one and installed properly.
15. Connect the manifold gauge to suction & discharge line service valves. Prepare recommended instruments for checking Voltage,
Amps, RPM, CFM, static pressure, etc.
16. Start the blower fan and condenser fan. Check the amperage against the nameplate ampere.
17. Start the compressor & observe the compressor discharge and suction pressures. If not within system design limits, determine
why & take corrective action.
12

187 253 2.3
342 418 2.3
414 506 1.1
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA
Nom. kW FLA
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA
Nom. kW FLA
VOLTAGE
RANGE
FLAMax.Min.
POWER
SUPPLY
(V-Ph-Hz)
PS036 PS048
MODEL NUMBER
DESCRIPTION
ELECTRICAL DATA
MODELS: PS036 & PS048
67
39
29.2
11.8
5.6
5.4
208/230-3-60
380-3-60 (4 WIRE)
460-3-60
––2740
5/6 12.6/15.1 27/27 40/40
7.5/10*18.8/25.1 29.4/37.3 40/40
12*30.1 43.5 45
– – 17.3 25
5/6 7.6/9.1 17.3/17.3 25/25
7.5/10*11.4/15.2 20.1/24.9 25/25
12*18.2 28.6 30
––1420
5/6 6.3/7.5 14/14 20/20
7.5/10*9.4/12.6 15/19 20/20
12*15.1 22.1 25
FM
(each)
– – 18.9 30
5/6 12.6/15.1 18.9/21.1 30/30
7.5/10*18.8/25.1 25.8/33.6 30/35
12*30.1 39.9 45
– – 11.1 15
5/6 7.6/9.1 11.8/13.6 15/15
7.5/10*11.4/15.2 16.5/21.3 20/25
12*18.2 25 30
– – 8.7 15
5/6 6.3/7.5 8.9/10.4 15/15
7.5/10*9.4/12.6 12.8/16.8 15/20
12*15.1 19.9 25
0.5
0.5
0.5
1.8
1.8
0.83
97
50
50
16
8.2
8.2
0.75
0.75
0.75
4.7
4.7
2.6
187 253 2.3
342 418 2.3
414 506 1.1
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
VOLTAGE
RANGE
FLAMax.Min.
POWER
SUPPLY
(V-Ph-Hz)
PS060 PS075
MODEL NUMBER
DESCRIPTION
MODELS: PS060 & PS075
105
55
55
19.6
10.4
10.4
208/230-3-60
380-3-60 (4 WIRE)
460-3-60
– – 33.8 50
5/6 12.6/15.1 33.8/33.8 50/50
7.5/10*18.8/25.1 33.8/38.4 50/50
12*/15*30.1/37.7 44.6/54.1 50/60
– – 34.8 50
5/6 12.6/15.1 34.8/34.8 50/50
7.5/10*18.8/25.1 34.8/39.6 50/50
12*/15*30.1/37.7 45.9/55.4 50/60
– – 19.1 25
5/6 7.6/9.1 19.1/19.1 25/25
7.5/10*11.4/15.2 19.1/23.3 25/25
12*/15*18.2/22.8 27/32.8 30/35
– – 19.7 30
5/6 7.6/9.1 19.7/19.7 30/30
7.5/10*11.4/15.2 19.7/24 30/30
12*/15*18.2/22.8 27.8/33.5 30/35
- – 16.4 25
5/6 6.3/7.5 16.4/16.4 25/25
7.5/10*9.4/12.6 16.4/19.3 25/25
12*/15*15.1/18.8 22.4/27 25/30
– – 17.1 25
5/6 6.3/7.5 17.1/17.1 25/25
7.5/10*9.4/12.6 17.1/20.1 25/25
12*/15*15.1/18.8 23.3/27.9 25/30
FM
(each)
4.7
4.7
2.6
0.75
0.75
0.75
156
72
74
20.7
10.7
10
– – 31.5 50
5/6 12.6/15.1 31.5/31.5 50/50
7.5/10*18.8/25.1 31.5/37.3 50/50
12*30.1 43.5 50
––2030
5/6 7.6/9.1 20/20 30/30
7.5/10*11.4/15.2 20.1/24.9 30/30
12*18.2 28.6 30
– – 16.7 25
5/6 6.3/7.5 16.7/16.7 25/25
7.5/10*9.4/12.6 16.7/19 25/25
12*15.1 22.1 25
5.6
6.6
3.4
4
2.8
3.5
1.5
2
1.5
2
1.5
2
FLA – Full Load Amps
HP – Horse Power
FM – Fan Motor (Condenser)
RLA – Rated Load Amps
MCA – Minimum Circuit Amps BM – Blower Motor
LRA – Locked Rotor Amps MOCP – Maximum Overcurrent Protection
*Combination of 2 heater modules
LEGEND:
13

187 253 4.1
342 418 1.7
414 506 2
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
VOLTAGE
RANGE
FLAMax.Min.
POWER
SUPPLY
(V-Ph-Hz)
PS090 PS100
MODEL NUMBER
DESCRIPTION
ELECTRICAL DATA
MODELS: PS090 & PS100
80
50
42
13.1
8.2
5.9
208/230-3-60
380-3-60 (4 WIRE)
460-3-60
– – 46.7 60
7.5/10 18.8/25.1 46.7/46.7 60/60
10*/12*25.1/30.1 46.7/46.7 60/60
15*/20*37.7/50.2 55.4/71 60/80
– – 48.9 60
7.5/10 18.8/25.1 48.9/48.9 60/60
10*/12*25.1/30.1 48.9/48.9 60/60
15*/20*37.7/50.2 58.1/73.8 60/80
– – 24.2 30
7.5/10 11.4/15.2 24.2/24.2 30/30
10*/12*15.2/18.2 24.2/27.8 30/30
15*/20*22.8/30.4 33.5/43 35/45
– – 25.3 30
7.5/10 11.4/15.2 25.3/25.4 30/30
10*/12*15.2/18.2 25.4/29.2 30/30
15*/20*22.8/30.4 34.9/44.4 40/45
– – 24 30
7.5/10 9.4/12.6 24/24 30/30
10*/12*12.6/15.1 24/24 30/30
15*/20*18.8/25.1 27.9/35.8 30/40
– – 24.6 30
7.5/10 9.4/12.6 24.6/24.6 30/30
10*/12*12.6/15.1 24.6/24.6 30/30
15*/20*18.8/25.1 28.6/36.5 30/40
FM
(each)
HP - Horse Power
FM - Fan Motor (Condenser)
BM - Blower Motor
FLA - Full Load Amps
RLA - Rated Load Amps
LRA - Locked Rotor Amps
MCA - Minimum Circuit Amps
MOCP - Maximum Over Current Protection
*Combination of heater modules
LEGEND:
– – 40.2 50
5/6 12.6/15.1 40.2/40.2 50/50
7.5/10*18.8/25.1 40.2/40.2 50/50
12*/15*30.1/37.7 45.9/55.4 50/60
20*50.2 71 80
– – 42.4 50
5/6 12.6/15.1 42.4/42.4 50/50
7.5/10*18.8/25.1 42.4/42.4 50/50
12*/15*30.1/37.7 48.6/58.1 50/60
20*50.2 73.8 80
– – 24.2 30
5/6 7.6/9.1 24.2/24.2 30/30
7.5/10*11.4/15.2 24.2/24.2 30/30
12*/15*18.2/22.8 27.8/33.5 30/35
20*30.4 43 45
– – 25.3 30
5/6 7.6/9.1 25.3/25.3 30/30
7.5/10*11.4/15.2 25.3/25.4 30/30
12*/15*18.2/22.8 29.2/34.9 30/40
20*30.4 44.4 45
– – 18.8 20
5/6 6.3/7.5 18.8/18.8 20/20
7.5/10*9.4/12.6 18.8/20.1 20/25
12*/15*15.1/18.8 23.3/27.9 25/30
20*25.1 35.8 40
– – 19.4 25
5/6 6.3/7.5 19.4/19.4 25/25
7.5/10*9.4/12.6 19.4/20.9 25/25
12*/15*15.1/18.8 24/28.6 25/30
20*25.1 36.5 40
6.6
8.8
4
5.14
3.5
4.1
2
3
2
3
2
3
97
50
50
16
8.2
8.2
6.6
8.8
4
5.14
3.5
4.1
2
3
2
3
2
3
14

187 253 4.1
342 418 1.7
414 506 2
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
VOLTAGE
RANGE
FLAMax.Min.
POWER
SUPPLY
(V-Ph-Hz)
PS120 PS180
MODEL NUMBER
DESCRIPTION
ELECTRICAL DATA
MODELS: PS120 & PS180
105
55
55
19.6
10.4
10.4
208/230-3-60
380-3-60 (4 WIRE)
460-3-60
––86110
7.5/10 18.8/25.1 86/86 110/110
10*/12*25.1/30.1 86/86 110/110
15*/20*37.7/50.2 86/86 110/110
25*/30*62.8/75.3 94.4/110 110/110
– – 93.7 125
7.5/10 18.8/25.1 93.7/93.7 125/125
10*/12*25.1/30.1 93.7/93.7 125/125
15*/20*37.7/50.2 93.7/93.7 125/125
25*/30*62.8/75.3 104/119.6 125/125
– – 44.7 60
7.5/10 11.4/15.2 44.7/44.7 60/60
10*/12*15.2/18.2 44.7/44.7 60/60
15*/20*22.8/30.4 44.7/48.5 60/60
25*/30*38/45.6 58/67.5 60/70
– – 50.4 60
7.5/10 11.4/15.2 50.4/50.4 60/60
10*/12*15.2/18.2 50.4/50.4 60/60
15*/20*22.8/30.4 50.4/55.6 60/60
25*/30*38/45.6 65.1/74.6 70/80
– – 42.9 50
7.5/10 9.4/12.6 42.9/42.9 50/50
10*/12*12.6/15.1 42.9/42.9 50/50
15*/20*18.8/25.1 42.9/42.9 50/50
25*/30*31.4/37.7 47.3/55.1 50/60
– – 46.7 60
7.5/10 9.4/12.6 46.7/46.7 60/60
10*/12*12.6/15.1 46.7/46.7 60/60
15*/20*18.8/25.1 46.7/46.7 60/60
25*/30*31.4/37.7 52/59.9 60/60
FM
(each)
HP - Horse Power
FM - Fan Motor (Condenser)
BM - Blower Motor
FLA - Full Load Amps
RLA - Rated Load Amps
LRA - Locked Rotor Amps
MCA - Minimum Circuit Amps
MOCP - Maximum Over Current Protection
*Combination of heater modules
LEGEND:
––5770
7.5/10 18.8/25.1 57/57 70/70
10*/12*25.1/30.1 57/57 70/70
15*/20*37.7/50.2 58.1/73.8 70/80
25*62.8 89.5 100
– – 30.2 40
7.5/10 11.4/15.2 30.2/30.2 40/40
10*/12*15.2/18.2 30.2/30.2 40/40
15*/20*22.8/30.4 34.9/44.4 40/45
25*38 53.9 60
– – 29.5 35
7.5/10 9.4/12.6 29.5/29.5 35/35
10*/12*12.6/15.1 29.5/29.5 35/35
15*/20*18.8/25.1 29.5/36.5 35/40
25*31.4 44.4 45
8.8
5.14
4.1
3
3
3
195
&
164
123
&
100
101
&
101
32.1
&
25
16.7
&
12
16.4
&
12
12.7
20.4
8.4
14.1
6.4
10.2
5
7.5
5
7.5
5
7.5
15

– – 96.5 125
7.5/10 18.8/25.1 96.5/96.5 125/125
10*/12*25.1/30.1 96.5/96.5 125/125
15*/20*37.7/50.2 96.5/96.5 125/125
25*/30*62.8/75.3 96.5/110 125/125
– – 104.2 125
7.5/10 18.8/25.1 104.2/104.2 125/125
10*/12*25.1/30.1 104.2/104.2 125/125
15*/20*37.7/50.2 104.2/104.2 125/125
25*/30*62.8/75.3 104.2/119.6 125/125
– – 53.7 70
7.5/10 11.4/15.2 53.7/53.7 70/70
10*/12*15.2/18.2 53.7/53.7 70/70
15*/20*22.8/30.4 53.7/53.7 70/70
25*/30*38/45.6 58/67.5 70/70
– – 59.4 70
7.5/10 11.4/15.2 59.4/59.4 7070
10*/12*15.2/18.2 59.4/59.4 70/70
15*/20*22.8/30.4 59.4/59.4 70/70
25*/30*38/45.6 65.1/74.6 70/80
– – 49.3 60
7.5/10 9.4/12.6 49.3/49.3 60/60
10*/12*12.6/15.1 49.3/49.3 60/60
15*/20*18.8/25.1 49.3/49.3 60/60
25*/30*31.4/37.7 49.3/55.1 60/60
– – 53.1 70
7.5/10 9.4/12.6 53.1/53.1 70/70
10*/12*12.6/15.1 53.1/53.1 70/70
15*/20*18.8/25.1 53.1/53.1 70/70
25*/30*31.4/37.7 53.1/59.9 70/70
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
VOLTAGE
RANGE
FLAMax.Min.
POWER
SUPPLY
(V-Ph-Hz)
PS215 PS240
MODEL NUMBER
DESCRIPTION
ELECTRICAL DATA
MODELS: PS215 & PS240
– – 123.1 150
7.5/10 18.8/25.1 123.1/123.1 150/150
10*/12*25.1/30.1 123.1/123.1 150/150
15*/20*37.7/50.2 123.1/123.1 150/150
25*/30*62.8/75.3 123.1/123.1 150/150
– – 127.2 150
7.5/10 18.8/25.1 127.2/127.2 150/150
10*/12*25.1/30.1 127.2/127.2 150/150
15*/20*37.7/50.2 127.2/127.2 150/150
25*/30*62.8/75.3 127.2/127.2 150/150
– – 70.4 90
7.5/10 11.4/15.2 70.4/70.4 90/90
10*/12*15.2/18.2 70.4/70.4 90/90
15*/20*22.8/30.4 70.4/70.4 90/90
25*/30*38/45.6 70.4/74.6 90/90
– – 72.1 90
7.5/10 11.4/15.2 72.1/72.1 90/90
10*/12*15.2/18.2 72.1/72.1 90/90
15*/20*22.8/30.4 72.1/72.1 90/90
25*/30*38/45.6 72.1/76.8 90/90
– – 57.4 70
7.5/10 9.4/12.6 57.4/57.4 70/70
10*/12*12.6/15.1 57.4/57.4 70/70
15*/20*18.8/25.1 57.4/57.4 70/70
25*/30*31.4/37.7 57.4/59.9 70/70
– – 59.4 70
7.5/10 9.4/12.6 59.4/59.4 70/70
10*/12*12.6/15.1 59.4/59.4 70/70
15*/20*18.8/25.1 59.4/59.4 70/70
25*/30*31.4/37.7 59.4/62.4 70/70
FM
(each)
HP - Horse Power
BM - Blower Motor
FM - Fan Motor (Condenser)
RLA - Rated Load Amps
FLA - Full Load Amps
LRA - Locked Rotor Amps
MCA - Minimum Circuit Amps
MOCP - Maximum Over Current Protection
*Combination of heater modules
LEGEND:
187 253 4.1
342 418 1.7
414 506 2
225
140
114
33.6
18.6
17.3
208/230-3-60
380-3-60 (4 WIRE)
460-3-60
12.7
20.4
8.4
14.1
6.4
10.2
5
7.5
5
7.5
5
7.5
239
145
125
42
23.5
19.2
20.4
24.5
14.1
15.8
10.2
12.2
7.5
10
7.5
10
7.5
10
16

– – 142.8 175
10*/12*25.1/30.1 142.8/142.8 175/175
15*/20*37.7/50.2 142.8/142.8 175/175
25*/30*62.8/75.3 142.8/142.8 175/175
35*/40*87.9/100.4 142.8/151 175/175
– – 146.9 175
10*/12*25.1/30.1 146.9/146.9 175/175
15*/20*37.7/50.2 146.9/146.9 175/175
25*/30*62.8/75.3 146.9/146.9 175/175
35*/40*87.9/100.4 146.9/156.1 175/175
– – 75.8 100
10*/12*15.2/18.2 75.8/75.8 100/100
15*/20*22.8/30.4 75.8/75.8 100/100
25*/30*38/45.6 75.8/75.8 100/100
35*/40*53.2/60.8 84.1/93.6 100/100
– – 77.5 100
10*/12*15.2/18.2 77.5/77.5 100/100
15*/20*22.8/30.4 77.5/77.5 100/100
25*/30*38/45.6 77.5/77.5 100/100
35*/40*53.2/60.8 86.3/95.8 100/100
– – 62.3 80
10*/12*12.6/15.1 62.3/62.3 80/80
15*/20*18.8/25.1 62.3/62.3 80/80
25*/30*31.4/37.7 62.3/62.3 80/80
35*/40*43.9/50.2 67.6/75.5 80/80
– – 64.3 80
10*/12*12.6/15.1 64.3/64.3 80/80
15*/20*18.8/25.1 64.3/64.3 80/80
25*/30*31.4/37.7 64.3/64.3 80/80
35*/40*43.9/50.2 70.1/78 80/80
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
MOCPMCA
ELECTRIC
HEATER
BM
COMPR-
ESSOR
(each)
RLA LRA HP FLA Nom. kW FLA
VOLTAGE
RANGE
FLAMax.Min.
POWER
SUPPLY
(V-Ph-Hz)
PS300 PS360
MODEL NUMBER
DESCRIPTION
ELECTRICAL DATA
MODELS: PS300 & PS360
– – 168.7 225
10*/12*25.1/30.1 168.7 / 168.7 225/225
15*/20*37.7/50.2 168.7 / 168.7 225/225
25*/30*62.8/75.3 168.7 / 168.7 225/225
35*/40*87.9/100.4 168.7 / 168.7 225/225
– – 181.2 225
10*/12*25.1/30.1 181.2 / 181.2 225/225
15*/20*37.7/50.2 181.2 / 181.2 225/225
25*/30*62.8/75.3 181.2 / 181.2 225/225
35*/40*87.9/100.4 181.2 / 181.2 225/225
– – 110.4 125
10*/12*15.2/18.2 110.4/110.4 125/125
15*/20*22.8/30.4 110.4/110.4 125/125
25*/30*38/45.6 110.4/110.4 125/125
35*/40*53.2/60.8 110.4/110.4 125/125
– – 117.7 150
10*/12*15.2/18.2 117.7/117.7 150/150
15*/20*22.8/30.4 117.7/117.7 150/150
25*/30*38/45.6 117.7/117.7 150/150
35*/40*53.2/60.8 117.7/117.7 150/150
– – 82.8 110
10*/12*12.6/15.1 82.8/82.8 110/110
15*/20*18.8/25.1 82.8/82.8 110/110
25*/30*31.4/37.7 82.8/82.8 110/110
35*/40*43.9/50.2 82.8/82.8 110/110
– – 89.1 110
10*/12*12.6/15.1 89.1/89.1 110/110
15*/20*18.8/25.1 89.1/89.1 110/110
25*/30*31.4/37.7 89.1/89.1 110/110
35*/40*43.9/50.2 89.1/89.1 110/110
FM
(each)
LEGEND:
HP - Horse Power
BM - Blower Motor
FM - Fan Motor (Condenser)
RLA - Rated Load Amps
FLA - Full Load Amps
LRA - Locked Rotor Amps
MCA - Minimum Circuit Amps
MOCP - Maximum Over Current Protection
*Combination of heater modules
187 253 4.1
342 418 1.7
414 506 2
245
145
125
47.1
24.4
19.6
208/230-3-60
380-3-60 (4 WIRE)
460-3-60
20.4
24.5
14.1
15.8
10.2
12.2
7.5
10
7.5
10
7.5
10
425
239
187
56.8
39
27.8
24.5
37
15.8
23.1
12.2
18.5
10
15
10
15
10
15
17

Performex-1TM CONTROLLER : OPERATION & FUNCTIONS
TheZamil Packaged units areprovided with technologically advancednewPerformexTM Controller Microprocessor Based Electronic
Control Board, incorporating the following benefits and features:
- COMPLETE UNIT CONTROL: Provides complete unit control for heating and cooling application whether single
stage or two stage utilizing the input from sensor that measure temperatures during unit operation.
- COMPRESSOR LOCKOUT: If any of the unit’s safety controls trip due to abnormal conditions the Electronic Control
locks out the compressor, preventing restart, unless attended by qualified service technicians. The unit can be re-
started only by reset the thermostat after ensuring safe system conditions.
- LEAD LAG OPERATION: The unit electronic controls automatically alternate lead and lag the compressors for even
operation. Compressor #1 can be set always lead as an option.
- ANTI-RECYCLE TIMER: For compressor safety in case of accidental manual reset or immediate recycling of
thermostat due to load demand. This considerably improves compressor life.
- PUMP DOWN OPTION: In units equipped with pump down system the time delay creates the required time gap be-
tween the solenoid opening and compressor start to equalize the pressure in the system prior to compressor start up.
- AUTO/MANUAL RESET OF THE ALARM SIGNALS.
- FULL CONTROL OF THE INDOOR FAN: Fan operation can be selected either to run continuously or stage with the
compressor/heaters.
-PROTECTION: The PerformexTM Controller will provide the following protection:
1. Compressor high pressure protection (option)
2. Compressor low pressure protection
ELECTRONIC THERMOSTAT
LCD display: a) Room temperature display
b) Mode of operation (Cool/Heat/Auto/Fan system control)
c) Set temperature
d) Compressor Status - ON/OFF/FAULT
e) Error Codes
1. ON/OFF: Press the ON/OFF button & the unit shall be switched ON. A status Led adjacent to this button shall light up
indicating the unit is switched ON. To shut off the unit, press this button again.
2. MODE: Press the mode button to select the desired mode. On selection the corresponding icon shall be displayed on
the LCD display panel.
3. TEMPERATURE RANGE AND SETTING: The operating temperature range is 160C to 300C (610F to 860F), both
inclusive. Press the UP or DN button to select the desired temperature. The temperature setting is effective only for
the Cool, Heat and Auto modes.
4. INDOOR (EVAPORATOR) FAN: Thereis one indoorfanwith single fanspeed. When fanspeedon LCDpanelis HIGH,
indoor fan will always turns on. Indoor fan can be set off, when the compressor is cut off by setting the fan speed to
AUTO on the LCD panel by pressing Fan button. By pressing the Fan button again the fan speed can resume to HIGH.
5. COOL MODE: Whenever the unit is started in cool mode (without Pump Down Solenoid-PDS), the compressors will
be turned on one by one depending on the load requirement of the unit.
6. HEAT MODE (HEATER MODEL): Whenever the unit is started in heat mode, the heaters shall be switched ON one
by one to meet the load requirement.
18

7. LEAD/LAG OPERATION: Whenever a compressor needs to be on, the controller will turn on the compressor with the
shorter accumulated run time provided its 3 minutes minimum off time has lapsed. Otherwise the other compressor will
on first. Similarly, the compressor with the longer accumulated run time will be the first one to be cut off. This is to load
the compressors evenly over long run period. Balance loading is enabled when compressor #1 lead option is disabled.
8. AUTO MODE: In Auto mode, operating mode will be selected automatically between Heat and Cool mode, depending
on the Room Temperature and Set Temperature.
9. ERROR CODE:
Error code is displayed on the LCD panel. When system on and error code is shown, the ON/OFF LED on the LCD
panel will blink. When system off, error code is still display for thermistor error but the ON/OFF LED will be off.
E06 Compressor 1 high pressure trip (or contact open)
E07 Compressor 2 high pressure trip (or contact open), (not applicable for single compressor units)
E10 Compressor 1 low pressure trip
E11 Compressor 2 low pressure trip, (not applicable for single compressor units)
CRANKCASE HEATER
The crankcase heater is provided to hold the compressor oil reservoir at higher temperature than the coldest part in the
system.
•Power must be supplied to crankcase heater for a minimum of 12-hours prior to system start-up. If power is off for 6-
hours or more, crankcase heater must be energized for 12-hours before operating the system. Otherwise compressor
damage may result.
PUMP DOWN CONTROL
If the unit is provided with pumpdown system, then a solenoid type valve is installed in the liquid line ahead of expansion
valve to prevent flow of refrigerant into the evaporator during off cycle. The controller is wired to solenoid valve which
energize in cooling and opening the valve. Whenever the thermostat temperature is satisfied, the solenoid will close
followed compressor off after pumping the refrigerant from low side of the system until the low pressure switch open the
control circuit.
19
