ZHC 928
MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE
INSTALLATION, USE AND MAINTENANCE HANDBOOK
MANUEL D’INSTRUCTIONS POUR L’INSTALLATION, L’EMPLOI ET L’ENTRETIEN
HANDBUCH FÜR INSTALLATION, BEDIENUNG UND WARTUNG
INSTRUCTIES VOOR MONTAGE, GEBRUIK EN ONDERHOUD

12GB
CONTENTS
Dear Customer,
If you follow the recommendations contained in this Instruction
Manual, your appliance will give you constant high performan-
ce and will remain efficient for many years to come.
RECOMMENDATIONS AND SUGGESTIONS 13
CHARACTERISTICS 14
INSTALLATION 16
USE 19
MAINTENANCE 20

13GB
RECOMMENDATIONS AND SUGGESTIONS
INSTALLATION
•The manufacturer will not be held liable for any damages resulting
from incorrect or improper installation.
•The minimum safety distance between the cooker top and the
extractor hood is 650 mm.
•Check that the mains voltage corresponds to that indicated on the
rating plate fixed to the inside of the hood.
•For Class I appliances, check that the domestic power supply
guarantees adequate earthing.
Connect the extractor to the exhaust flue through a pipe of
minimum diameter 120 mm. The route of the flue must be as short
as possible.
•Do not connect the extractor hood to exhaust ducts carrying
combustion fumes (boilers, fireplaces, etc.).
•Iftheextractorisusedinconjunctionwithnon-electricalappliances
(e.g. gas burning appliances), a sufficient degree of aeration must
be guaranteed in the room in order to prevent the backflow of
exhaust gas. The kitchen must have an opening communicating
directly with the open air in order to guarantee the entry of clean
air.
USE
•The extractor hood has been designed exclusively for domestic
use to eliminate kitchen smells.
•Never use the hood for purposes other than for which it has ben
designed.
•Never leave high naked flames under the hood when it is in
operation.
•Adjust the flame intensity to direct it onto the bottom of the pan
only, making sure that it does not engulf the sides.
•Deep fat fryers must be continuously monitored during use:
overheated oil can burst into flames.
•The hood should not be used by children or persons not instructed
in its correct use.
MAINTENANCE
•Switch off or unplug the appliance from the mains supply before
carrying out any maintenance work.
•Clean and/or replace the Filters after the specified time period.
•Clean the hood using a damp cloth and a neutral liquid detergent.
650 mm min.

14GB
CHARACTERISTICS
Dimensions
790 min
970 max
68
512
790
898
730
340

15GB
Components
Ref. Q.ty Pro uct Components
11 Hood Body, complete with: Controls, Light,
Blower, Filters
21 Telescopic Chimney comprising:
2.1 1 Upper Section
2.2 1 Lower Section
7.1 1 Telescopic frame complete with extractor,
consisting of:
7.1a 1 Upper frame
7.1b 1 Lower frame
81 Air Outlet Grill
91 Reducer Flange 150-120 mm
14 1 Hood Body Air Outlet Extension Piece
consisting of two Half Shells
14.1 1 Air Outlet Connection Extension
15 1 Air Outlet Connection
25 2 Pipe clamps
Ref. Q.ty Installation Components
11 4 Wall Plugs 10
12b 3 Screws 2,9 x 4,5
12f 4 Screws 3,5 x 9,5
12g 4 Screws M6 x 80
12h 4 Screws 5,2 x 70
21 1 Drilling template
22 4 6.4 mm int. dia washers
23 4 M6 nuts
Q.ty Documentation
1 Instruction Manual
12f
2
2.1
2.2
11
12h
22
23
21
7.1
1
14.1
15
12g
14
9
8
7.1a
7.1b
25

16GB
INSTALLATION
Drilling the Ceiling/shelf an fixing the frame
DRILLING THE CEILING/SHELF
•Use a plumb line to mark the centre of the hob on the ceiling/support shelf.
•Place the drilling template 21provided on the ceiling/support shelf, making sure that the template
is in the correct position by lining up the axes of the template with those of the hob.
•Mark the centres of the holes in the template.
•Drill the holes at the points marked:
•For concrete ceilings, drill for plugs appropriate to the screw size.
•For hollow brick ceilings with wall thickness of 20 mm: drill ø10 mm.
•For wooden beam ceilings, drill according to the wood screws used.
•For wooden shelf, drill ø7 mm.
•For the power supply cable feed, drill ø10 mm.
•For the air outlet (Ducted Version), drill according to the diameter of the external air exhaust
duct connection.
FIXING THE FRAME
Before fixing, separate the Upper Section 2.1 and
the Lower Section 2.2 from the Frame by
unscrewing the screws 12c, then separate the two
sections of the frame by unscrewing the 6 side
screws to obtain the Upper frame and Lower fra-
me.

17GB
Upper frame
•Align the power supply cable feed hole
•Fix the upper frame to the ceiling or shelf using:
•For concrete ceilings, use the appropriate plugs for the screw size (not provided).
•For hollow brick ceilings of wall thickness of approximately 20 mm: use 4 plugs 11 and 4
screws 12h, provided.
•For wooden beam ceilings, use 4 wood screws (not provided).
•For wooden shelf, use 4 screws 12g with washers 22 and nuts 23, provided.
Lower frame
•Fix the lower frame using the 8 previously removed screws, adjusting the length according to the
installation height (hood body lower fixing surface must be at least 720 mm from the hob).
•For the recirculation version, turn the frame in the direction chosen for the recirculated air outlet.
•The frame mountings must be secure to withstand the weight of the hood and any stresses caused
by the occasional side thrust applied to the device. On completion, check that the base is stable,
even if the frame is subjected to bending.
•In all cases where the ceiling is not strong enough at the suspension point, the installer must
provide strengthening using suitable plates and backing pieces anchored to the structurally sound
parts.
Connections
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the chimney using either a flexible or rigid
pipe ø150 or 120 mm, the choice of which is left to the installer.
•To install a ø120 mm air exhaust connection,
insert the reducer flange 9on the hood body
outlet.
•Fix the pipe using the pipe clamps 25 provided.
•Remove any activated charcoal filters.
RECIRCULATION VERSION AIR OUTLET
•Insert reducer flange 9on the extractor outlet.
•Push fit the extension piece 14 onto the flange.
•Push fit connector 15 onto the extension piece.
•Insert extension piece/connector 14.1 laterally
on connector 15, ensuring that the outlet is in
line with the chimney intake.
9
ø 120ø 150
15
14.1 14
9

18GB
Flue assembly - Mounting the hoo bo y
•Position the upper chimney section and fix the
upper part to the frame using the 2 screws 12c
provided.
•Similarly, position the lower chimney section
without fixing it, ensuring that the outlet from
connector 15 is in line with the chimney intake.
•The air outlet directional grill 8must be fitted
after the installation of the chimney.
Before fixing the hood body to the frame:
•remove the grease filters from the hood body;
•remove the activated carbon odour filters, if
fitted.
•from below, use the 4 screws 12f provided to
fix the hood body to the frame.
•For the recirculation version, locate the
directional grill 8in its housing. Ensure that it
is inserted correctly in connector 15.
ELECTRICAL CONNECTION
•Connect the hood to the mains through a two-
pole switch having a contact gap of at least 3
mm.
•Take off the upper protection bracket by
unscrewing the screws.
•Connect the control connector Cmd.
•Reassemble the protection bracket.
•Take off the bracket which is opposite to the
previous one by unscrewing the screws.
•Connect the spotlights connector L.
•Reassemble the protection bracket.
•For the recirculation version, fit the activated
carbon odour filter.
•Replace the grease filters.
12f
8b
Cmd
L

19GB
USE
Control panel
LLight Switches the lighting system on and off.
S1 Led Motor running led.
S2 Led Optimum speed led.
S3 Led Intensive speed led.
S4 Led Grease filters saturated alarm led.
S5 Led Activated charcoal filter exhausted alarm led.
To disable this indicator (Ducted hoods) simultaneously press buttons R(using
a sharp object, for example a pencil) and V2. To enable it again, press buttons R
and V3.
RReset Internal Filter Alarms Reset button.
V1 Motor Switches the extractor motor on and off.
V2 Speed Decreases the operating speed.
V3 Speed Increases the operating speed.
V4 Optimum Preset optimum speed.To customise the Optimum speed setting, select the Speed
speed you require using buttons V2 and V3 then press V4 within 10 seconds (during
this period the corresponding led S2will flash). The setting you enter will remain
active until the Hood is turned off.
V5 Intensive Maximum speed, used to eliminate the highest levels of cooking vapour
speed emission. Returns to Optimum speed automatically after it has been in operation
for 15 minutes. Intensive speed can also be turned off manually by pressing
button V4.
TDelayed This device allows any residual odours to be removed without having to wait
shutdown andturn the appliance off,asthe Motor and Lighting will switchoff automatically
at the end of the selected time.
By pressing button Tin succession it is possible to set the delayed shutdown of
the appliance to 15, 30 and 60 minutes, respectively. The selected time is shown
by leds T1, T2, T3. To move from one time to another, simply press button T
until the required led lights up. The time selected in this way will start from
zero. The delayed shutdown function can be turned off by pressing button V4.
T1 Led 15’delayed shutdown indicator led.
T2 Led 30’delayed shutdown indicator led.
T3 Led 60’delayed shutdown indicator led.
0 - 1
0 - 1
15 30 60
reset
reset
delay
L
S1
V1 V2 V3 V4 V5 T
S2 S3
S4
T1 T2 T3 S5 R

20GB
MAINTENANCE
Grease filters
CLEANING METAL SELF-SUPPORTING GREASE FILTERS
Resetting the alarm signal
•Press button R, using a sharp object (for
example the tip of a pencil).
•The Alarm indicator led S4 will go out.
Cleaning the filters
•The filters are washable and must be cleaned
when led S4 flashes or at least every 2 months
of operation, or more frequently for particularly
heavy usage.
•Removethefiltersoneatatimebypushingthem
towards the back of the group and pulling down
at the same time.
•Wash the filters, taking care not to bend them.
Allow them to dry before refitting.
•When refitting the filters, make sure that the
handle is visible on the outside.

21GB
Activate charcoal filter (Recirculation version)
REPLACING THE ACTIVATED CHARCOAL FILTER
•The filter is not washable and cannot be
regenerated. It must be replaced when led S5
flashes or at least every 4 months. The alarm
signal will only light up when the extractor
motor is switched on.
Resetting the alarm signal
•Press button R, using a sharp object (for
example the tip of a pencil).
•The Alarm indicator led S5 will go out.
Replacing the Filter
•Remove the metal grease filters
•Remove the saturated activated carbon filter by
releasing the fixing hooks
•Fit the new filter by hooking it into its seating
•Replace the metal grease filters.
Lighting
LIGHT REPLACEMENT
20 W halogen light.
•Remove the 2 screws fixing the ring nut.
•Extractthe lamp from the lamp holder by pulling
gently.
•Replace with another of the same type, making
sure that the two pins are properly inserted in
the lamp holder socket holes.
•Replace the ring nut and fix it in place using the
two screws removed as above.

Quest’apparecchio é conforme alla norma europea sulla bassa tensione C.E.E. 73/23 relativa
alla sicurezza elettrica e alle norme europee: C.E.E. 8 /336 relativa alla compatibilità elettro-
magnetica e C.E.E. 3/68 relativa alla marcatura CE.
This appliance complies with European regulations on low voltages, EEC Directive 73/23 on
electrical safety, and with the following European regulations: EEC Directive 8 /336 on
electromagnetic compatibility and EEC Directive 3/68 on EC marking.
Cet équipement est conforme à la norme européenne sur la basse tension C.E.E. 73/23 relati-
ve à la sécurité électrique et aux normes européennes: C.E.E. 8 /336 relative à la compatibilité
électromagnétique et C.E.E. 3/68 relative au marquage CE.
Dieses Gerät entspricht den europäischen Niederspannungsrichtlinien 73/23/EWG zur
elektrischen Sicherheit, den europäischen Richtlinien 8 /336/EWG zur elektromagnetischen
Verträglichkeit und den Richtlinien 3/68/EWG zur CE-Kennzeichnung
Dit apparaat voldoet aan de Europese Laagspanningsrichtlijn 72/23/EEG inzake de elektrische
veiligheid en aan de Europese normen 8 /336/EEG inzake de elektromagnetische compatibiliteit
en 3/68/EEG inzake de CE-markering.
436000224 02 020206
