Zebex Z-217 Plus Series User manual

Z-217XPlusQuickStartGuide 593-7XPL00-002
QUICK START GUIDE
Quick Start Guide for ZEBEX Z-217X Plus Series
Package Contents
USB Cable
(Device to PC) Power Adapter+
Selected Plug Head
Battery Pack Stylus Pen
Hand strip Holder Hand Strip Sling
(for stylus Pen)
Optional Accessories
Docking Cradle Power Adapter + RS232 Cable USB Cable
Selected Plug Head
Charging
Notes:
*When charging the battery for the first time, charge it for at least 12 hours.
*Battery can also be charged inside the additional charging slot provided by the cradle (optional).
(Optional)
LED lit red during charge
and turns green when the
battery is fully charged
Please see
below
Cradle Connection
To communicate with a PC via cable connection, a cradle must be used to connect to the PC’s USB or RS-232 ports.
Attach one end of the cable to the USB interface or RS-232 on the cradle and the other to your PC then plug in the
power adapter to the cradle.
1 LED indicator Battery charging
indicator
2 LED indicator Green for good read
3 LCD screen Display various programs
4 Scan button Barcode reading trigger
5 Keypad Activate device functions
6 Reset switch Insert needle to reset
7 Scan windows Emits laser for barcode
reading
8 Buzzer Outputs confirmation
tones
9 Stylus pen Touch screen operation
and RESET needle
10 Hand strip Protects the Handheld
Terminal from dropping.
11 Battery compartment
Main battery inside
12 Communication port
Communication with
cradle
13 Expansion Slot MicroSD expansion slot
Cradle LEDs
LED A- The LED lit when the cradle is connected to AC power.
LED B- The LED shows red when a battery is inserted into the rear battery slot of the cradle for recharge.
The LED changes to green when the battery is fully charged.

Z-217X Plus Quick Start Guide
QUICK START GUIDE
Using Barcode Scanner
The Z-217X Plus is a highly versatile tool that can scan a wide range of barcodes but it is imperative that it is used in
the correct manner.
To scan a barcode:
1. Hold the Z-217X Plus horizontally and point it directly at the barcode you wish to scan.
2. Once in the correct position, press the SCAN button.
3. An audible alarm is heard and the barcode digits will appear on the LCD screen if the scan is successful.
Volume Control
To set the volume, go to Control Panel and click on Volume and Sound.
Or press [SF/Fn] on the keypad; press F1 for volume up or F2 for volume down.
Reset
Using the Warm reset function:
Warm reset function allows you to return the device to the default settings, wile not wiping all data from the
memory. Insert a needle into the reset hole as shown and press down gently, to reset the device.
Using the Cold reset function:
Cool reset function allows you to return the device to the factory settings, wile wiping all data from the memory.
Press down and hold the power key for 8 seconds to cold reset the device.
*Please visit the support section of our website http://www.zebex.com/ to download the latest software and driver.
Reset
Power
