ZENCAR EV 2 User manual

User Manual
Read all instructions before using, operating, or maintaining.

CONTENTS
Zencar is a versatile portable electric car charger that ensures reliability, safety and
convenience of use in various conditions.
The charger is powered from a standard CEE outlet. The charger is compatible with all
cars that are fitted with the relevant charging socket. The charger has a built-in electrical
protection, RFID card reader (2 cards are included in the set). The housing also has
special, elongated holes that will attach the charger to the wall. The five-meter charging
cable is made of light, flexible and durable material. You will find more information about
the product specification in the separate section of this document.
The device's display allows to read various, detailed information and statuses such as
time, charging power, the amount of energy supplied, status of charging, operating
temperature and many other parameters. It also displays safety warnings. You will find
more information about the display in the separate section of this document.
GENERAL INFORMATION
01 Safety Precautions ..........................................................................1
02 Display ............................................................................................2
03 Status Indicator ...............................................................................2
04 Charging Steps ...............................................................................3
05 Circuit Board Sensor ......................................................................3
06 12 Safety Protection .......................................................................3
07 Timer Function ...............................................................................4
08 Warranty .........................................................................................5

SAFETY PRECAUTIONS
Thank you for purchasing and using ZENCAR EV Charging Model 2 cable. In order to
help you properly use this product, please read this user' s manual carefully before
charging.
Caution
It's not recommended to use the device for charging while raining due to the
safe use of electricity.
Do not submerge the control box in water.
Do not step on, pull, fold or knot the cable.
Do not drop the control box or place a heavy object on it.
Do not place the charging cable near high temperature object when charging.
Do not place the device in the car or in a sealed space when charging.
Do not operate the device in temperatures beyond its operating range of -25℃
to +50℃.
Power-supply side input cable should be at least 3*2.5mm² （recommended
3*4mm²), with a standard 16A socket. It is suggested that the power distribution
is done by the professionals.
1
Warnings
Only for the limited using at the condition of there is RCD protection breaker in
the power supply section.
Do not use this product if the EV charging cable is damaged.
Only for use with EV charging.
The product must be grounded.
Do not use this device with an extension cord or adapter.
Do not put fingers into the charging connector.
The device contains no users seriveable parts. Do not attempt to repair or
service the device yourself.
If device fails to operate correctly in accordance with the operation manual, do
not use this device. Contact dealer for repair or replacement.

2
Green
DISPLAY
STATUS INDICATOR
Current charging time
Normal grounding
Quantity of electric
charge
Current controller
temperature
Working current
Current charging voltage
Actual charging
power
Actual current
setting
The display in of the device allows you to read various detailed information, statuses and
safety warnings.
Current charging time Normal grounding
Abnormal grounding
Quantity of electric charge
Current controller temperature
Working current
Current charging voltage
Actual charging power
Actual current setting
Charging...(Dynamic picture guide)
Delayed charging
Charging failure
Error code
When the vehicle-end is disconnected, please
connect the vehicle (Dynamic picture guide)
The charging device is connected to the vehicle and waiting for the vehicle to match
230V
0.0A
0.00KW
0.0KWH
00:00:00
Ready
Blue
Schedule Charging
Green flash
EV Connected
Green flash
Charging Completed by the car
Red flash
Connected Error
Indicator off
Charging completed
and charger disconnected
Multicolour flash
Charging
Yellow filash
Charging Fault

Leakage
Protection
Overheat
Protection
Electrostatic
Protection
Prorecting
Earthing Detection
Lightning
Protection
Undervoltage
Protection
Crush Test Intelligent
Kernel
Water-proof
Protection
Overvoltage
Protection
Overcurrent
Protection
Circuit Board
Temp Sensor
3
Charge vehicle
Connect power cord to grid
12 3 4
Double click to set delayed
start timer
Double click to set AMP
The charging power may be automatically reduced or charging suspended in case the
internal temperature raises above the safety level. Please observe the display in order to
obtain actual temperature readings:
CHARGING STEPS
CIRCUIT BOARD SENSOR
12 SAFETY PROTECTION
Reduce
Amp Automatically
Suspend
charging Automatically
Automatically
Resume charging

4
Use the Delayed Start Timer to schedule your charging session. This allows you to
benefit from off peak rates and saves your money.Double click the indicating position
when the plug is connected to the car to schedule the charging session.
TIMER FUNCTION
No Timer; Charging starts immediately
Start Charge session after 2 hours
Start Charge session after 4 hours
Start Charge session after 6 hours
Turn off timer; Charging starts immediately
Double Click Timer Status
Without
double clicking
1st double click
2nd double click
3rd double click
4th double click
Delayed Charging

WARRANTY
5
Precautions before use
Ensure charging connector, plug, cable and control box are free of any abnor-
malities such as scratches,rusts, cracks, etc.
Please do not Charging if the socket or plug surface is damaged, rusted, broken
or too loose; It should be replaced immediately if any abnormal founded. The
socket must be replaced at least every 3 years.
Wipe with a clean and dry cloth if the plug get dirty or wet.
Ensure power plug and socket are consistent before charging.
When the new energy pure electric/hybrid vehicle's battery is fully charged, the
vehicle side cuts off the current automatically, the ZENCAR controller's green
indicator light flickers.
ZENCAR Mode 2 Cable is warranted to be free of defects in material and
workmanship for a period of one year from the date of shipment.
This warranty does not cover any damage due to the following cases:
1. Improper handling,installation, use and maintenance by users.
2. The break down and the failure caused by the force majeure, such as direct
damage and inability to function properly caused by natural disasters.
3. Products are filled with water or soaked in water.
This warranty does not include the cost of returning to the factory for repair.
This warranty is only valid to the original purchaser of the device and is not
transferable.
