Zenox Orion Series User manual

Got your back on every mission
Orion Series
Gaming Desk
Installation Manual
www.zenoxstore.com/pages/assembly-guides
獵戶電競桌安裝指南
1. The product has to be used within the constraints of its
specifications.
2. We recommend installtion of desk by 2 adults, as some parts
are considerably heavy;
3. The desk is designed for regular desktop work only. Do not
use it as a stepstool or any other purposes;
4. Keep the product away from corrosive chemicals and dusty
environments;
5. Clean with gentle cleaners if necessary, and do not scrub
excessively;
6. All parts should be checked regularly to ensure the desk is
safe to use;
7. Stop using the product immediately if the table is found
damaged. Please check the maintenanace guide on our
website or contact us over the phone or via e-mail at
[email protected].

FIXED VERSION
固定版本
5mm
D
5x5
x4
*Slide the Lifting Columns
into the slot and affix to
the frame with the 4 M8
bolts.
*把升降柱滑入固定孔卡槽，
並用4顆M8螺絲鎖在框架上.
重物
*桌子有一定重量，建議由最少2位成人移動.
*The desk is considerably heavy, and we suggest moving by at least 2 adults.
步驟
3
3
步驟
2
2
+
Lifting Columns x 2
BOX 01
BOX 02
M8*20mm x 4
M6*25mm x 8
步驟
E
5x5
x8
Table Top x 1
桌面
Fixed Columns x 2
固定柱 x 2
Support Plates x 2
固定板 x 2
*Align and join the
columns and plates,
tighten bolts with tool.
*把升降柱跟固定板
用螺絲連上並收緊.
E
E

*Slide the Lifting Columns
into the slot and affix to
the frame with the 4 M8
bolts.
USB Adpt. x 1
*UK or AUS
Plug
USB 配電器
*把升降柱滑入固定孔卡槽，
並用4顆M8螺絲鎖在框架上.
F
5x5
Gx4
升降版本 STANDING VERSION
Table Top x 1
Lifting Columns x 2
Power Chord x 1
5mm
BOX 01
BOX 02
Cable Management
Trays x 2
Hex Keys
4mm x 1 5mm x 1
Control Panel x 1
M8*20mm x 4
ST4.2x12mm x 2
E
步驟
桌面
升降柱
電源線
六角匙
電線收納槽 控制面板
*UK or AUS
Plug
5mm
*Slide the Lifting Columns
into the slot and affix to
the frame with the 4 M8
bolts.
*把升降柱滑入固定孔卡槽，
並用4顆M8螺絲鎖在框架上.
5x5
Gx4
步驟
*按指示插入電線
*把電線收納槽滑入
固定卡控並收緊.
*Plug in the cables accordingly.
步驟
3
3
步驟
2
2
4
4
*Slide in the Cable
Management Trays,
tighten with tool.
5x5
AC
HS M1 M2
5x5
*把電線收納槽滑入
固定卡控並收緊.
+
I


E01 Overuse Protection Mode Allow system rest for 13 minutes
to prevent overheating.
E02 Overuse Protection Mode System is overheating. Allow
system rest for 25 minutes
before resuming useage.
E03/ Overload Protection Mode
E04
Reduce load applied should it
be above the recommended
value. Reset the system after
adjusment by holding the
“▼” button for 10 seconds.
E05 Motor 01 Protection Mode
E06 Motor 02 Protection Mode
Motor might be jammed.
Check and try resetting the
system after adjusment by
holding the “▼” button for
10 seconds.
E07 Motor 01 Single HALL
Malfunction
E08 Motor 02 Single HALL
Malfunction
Poor connection between
Motors and Control Box.
Check and try resetting the
system after adjusment by
holding the “▼” button.
E09 Imbalanced Desktop
Warning
Check for serious imbalance.
Reset system after adjusment
by holding the “▼” button.
E30 6 Axles Motion Sensor
Malfunction
Major malfunction. Please
contact manufacturer.
_OL Severe Overload
Protection Mode
Reduce load applied should it
be above the recommended
value. Reset the system after
adjusment by holding the
“▼” button for 10 seconds.
E20/ Motor Double HALL
E21 Malfunction
E22/ Motor 01 Power Supply
E23 and HALL Malfunction
Poor connection between
Motors and Control Box.
Check and try resetting the
system after adjusment by
holding the “▼” button
錯誤診斷碼一覽
E01 過度使用保護模式 暫停使用系統 13 分鐘，避免發生
過熱情況.
E02 過度使用保護模式 系統過熱， 暫停使用系統 25 分
鐘讓系統冷卻.
E03/ 負重超載保護模式
E04
減少負重到建議數值， 按著“▼”
10 秒鐘重置系統.
E05 摩打 01 保護模式
E06 摩打 02 保護模式
摩打可能受阻.
檢查及調整後長按 “▼” 10 秒鐘
重置系統.
E07 摩打 01 單 HALL 故障
E08 摩打 02 單 HALL 故障
摩打與控制盒信號出現問題.檢查
及調整後長按 “▼” 10 秒鐘重置
系統.
E09 桌面不平衡警告 檢查及調整負載不平衡情況.然
後長按 “▼” 10 秒鐘重置系統.
E30 6 軸動態感應故障 嚴重錯誤，請聯繫 本公司.
_OL 負重嚴重超載保護模式 減少負重到建議數值. 長按“▼”
10 秒鐘重置系統.
E20/ 摩打 雙 HALL 故障
E21
E22/ 摩打 01 供電及HALL 故障
E23
摩打與控制盒信號出現問題.檢查
及調整後長按 “▼” 10 秒鐘重置
系統.

步驟
5
5
重物
*桌子有一定重量，建議由最少2位成人移動.
*The desk is considerably heavy, and we suggest moving by at
least 2 adults.

1. Set the desk to a preferred height by using the “▼”“”
buttons, 70cm for instance.
2. Press the “M” SAVE button and the LED display shows “S-“,
then press “1” to save the 1st height position to 70cm. The LED
display shows “S-1”.
3. Repeat step 1 and Step 2 with “2” and “3” to save the 2nd
and 3rd height.
4. To recall saved settings, press “1”, “2” or “3”, and the desk
would automatically reposition to the saved height.
高度記憶設定
1. 使用 “▼”“” 按鈕調節至理想高度，例如70CM 高.
2. 按 “M” 儲存鍵直至 LED 控制面板顯示 “S-”, 然後再按 “1” 儲存現在
高度為第一個高度記憶. LED 控制面板 “S-1”代表設定完成.
3. 重複以上動作至“2” 跟 “3” 設定第二跟三高度記憶.
4. 如要返回已儲存高度, 按 “1”, “2” or “3” 一下, 桌子便會自動回到
自定高度.
防撞功能靈敏度設定
1. 同時按下 “▼”“” 按鈕進入設定模式.
2. 靈敏度設定有4個階段，分別爲：
“A-0”,“A-1”,“A-2” 和“A-3”.
“A-0” - 防撞功能關閉
“A-1” - 防撞功能靈敏度為低
“A-2” - 防撞功能靈敏度為中
“A-3” - 防撞功能靈敏度為高
3. 同時按下 “▼”“” 按鈕退出設定模式.

1. Press and hold the “▼”“” buttons for 5 seconds simult-
aneously to switch to sensitivity setting mode.
2. There are 4 sensitivity levels, and will be shown as follows:
“A-0”,“A-1”,“A-2” and “A-3”.
“A-0” - Anti collision function is OFF
“A-1” - Anti collision function at is at LOW sensitivity
“A-2” - Anti collision function at is at MIDIUM sensitivity
“A-3” - Anti collision function at is at HIGH sensitivity
3. Press and hold the “▼”“” buttons for 5 seconds to exit
sensitivity setting mode.

廢物處理
警告 此標記表明該產品不應與其他生活垃圾一起處理.為防止未
經控制的廢物處理對環境或人類健康造成的危害，請以負責
任的方式進行回收，以促進物質資源的可持續再利用.丟棄本
產品時，請遵守您當地的環境法律和規程.
規格
升降柱段數: 3
最大負重: 100 KG
高度航程: 600 - 1230mm
輸入伏特數: 100 - 240V
最高速度: 38mm/s
運作溫度 °C: 0 - 40 °C
坐姿提示功能設定
1. 按下“A”按鈕進入提示設定模式，“ON” 為成功進入.
2. 兩秒後顯示屏會開始閃爍，按下 “▼”“” 按鈕調節時間分段.
3. 預設時間分段為 45 分鐘，為“=45”.
4. 完成設定後按下任何按鈕儲存，或 5 秒後系統會自動退出.
5. 當接近時間分段結束是，系統會開始倒數. 倒數結束時，“=00”
會顯示，和發出 10 秒提示聲響.
6. 在提示中按下任何按鈕會重置系統計時功能.
7. 長按“A”直到 “OFF” 顯示, 代表提示功能已關閉.
Waste Disposal
Warning
This marking indicates that this product should not be
disposed with other household wastes. To prevent
possible harm to the environment or human health
from uncoltrolled waste disposal, recycle it responsibly
to promote sustainable reuse of material resources.
Please follow your local environmental law and protocol
when dispose of this product.

Column Stages: 3
Max Loading: 100 KG
Height Range: 600 - 1230mm
Input Voltage: 100 - 240V
Max Speed: 38mm/s
Operating °C: 0 - 40 °C

1. Press the “A” button on the control panel to switch to
alarm setting mode, and “ON” will be shown.
2. After 2 seconds, the display will start to flash, press the
“▼”“” buttons to adjust alarm intervals.
3. Default setting is at 45 minutes, shown as “=45”.
4. After setting a preferred interval, press any button to
save, or wait for 5 seconds and the system will exit settings.
5. When approaching the end of intervals, a countdown will
commence and “=00” will be displayed, together with a 10-
second buzzer as reminder.
6. Press any button during the reminder to reactivate the alarm.
7. To turn off the alarm system, press and hold the “A” button,
and “OFF” will be displayed.
