Zephyr Port-A-Blaster ZPB140 User manual

Coil Cleaning Made Easy
Model:
#ZPB140
TM
#ZPB140

Coil Cleaning Made Easy
TM
Contents:
Warnings ....................................................................... Page 2
Product Description
& Application .............................................................. Page 3
Technical Data ............................................................ Page 3
Parts & Operating Instructions ............................. Page 4
Operating Instructions (continued) ....................... Page 5
Troubleshooting ........................................................ Page 6
16
Troubleshooting
Make sure you have
120V Power.
Check Power Switch
Increase Temperature.
Clean Inlet Filter / Screen
Disconnect Trigger
Sprayer, Run Pump
for Few Seconds to
Remove Air.
Fix Hoses.
Clean Pump.
Check Quick Connects.
Replace O Ring.
Clean Inside.
Fix Leaking Connections.
Check Water Level in
Bucket / Container.
Repair or Replace Pump.
Pump Doesn’t Run.
Low Pressure.
Water Leakage.
Pump Doesn’t Stop
when Trigger is Released.
Pump is Noisy.
Pump Parts are Damaged.
Check Power Supply.
Temperature is Too Low.
Inlet Filter Screen or
Hose is Plugged.
Pump is Air Bound.
Hoses are Kinked.
Dirt Clogging Inside.
Quick Connects Not
Firmly Connected.
O-Ring Damaged.
Dirt Inside Pump
or Connections Leaking.
Pump is Drawing In Air or
Problem Cause Action

34
Description & Application
The Port-A-Blaster pressure washer is designed to clean air conditioning
and refrigeration coils. It is designed with a low pressure setting for
indoor evaporator coils and a high pressure setting for outdoor condenser
coils. It is lightweight, ruggedly built, reliable, self-priming and easy to use
and carry. All accessories (trigger sprayer, wand/nozzle, and hoses) are
the pressure control.
Technical Data
Model ZPB140
Voltage: 120V
Watts: 80
Flow Rate: .25 GPM
Max Pressure: 140 psi
Weight: 11 lbs.
Dimensions
Height: 12”
Length: 11.5”
Width: 7”
Opening Under Handle: 1.5”
Handle Width: 1.5”
12”
11.5”
1.5”
1.5”
7”
Pump
Trigger Sprayer with
Wand & Adjustable Nozzle
5’ Suction Inlet Hose
Detachable
Filter Screen
16’ Sprayer Outlet Hose
with Quick Connect Fittings
Operating Instructions
1. For professional use, for cleaning air conditioning & refrigeration coils.
2. Make sure all components are in working order and that suction
“OUT” on the unit.
marked “IN” on the unit.
water or non-corrosive coil cleaning detergent solution.

52
Warning
Always disconnect power before making any adjustments
or service to the machine. Do not operate in the vicinity of
Warnings
Warning
Do Not Run Port-A-BlasterTM without water or cleaning
solution. Doing so will damage the pump.
1. Do not run the unit continuously for more than 30 minutes.
This could overheat the pump and motor and damage the equipment.
2. Be sure unit electrical cord is not frayed or damaged.
3. Use only non-corrosive cleaners with this unit. Strong coil cleaners
can damage the pump.
4. Make sure you are in a safe position when using the Port-A-BlasterTM
5. Check and clean the inlet screen on the suction tube.
Do not remove this screen.
6. Pump operates when trigger sprayer is squeezed and will cycle
OFF when sprayer is not in use.
Operating Instructions (continued)
7. Turn Power on and choose “INDOOR” (low pressure) or “OUTDOOR”
(high Pressure). Squeeze trigger to activate pump. Pump will discharge
air as it primes.
8. The adjustable nozzle can be turned to vary the spray pattern from
a narrow jet to a fan jet. Don not turn the nozzle too far as it will
unscrew from the wand.
9. IMPORTANT! Run clean water through the pump after each use if
you were using a coil cleaning detergent. This will rinse the pump of
chemicals and increase life of pump.
11. Disconnect hoses and break down trigger sprayer wand to
store all accessories in the on-board compartment.
