Zephyr Anzio Island Installation guide

WWW.ZEPHYRONLINE.COM
MAR22.0101
Anzio Island
ZAZ-M90DS
ZAZ-E42DS
EN Use, Care, and Installation Guide
FR Guide d’utilisation, d’entretien et d’installation
Luce Island
ZLC-M90CS
ZLC-E42CS
Roma Island
ZRM-E36FS
ZRM-E42FS
Ravenna Island
ZRE-M90BBSGG
ZRE-E42BBSGG
Ai
rflow Control Te chnolo
gy
TM
C

2Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE

3
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Contents
Page
Safety Information ............................................................................ 4-6
Types of Safety Warnings................................................................... 4
General Safety ..................................................................................4-5
Operation........................................................................................... 6
Electrical Requirements ...................................................................... 6
Federal Communication Commission Interface Statement................. 6
List of Materials................................................................................... 7
Installation Instructions.....................................................................8-19
Ducting Calculation Sheet.................................................................. 8
Mounting Height, Clearance, & Ducting ............................................. 9
Ducting Options .................................................................................10
ZAZ Hood Specifications.....................................................................11
ZLC Hood Specifications ....................................................................12
ZRM Hood Specifications....................................................................13
ZRE Hood Specifications.....................................................................14
Electrical Supply.................................................................................15
Cable Lock .........................................................................................15
Mounting the Hood.......................................................................... 16-18
Ductless Recirculation ........................................................................19
Features & Controls......................................................................... 20-23
ICON Touch Controls.......................................................................20-21
Optional Remote Control.................................................................22-23
Maintenance ................................................................................... 23-24
Hood & Filter Cleaning.....................................................................23-24
LumiLight LED ................................................................................... 24
ACT™ Conversion............................................................................ 25-26
Airflow Control Technology (ACT™) ................................................... 25
Enabling ACT™.................................................................................. 26
Wiring Diagram................................................................................27-31
Troubleshooting............................................................................... 32-33
List of Parts & Accessories..................................................................34
Limited Warranty ...............................................................................35
Product Registration...........................................................................36

4Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Safety Information
Your safety and the safety of others are very important.
We have provided many important safety messages in this
manual for your appliance. Always read and obey all safety
messages.
This is the Safety Alert Symbol. This symbol alerts you to
potential hazards that can cause severe bodily injury or death.
All safety messages will follow the Safety Alert Symbol and either
the words “DANGER” “WARNING” or “CAUTION”
DANGER
Danger means that failure to heed this safety statement may
result in severe injury or death.
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power o at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
General Safety
WARNING
Warning means that failure to heed this safety statement
may result in extensive product damage, serious personal
injury, or death.
CAUTION
Caution means that failure to heed this safety statement
may result in minor or moderate personal injury, property or
equipment damage.
WARNING
To reduce the risk of fire or electric shock, do not use this fan
with any solid-state control device.
WARNING
CAUTION
For General Ventilating Use Only. Do Not Use To Exhaust
Hazardous Or Explosive Materials And Vapors. Take care
when using cleaning agents or detergents. Suitable for use in
household cooking area.
WARNING
WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE:
a) Never leave surface units unattended at high settings.
Boilovers cause smoking and greasy spillovers that may ignite.
Heat oils slowly on low or medium settings.
b) Always turn hood ON when cooking at high heat or
when flambeing food. (i.e. Crepes Suzette, Cherries Jubilee,
Peppercorn Beef Flambe’).
c) Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filter.
d) Use proper pan size. Always use cookware appropriate for
the size of the surface element.

5
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
WARNING
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING:
a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or
metal tray, then turn o the burner. BE CAREFUL TO PREVENT
BURNS. If the flames do not go out immediately, EVACUATE AND
CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN – You may be burned.
c) DO NOT USE WATER, including wet dishcloths or towels – a
violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class ABC extinguisher, and you
already know how to operate it.
2) The fire is small and contained in the area where it
started.
3) The fire department is being called.
4) You can fight the fire with your back to an exit
Based on “Kitchen Firesafety Tips” published by NFPA.
WARNING
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
CAUTION
To reduce risk of fire and to properly exhaust air outside, do
not vent exhaust air into spaces within walls, ceilings, attics,
crawl spaces, or garages.
WARNING
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction.
b) Sucient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel burning
equipment to prevent back drafting. Follow the heating
equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association
(NFPA), and the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code
authorities.
c) When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
d) Ducted fans must always be vented to the outdoors.
e) If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application and be connected
to a GFCI (Ground Fault Circuit Interrupter) - protected branch
circuit.
WARNING
Prop. 65 Warning for California Residents: This product may
contain chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.

6Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Safety Information
Operation
►Always leave safety grilles and filters in place. Without these components, operating blowers could catch onto hair, fingers and
loose clothing.
►The manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation,
maintenance and suitable use of the product. The manufacturer further declines all responsibility for injury due to negligence and
the warranty of the unit automatically expires due to improper maintenance.
NOTE: Please check www.zephyronline.com for revisions before doing any custom work.
Electrical Requirements
Important:
►Observe all governing codes and ordinances.
►It is the customer’s responsibility to be aware of these below:
►To contact a qualified electrical installer.
►To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70 latest
edition* or CSA standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and all local codes
and ordinances.
►If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path
is adequate.
►Do not ground to a gas pipe.
►Check with a qualified electrician if you are not sure the range hood is properly grounded.
►Do not have a fuse in the neutral or ground circuit.
►This appliance requires a 120V 60Hz electrical supply and connected to an individual properly grounded branch circuit protected
by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to Electrical Diagram
on product.
►A cable locking connector (not supplied) might also be required by local codes. Check with local requirements, purchase and
install appropriate connector if necessary.
* National Fire Protection Association Batterymarch Park, Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
Federal Communication Commission Interface Statement
►This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
►This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following
measures:
►Reorient or relocate the receiving antenna.
►Increase the separation between the equipment and receiver.
►Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
►Consult the dealer or an experienced radio/TV technician for help.
READ AND SAVE THESE INSTRUCTIONS

7
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
List of Materials
Parts Not Supplied
Ducting, conduit and all installation tools
Cable locking connector (if required by local codes)
Extension duct covers
Optional recirculating kit
Optional remote control
(3) Wire Nuts (4)ø12 OD / ø5
ID Washers
(4) M4 x 1”
wood screws
(4) 3/16 x 1/4” flat-head
machine screws
(1) Hardware package
(1) 6” round damper (pre-installed)
HARDWARE PACKAGE CONTENTS
(2) Top Duct Covers
(1) Top Support Frame
(2) Bottom Duct Covers
(1) Bottom Support Frame
(1) Hood Body
(4) LumiLight LED
(2) Mesh Filters
(ZAZ-E42 & ZRM-E42 x 3)
(1) M4 x 12
safety screw
A
B
Front of Hood
CL
/
Cut-Out Shaded Area
(1) Paper ceiling template
(20) M4 x 8 pan-head
machine screws
(ZLC x 8)
(2) Lateral support brackets
(ZLC ONLY)
(1) Square support bracket
(ZAZ ONLY)
(4) 3/16 x1/4 pan-head
machine scews
(ZRE only)

8Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Installation Instructions
Duct pieces To tal
Equivalent number
length x used =
3- 1/ 4” x 10”
Rect.,
straight
1 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. to
6” round
transition
5 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. to
6” round
transition
900 elbow
20 Ft. x ( ) =Ft.
6”, 7”, 8”, 10”
Round,
900
15 Ft. x ( ) =Ft.
6”, 7”, 8”, 10”
Round,
450
9 Ft. x ( ) =Ft.
Ft.
6”, 7”, 8”, 10”
Round,
straight
1 Ft. x ( ) =Ft.
Subtotal column1 =
Duct pieces To tal
Equivalent number
length x used =
6”, 7”, 8”, 10”
Round, wall
cap with
damper
30 Ft. x ( ) =Ft.
Ft.
Ft.
Ft.
6”, 7”, 8”, 10”
Round
roof cap
30 Ft. x ( ) =Ft.
Subtotal column2 =
Subtotal column1 =
Total ductwork =
Maximum Duct Length: For satisfactory air movement,
the total duct length
should not exceed 150 equivalent feet.
6” round to
3- 1/ 4” x 10”
rect.
transition
1 Ft. x ( ) =Ft.
6” round to
3- 1/ 4” x 10”
rect.
transition
900 elbow
16 Ft. x ( ) =Ft.
7” round to
3 1/ 4” x 10”
rect.
transition
8 Ft. x ( ) =Ft.
7” round to
3- 1/ 4” x 10”
rect.
transition
900 elbow
23 Ft. x ( ) =Ft.
elbow
elbow
7” to 6” or
8” to 7” Round
tapered
reducer
25 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. 900
elbow
15 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. 450
elbow
9 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. 900
flat elbow
24 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect.
wall cap
with damper
30 Ft. x ( ) =Ft.
Ft. x ( ) =Ft.
15
6”, 7“, 8”
Round
in-line
damper
Ducting Calculation Sheet

9
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Mounting Height, Clearance, & Ducting
A minimum of 6” round duct must be used to maintain
maximum air flow eciency.
Always use rigid type metal ducts only. Flexible ducts could
restrict air flow by up to 50%.
Also use calculation (on page 8) to compute total available
duct run when using elbows, transitions and caps.
ALWAYS, when possible, reduce the number or transitions
and turns. If long duct run is required, increase duct size.
If turns or transitions are required; install as far away from
hood duct output and as far apart, between the two as
possible.
Minimum mount height between range top to hood bottom
should be no less than 24”. Maximum mount height should
be no higher than 34”.
It is important to install the hood at the proper mounting
height. Hoods mounted too low could result in heat
damage and fire hazard; while hoods mounted too high
will be hard to reach and will lose its performance and
eciency.
If available, also refer range manufacturer’s height
clearance requirements and recommended hood mounting
height above range.
For shipment and installation damages:
►Please fully inspect unit for damage before installation.
►If the unit is damaged in shipment, return the unit to the
store in which it was bought for repair or replacement.
►If the unit is damaged by the customer, repair or
replacement is the responsibility of the customer.
►If the unit is damaged by the installer (if other than
the customer), repair of replacement must be made by
arrangement between customer and installer.
A
B
C
D
E
F
ZAZ ZLC ZRM
Standard Duct Cover
Extension Duct Cover
A
B
C
D
E
F
ZAZ ZLC ZRM
28”
31”
39”
88” (7’ 4”)
80”
150” (12’ 6”)
29”
89” (7’ 5”)
47”
51”
80”
150” (12’ 6”)
107” (8’ 11”)
111” (9’ 3”)
36”
50”
96” (8’ 0”)
120” (10’)
47”
51”
80”
107” (8’ 11”)
111” (9’ 3”)
150” (12’ 6”)
A : Minimum Ducted Hood Height
B : Minimum Recirculating Hood Height
C : Maximum Hood Height
D : Minimum Ducted Ceiling Height
E : Minimum Recirculating Ceiling Height
F : Maximum Ceiling Height
min. A
min. B
max. C
36”
24” min.
34” max.
min. D
min. E
max. F
31-1/2”
91- 1/2 ” (7’ 7- 1/2 ”)
32-1/2”
46-1/2”
92- 1/2 ” (7’ 8- 1/2 ”)
116-
1/2 ” (9’ 8- 1/2 ”)
91” (7’ 7”)
109” (9’ 1”)
50-1/2”
50-1/2”
110- 1/2 ” (9’ 2- 1/2 ”)
110-
1/2 ” (9’ 2- 1/2 ”)
ZRE
ZRE
28-1/2”
39”
78”
148” (12’ 4”)
109” (9’ 1”)
48-1/2”
48-1/2”
108- 1/2 ” (9’ 1/2 ”)
109-
1/2 ” (9’ 1/2 ”)
28-1/2”
88- 1/2 ” (7’ 4- 1/2 ”)
88-
1/2 ” (7’ 4- 1/2 ”)

10 Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Installation Instructions
Ducting Options
►Use single wall rigid metal ductwork only.
►Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
Fire Hazard: NEVER exhaust air or terminate ductwork into
spaces between walls, crawl spaces, ceilings, attics, or garages.
All exhaust must be ducted to the outside, unless using the
recirculating option.
WARNING
Roof Pitch w/
Flashing & Cap
Sot or crawl space
(blower
housing)
ductless
recirculating
side wall cap
w/ gravity damper

11
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
ZAZ Hood Specications
FRONT SIDE
TOP TOP SUPPORT FRAME
(top view)
C/L
8-1/8”
7-9/16”
3-9/16”
13/16”
4-3/16”
8-1/4”
STANDARD
min. ducted - 31-
1/2”
min. recirc. - 36”
max. - 50”
Z1C-00AZ
min. ducted - 47”
min. recirc. - 51”
max. - 80”
10-5/8”
25-9/16”
1-3/16”
11”
35-7/16”, 41-15/16”
9-7/16”
16-9/16”
5-1/4”
5-
15/16
”
3-1/2”
AC In
1-1/4”
C/L
C/L
1-7/8”
5-5/16”

12 Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Installation Instructions
ZLC Hood Specications
FRONT SIDE
TOP of HOOD TOP SUPPORT FRAME
(top view)
FRONT
11”
35-7/16”, 41-7/8”
STANDARD
min. ducted - 29”
min. recirc. - 32-1/2”
max. - 46-1/2”
Z1C-00LC
min. ducted - 47”
min. recirc. - 51”
max. - 80”
6”
C/L
C/L
9-7/16”12-3/8”
2-1/16”
10-5/8”
25-9/16”
3-7/16”
2-1/2”
1-1/4”
7-9/16”
7-13/16”
8-1/8”
6-3/4”

13
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
ZRM Hood Specications
3”
STANDARD
min. ducted - 28”
min. recirc. - 31”
max. - 39”
Z1C-01RM EXTENSION
min. ducted - 50-
1/2 ”
min. recirc. - 50-
1/2 ”
max. - 80”
12”
AC-IN
CL
FRONT SIDE
TOP
14”
9-11/16”
11-3/16”
35-7/8”, 41-7/8” 26-7/8”
12-7/16”
4-3/16”
11”
ø 6”
9-7/16”
2-3/8”

14 Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Installation Instructions
ZRE Hood Specications
FRONT SIDE
TOP TOP SUPPORT FRAME
(top view)
10-3/8”
23-15/16”
35-3/16”25-9/16”
24-
1/2
”
3-
9/16
”
10-
7/8
”
2-
3/4
”
11-
5/8
”
4-
3/8
”
(top of electrical box)
13-
3/4
”
5/16”
C/L
6”
8”
8-
3/4
”
8- 1/4 ”
3-
3/4 ”
4-
3/16 ”
5/8”
elec. k/o
STANDARD
min. ducted - 28-
1/2 ”
min. recirc. - 28-
1/2 ”
max. - 38”
Z1C-01REBS EXTENSION
min. ducted - 48-
1/2 ”
min. recirc. - 48-
1/2 ”
max. - 78”

15
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Electrical Supply
Electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards. Turn o
electrical power at service entrance before wiring.
WARNING
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not
use extension cord or adapter plug with this appliance.
Follow national electrical codes or prevailing local codes and ordinances.
This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly
grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring
must be 2 wire w/ ground. Please also refer to the Electrical Diagram labeled on product.
Cable Lock
A cable locking connector (not supplied) might be required by local codes. Check with local
requirements and codes, purchase and install appropriate connector if necessary. (FIG. A)
Cable Lock
FIG. A

16 Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Installation Instructions
Mounting the Hood
At least two installers are required due to the weight
and size of the hood.
CAUTION
1. Determine mounting location on ceiling and
temporarily tape paper template (included with
the hood) to the ceiling. Cut out internal shaded
area of template to allow the ducting and electrical
to pass through. If necessary, add wood blocking
(min. 2” x 4”) to ceiling joists located behind the
drywall to reinforce the mounting location*. (FIG.
B1). Secure (2) M6 x 1” wood screws to points A and
B of the paper template (FIG. C). Do not completely
tighten screws, leave approximately 1/4” exposed.
2. Remove screws securing top and bottom support
frames together. Adjust support frame to
accommodate the desired hood height and re-
assemble the frame using the previously removed
screws (2 screws for each support frame arm). (FIG.
B3).
FIG. B
1
2
Ceiling Joists
Wood Blocking
Top Support Frame
Support Frame Arm
Bottom Support Frame
Hood Body
3
Mounting Screws
(pre-installed)
4
*Hood is intended to be mounted to a finished ceiling.
FIG. C
XP022220
A
B
Cut-Out Shaded Area
FRONT
FIG. D
Top Support Frame
Side
Front

17
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
3. Lift support frame assembly up to the ceiling
making sure the word “front” on the top support
frame faces the front of the hood where the
controls will be located. (FIG. D) The key holes
on the top support frame should cover the wood
screws previously installed in the ceiling. Slide
support frame towards narrow end of key holes to
lock the frame in place. Install the last (2) M6 x 1”
wood screws with washers into the two remaining
corners of the top support frame to secure it to the
ceiling. Tighten all screws.
4. ZRE ONLY: Remove aluminum mesh filters from
hood. Place canopy over blower housing and
secure it to hood body using (4) 3/16 x 1/4 pan
head machine screws through filter opening. (FIG.
E)
5. Lift hood and align the (4) pre-installed mounting
screws located on top of the unit body (FIG. A4)
with the (4) key holes on the Bottom of Support
Frame. (FIG. F). Slide hood towards the narrow end
of key holes to lock into place. Hand tighten each
of the (4) screws with a screwdriver to secure hood
to Bottom Support Frame. Further secure bottom
support frame to unit body by one M4 x 12 safety
screw. (FIG. G).
6. Remove tape securing electronics mounting bracket
to hood and reposition electronics mounting
bracket. Install electrical and duct work.
7. Power up hood, verify all functions and check for
leaks around duct tape.
Mounting the Hood
FIG. E
BLOWER
HOUSING
FIG. F
Bottom Support Frame
(secures to top of blower housing)
Key Holes
front - facing controls
back
FIG. G

18 Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Installation Instructions
8. Assemble Top Duct Covers (with louver holes)
together over Top Support Frame, secure Top
Duct Covers together by magnetic strips.
NOTE: If using hood in ductless recirculating
mode, you must install the air diverter plate to
the Top Support Frame prior to assembling the
duct covers.
9. Secure Top Duct Covers to Top Support Frame
by using (4) 3/16 x 1/4 screws (2 screws for
each Top Duct Cover). (FIG. H1).
10. Assemble Bottom Duct Covers together over
Top Duct Covers and secure together by
magnetic strips. Bottom Duct Covers should
rest on top of the Hood Body.
Mounting the Hood
FIG. H
1
Top Duct Covers
Top Support Frame
Bottom Duct Covers
Bottom Support Frame

19
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Ductless Recirculation
Ductless recirculation is intended for applications where an exhaust duct work is not possible to be
installed. When converted, the hood functions as a recirculating hood rather than an exhaust hood.
Fumes and exhaust from cooking are drawn and filtered by a set of optional charcoal filters. The air is
then purified and re-circulated back within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new
duct work, if possible. The hood is most eective and ecient as an exhaust hood. Only when the
exhaust option is not possible should you recourse to converting the hood into a recirculating hood.
When converted to be a recirculating hood, a set of charcoal filters are required on top of its standard
Metal Filter set. Order according to its part number below. The standard mesh filters are intended to
capture residue from cooking, and the optional charcoal filters help to purify fumes exhausted from
cooking for recirculation.
Recirculating Kit Installation (required if no ducting is used)
For detailed installation instructions, please refer to the manual included with the recirculating kit.
The kit includes the charcoal filters, filter attachment clip, and air diverter plate.
Hood Model Recirculating Kit
Part Number
Quantity to
Order
Charcoal Filter
Replacement Part
Number
Quantity to
Order
ZAZ ZRC-02AZ 2 Z0F-C091 2
ZLC ZRC-00LC 1 Z0F-C092 1
ZRM-E36DS ZRC-02RM 2 Z0F-C002 2
ZRM-E42DS ZRC-01RM 3 Z0F-C002 3
ZRE ZRC-00RE 2 Z0F-C002 2
1. Purchase recirculating kit per the part number above. Secure air diverter plate to top support
frame. Open sides of air diverter plate should face left and right to direct air through the louver
holes located on the top duct cover. Run 6” ducting from top of hood and secure to air diverter
plate.
2. Remove mesh filters from hood. Install charcoal filters as referenced with the manual included with
recirculation kit. Reinstall mesh filters.
3. Turn on charcoal filter replace indicator on control panel. The microprocessor in the controls will
indicate the need to change the charcoal filter after 120 hours of continuous use.
DO NOT WASH CHARCOAL FILTERS. Charcoal filters may need to be changed more often depending
on cooking habits.

20 Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
ZAZ, ZLC, ZRM, ZRE
ISLAND
CORE
Features & Controls
Lights Low/High/O
Display (speed level, delay o, filter clean/change)
Adjust 5 Speed Levels
Power / Delay O
1 POWER / DELAY OFF BUTTON
Power Button Function
- Button will turn power on and o for entire hood (fan and lights).
- Hood will remember the last speed and light level it was turned o at.
(Example: Press Button to turn o hood when on fan speed 4 and high lights.
Press Button again and the hood will turn back on at speed 4 and high lights
level.)
Delay O Button Function
- With the fan on press and hold the Button for two seconds. The fan will change
to speed 1 and the 5 minute delay o timer will start.
+ LEDs will illuminate and slowly blink in accordance
with the time remaining until the fan and lights automatically turn o.
- Pressing Button while Delay O Function is enabled will turn the hood o and
cancel the Delay O Function.
ACT Verification
- Airflow Control Technology (ACT) allows the installer to set the maximum fan
CFM to align with local codes and regulations.
- To verify the maximum fan CFM:
- With hood o, hold the Button for two seconds. If all five fan speed
indicators illuminate = default maximum CFM. If four fan speed indicators
illuminate = 390 maximum CFM. If 3 fan speed indicators illuminate = 290
maximum CFM.
2 SPEED SELECTION BUTTON
Fan Speed Decrease Button
- Press this button to decrease fan speed. 5, 4, 3, 2, 1.
- If fan is On Speed 1 and this button is pressed, fan will power O.
Fan Speed Increase Button
- Press this button to increase fan speed. Fan On, 1, 2, 3, 4, 5.
- If hood is O and this button is pressed, fan will turn On Speed 1.
Act Enabled Speed Selections
- When ACT is enabled, the number of fan speeds will be reduced as follows:
- 390 CFM = Maximum 4 speeds
- 290 CFM = Maximum 3 speeds
Lighted Glass Button
5
MODEL ZLC ONLY
ICON Touch Controls
