Zephyr Tornado II Installation guide

WWW.ZEPHYRONLINE.COM
MAR21.0101
Tornado II
AK8200BS
EN Use, Care, and Installation Guide
FR Guide d’utilisation, d’entretien et d’installation
Tornado III
AK8300BSX (blower sold separately)

2Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO

3
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Contents
Page
Safety Information ............................................................................ 4-6
Types of Safety Warnings................................................................... 4
General Safety ..................................................................................4-5
Operation........................................................................................... 6
Electrical Requirements ...................................................................... 6
Federal Communication Commission Interface Statement................. 6
List of Materials................................................................................... 7
Installation Instructions.....................................................................8-16
Ducting Calculation Sheet.................................................................. 8
Mounting Height, Clearance, & Ducting ............................................. 9
Ducting Options .................................................................................10
Hood Specifications............................................................................11
Electrical Supply.................................................................................12
Cable Lock .........................................................................................12
Preparation & Installation ...................................................................13
Repositioning the Electrical Box..........................................................14
Single & Dual Internal Blower Installation............................................15
Remote Blower Preparation.................................................................16
Features & Controls..........................................................................17-20
Touch Controls .................................................................................17-18
RF Remote Control ..........................................................................19-20
Maintenance ....................................................................................21-22
Hood & Filter Cleaning.....................................................................21-22
LumiLight LED ................................................................................... 22
Wiring Diagram............................................................................... 23-24
Troubleshooting............................................................................... 25-26
List of Parts & Accessories .................................................................. 27
Notes.................................................................................................. 28
Limited Warranty ............................................................................... 29
Product Registration...........................................................................30

4Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Safety Information
Your safety and the safety of others are very important.
We have provided many important safety messages in this
manual for your appliance. Always read and obey all safety
messages.
This is the Safety Alert Symbol. This symbol alerts you to
potential hazards that can cause severe bodily injury or death.
All safety messages will follow the Safety Alert Symbol and either
the words “DANGER” “WARNING” or “CAUTION”
DANGER
Danger means that failure to heed this safety statement may
result in severe injury or death.
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power o at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
General Safety
WARNING
Warning means that failure to heed this safety statement
may result in extensive product damage, serious personal
injury, or death.
CAUTION
Caution means that failure to heed this safety statement
may result in minor or moderate personal injury, property or
equipment damage.
WARNING
To reduce the risk of fire or electric shock, do not use this fan
with any solid-state control device.
WARNING
CAUTION
For General Ventilating Use Only. Do Not Use To Exhaust
Hazardous Or Explosive Materials And Vapors. Take care
when using cleaning agents or detergents. Suitable for use in
household cooking area.
WARNING
WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE:
a) Never leave surface units unattended at high settings.
Boilovers cause smoking and greasy spillovers that may ignite.
Heat oils slowly on low or medium settings.
b) Always turn hood ON when cooking at high heat or
when flambeing food. (i.e. Crepes Suzette, Cherries Jubilee,
Peppercorn Beef Flambe’).
c) Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filter.
d) Use proper pan size. Always use cookware appropriate for
the size of the surface element.

5
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
WARNING
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING:
a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or
metal tray, then turn o the burner. BE CAREFUL TO PREVENT
BURNS. If the flames do not go out immediately, EVACUATE AND
CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN – You may be burned.
c) DO NOT USE WATER, including wet dishcloths or towels – a
violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class ABC extinguisher, and you
already know how to operate it.
2) The fire is small and contained in the area where it
started.
3) The fire department is being called.
4) You can fight the fire with your back to an exit
Based on “Kitchen Firesafety Tips” published by NFPA.
WARNING
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
CAUTION
To reduce risk of fire and to properly exhaust air outside, do
not vent exhaust air into spaces within walls, ceilings, attics,
crawl spaces, or garages.
WARNING
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction.
b) Sucient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel burning
equipment to prevent back drafting. Follow the heating
equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association
(NFPA), and the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code
authorities.
c) When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
d) Ducted fans must always be vented to the outdoors.
e) If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application and be connected
to a GFCI (Ground Fault Circuit Interrupter) - protected branch
circuit.
WARNING
Prop. 65 Warning for California Residents: This product may
contain chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.

6Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Safety Information
Operation
ŹAlways leave safety grilles and filters in place. Without these components, operating blowers could catch onto hair, fingers and
loose clothing.
ŹThe manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation,
maintenance and suitable use of the product. The manufacturer further declines all responsibility for injury due to negligence and
the warranty of the unit automatically expires due to improper maintenance.
NOTE: Please check www.zephyronline.com for revisions before doing any custom work.
Electrical Requirements
Important:
ŹObserve all governing codes and ordinances.
ŹIt is the customer’s responsibility to be aware of these below:
ŹTo contact a qualified electrical installer.
ŹTo assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70 latest
edition* or CSA standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and all local codes
and ordinances.
ŹIf codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path
is adequate.
ŹDo not ground to a gas pipe.
ŹCheck with a qualified electrician if you are not sure the range hood is properly grounded.
ŹDo not have a fuse in the neutral or ground circuit.
ŹThis appliance requires a 120V 60Hz electrical supply and connected to an individual properly grounded branch circuit protected
by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to Electrical Diagram
on product.
ŹA cable locking connector (not supplied) might also be required by local codes. Check with local requirements, purchase and
install appropriate connector if necessary.
* National Fire Protection Association Batterymarch Park, Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
Federal Communication Commission Interface Statement
ŹThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
ŹThis equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following
measures:
ŹReorient or relocate the receiving antenna.
ŹIncrease the separation between the equipment and receiver.
ŹConnect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
ŹConsult the dealer or an experienced radio/TV technician for help.
READ AND SAVE THESE INSTRUCTIONS

7
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
List of Materials
M4 x 8 (4) Wire Caps (3)
M4 x 1” (4)
RF Remote Control (1) Remote Holder (1)
Parts Not Supplied
Ducting, conduit and all installation tools
Cable locking connector (if required by local codes)
Single internal blower kit (CBI-390A, CBI-600A) - AK8300BSX only
Dual internal blower (PBI-1100B) - AK8300BSX only
External blower kit (CBE-1000) - AK8300BSX only
In-line blower kit (PBN-1000A) - AK8300BSX only
Optional stainless steel hood liner (AK08xxAS)
Parts Supplied (AK8200BS)
Quantity Part
1 Power pack
2 Pro bae filters
2 LumiLight LED, 6W (pre-installed)
1 Dual internal blower (pre-installed)
1 10” round adapter w/ damper
1 RF remote control
1 Hardware package
Parts Supplied (AK8300BSX)
Quantity Part
1 Power pack
3 Pro bae filters
4 LumiLight LED, 6W (pre-installed)
1 Single blower mounting plate
1 Remote blower wiring harness
1 10” round adapter w/ damper
1 RF remote control
1 Hardware package

8Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Installation Instructions
Duct pieces To t al
Equivalent number
length x used =
3-1/ 4” x 10”
Rect.,
straight
1 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect. to
6” round
transition
5 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect. to
6” round
transition
900 elbow
20 Ft. x ( ) = Ft.
6”, 7”, 8”, 10”
Round,
900
15 Ft. x ( ) = Ft.
6”, 7”, 8”, 10”
Round,
450
9 Ft. x ( ) = Ft.
Ft.
6”, 7”, 8”, 10”
Round,
straight
1 Ft. x ( ) =Ft.
Subtotal column1 =
Duct pieces To t al
Equivalent number
length x used =
6”, 7”, 8”, 10”
Round, wall
cap with
damper
30 Ft. x ( ) = Ft.
Ft.
Ft.
Ft.
6”, 7”, 8”, 10”
Round
roof cap
30 Ft. x ( ) = Ft.
Subtotal column2 =
Subtotal column1 =
Total ductwork =
Maximum Duct Length: For satisfactory air movement,
the totalductlength
should not exceed 150 equivalent feet.
6” roundto
3-1/ 4” x 10”
rect.
transition
1 Ft. x ( ) = Ft.
6” roundto
3-1/ 4” x 10”
rect.
transition
900 elbow
16 Ft. x ( ) = Ft.
7” roundto
3 1/ 4” x 10”
rect.
transition
8 Ft. x ( ) = Ft.
7” roundto
3-1/ 4” x 10”
rect.
transition
900 elbow
23 Ft. x ( ) = Ft.
elbow
elbow
7” to 6” or
8” to 7” Round
tapered
reducer
25 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect. 900
elbow
15 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect. 450
elbow
9 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect. 900
flatelbow
24 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.
wall cap
with damper
30 Ft. x ( ) = Ft.
Ft. x ( ) = Ft.
15
6”, 7“, 8”
Round
in-line
damper
Ducting Calculation Sheet

9
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Mounting Height, Clearance, & Ducting
A minimum of 10” round duct must be used for AK8200BS to
maintain maximum air flow eciency.
A minimum of 6” or 10” round duct must be used for AK8300BSX.
Always use rigid type metal ducts only. Flexible ducts could
restrict air flow by up to 50%.
Also use calculation (on page 8) to compute total available duct
run when using elbows, transitions and caps.
ALWAYS, when possible, reduce the number or transitions and
turns. If long duct run is required, increase duct size.
If turns or transitions are required; install as far away from hood
duct output and as far apart, between the two as possible.
Minimum mount height between range top to hood bottom
should be no less than 24”.
Maximum mount height should be no higher than 36”.
Min 24” - Max 36”
36”
It is important to install the hood at the proper mounting height. Hoods mounted too low could result
in heat damage and fire hazard; while hoods mounted too high will be hard to reach and will lose its
performance and eciency.
If available, also refer range manufacturer’s height clearance requirements and recommended hood
mounting height above range.
For shipment and installation damages:
ŹPlease fully inspect unit for damage before installation.
ŹIf the unit is damaged in shipment, return the unit to the store in which it was bought for repair or
replacement.
ŹIf the unit is damaged by the customer, repair or replacement is the responsibility of the customer.
ŹIf the unit is damaged by the installer (if other than the customer), repair of replacement must be
made by arrangement between customer and installer.

10 Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Installation Instructions
Ducting Options
ŹUse single wall rigid metal ductwork only.
ŹFasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
Fire Hazard: NEVER exhaust air or terminate ductwork into
spaces between walls, crawl spaces, ceilings, attics, or garages.
All exhaust must be ducted to the outside, unless using the
recirculating option.
WARNING
Sot or crawl space
Roof Pitch w/
Flashing & Cap
side wall cap
w/ gravity damper
side wall cap
w/ gravity
damper

11
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Ů
5-1/4”
11-7/16”
14-11/16”
2-1/2”
15-13/16”
9-15/16”
10-3/8”
14-3/16”
13-7/8”
6-3/8”
35-7/16” 38-3/8”
C/L
C/L
33-3/4”
34-1/2”
4-5/16”
11-1/2”
15-13/16”
9-15/16”
25-1/8”
25-15/16”
10-3/8”
14-3/16”
13-7/8”
26-7/8”
6-3/8”
C/L
C/L
4-5/16”
11-1/2”
15-13/16”
29-3/16”
AK8200BS
Top
AK8200BS
Front
AK8300BSX
Top
AK8300BSX
Front
AK8200BS & AK8300BSX
Side

12 Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Installation Instructions
Electrical Supply
Electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards. Turn o
electrical power at service entrance before wiring.
WARNING
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not
use extension cord or adapter plug with this appliance.
Follow national electrical codes or prevailing local codes and ordinances.
This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly
grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring
must be 2 wire w/ ground. Please also refer to the Electrical Diagram labeled on product.
Cable Lock
A cable locking connector (not supplied) might be required by local codes. Check with local
requirements and codes, purchase and install appropriate connector if necessary. (FIG. A)
Cable Lock
FIG. A

13
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Preparation & Installation
At least two installers are required due to the
weight and size of the hood.
CAUTION
1. Install blower into power pack:
AK8200BS - Blower is pre-installed
AK8300BSX - Refer to page 15 for instructions
NOTE: Remove blower mounting support screw
located on top of the motor housing before
installing the hood into cabinet.
2. Install 10” round adapter to the top of power
pack.
3. Install optional AK08xxAS Stainless Steel Liner.
Review manual included with liner for more
details.
4. If no liner is used, cut an opening in the bottom
of the cabinet by following the dimensions in
FIG. B.
5. Lift power pack into opening and secure to
bottom of cabinet using (4) M4 stainless steel
screws, (1) in each corner; see FIG. C.
NOTE: Wood blocking may need to be added
to cabinet base if additional support is
needed.
cabinet bottom cut-out size
26-1/16” - 34-11/16”
AK8200BS AK8300BSX
14-3/4”
Front View
minimum
3/4” wood base
metal or other non
combustible material
(4) M4 ss wood screws
(1) in each corner
F
ront
V
iew
m
inimum
3
/
4” wood base
Ductwork
Elec.
FIG. B
FIG. C
6. Install ductwork and seal with duct tape.
7. Install electrical.
8. Remove all packaging materials before using power pack. Switch power on and check for leaks
around duct tape.
9. Install bae filters.

14 Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Installation Instructions
Repositioning the Electrical Box
The electrical box in the front can be repositioned to the top of the blower housing if additional
clearance is required during installation.
1. Remove the (2) screws from the
electrical box in front of the
blower housing.
2. Position the electrical box on top
of the blower housing and secure
with (2) screws. Reroute the
wiring inside the hood for the new
electrical box placement.

15
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Single & Dual Internal Blower Installation
1. Position blower plate over the
bracket inside the back of the
hood and pivot up. Secure the
plate to hood with (2) 3/16x3/8”
screws.
2. Connect 6 pin male connector
from blower wiring to 6 pin female
connector in the power pack.
Single Blower - Connect 6” round
ductwork to blower collar.
Dual Blower - Place 10” round
adapter on top of power pack
and secure it with (4) M4x8
screws. Connect 10” round
ductwork to 8” round adapter.
Multiple blowers are compatible with AK8300BSX only. AK8200BS includes a 1000 CFM dual blower
only. For remote blower preparation instructions, turn to page 16.

16 Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Installation Instructions
Remote Blower Preparation
1. Place 10” round adapter on top of
Power Pack and secure it with (4)
M4x8 screws. Connect 10” round
ductwork to 10” round adapter.
2. Install threaded end of remote
blower wiring through external
blower wiring knock out locked
in junction box on top of power
pack.
3. Place cap over threaded end of
remote blower wiring and secure
by turning clockwise. Connect 6
pin male connector from blower
wiring to 6 pin female connector
in the power pack.
4. Secure green ground wire from
remote blower wiring to ground
screw located inside the power
pack.
CBE-1000 / PBN-1000A: WIRING DIAGRAM
White (common)
Black (high)
Blue (med)
Red (low)
Green (ground)
Remote Blower
Wiring Box
(hood)
Junction Box
(Remote Blower)
NOTE: For instructions on installing remote blowers, please refer to the CBE-1000 or PBN-1000A
manuals included in the blower packaging and on our website: www.zephyronline.com

17
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Features & Controls
1. Blower On/O
By pressing the blower is switched on and o. When switched on, the blower starts up on speed level 1.
2. Speed Selection
- Press to decrease fan speed. 3, 2, 1.
- If fan is on Speed 1 and is pressed, the fan will power o.
- Press to increase fan speed. Fan On, 1, 2, 3.
- If hood is o and is pressed, the fan will turn on speed 1.
3. Delay O
This feature is used for programmed shut down of blower 5 minutes after the function is activated. Press
once, a dot flashes in the lower right side of display indicating the function is on. The blower will
completely shut down after 5 minutes.
4. Lights Low/Medium/High/O
Switch lights on to low by pressing once, press a second time for medium, press a third time for high
and again to shut o lights.
5. Display Window
The display window indicates speed levels and features such as bae filter clean reminder, delay o and
clean air indicator.
Lights Low/Medium/High/O
5 Min Delay O
Display (speed level, delay o, filter clean)
Adjust 3 Speed Levels
Blower On/O
1
23
4
5
Touch Controls

18 Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Features & Controls
Touch Controls
Bae Filter Clean Reminder
A set of bae filters are fitted by the factory, these bae filters are intended to filter
out residue from cooking. The filters need not be replaced on a regular basis but are
required to be kept clean. The Bae Filter Clean reminder function in the microproces-
sor will automatically indicate by a flashing when the bae filters need to be
cleaned after every 60 hours of use. Filters can be cleaned by hand with non-abrasive
soap or in a dishwasher. Heavily soiled filters should also be soaked in grease cutting
detergent prior to cleaning.
Bae Filter Clean Indicator
When flashes on the display, the bae
filters needo be cleaned. This will occur
after every 60 hours of use.
Reset the filter clean reminder timer after
filters are cleaned and re-installed. With
hood o, press and hold for approxi-
mately 5 seconds until on display
disappears . The filter clean reminder
function is now reset and a new 60 hours
elapse cycle is initiated.
Clean Filters
display < F > flashes
hold 5 sec. display from < F > to < >
To Reset
hold 3 sec. display from < A > to < >
To Disable
hold 3 sec.
To Enable
display < A > flashes
Clean Air Indicator
While Clean Air is active, the display will
alternate between , , , .
After 10 minutes of Clean Air operation, the
blower will power o and the 4 hour timer
will reset.
If the blower speed is changed while the
Clean Air Function is in use, the cycle will be
interrupted and the timer will reset after.
Clean Air Function
Clean Air is a feature that turns on the blower on low speed every 4 hours for 10 minutes
to remove stagnant air in the kitchen. The Clean Air function is disabled by default and
must be enabled by the user.
and
and
F
F
F
A
AA
11
A
F
F

19
Tornado II & Tornado III Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Features & Controls
RF Remote Control
FCC Caution
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment. (Example -
use only shielded interface cables when connecting to computer or peripheral device. This device
complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1)
This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Synchronization
To create a unique link between your hood and remote control please follow these steps.
1. With hood o, press and hold the “lights” button on the hood until the letter “F” shows on the
display screen.
2. Press on the remote, the lights on the hood will turn on and synchronization is complete.
RF Remote Control Functions
Blower On / Speed Selection
Press to power on blower and cycle through all three blower speeds.
Blower On / Power O
By pressing , the blowers will power on at the last speed setting. Press
again and the entire hood will power o, including lights.
Delay O
Lights Low/Medium/High/O
Switch lights to low by pressing once, pressing two times for medium, three
times for high, and again to switch o.
Blower On/
Speed Selection 1
1
2
3
4
Blower On/
Power O
2
5 Min Delay O 3Lights
Low/Medium/High/O
4
By pressing , the blower and lights will enter Delay O mode. A dot will
appear in the lower right corner of the hood display indicating the function
is on. The blower will change to speed 1 and shut down after 5 minutes.

20 Tornado II & Tornado III Use, Care, and Installation Guide
TORNADO II &
TORNADO III
INSERT
PRO
Features & Controls
RF Remote Control
RF Remote Features
The RF remote control is equipped with a magnet on the back for easy storage. The remote may be
placed on any magnetic surface such as a refrigerator or the Zephyr remote holder, FIG. D. The
remote holder can be inserted into a standard electrical outlet for easy storage. Note: The remote
holder does not charge the RF remote.
Maximum remote control communication distance is 15 feet from the liner.
RF Remote Maintenance
Clean the remote control using non abrasive detergents.
Follow instructions below for replacing battery. Using a small flat head screwdriver, raise the cover of
the battery door (A) in order to access the battery compartment. FIG. E.
Remove the battery and replace with battery type A23 12V. Negative end of battery should face the
spring inside the remote.
Re-install battery door and recycle old battery.
FIG. D
A
-
+
FIG. E
