Zephyr Europa Series Installation guide

www.zephyronline.com
Use, Care and Installation Guide
Europa Series
Carbon Filter Kit
Z0F-C022 - 2 Pack
Z0F-C023 - 3 Pack
Z0F-C042 - 2 Pack
Z0F-C043 - 3 Pack
0Z0FC-70001 REV: 11/04 © Zephyr Corporation

Table of Contents
LIST OF MATERIALS ————————–— 2
SPECIFICATIONS —–—————————— 3
INSTALLATION ————————————— 4
CLEANING AND
CONTACT INFORMATION ———————– 5
1

List of Materials
Z0F-C022, Z0F-C042
2 - Carbon Filters
2 - Metal Filter Brackets
Z0F-C023, Z0F-C043
3 - Carbon Filters
3 - Metal Filter Brackets
Note: If any parts are missing, please call
1-888-880-8368 for replacements.
2

3
The following is the list of models that each carbon filter kit is designed for.
Z0F-C022 (2pk) Z0F-C023 (3pk)
ZFI-M90S ZVE-E36S
ZPA-M90S ZVE-E42S
ZMI-M90x ZNA-M90S
ZVE-E30S ZNA-E42S
ZPY-E30x ZPY-E36x
ZSA-M90S
ZML-M90x
ZML-E42x
Z0F-C042 (2pk) Z0F-C043 (3pk)
ZTO-M79S ZTA-E36S
ZTR-M90s
ZTA-E30S
Specifications
Note: The only model hoods which will use the metal carbon filter brackets are
the ZPY-E30x,ZPY-E36x,ZTA-E30x,ZTA-E36x and ZSA-M90S. The rest of
the above Zephyr hoods have diffuser panels built into them behind the metallic
filter. You may discard the metal bracket which came with your carbon filter kit if
you are using the carbon filters on a hood which has a diffuser panel. To install
carbon filters, just snap them into the diffuser panels..

Installation
4
Follow the instructions below for installing the carbon filters to your metallic filters.
1. Install metal bracket onto metallic filter from
hood by sliding one end of the metal bracket
underneath the backside of the gray handle as
shown above.
2. Push two corner tabs into metallic filter
frame to lock it in. If pushing tabs in is difficult,
gently lift up on the corner lip of the bracket
near the gray handle and push down on the
corner tab.
3. Install carbon filter onto metal bracket with
plastic side up. Insert bottom side of carbon
filter where the tab cut-outs are first.
4. Push carbon filter down and click locking
tabs in place.
5. Installation complete.

Cleaning and Contact Information
Carbon filters are not meant to be cleaned. DO NOT place carbon
filters in the dishwasher or soak them in soapy water. Under normal
usage, carbon filters should be replaced every 4 - 6 months.
Carbon filters may need to be replaced more frequently if you do
much deep frying or if cooking odors are more noticeable.
Zephyr Corporation
395 Mendell Street
San Francisco, CA 94124
1-888-880-8368
www.zephyronline.com
5
