ZEPP Z A1934 User manual

Product Manual
Zepp Z
A1934

Smartwatch with the band × 1 Charging base × 1 Instruction Manual × 1
01 Package Contents
1

Note:
Press and hold the crown to turn on the watch. If the watch cannot be turned on, please charge it and
then try again.
Optical heart rate/
Blood oxygen sensor
Upper button/
Front electrode
Crown
Touch
screen
Lower button
Microphone
Rear electrode
02 About the Watch
2

Note:
1.
2.
3.
For a better user experience, please use the most recent version of the App.
The operating system needs to be Android 5.0, iOS 10.0, or above.
Do not pair the watch directly using your mobile phone’s Bluetooth. Follow the
steps in the app to pair your watch correctly.
03 Pairing the Watch
1.
2.
3.
4.
Scan the QR code on the Instruction Manual with your mobile phone to download the app to your mobile
phone. You can also download the latest version of App from the Google Play Store or Apple App store.
Open the APP, register an account and log in.
Follow the steps in the app to pair your watch correctly. Once the pairing is done, the watch will display
the correct time.
You can set the other watch functions as needed.
3
Download Zepp App

Note:
1.
2.
Please use the charging base that comes with the watch. Make
sure that the charging base is dry before charging.
Please use a 1A power adapter.
1.
2.
3.
Connect the watch's charging cable to a power adapter or a computer's USB port.
Place the bottom of the watch on the charging base.
When charging starts, the watch screen displays the charging progress.
04 Charging the Watch
4

05 Disassembly and Assembly of the Watch Strap
Please refer to the illustrations to disassemble or assemble the watch strap.
Note:
Once the strap is assembled, pull the strap properly to ensure it is installed successfully.
5

06 Wearing
1.
2.
3.
Wear the watch strap not too tight or too loose, and leave enough space for the skin to breathe. This
makes you feel comfortable and allows the sensor to function.
When measuring blood oxygen saturation, wear the watch correctly. Avoid wearing the watch on the
wrist joint, keep your arm flat, maintain comfortable (appropriately tight) fitting between the watch and
the wrist skin, and keep your arm still throughout the measurement process. When affected by external
factors (arm sag, arm sway, arm hair, tattoo, etc.), the measurement result may be inaccurate or the
measurement may fail with no output.
We recommend that you tighten the watch strap during exercise and loosen it afterwards.
6

Product model: A1934
Input: 5 V d.c. 1 A MAX
Bluetooth Frequency: 2400–2483.5 MHz
Water resistance rating: 5 ATM
Device requirements: Devices installed with Android 5.0 or iOS 10.0 or above OS versions
View product certification information on the watch's Settings > System > Regulation page.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Anhui Huami Information Technology Co., Ltd. is under license. Other trademarks
and trade names are those of their respective owners.
07 Basic Parameters
7
Bluetooth version: BLE V5.0
BLE output power: <5 dBm
Operating temperature: 0°C to 45°C

08 Regulatory Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.
2.
FCC ID: 2AWQ5A1934
Any changes or modifications that are not expressly approved by the party responsible for the
compliance may void the user’s authority to operate the device.
8
This device may not cause harmful interference, and
This device must accept any interference received, including the interference that may cause
undesired operation.

Note:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
9

- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
10

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
IC: 26244-A1934 CAN ICES-3(B)/NMB-3(B)
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de
licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
11

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres
utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée
équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication
satisfaisante.
12

All products bearing this symbol are waste electrical and electronic equipment (WEEE as in
directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you
should protect human health and the environment by handing over your waste equipment to
a designated collection point for the recycling of waste electrical and electronic equipment,
appointed by the government or local authorities. Correct disposal and recycling will help
prevent potential negative consequences to the environment and human health. Please
contact the installer or local authorities for more information about the location as well as
terms and conditions of such collection points.
09 Disposal and Recycling Information
13

Hereby, Anhui Huami Healthcare Co., Ltd. declares that the radio device type A1934 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: https://support.zepp.com/en/
For more regulatory information and product certification/compliance logos related to Zepp Z,
please go to Regulatory on your Zepp Z.
10 Certifications and Safety Approvals
14

1.
2.
3.
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can
result in an explosion.
Leaving a battery in an extremely high temperature surrounding environment that can result in an
explosion or the leakage of flammable liquid or gas.
A battery subjected to extremely low air pressure that may result in an explosion or the leakage of
flammable liquid or gas.
11 Battery Safety
15

12 Safety Notice
16
1.
2.
3.
4.
5.
6.
7.
Do not allow children or pets to bite or swallow the product or its accessories, as this may cause injury.
Do not place this product under excessively high or low temperatures, which may cause the product to catch fire or
explode.
Do not place this product near heat sources or open flame, such as ovens and electric heaters.
Some people may experience allergic skin reactions to plastics, leathers, fibers, and other materials, and symptoms such
as redness, swelling, and inflammation will occur after long-term contact with this product's components. If you experience
such symptoms, please discontinue use and consult your doctor.
Do not use unauthorized or incompatible power adapters, chargers, or data cables, which may damage the watch and
accessories, or cause fire, explosion, or other hazards.
The radio waves generated by this product may affect the normal operation of implanted medical devices or personal
medical devices, such as pacemakers and hearing aids. If you use any such medical devices, consult the manufacturer
for relevant usage restrictions.
Do not dispose of this device or its accessories as ordinary household waste. Please comply with local regulations for the
disposal of this device and its accessories, and support recycling.

13 Repair and Maintenance
1.
2.
3.
4.
5.
6.
7.
Avoid using detergents such as soap, hand sanitizer, bath foam, or lotion for cleaning to prevent
chemical residues from irritating the skin, corroding the device, or degrading the water resistance of the
device.
After wearing the device while bathing (for devices that support bathing), swimming (for devices that
support swimming), or sweating, please promptly clean and dry the device.
The leather strap is not waterproof. Avoid getting the strap wet, as this may shorten its service life.
When using light-colored watch straps, avoid contact with dark clothing to prevent color staining.
Do not wear your watch during snorkeling, showers, hot springs, saunas (steam rooms), diving,
underwater diving, water skiing, and other activities involving high-speed water currents.
Do not place the device in direct sunlight for long. Excessively high or low ambient temperature may
cause device failure.
Handle with care during transportation. Keep the device dry and away from humidity.
17

14 Troubleshooting
Please check the FAQ on the website: https://support.zepp.com/en.
15 Warranty and Return Policy
The Zepp Limited Warranty covers Zepp products against manufacturing defects beginning on the
original purchase date. The warranty period is 12 months or other period as the applicable consumer
laws in the consumer’s country of purchase require. Our warranty is in addition to rights provided by
applicable consumer laws.
Official website: www.zepp.com
Support: support.zepp.com
18
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz
