zerona KSV-23P User manual

USER MANUAL
ZERONA
Manual & Warranty Card
CS Center
070.4116.8776 www.madekr.co.kr
Product Name
Model Name
Certication Number
Rated Voltage
Power Consumption
Body Specications
Body Weight
Filter
Material
Area of Use
Manufacturer
Country of Origin
ZERONA(Air Sterilizer)
KSV-23P
R-R-mKR-KSV-23P
AC100-220V, 12V 2A
24W
270(W), 270(D), 270(H)
About 2.7Kg
HEPA lter : H13
ABS, GPPS, Metal
Approximately 530 to 710 square feet (about 49 to 66m²)
MADEKR
Republic of Korea
• For your safety, please read carefully before use.
• Please keep the product warranty card at the back of this manual.
• This product is free volt (100V ~ 240V). Please note when using the product.
ZERONA
KSV-23P
FDA class1 APPROVED
Oce Hour 10:00~17:00(Mon~Fri / closed on Sat, holidays) 65-37, Gojeong 1-ro 30 beon-gil, Tongjin-eup, Gimpo-si,
Gyeonggi-do, Repubilc of Korea MADEKR
015
It produced under strict quality managing
and acquired ISO9001 certification .

02 ㅣ Anytime Anywhere, The Fresh Air for Me ZERONA USER MANUAL ㅣ 03
Wind speed
(sleep mode/weak wind/strong wind)
You can effectively control the virus sterilization time
in space by controlling the wind speed.
1-2-3
Simple touch button implementation (power)
Press the power button for 1 second to start the
air sterilization function, and press it again
for 1 second to turn it off.
Simple touch button implementation (wind speed)
The wind speed is from stage 1 to stage 3,
and the sterilization time can be efficiently controlled
with 3 touches.
LED mood light • Nursing light!
It supports 1st to 3rd stage touch dimming function,
and the combination of subtle mood light and air
sterilization function can be used as the best nursing light.
Simple touch button implementation (LED)
You can select the desired brightness with 3 touches
in the 1st to 3rd stage of the LED mood nursing light.
Air sterilization (purification) effect
Virus and COVID-19 sterilization and
air purification at the same time!
(Recommended area : 530 to 710 square feet,
about 49 to 66m²)
Voice support service!
By supporting the voice message to replace the
sterilization lamp in accordance with the replacement
time of the sterilization lamp, it is possible to use it
conveniently even if you do not know the replacement time.
Convenient remote control!
On/off, mood light, and wind speed can be conveniently
controlled with the wireless remote control.
“Simple remote control”
• Do not extend or modify the power cord arbitrarily.
• When using the multi-outlet, do not use multiple devices at the same time.
• If the adapter or wire is damaged, stop using it and contact our Customer Support Center.
• Be careful not to bend the power cord excessively or not to place heavy objects on it.
• Do not disassemble, repair, or modify the product.
• Do not install the product where the ammable gas leaks, or where there is a lot of industrial oil
or metallic dust.
• Keep away from direct sunlight, strong light xtures and hot air balloons.
It may cause deformation, breakdown and explosion of the product.
• Do not leave the product in hot or humid places such as bathrooms, toilets, laundry rooms, or
swimming pools.
• Do not use or place combustible materials (ether, benzene, alcohol, chemicals, LP gas,
ammable sprays, insecticides, fragrances, cosmetics, etc.) or ammable materials
(candles, lamps, etc.) near the product.
• Unplug the power cord if not used for a long time or during heavy thunder and lightning.
• Do not operate with wet hands.
• If the product is indundated, stop using it and contact our Customer Support Center. It may
cause product malfunction or electric shock.
• If a strange sound, smell or smoke comes from the product, turn off the power immediately
and contact our Customer Support Center.
• Do not insert foreign objects into the air intake and exhaust vents.
• Do not let children or those who have hard time using the product. It may cause injury or safe
accidents.
• Do not allow foreign objects such as water, coffee, or coke to enter the product. It may cause
re, electric shock or product failure.
• Install the power plug (adapter) where it is easy to remove.
• Turn off the power before cleaning or replacing the product lter.
• Unplug the power plug when not in use for a long time.
• Make sure that the air intake or outlet is not blocked by laundry or curtains.
• Using the product as the air vents in the kitchen can shorten the lter life and result in product deformation.
• Do not install the product the way it faces the wind blowing direction.
• Do not install the product in conned spaces or on sloped, uneven oors.
• Do not move the product while it is in operation.
• Do not allow children to climb on the product or subject it to excessive shock.
• Do not clean with solvent-based detergents. Use a soft cloth.
• Do not let the humidier moisture directly touch the product.
• Be careful not to get your body caught in the product when removing and reinstalling the accessory.
• Do not attach damaged accessories.
• Do not operate the product with the cover open.
• Do not push the vibrator (metal) part of pest control with metal or nger.
Precautions
for
Safety
Please read this information carefully before using the product
safely to prevent property damage.
The “Precautions for Safety” are designed to help you use the product
safely and accurately to prevent unexpected risks or damages.
When violation of instructions could result in serious injury or death
WARNING
Warning
Caution When violation of instructions could result in a risk of minor injury
or product damage
Installation InstallationUsage Usage
Caution

04 ㅣ Anytime Anywhere, The Fresh Air for Me ZERONA USER MANUAL ㅣ 05
1. Cover removal
• Grasp both sides of the top of the product and lift it slightly.
2. Separation of sterilizer
• Hold the sterilizer set with both hands and turn it counterclockwise to separate the sterilizer.
• Our sterilizer set is designed to be separated from the HEPA lter.
• When replacing the sterilization lamp in the sterilization device, please replace
the HEPA lter as well.
* When it comes to replacing the sterilization lamp, a voice message prompting you to replace
the sterilization lamp is guided through the speaker.
3. Tripod stand
• The tripod mount is shipped with this product. After receiving the product, you can use it
by placing it on the tripod stand.
Sterilization lamp replacement and mounting
(The COVID-19 sterilizing substance generator is attached to the lter.)
When cleaning the lter and replacing the sterilization lamp, follow the steps below.
Sterilizer
bracket
COVID-19
sterilization
equipment
Sterilization
lamp
replacement
and
mounting
1. After removing the cover,
remove the connector as well.
2. Turn the combined sterilizer set
counter-clockwise to separate it.
3. Loosen the screw connected
to the lter.
5. Remove the two screws on the top
cover of the sterilizer and separate
the top cover and the sterilizer.
4. Remove the sterilizer and lter.
6. Disconnect the connector from
the sterilizer.
Component
and
Part Names
How
to
Install
Cover
HEPA Filter
Cleanliness Indicator
Mood Light
Control Panel
Tripod Holder
Air Intake
Body
Air Outlet
H 299mm
(When using tripod mount)
W 270mm
Speaker
Power Terminal
Air Intake Port
Tripod Holder
Coupling
Fan Hole Inlet
Safety Guard
Safety Switch
Main Body HEPA Filter
Filter/Sterilizer SET
Tripod
Holder
Remote
Control
Power
Adapter
Leaet Manual

06 ㅣ Anytime Anywhere, The Fresh Air for Me ZERONA USER MANUAL ㅣ 07
• The sterilization lamp and lter replacement cycle in the sterilizer is one year.
(When replacing the sterilization lamp, replace the lter as well.)
(If you use it for a short time during the day, you can use it for a longer period.)
• For the sterilization lamp and lter in the sterilization device, be sure to use
the genuine lter provided by MADEKR Co., Ltd.
• The replacement cycle of the sterilization lamp in the sterilizer may vary depending
on the environment of use.
• There may be a new lter smell at rst, but it will disappear naturally after using
the product for more than a day.
• Avoid using perfumes, air fresheners or sprays around the product. The lter life will be shortened.
Power button starts or stops the air sterilizer (purication) operation.
Starts or stops mood, feeding, etc.
• One-touch smart dimming function allows you to adjust the brightness
from level 1 to level 3
The wind speed can be adjusted from stage 1 to stage 3.
• Filter management is important for purication function. If you clean the
lter with a vacuum cleaner or soft brush once every two weeks, it can
be used for a longer period.
* This lter cannot be washed with water. Never wash the lter,
as it may seriously damage the lter performance.
• Cleaning the exterior of the space sterilizer is also easy for lter
management. Use a vacuum cleaner to remove dust from the air inlet
and air outlet.
Precautions
for replacing
sterilization
lamps
Operation
panel
TiP
• Sterilization lamps and lters must be genuine products provided
by MADEKR Co., Ltd., and the use of counterfeit products may cause
performance degradation.
Purchase Inquiry 070
.4116.8776
ㅣ www.madekr.co.kr
How to buy a lter
1. After connecting the power plug to the outlet, press the power button
for about 1 second to start the air sterilizer.
2. You can adjust the sterilization intensity by pressing the wind speed button.
Stage 1 (sleep mode) ㅣ Stage 2 (weak wind) ㅣ Stage 3 (strong wind)
Air
sterilization
(purica-
tion)
function
Level 1 (sleep mode) Use during normal or sleep
Level 2 (weak wind mode) Large area or crowded space
Level 3 (Strong wind mode) When you want to volatilize sterilizing
substances in the space
Notes when
selecting
wind speed
7. Loosen the 4 screws connected
to the sterilization lamp.
9. Remove the lamp in the separated
sterilizer and replace it with
a new accessory.
8. Remove the bracket by pushing it
down as indicated by the arrow.
Tips to
make your lter
last longer

8 ㅣ Anytime Anywhere, The Fresh Air for Me ZERONA USER MANUAL ㅣ 9
1. Operates when touching the Mood Light Mode button while power is connected.
2. The mood light has a light bulb color, and the brightness can be nely adjusted
from 1 to 3 levels.
3. You can manually set the brightness level from 1 to 3 with a short touch.
4. With one-touch smart dimming function, press and hold for more than 1 second to
automatically adjust brightness from 1 to 3 levels. A buzzer sounds at the Max level.
5. When touched short or longer at Max level, brightness decreases and buzzer beeps
while mood light turns OFF.
Mood
Light
Function
Safety
Switch
Function
It is equipped with a safety switch function.
• The unit will turn off automatically when you open the lid and remove the lter
from the main unit.
• The power will not turn on if the lter is not inserted even during initial power connection.
• When Forcibly press the safety switch, operate the unit, and insert foreign materials
into the fan hole openings, fan will stop operating and the red warning light will blink
10 times and turn off.
Check
Before
Reporting
Trouble Symptom
It doesn’t work.
There is a strange smell
at the air outlet and lter.
Solution
• Check if the power plug is plugged in properly.
• Check if the surrounding temperature is too high or too low.
• Check if the supplied power adapter is correct.
• Where there is a lot of smoke or odor, the product’s function
may be impaired. Use the product after ventilation.
• Odor may be adsorbed on the lter and the lter may be replaced.
Customers have the right to receive free service for one year from
the date of purchase for any malfunctions that occur while
using the product. Keep the written warranty letter attached in the
designated section of the warranty card provided when purchasing
the product and the receipt to receive the Consumer Damage
Compensation Standard.
Warranty
Card
For 1 Year
Warranty
Product Name
Model Name
Purchase Date
Purchase Place
Address
Name
Customer
Information
Phone
Air Purier ANYPURI
KSV-23P
Month Day Year Warranty 1 year
ㅣ

10 ㅣ Anytime Anywhere, The Fresh Air for Me ZERONA USER MANUAL ㅣ 11
In case of requesting for service when the product is not defective,
the service fee will be charged, so please check once more before
requesting the service. When applying for service, the following
cases will be charged even within the free period.
• When defect occurred due to careless handling of the consumer or incorrect
repair or modication of the product.
• When the customer disassembled the product and the part is missing or damaged.
• When defects occurred by using adapter other than the supplied adapter
• When a breakdown or damage occurred due to an external impact or drop
• Defect occurred due to the use of non-genuine consumable parts or repair materials.
• The appearance is damaged or deformed by organic solvents such as thinner
or benzene.
• When a defect occurred due to violating the ‘Safety Precautions’ in the user manual.
• If the product is damaged due to external causes other than the product itself
• When a defect occurred due to natural disasters
(lightning, re, earthquake, geomancy, etc.)
• When the life of consumable parts is over (lters, etc.)
• For simple inspection requests, not product failures
• If a foreign object such as a toy or drink entered the product and caused a defect
• If the product is not repaired or modied by a non-repair technician of the dealer
or our service center
• When requesting services such as lter replacement / cleaning and product cleaning
1. Check with Customer Support for the possibility for repair.
2. If the repair is possible, apply for the service.
3. Place the product or parts in the box and send it by courier.
4. In principle, exchanges and other A / S should be carried out by exchange through
courier.
5. If the returned goods or parts are not returned in the normal condition, a separate
fee will be charged.
If you have any questions,
please contact our Customer Support Center.
Responsi-
bility
for Paid
Service
Warranty
Repair
Procedure
We, THEMADEKR, guarantee the products as follows according to
the consumer dispute resolution standard.
Consumer
Dispute
Resolution
Criteria
Consumer Damage Type
When a major repair is required
due to a performance / function
defect occurring under normal
use within 10 days of purchase.
When a major repair is required
due to a performance / function
defect occurring under normal
use within one month of purchase.
If the company loses the product
requested by the consumer for
repair
If the consumer does not
collect the product
Defects in
performance or
function which
occurred under
normal use
within the
warranty period
Damage
caused for
not having the
repair parts
within the parts
retention period
In case of defect
Defects in
performance
and function
in normal use
Defects due
to the
intention of
or negligence
by the consumer
If the defect is repaired up to 2 times for the same defect within the
warranty period or if the defect recurs up to 4 times for the various
parts, but the defect is recurring, it is considered impossible to repair.
Compensation Details
Within Warranty Period After Warranty Period
Product exchange or
free of charge repair
Free of charge repair
Product Exchange
Product Exchange
Product Exchange
Exchange of product
after receiving the
amount corresponding
to paid repair
• Storage charges may be charged 30 days after
the repair request date
• If the customer does not take over the product
after 60 days, it will be considered abandonment
and the product will be disposed within the company
Same product exchange
or equivalent model
exchange
Same product exchange
or equivalent model
exchange
Paid Repair
Paid Repair
