Zicom Z.HA.HA.SC.ATOUCH.SENSOR User manual

Shutter Door Sensor
Z.HA.HA.SC.ATOUCH.SENSOR
UserManual
Introduction
TheZ.HA.HA.SC.ATOUCH.SENSOR Roller Shutter Door
Sensor is used for rolling gates. When the Metal Magnet and the
Metal Reed Switch are separated more than 2cm, it will transmit
wireless alert signal to the connected control panel immediately.
The lifespan of the battery depends on the frequency of
opening and closing the door/gate, the normal battery's service
life is about 12 to 15 months.
Product Overview
LED Indication
Flashes once:Door opening is detected.
Flashes onceevery3 seconds: Low power indication; pleasechange
thebatteries as soon as possible.
Pair with Control Panel
1. Make sure the control panel enters Pairing Accessory State
(Please refer to the details in the control panel's user manual)
2. Separate the Metal Magnet and the Metal Reed Switch for more
than 2cm. The control panel beeps once to indicate a successful
pairing.
Installation
Important:
Please test the sensor to make sure the
connected control panel can receive the transmitting signal of the
sensor before fixing it in place.
Install thesensor insidethe house.
Steps:
1.Metal magnet: Install it on the bottom of the rolling gate which
can move up and down, it should be parallel to the ground but
don't over the bottom.
2. Metal reed switch: Install it on theground and make sure the
distance between the metal magnet is less than 2cm.
3. Transmitter: It isconnected with the metal reed switch and
should be mounted on the wall beside the rolling gate (Away from
the gate as far as possible because metal may disturb wireless
transmission).
4. Test: Set thecontrol panel to Arm State, close the gate and
open it over 2cm, thesensor is working well if the LED indicator
flashes once and the system alarm goes off
Note: IfonlyLEDindicatorflashesoncebutthesystemalarmdoesnotgo
off,pleasepullouttheantennaofZ.HA.HA.SC.ATOUCH.SENSOR or
movethecontrolpanel alittle closer to the sensor.
Specifications
Battery DC 3V (AAA 1.5V LR03 x 2 PCS)
Static Current < 23 uA
Alarm Current < 40 mA
Transmitting Distance < 80m (in open area)
Radio Frequency 315 MHz/433.92MHz (±75KHz)
Housing Material ABS + Aluminum Alloy
Operation Condition Temperature -10°C~+55°C
Relative Humidity < 80% (non-condensing)
Metal Magnet Dimensions (L xW xH) 105.5 X 15.5 X15.5 mm
Metal Reed SwitchDimensions (L xW xH) 105.5 X 38 X 9.6 mm
Transmitter Dimensions (L x W xH) 107 X 54 X 14.5 mm
Antenna
LedIndicator
Transmitter
MetalReedSwitch MetalMagnet
Zicom Electronic Security Systems Ltd.|
Address: 501, 5th Floor, Silver Metropolis, Goregoan (E), Mumbai–400 063, India.
Website: www.zicom.com | Toll Free : 1-800-270-4567
