6. Fit the 4 stand legs to their
matching positions as marked
on the bbq legs.
A
A
B
B
B
B
9. Stand the bbq upright,
UNLOCK the knobs, then fit
the cooking grill.
10. The strap provided must be
connected to the gas supply and
the barbeque legs to prevent the
gas hose from being over-stretched.
8. Fit the 2 bottom braces,
engage the locking screws and
tighten with the Allen key.
ASSEMBLY INSTRUCTIONS FOR ZIEGLER & BROWN PORTABLE BARBEQUE STAND
PLEASE NOTE STEPS 1-8 are shown without the factory fitted gas hose and regulator for clarity.
DO NOT DISCONNECT GAS HOSE OR REGULATOR.
Read the barbeque instruction manual before positioning or using your barbeque. FIRSTLY, check that you have all the parts as shown overleaf.
Locking
knob
7. Engage the captive locking
screws and tighten with the
Allen key provided.
1. Make sure the grease cup
is screwed clockwise fully into
bottom of the barbeque.
Screw clockwise
4. On a clean soft surface turn
the barbeque upside down.
This will make assembly easy.
Remove
feet
5. Remove the 4 rubber feet
and store in the top flap of the
carry bag.
3. Remove the cooking grill then
lock both sides of the barbeque
adjusting both knobs to the
LOCKED position.
2. Pulling the 2 locking knobs
away from the sides of the
barbeque and setting the knobs
in the UNLOCKED position
will enable you to fully roll back
the hood.
