ZETA Motion Sensor

IRZ1ZT92
2
Copyright Statement
ZiFiSense owns the copyright on this specification. No part of
this specification may be reproduced in any form or means,
without the prior written consent of ZiFiSense.
Disclaimer
This specification is preliminary and is subject to change at any
time without prior notice. ZiFiSense assumes no responsibility
for any errors contained herein. ZiFiSense is not responsible for
any patent infringement of third party on its use or as a result
of its uses. Other products/services not certified by the patent
license, shall be deemed within patent ownership of ZiFiSense.

IRZ1ZT92
3
Table of Contents
1. Product Description.........................................................................................................................4
2. Applications....................................................................................................................................... 4
3. Appearance........................................................................................................................................ 4
4. Features.............................................................................................................................................. 4
5. Product parameters......................................................................................................................... 5
6. Packing List....................................................................................................................................... 5
7. Installation..........................................................................................................................................6
7.1. Screw...................................................................................................................................... 6
7.2. Adhesive 3M.......................................................................................................................... 8
7.3. Cable Ties.............................................................................................................................. 9
8. Use of Device...................................................................................................................................12
8.1. Power on.............................................................................................................................. 12
8.2. Support function.................................................................................................................. 12
9. Common faults and handling......................................................................................................12

IRZ1ZT92
4
1. Product Description
ZETA Motion Sensor is a low power infrared sensor which can sense
human movements with its high-sensitivity amplifiers, anti-jamming
devices, and differential inputs, so that the false detection is avoided.
2. Applications
Rooftops, computer rooms, important equipment rooms, illegal entry
detection, operating position detection.
3. Features
Wireless transmission
Battery-powered, low power consumption
Easy to install, high sensitivity
Reliable detection
Real-time transmission

IRZ1ZT92
5
4. Product parameters
Product No.
IRZ1ZT92
Wireless Features
Transmission protocol
ZETA
Frequency band
Sub-GHz, adjustable according to
local regulations
Output power
20dBm max, adjustable according
to local regulations
Electrical Features
Power supply
Battery, 2*ER14505
Battery capacity
2*2700 mAh
Stand-by current
≤ 10 μA
Working current
≤ 70 mA
Physical Features
Size
66*55*36 mm
Enclosure material
ABS
Waterproof level
IP30
Antenna
External glue stick antenna
Sensor
Characteristics
Sensing distance
3~5m
Sensing angle
120°
Working
Environment
Operating temperature
-20℃~+75℃
Storage temperature
-30℃~+85℃
5. Packing List
Motion Sensor
1
Battery
2

IRZ1ZT92
6
6. Installation
There are three installation methods: Screw, 3M Adhesive and cable ties.
6.1. Screw
6.1.1.Auxiliary material
No.
Materials
Quantity
1
self tapping screw (M3*20)
2/device
2
#4 expanded plastic pipe
2
3
Percussion drill，#4 drill bit，hammer
1
4
slotted screwdriver, cross screwdriver
1
6.1.2.Installation instructions
Open the device case
Use a slotted screwdriver to open the top cover from the bottom edge.
Punching
Place the device in the mounting position, punch and insert the expanded
plastic pipe.
Fixation
opening

IRZ1ZT92
7
Use the self-tapping screws to secure the device in the mounting position.
Power on
Insert the power plug into the upper power socket, install two 14505
batteries (remove the insulation sheet for the existing battery), and close
the upper cover.
mounting hole
mounting hole
power socket

IRZ1ZT92
8
6.2. Adhesive 3M
6.2.1.Auxiliary material
No.
Materials
Quantity
1
3M seamless thickened double-sided adhesive
5CM
2
Slotted screwdriver, utility knife
2
6.2.2.Installation instructions
Installation position
Select a flat mounting position, and clean it up.
Open the device case
Use a slotted screwdriver to open the top cover from the bottom edge.
Power on
Insert the power plug into the upper power socket, install two 14505
batteries (remove the insulation sheet for the existing battery), and close
the upper cover.
opening

IRZ1ZT92
9
Adhesive device
Take the appropriate amount of 3M adhesive, attach it to the back of the
sensor, remove the protective film of the 3M adhesive, and install the
device to the specified position.
6.3. Cable Ties
6.3.1.Auxiliary material
No.
Materials
Quantity
1
Metal cable ties（5*300mm)
2
2
Slotted screwdriver, utility knife
6.3.2.Installation instructions
Open the device case
Use a slotted screwdriver to open the top cover from the bottom edge.
power socket

IRZ1ZT92
10
Fixation
Pass the 2 cable ties through the device and secure to the installation rod
opening
Installation position

IRZ1ZT92
11
Power on
Insert the power plug into the upper power socket, install two 14505
batteries (remove the insulation sheet for the existing battery), and close
the upper cover.
power socket

IRZ1ZT92
12
7. Use of Device
The sensor detection distance is about about 3 meters without occlusion.
The detection is based on the amount of change in infrared detection to
determine whether there is the motion, so it is unable to detect a
stationary person.
7.1. Power on
Place the device within the coverage of the ZETA network, install the
battery, and wait for the device to go online. After the device is online, the
current device status is reported. You can set the threshold for motion
detected and the threshold for no motion detected according to the usage
scenario.
7.2. Support function
Status report: Reports motion/no motion detected status.
Set threshold for motion detected: within the detection time range, the
sensor reaches the required number of triggers is determined as
motion detected. (Default setting for motion detected is: triggered 2
times in 5 seconds.)
Set threshold for no motion detected: When the current status is
Motion Detected, and if the number of triggers is 0 within the detection
time range, it will be determined as No Motion. (Default setting for no
motion detected is, triggered 0 times in 20 seconds.)
Query device status:Query the current threshold status for motion
detected/no motion set by the device.
8. Common faults and handling
Ensure ZETA signal coverage
Ensure that the device is powered on, and the ZETA network device
management platform can observe that the ZETA module is on line
Check the battery usage of the device. When the battery is low, replace
the battery in time.
