ZIGBEE QOTO User manual

（Zigbee）Smart Water ValveQOTOUser ManualSHENZHEN POWER-TOMORROW ACTUATOR VALVE CO.,LTD.www.qotoactuator.com

●Smart water valve Remote operation: remote control of mobile APP anytime and anywhere, manual control of field devices, and timing control of APP Signal distance: the open distance between gateway and smart water valve is ≤50 meters Battery:4*AA alkaline dry batteries are used. Protection grade: IP66. Smart water valve can be installed and used outdoors.1. One gateway can be connected with 8 smart water valves. 2. The open distance from the gateway to the smart water valve is ≤100 meters, (determined according to the actual installation environment). 3. Zigbee signal cannot be relayed and jumped through smart water valve. 4. After setting the timing, if the smart water valve is offline, it will be watered according to the timing program.5. Operational requirements of water flowmeter: the water flow rate is at least 2L/ min, and the water flow is too small to drive the flowmeter to work. There will be a false alarm of "water shortage warning".6. Statistics will be recorded only when the smart water valve is online for historical records. 7. Water shortage reminder: When the water valve is opened and there is no water, the water shortage warning will be prompted after 15 seconds in the connected state.Instructions for use:Performance and instructions฀Water pipeRouterSmart water valveSmart gatewaySmart water valveMobile phone/Tablet812 HoseDual-purpose nozzleRemote control via APPWater pipeWifi2.4GhzCloudservice

Product parameters
½"or ¾"&1"
Ip66
0.2~8bar
Power
-10℃~+50℃
Power
DC5V/1A
Switch / reset button
¾"water inlet
1 inch internal thread water inletBattery slot ¾"external thread outletSmart water valve（Zigbee） Smart gateway（Zigbee）Product nameProduct nameCaliberWaterproof levelWithstand water pressure 4*AA alkaline dry batteryOperating temperatureWorking humiditySignal rangeOpen area ≤ 100 meters0-90%RH No condensation½"water inlet

Gateway networking tutorial① Open the APP and click add device or "+"in the upper right corner, ② Select gateway central control → wireless gateway (zigbee),③ Enter WiFi account and password (2.4Ghz),④Check to confirm that the indicator light is flashing, and EZ mode is in the upper right corner,⑤Next, enter the interface of adding equipment ,⑥Wait a moment and add successfully.①②③Operation Guide①Scan the QR code to download the “Smart Life” app, ②Register a member account. ฀Input your mobile phone number or email address. ฀Receive the verification code SMS. ฀Configurate your own password.

Gateway adds and connects intelligent water valve①Open the gateway interface and select "+Add Subdevice".② Confirm whether the indicator light of the intelligent water valve flashes (press and hold the switch button of the intelligent water valve for 5 seconds, and the indicator light switches from long on to flash or extinguish). ③Automatically search for equipment, and click Finish after searching for the equipment. ④ If the addition is successful, click the name of the brush to modify it.④⑤⑥

Mobile APP InterfaceIt's easy to understand and operateWater capacity1.Single irrigation2.Cycle irrigation1. Real-time feedback of watering time 2.Real-time feedback of watering flow Timing watering1.Set timing by flow2.Set timing by duration3.Rain and snow delayWatering history1.Total monthly watering volume 2.Records of each open1.Last irrigation time 2.Remaining power1.Next irrigation time2.Current weatherWatering time1.single irrigation2.cycle irrigationControl switch button

Warranty Regulations1. The warranty period of this product is one year. 2. During the warranty period, any failure occurred under normal use according to the instruction manual (judged by the official staff of our company) shall be repaired free of charge. 3. During the warranty period, if one of the following situations occurs, it must be repaired as a charge: ①This guarantee and valid purchase certificate cannot be provided. ②Faults and damages caused by incorrect use and improper repair by oneself. ฀ Failure or damage caused by transportation, moving and falling after receiving goods. ฀ Damage caused by other inevitable bad factors. ฀ Failure or damage caused by equipment soaking in water. ฀ If the temperature is lower than 0฀, please disassemble and put it back indoors. If the equipment is damaged due to this problem, there is no warranty. 4. We only make the above warranties, and do not make any other express or implied warranties (including implied warranties of merchantability, rationality and adaptability to a specific application, etc.). Our company is not responsible for any special, accidental or indirect damages, whether in contract, civil negligence or other aspects.QOTO Website

Product Warranty CardProduct name:Customer name: Contact number: Customer address: Warranty contents: Warranty contents: Warranty contents: Client signature: Client signature: Client signature: After sale: After sale: After sale: SatisfiedSatisfiedSatisfiedDissatisfiedDissatisfiedDissatisfiedProduct model:Ex-factory number:Date of appearance:

FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
RF warning for Mobile device:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated withminimum distan
ce 20cm between the radiator & your body.
