Zip Hydroboil Plus 303562 Manual

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Installation instructions & user manual
Zip
Hydroboil Plus
On wall boiling water.
Model number:
303562, 305562, 307562

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Table of contents
Intended Use................................................................................................................................ 2
Warnings and precautions ........................................................................................................... 3
Before installation......................................................................................................................... 5
Technical specification................................................................................................................. 6
Installation instructions
Before you begin............................................................................................................... 6
Step 1 - Position the Hydroboil Plus
Positioning......................................................................................................................... 6
Step 2 - Fasten to the wall
Fastening .......................................................................................................................... 6
Step 3 - Connection and venting
Plumbing connections....................................................................................................... 7
Venting.............................................................................................................................. 7
Electrical connections ....................................................................................................... 8
Step 4 - Assembly
Assembly........................................................................................................................... 8
Step 5 - Commission the Hydroboil Plus
Earth continuity verification ................................................................................................. 9
Turn the mains power and water on.................................................................................... 9
Trouble shooting
Trouble shooting table.................................................................................................................. 10
Operation
LCD menu functions..................................................................................................................... 11
Tap & safety lock operation.......................................................................................................... 19
Appendix
Mounting template........................................................................................................................ 20
Spare parts................................................................................................................................... 21
End of life disposal....................................................................................................................... 23
Cleaning....................................................................................................................................... 23
Contact details ............................................................................................................................. 24
Intended use
This appliance is intended to be used in commercial applications such as:
• Staff kitchens, shops, offices and other working environments.
• Small hotels and bed and breakfast type environments.
• Catering and similar non-retail applications.

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
WARNINGS AND PRECAUTIONS
!
This manual contains important safety and installation instructions for the Zip Hydroboil Plus.
Please read all warnings, installation requirements and installation instructions before installing any Zip
Hydroboil Plus. This system must be installed in accordance with water supply byelaws, current IEE
regulations and relevant local authority byelaws.
Warnings
• The Zip Hydroboil Plus must be earthed. The resistance of the earth connection from each exposed metal
part must be less than 1Ω.
• All installation and service work must be completed by trained and suitably qualified tradespeople. Faulty
operation due to unqualified persons working on this product, or any other Zip product may void warranty
coverage.
• Never attempt to install a Zip Hydroboil Plus instant boiling water heater without reading all of the applicable
instructions.
• Do not remove the cover of the Hydroboil Plus under any circumstances without first isolating it from the
power supply.
• In hard water areas mineral scale accumulation in the boiling chamber of the Zip Hydroboil Plus may become
a problem, consideration should be given to the maintenance required. A suitable form of water treatment
may be necessary.
• The Zip Hydroboil Plus instant boiling water heater is not intended for use by young children or infirm people
without supervision.
• Young children should be prevented from having access to ensure that they are not able to use or play with
the Hydroboil Plus.
• Do not use strong, corrosive or abrasive cleaners to clean the case of the Hydroboil Plus.
• The ambient temperatures this Hydroboil Plus must operate within are 5ºC - 50ºC.
• The Hydroboil Plus is intended only for indoor use and should never be installed outdoors or be exposed to
the elements of nature.
• The Hydroboil Plus must not be positioned in an area that may be cleaned by a water jet. The Hydroboil Plus
must not be cleaned by a water jet.
• Frost protection: If the Hydroboil Plus is located where ambient air temperature could fall below 5ºC when the
Hydroboil Plus is not in use, do not turn off the Hydroboil Plus electrically. This safeguard does not offer the
same protection to the connecting pipework and ttings.
• As the installer, it is your responsibility to supply (if necessary) and install all valves as required by local
regulations and relevant standards.
• The Hydroboil Plus is rated for 230V 50Hz AC operation.
• Due to the process of continuous improvement, Zip reserves the right to change details mentioned in this
manual, without notice.
• Visit www.zipwater.co.uk to ensure you have the latest copy of this document.

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
WARNINGS AND PRECAUTIONS
Safety
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. For products sold in Europe, this appliance can be used
by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of the Hydroboil Plus in
a safe way and understand the hazards involved. Children should be supervised to ensure that they do not play with
the Hydroboil Plus.
The Hydroboil Plus is intended to be used in commercial applications.
Qualifications
If the power cable is damaged it must be repaired only by a qualified technician. To avoid hazards, all installation
procedures must be carried out by a suitably qualified tradesperson.
Venting
Sometimes steam and / or boiling water may discharge through a vent outlet or the tap. Ensure the tap body is
located so the tap outlet safely dispenses into the drip tray or sink bowl area, and that the vent is plumbed to a safe
location, see page 7.
Lifting
Take care when lifting. The Hydroboil Plus may exceed safe lifting limits. If you feel this is beyond your personal
capabilities, please seek assistance with the lift. Do not lift the Hydroboil Plus by the tap or any of its connections.
Refer to the Technical specification, page 6 for the weight of the product.
Positioning
It is important to ensure the Hydroboil Plus is positioned in an accessible area. The Hydroboil Plus must have it’s
base mounted in a horizontal position.

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
!
!
Before installation
Before installation ensure that provision has been made for the
following
• Review the technical specifications.
• Ensure the mounting wall can support the product weight when full of water
(See Technical specification, page 6).
• Provide sufficient space to install the Hydroboil Plus and other components in
accordance with these installation instructions.
• Position the Hydroboil Plus so there is at least 150 mm clearance above it
for service access, 65 mm to its left and 20 mm to its right – the tap nozzle is
usually positioned nominally 360 mm above a draining board, drip tray or sink
bowl area.
• For all Zip Hydroboil Plus models, user easy accessible 1 x 230V AC 13A socket or
double pole isolation switch, (correctly rated for the appliance), is required.
• The Hydroboil Plus must be connected in accordance with IEE regulations. See
Technical specification, page 6 for power ratings.
Note Check cable and plumbing against inlet /outlet positions before proceeding.
• A wholesome (cat 1) water supply connection with isolating valve within
reach of the Hydroboil Plus (and positioned so that the stop cock will not be
obstructed when the Hydroboil Plus is installed).
• Vent / outlet drainage to a draining board, drip tray or sink bowl area .
• Access to drainage from a vent situated at the base of the Hydroboil Plus.
• A wholesome (cat 1) cold water supply with a minimum working pressure of:
(see Technical specification, page 6 min. / max. water supply pressure).
• A 0.35 MPa (3.5 bar) pressure limiting valve supplied must be fitted if the
incoming mains water pressure is likely to exceed 0.5 MPa (5.0 bar).
• The Hydroboil Plus must be placed with its base in a horizontal position.
IMPORTANT! Do not proceed with the installation if these requirements are not
met.

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Technical specification
Installation instructions
Min / Max water supply pressure
Hydroboil Plus.........................................0.07 MPa (0.7 bar) - 0.5 MPa (5.0 bar)
WARNING If the incoming mains water pressure is likely to exceed 0.5 MPa (5.0 bar), a 0.35 MPa (3.5
bar) pressure limiting valve must be installed in the cold water supply line.
Note Optional Water Block is recommended to be fitted in the water supply line to minimise the potential
damage in the event of leakage, call Zip on 0345 6 005 005.
!
Before You Begin
Locate the paper mounting-hole template packed with the Hydroboil Plus. (Also
see page 20).
Read the installation and operating instructions completely.
Decide whether to install with concealed or exposed plumbing connections.
Concealed connections are preferred for superior appearance.
Step 1 – Positioning
• Position the Hydroboil Plus so the nozzle will drain on to a draining board
or drip tray.
• Position the base of the tap nozzle to be not less than 280mm (nominally
360mm) above the draining board (height should be increased only if
essential for filling larger vessels).
• Provide clearance for service access of not less than 150mm top, 65
mm left, 20mm right.
• Mark corner positions for the Hydroboil Plus on the wall in order to position
the paper mounting-hole template.
Step 2 – Fastening
• Position mounting-hole template on wall and drill holes where shown.
• Drill holes for water inlet and vent outlet if rear access is intended.
• Install plumbing and wiring and prepare pipe ends as shown.
• Remove cover fastening screws from Hydroboil Plus and lift off cover.
• Screw Hydroboil Plus chassis to the wall using screws or bolts suited to
the wall, (supplied).
• Fasteners must be able to support the product weight when full, (see
Technical specification, above).
45mm
Elbow
Inlet clearance
Cold
inlet
Vent
outlet
Inlet
position
Vent
position
Product
code
Tank
size
(litres)
Heat up
time
(Inlet
15°C)
Heat up
time
(Inlet
10°C)
Power rating
kW@230V
Dimensions
(mm)
W x D x H
Filled
weight(Kg)
303562 3.0 16mins 17mins 1.4 289 x 180 x 431 12.5
305562 5.0 16mins 17mins 2.2 318 x 198 x 465 16.5
307562 7.5 23 min 24 min 2.2 318 x 198 x 578 20.5

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Installation instructions
Step 3 – Connecting
Plumbing
For exposed plumbing connection, connect the cold water inlet pipe from the base
of the Hydroboil Plus directly to the ½” BSP compression fittings with nuts and
olives supplied.
For concealed plumbing connections, connect the cold water pipe through the rear
of the chassis using a ½” BSP capillary elbow.
Cold water pipes must be flushed before connection to the inlet. Any clogging due
to sediment or fines will adversely affect the operation of the Hydroboil Plus.
The Hydroboil Plus must be installed with an isolating valve which allows it to be
isolated from the mains water supply for servicing.
Water pressure requirements. (See Technical specification , page 6).
Venting
A vent at the base of the Hydroboil Plus must be plumbed to a safe location as,
under certain conditions, it may discharge cold, boiling water and/or steam.
For concealed or exposed vent plumbing, connect vent outlet from the base of
Hydroboil Plus to a Ø15 mm pipe which has a continuous fall, is no more than
3m long, has no more than 3 right angle bends, and discharges to a waste water
drain. (the vent outlet must be visible).
For concealed vent plumbing, direct the vent outlet from the rear of the Hydroboil
Plus
Alternatively install a visible tundish. (see adjacent diagram) and plumb to
trapped waste.
45mm
Concealed
vent
Concealed
Inlet
Internal bulkhead
connections
External
tundish
Vent

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Installation instructions
Electrical
• Refer to current IEE guidelines for installation
requirements, cable size and selection to ensure
suitability for local installation conditions.
• Do not turn the power ON until the Hydroboil Plus can dispense
water from the tap outlet.
• Do not connect both options. It is essential that the ex
and plug cable is removed from the PCB if the concealed
connection is used. Otherwise the mains plug will become live.
Exposed electrical connection See diagram below.
• Connect to a 13A socket via the 3 core pre-fitted cable.
• Ensure that the 3 core cable is conected to the PCB via
connector (J1) on the PCB.
• Ensure that the strain relief bush is tightened to secure the
cable.
Concealed electrical connection See diagram below.
• Disconnect the pre fitted cable & discard.
• Connect a 1.5mm23 core cable to a 13A supply through the
rear access opening to the terminal block J4 on the PCB via
the strain relief bush.
• Tighten the strain relief bush, to secure the cable.
• Crimp a 6.3mm QC female spade connection to the earth
conductor & attach to chassis earth.
• Verify earth continuity (see page 9).
!
Strain relief
bush (cable
gland)
PCB
Concealed access
Step 4 - Assembly
• Without the cover on, turn the water on to check for any leaks. These should become apparent within a short
period of time. If all is dry then isolate water and replace cover. If there are any leaks repair as necessary.
Mains electricity supply connections See diagram below.
L N
Exposed electrical
connection
Concealed electrical
connection
OR
J1
J4
!

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Commissioning
Step 5 – Commissioning
• Check previous steps.
• Check the earth continuity (see below).
Upon installation or following service, the earthing continuity of the Hydroboil Plus must be tested by a qualified
technician using a resistance meter of minimum accuracy of 5% full scale deflection.
• Isolate power supply.
• Verify meter ohms range, connect leads together, reading should be 0 ohms.
• Connect one test lead to the earth of the power lead.
• Connect the other test lead to a cover fixing screw, then the tap.
Warning The water may be boiling
• Verify that in every instance the electrical resistance does not exceed 1 ohm.
Warning This appliance must be earthed
• Turn water supply ON. Water will flow into the Hydroboil Plus , check connections for leaks. Wait approximately
5 minutes then pull the tap forward to test for water flow.
• Turn the mains electrical power ON only after the water flows freely from this outlet.
• After a short period, boiling water will be available and will be maintained close to boiling point thereafter.
Do not turn the power ON until the Hydroboil Plus can dispense water from the tap outlet.
!
!

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Trouble-shooting table
Symptom Possible cause Solution
Fails to dispense water.
Water isolating valve turned off.
Blocked filter, blocked meter tube,
blocked strainer, jammed ball
valve assy, airlock in transfer tube.
Check water supply valve.
Contact Zip authorised agent.
Water not boiling.
No power.
Faulty PCB, faulty element, faulty
cut-out.
Check power supply.
Contact Zip authorised agent.
Runs out of boiling water and fails
to refill.
Outlet tap drips.
Overflow from vent.
Excessive steam from vent.
Power “on” but no heat.
Overload repeatedly tripping with
excessive steam.
Overload repeatedly tripping
without
excessive steam.
Internal adjustment. Contact Zip authorised agent.

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
The Hydroboil uses a display and button menu
system for setup and operation adjustment.
The display does not have a touch screen feature.
The side buttons are used to navigate, perform
selections and modify values.
The icon changes according to the button action.
A button has no function when no icon is shown.
1 Understanding icons and buttons
Move to the next item able to be highlighted.
Move to the previous item able to be highlighted.
Confirm menu selection
Move to the previous menu.
Perform one of 3 functions:
• Move to the menu titled by the highlighted item.
• Select the currently highlighted item to adjust it.
• Confirm the value of a selected item.
Increment the item selected.
Decrement the item selected.
2 Home screen modes
2.1 Normal mode
• There are 3 Home screen modes, detailed as follows:
• Normal mode.
• Energy mode.
• Energy override mode.
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Button 3 shows more information about the lter life.
Using to navigate to the lter life settings
menu.
Button 4 will show more information about the energy
mode settings.
Using to navigate to the energy mode settings
menu.
Filter indication
Days remaining of lter life.
Note Disabled will be shown under this icon if lter
life has been disabled in the settings menu. This is the
default option.
Energy mode indication
Hydroboil will enter energy mode at the time
shown.
Hydroboil will enter energy mode when it is
dark.
All energy saving modes are disabled.
Button 2 shows faults information. Fault indication
There are no current faults.
There are current faults.
2.2 Energy mode
Trigger Indication
Hydroboil will exit energy mode at the time shown.
Hydroboil will exit energy mode when ambient light returns to normal (bright room).
LCD menu functions
Note If lter life has been disabled in the settings menu,
0 Days remaining will be shown in this information
screen. This is the default option.

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
4 SETTINGS menu
2.3 Energy Override Mode
Energy Mode Timer Indication
Hydroboil will return back to the energy mode after this time. Button 4 will restart the timer.
3 MAIN menu
• To navigate to the main menu.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
Settings
Choose and select options from the settings menu, in the following section in the same manner as above.
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
4.1 SETTINGS - date / time
4.2 SETTINGS - temperature
4.3 SETTINGS - energy modes
The Hydroboil will not
enter its energy mode.
The Hydroboil will use
the on /off timer settings
to enter and exit its
energy mode.
The Hydroboil will enter
its energy mode when
darkness is detected and will exit its energy mode
when the ambient light returns to a normal level.
• Scroll menu options.
• Select option.
Disabled
Timer
Ambient Light
Settings
To navigate to, and use the Date & time screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll parameters.
• Select parameter.
• Modify parameters.
• Confirm value.
• Exit and return to previous screen.
Date & Time
Settings
To navigate to, and use the Temperature screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Modify parameters.
• Exit and return to previous screen.
Temperature
Settings
To navigate to, and use the Energy modes screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose 1 of 3 options.
• Scroll parameters.
• Select option.
Energy Modes
Sleep Trigger
Sleep Action
Timer Settings
4.3.1 Energy modes - sleep trigger
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
4.3.2 Energy modes - sleep action
68ºCWhile the unit is in its energy
mode the set point of the
water will be reduced to 68°C.
While the unit is in its energy
mode no heating of the water
will occur.
• Scroll options.
• Exit and return to previous screen.
Off
4.3.3 Energy modes - timer settings
Everyday Adjust on/off timer settings for
all 7 days simultaneously.
Adjust on/off timer settings for
all 5 weekdays simultaneously.
Adjust on/off timer settings
for the 2 weekend days
simultaneously.
Adjust on/off timer settings for
the 7 days separately.
Weekdays
Weekends
Individual Days
• Choose 1 of 4 options.
• Select option.
• Scroll parameters.
• Select parameter.
• Modify parameters.
• Confirm value.
• Exit and return to previous screen.
Everyday
Weekdays
Weekends
Individual Days
4.4 SETTINGS - filter
Settings
To navigate to, and use the Filter screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
Filter
• Scroll menu options.
• Select option.
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Allows modication of lter life and usage
parameters.
Filter life options are as follows.
Filter replacement reminder
will not appear on home
screen.
Filter replacement reminder
will appear as set at 1-14
months (default 12 months).
Filter Usage
Automatically increments
daily. Reset to [0 Days] when
the lter is reset. Can be
adjusted if a partially used lter is inserted.
The days of lter life remaining on the home screen
are based on these 2 parameters.
To navigate between options.
• Scroll menu options.
• Select option.
The log displays the dates that the lter usage
counter was reset and the days of lter life
remaining.
• Scroll to view log history.
Show / hide energy consumption on the home
screen.
Enable / disable backlight dimming after 4 minutes
without buttons being pressed.
4.4.1 Filter - filter life / usage
Disabled
1 Month
50 Days
4.4.2 Filter - replace filter
Continue
This action will reset the lter usage counter.
A reminder will appear, to ush the new lter before
resetting.
•
• Select
4.4.3 Filter - filter log
4.5 SETTINGS - display
Settings
To navigate to, and use the display screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Display energy
Backlight timer
• [Enable /Disable]
• Select option.
Display
Enable
Enable
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
5 INSTALL menu
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
Install
5.1 INSTALL - light calibration
Calibrate the light sensor, for energy modes.
Install
To navigate to, and use the light calibration screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
• To calibrate.
• Display will confirm that the Hydroboil is
calibrating.
• Display will confirm calibration.
• To return to the Install menu.
Light Calibration
5.2 INSTALL - boiling calibration
Undertake the boiling calibration.
Install
To navigate to, and use the boiling calibration screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
• Follow on-screen instructions to complete the
calibration.
• To return to the install menu.
Boiling calibration
Manual (faster)
Auto
5.3 INSTALL - power cycle
Hydroboil turns off, then back on.
Install
To navigate to, and use the power cycle screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option [Continue / Cancel].
• To confirm.
Power cycle
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Product
6 INFO menu
To view product info.
To view the current fault log.
Current Fault
Info
To navigate to, and use the info screen.
• Symbol to navigate to the main menu.
• Scroll menu options.
• Choose option.
• Select option.
• Scroll menu options.
• Choose option.
• Select option.
Product
Current faults
6.1 INFO - product
To view model, product, serial number and rmware
version of the Hydroboil.
• Scroll menu options.
• To return to previous menu.
6.2 INFO - current faults
To view the current fault log of the Hydroboil
• Scroll menu options.
• To return to previous menu.
LCD menu functions

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Tap operation
Tap Operation
Safety lock
Zip Hydroboil Plus has a unique safety device designed to reduce the incidence of accidental operation of the tap.
The tap can be “Locked” to prevent the Hydroboil Plus from dispensing boiling water.
In order to “lock” the tap, ensure the safety button is protruding from the right hand side of the control panel and the
locked indicator is illuminated.
This can be achieved by pressing the button and simultaneously rotating it until the groove in the head of the button
faces toward the body of the appliance. In this position an internal spring will push the button out. Once the button
is in the extended position, the tap will be “Locked” and unable to dispense hot water.
Disengage safety feature:
Press and simultaneously rotate (aprox. 90 degrees) the safety button on the right hand side of the control panel,
until it latches in the closed position, and the unlocked indicator is illuminated.
The unit is now capable of dispensing boiling water without the safety feature.
To dispense boiling water
Zip Hydroboil Plus is fitted with a safety, two-way cool-touch safety tap for instant boiling water.
Normal operation (for filling cups and small containers).
To activate the tap, press the safety button (if locked) on the right side of the control panel and while holding the
button in, gently push the lower end of the tap paddle inwards and boiling water will flow until the tap paddle is
released. Without the lock activated just gently push the tap paddle and release when finished.
Continuous operation (for filling, tea pots, saucepans and large containers).
Press the safety button (if locked) on the right side of the control panel and while holding the button in, lift the tap
paddle until it locks into a horizontal position, the button can now be released and boiling water will flow until the
paddle is returned to its normal vertical position. This operation allows a vessel to be filled without holding your hand
where it may be affected by steam.
Without the lock activated just lift the tap paddle until it locks into place, return paddle to normal position to stop
water flow.
Dispensed water
Lift for continuous dispense
Press and hold for nger controlled dispense
Locked
Press to
unlock
Safety lock
!

Installation instructions & user manual
804546UK V2.06 Oct 2018 - Zip Hydroboil Plus
Technical support
Tel: [phone] Email: [email protected] www.zipwater.co.uk
Wall mounting dimension
37 3.0L
198
52 (5.0 & 7.5)L
38 3.0L
52 (5.0 & 7.5)L
19
395 3.0L
429 5.0L
542 7.5L
37
76 273 3.0L
302 (5.0 & 7.5)L
56
COLD INLET BOILING WATER VENT
25
40
70
Positioning pin Ø6
External plumbing
Internal plumbing
150 TOP CLEARANCE
65 SIDE
CLEARANCE
Dimensions in mm
Not to scale
20 SIDE
CLEARANCE
Concealed electrical connection
