ZKTeco PT100 User manual

Patrol Device Installation and Quick Start Guide
Ver 1.0 Date: October, 2013
user information shall be registered with patrol software and user fingerprints
can be enrolled by USB fingerprint scanner or patrol device. All the data such
as route and patrol plan configured by software should be synchronized with
the patrol device before using.
4. Product Dimension
128mm
81mm
183mm
52mm
74mm
1. Installtaion Mode I : Wall-Mount
2) Pull the cables(includes the power
cables and USB cables) out of the
cabling holes.
3) Fix the wall mounting
plate with screws.
4) Connect the power cables and USB
cables to the base.
3) Fix the base to the
mounting plate with
screws.
5 Fix the base to the mounting
plate with screws.
)
6 Place the patrol machine
on the base.
)
2 Connect the power cables
and USB cables to the base.
) 4 Place the patrol machine
on the base.
)
1) Drill holes on the accord
to the rear plate to mark positions.
wall ing
2. Installation Mode II : Desktop
1) Fix the wall mounting
plate on the desk with
screws.
Note:
Back View
ID Card Swipe Area
LED Indicator
Fingerprint Sensor
Display Screen
Power Button
Up Key
Down Key
Communication Interface
Front View
3. Product Introduction
PC, Patrol Software, USB Fingerprint Scanner/Card Issuer, Patrol Device,
Charging/Acquisition Base, USB Cable, Checkpoints (Location Tags).
5. Workflow
Guard Patrol System Components:
Install patrol software
Set checkpoint
Register patroller
Set event
Set route
Set shift
Set patrol plan
Start to patrol
Collect data by software
Make reports
Connect patrol device with
software to synchronize data

6. Operation Instructions 6. Operation Instructions
1.
boots up.
2. : Press power button and hold for 3 seconds to shutdown the device.
3.
4.
Verify 3 times does not pass,
the default validation fails.)
5.
6.
7.
8.
Power On: Press power button to start the patrol device, waiting it vibrates and
Power Off
Sleeping Mode: The device will enter sleeping mode if there is no operation
within 20 seconds (default), this time could be configured by software. Press
power button once to wake the device up and once again to make it sleep.
Start to patrol
1) Place finger or swipe card on the patrol device to sign in at first, the screen
will display patroller ’s name, ID number and prompts to begin patrolling under
a specified route.
2) Go to the first checkpoint and swipe the patrol device to the location tag, the
screen will display current and next point name, and the device will request to
verify patroller’s identity if it’s preset in the software. There are four verification
types:no, only fingerprint, only card, card or fingerprint. Please verify as
required and complete verification within 20 seconds.(
3) Once the patroller is verified, the screen will display events to select for this
checkpoint. These events shall be preset in the software and it’s optional to
apply.
4) After the event is recorded, the screen instructs next point to check, just do the
same steps as above while following the route preset by software till the device
notify that final point is checked, thus the patrol is completed.
Note: If the patroller wants to quit or end the patrol, please verify his identity by
fingerprint or card. If the patroller goes to wrong checkpoints, the screen will
prompt and instruct the correct point to check.
Out of Memory: The device will notice its available capacity if there are less than 500
records left, the screen will prompt each time when a new record is generated.
Note: When the record number reaches 30,000, the device will automatically delete
the oldest 10,000 records.
Battery: The battery level is displayed in the status bar on the screen; please recharge
the device when there is only one cell of battery bar left.When the device battery is dead,
you need to charge about 10 minutes and then start.
Communication: The device shall be connected to PC via charging/acquisition base
by a USB cable and make sure the device is not in sleeping mode.
Working temperature: -10℃ ～+40℃.
9. Packaging List
Patrol Unit
Charging/Acquisition Base
Rear Plate
USB Cable
Quick Start Guide
Protective Tube
Power Supply
Software CD
Screws&White Rubber Plug
6. Power Connection
DC 5V Charging base
7. Power Connection
The device charging power is DC5V, the
current is 800mA.
The device connects with though USB cable. PC
USB cable
The device
PC
8. USB Connection
10.Optional Accessories
Card Issuer USB Fingerprint Scanner
Location Tag
Card &Key Fob
10. Optional Accessories
