ZKTeco ZK-D3180S User manual

Contents I
User Manual
Walk Through Metal Detector: ZK-D3180S
Version: 1.2
Date: August 2019

Contents I
Contents
Notes.......................................................................................................................................................... 1
Product Specification...................................................................................................................... 2
Installation Environment............................................................................................................... 3
Performance and Features........................................................................................................... 5
Parts............................................................................................................................................................. 7
Installation .............................................................................................................................................. 8
Control Panel ......................................................................................................................................10
Detection Zones...............................................................................................................................12
Operation..............................................................................................................................................13
Detection Adjustment..................................................................................................................18
Brief Maintenance ...........................................................................................................................20
Packing List ..........................................................................................................................................21
Warranty Card.....................................................................................................................................22

Notes 1
Notes
PLEASE READ THE FOLLOWING INSTRUCTION CAREFULLY BEFORE
OPERATION:
1. It's available for both indoor and outdoor use, if need use outdoor,
please use canopy to protect it against rain.
2. Choose the smooth and stable installation place, don't touch the
detector during security checking to avoid false alarm.
3. Make sure there's no big metal object or strong magnetic field
around the detector within 2 meters.
4. Detector probe mustn't install in high temperature or wet
circumstance.
5. Please wait 1 minute for its self-diagnosing when machine starts.
6. Do not disassemble the control units except the professional
technician.
7. Follow the user manual and make sure the right wire connection
when the device starts.

2ZK-D3180S User Manual
Product Specification
Walk Through Metal Detector is mainly used to check the metal items
hidden on the body. When the passengers pass through the device, if
they carried metals more than preset parameters value, the device would
immediately alarms, and display alarm location, let the security guard find
the people with the prohibited metal articles timely.

Installation Environment 3
Installation Environment
1. Stationary Metallic Items
When installing walk through metal detector, it should stay away from
the stationary or fixed bulk metal items 50cm; otherwise it will affect the
sensitivity, causing false alarm. Metal items such as: aluminum alloy /
stainless steel doors and windows, etc.
2. Movable Metallic Items
The big metal items can be moved, should stay away from the device
about 2 meters to avoid false alarm.
3. Floor Vibration
The floor should be flat and fixed, to avoid false alarm after installation by
the movement of people walking or moving and shaking of metal
objects.
4. Electromagnetic Radiation And Electromagnetic Interference
Because the device uses bilateral transceiver technology, therefore, any
electromagnetic interference sources and electromagnetic radiation
source is not allowed to close the device, the recommended distance is 1

4ZK-D3180S User Manual
meter. The parameters of the distance are determined by the installation
environment, and different installation environments with different
parameters.
The lectromagnetic interference sources and electromagnetic radiation
sources as following:
Electrical Control Box, Radio Equipment, Interphone, High Power Motor,
Power Transformer, Ac Power Lines, Thyristor Control Circuit (High Power
Switching Power Supply, Inverter Welder), Engine, Motor etc.
5. Side-By-Side Using
When installing the devices side by side, the distance between two walk
through metal detectors cannot be less than 50cm and the device work
frequency must be different. Specific distance parameters according to
the actual environment and the selection of the work frequency to
adjust.

Performance and Features 5
Performance and Features

Accurate Positioning: 18 overlapping network detection zone,
bilateral transmit and receive, can be accurately positioned to detect
objects, intuitive display of the target location.

Micro Processor Technology: the scanning electromagnetic wave
generated by the microcomputer control circuit, the scanning rate
can be precisely controlled.

Sensitivity Adjustable: Each detection zone has 256 sensitivity
levels (0 ~ 255). Preset metal size, you can exclude the coins, keys,
jewelry, belt buckle etc.

Digital Pulse Technology: Digital signal processing and filtering
system, has excellent anti-interference ability.

Password Protection: Only the correct password can change the
sensitivity and other parameters. Password with four digits can be set
by the user.

Count Statistics: Pass count and alarm count.

Harmless to human body: Harmless to heart pacemaker, pregnant
women, magnetic floppy disk, recording tapes etc.

Power Supply Security: The power supply on the top of the control

6ZK-D3180S User Manual
box, waterproof.

Waterproof Foot Cover: Not only can fixed the device, but also
waterproof.

Waterproof: Using PVC synthetic material, special technology,
waterproof, fireproof, and shockproof.

Easy to install: The system is integrated design, just 15 minutes to
complete the installation or disassemble.

Parts 7
Parts
1. Beams 2. Alarm zone LED
3. Built-in Probe 4. Infrared Sensors
5. Waterproof Foot Cover 6. Power Line Interface
1
2
4
5
6
3

Installation 9
4. Lift the walk through metal detector to the vertical position and
move to the assigned position.
5. Plug power cable.

10 ZK-D3180S User Manual
Control Panel
1. LCD display: Display pass count, alarm count, password settings and
other information
2. Standby indicator lights: Non alarm status indicator (green light)
3. Alarm indicator light: Alarm status indicator (red light)
4. Signal interference indicator: Indicating the current environment
interference
5.
↑
: UP
6.
←
:Adjustment, increasing parameter values
7.
↓
: Down
8.
→
: Adjustment, decreasing parameter values. If press “
→
”for 5
seconds at the main interface (Showing PASS CNT and ALARM CNT),
can setting total sensitivity (5-50 adjustable, 5 is the highest total
sensitivity).

Control Panel 11
9. MENU: Menu interface
10. ENTER: Save settings, exit menu
11. EXIT: Do not save the settings, exit menu
12. RESET: Reset PA SS CNT and ALARM CNT. In addition, press “RESET” for
5 seconds to startup or shutdown.

12 ZK-D3180S User Manual
Detection Zones
A. Standby Indicators: Indicate standby working status.
B. Alarm zones display
There are Eighteen unique sets of precise
positioning LED evenly distribution on the door
panels, means 24 detection zones (from bottom
to top is zone 1-3, zone 4-6,zone 7-9, zone 10-12,
zone 13-15, zone 16-18). If the metal reaches or
exceeds preset value, the red LED alarm. If there
are multiple alarm targets, the LED light of each
target location would be lit and with sound alarm
(mute except).
C. Infrared sensor
After connected power supply, the metal detector starts to work. When
there is no person or object passes the device, the infrared sensors can
effectively stop alarming to avoid false alarm. And accurate count
passengers and alarm times.
B B
C
C

Operation 13
Operation
Connect the power supply. After 2 seconds into the working status, the
operation method as follows:
A. Showing PASS CNT and ALARM CNT
B. Press “MENU”to input the password. The initial password is 1234.
C. Press “ENTER”. If you have input the wrong password, you can not
entering the menu.
D. If you have forgot password, you can input the universal password
“8888”to reset a new password.
PASS CNT 000000
ALARM CNT 000000
PASSWORD INPUT
INPUT PASSWORD
-××××
PASSWORD INPUT
INCORRECT PASSWORD!
PRESS ANY KEY TO CONTINUE

14 ZK-D3180S User Manual
After input the correct password, press“ENTER”, the main menu as below:
1. SENSITIVITY LEVEL
Under main menu interface, select “SENSITIVITY LEVEL”, press “ENTER” to
set the sensitivity. Press “
←
”and “
→
”to change the sensitivity value, press
“
↑
”and “
↓
”to select detection zones. Then press “ENTER” to save the
settings.
SETTING
1. SENSITIVITY LEVEL
2. ALARM DELAY
3. FREQUENCY SPAN
4. QUICK SETTING
5. SELECT LANGUAGE
6. DETECTOR ID
7. CHANGE PASSWORD
8. RESTORE TO DEFAULT

Operation 15
2. ALARM DELAY
Under main menu interface, select “ALARM DELAY”, then press “ENTER”.
The alarm time is 1 second, 2 seconds and 3 seconds for option. Default is
1 second. Press “ENTER” to save the settings.
3. FREQUENCY
Under main menu interface, select “FREQUENCY SPAN”, then press “ENTER”.
The FREQUENCY from 1 to 12 is for option. Press “ENTER” to save the
settings.
SENSITIVITY LEVEL
1~3 SENS. LEVEL -255
4~6 SENS. LEVEL -255
7~9 SENS. LEVEL -255
10~12 SENS. LEVEL -255
13~15 SENS. LEVEL -255
16~18 SENS. LEVEL -255
ALARM DELAY
ALARM DELAY -1 SEC

16 ZK-D3180S User Manual
4. QUICK SETTING
Under main menu interface, select “QUICK SETTING”, then press “ENTER”
and select the applications. Press “ENTER” to save the settings.
5. SELECT LANGUAGE
Under main menu interface, select “SELECT LANGUAGE”, then press
“ENTER”. Press “←”and “→” to change the language. Press “ENTER” to save
the settings.
FREQUENCY SPAN SELECTION
FREQUENCY SPAN -1
QUICK SETTING
1. NIGHTCLUB
2. COURT
3. HARDWARE FACTORY
4. SCHOOL
5. HOSPITAL
6. BARRACKS, EMBASSY
7. EXHIBITION HALL
8. AIRPORT,STATION,CUSTOMS
9. PRECIOUS METALS,ELECTRONICS
10. PRISON

Operation 17
6. CHANGE PASSWORD
Under main menu interface, select “CHANGE PASSWORD”, then press
“ENTER”. Press “←”and “→” to shift, press “↑”and “↓” to change password.
Press “ENTER” to save the settings.
7. RESTORE TO DEFAULT
Under main menu interface, select “RESTORE TO DEFAULT”.
It would show below interface after press “ENTER”.
LANGUAGE SELECTION
LANGUAGE - ENGLISH
CHANGE PASSWORD
NEW PASSWORD
-××××
RESTORE TO DEFAULT
ARE YOU SURE TO RESTORE?
[ENT] - ENTER
[ESC] - CANCEL

18 ZK-D3180S User Manual
Detection Adjustment
1. The device must be in a stable status to achieve the best detection
effect (refer to the "Installation Environment"), to check whether the
device in a stable status, the steps as follows:
a) The device is not shaking after power ON for 1 minute.
b) The device would not alarm when the tester did not carry any
metal items walk through the detector.
2. Excluding small portable metal objects such as rings, key, belt buckle,
shoes and so on, according to the following steps to adjust:
a) Choose a small metal as the sample, such as keys.
b) Increasing the sensitivity, so that when the tester carry the
sample and pass through the device, the detector would alarms.
c) Decreasing the sensitivity a little, carry the sample pass through
the device again, if it still alarms, once again to reduce the
sensitivity, until the device not alarm when the sample passed
through.
Note: If you want to decrease the sensitivity in a certain zone, only have
to adjust the sensitivity of relative zone. After finished the above
adjustment, the metal which smaller than the sample will not alarm, but
